Maxton Spoiler Cap User manual

Cap Spoiler
Installation Manual
1. Place the extension cap to the spoiler for the initial fitment.
2. Place masking tape on the car spoiler at the extension
cap edges that will be used for marking the placement of the
part.
3. Use measuring tape to find even distances from the
reference points of your car to the edges of the extension cap
(ask for assistance to hold part in place while taking
measurement)
Make sure that distances measured from the left and the right
side are equal.We do not recommend finding the center point
of the extension cap and the spoiler since it will make correct
fitment more difficult.
Spoiler Cap
Installation Manual
1+2
3
4
3
R
d e s i g n. c o m
6
5
6. Remove 2-3cm of the foil from the double sided mounting
tape at the edge of the extension cap.
4. Outline the edges of the extension cap on the
masking tape.
5. Put the extension cap to the side.
Use provided degreasing cloth to clean the spoiler prior
installation.

7. Place the extension cap at the both points that you marked
on the masking tape (as described in point 4 of this manual).
8. Slowly remove the rest of the foil from the double sided
mounting tape holding extension cap in the marked place of
fitment and applying pressure (ask someone for assistance to
prevent part from movement)
9. Remove the protective foil from the part.
10. Use the heat gun to slightly heat the extension cap, so the
mounting tape sticks well to the surface of the spoiler. Be
cautious not to use excessive heat or if possible set the heat to
a minimum. Keep 30-40cm distance while heating the extension
cap. Overheating could cause damage to the product.
minimum
30-40cm
7
9
R
d e s i g n. c o m
maxtondesign_official
Maxton Design
Maxton Design
10
8
