Maxxus AirBike 90PRO Installation instructions

AirBike
90PRO
ENG
INSTALLATION & OPERATING MANUAL

2
Index
Index 2
Safety Instructions 3
Overview of the Device & Scope of Delivery 4 – 5
Assembly 6 – 9
Levelling 9
Saddle Adjustment 10
Transport, Location & Storage 11
Care, Cleaning & Maintenance 11
Cockpit 12 – 17
Pulse & Heart Rate 18 – 19
Training Recommendations 20 – 21
Technical Details 22
Recommended Accessories 22
FAQ 23
Exploded Drawing 24
Spare Parts List 25 – 26
Disposal 26
Notes 27 – 29
Warranty 30
Service Contract 31
© 2021 MAXXUS Group GmbH & Co. KG
All rights reserved / All rights reserved
This publication may not be reproduced, stored in a retrieval system, or transmitted in whole or in part, in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise without the prior written permission of Maxxus Group GmbH & Co. KG.
Errors, colour and technical modication subject to change, reproduction as well as electronic duplication only with written permission of MAXX-
US Group GmbH & Co. KG.

3
ENG
Safety Instructions
Before you start exercising, be sure to read the entire operating manual, especially the Safety Information, the Maintenance and Clean-
ing Information and the Training Information.Also make sure that anyone else who uses this training device is familiar with this informa-
tion and observes it.
Always follow the maintenance and safety instructions in this manual very carefully.
This training device may only be used for its specic intended use. Any misuse can cause risk of possible accident, damage to health
or damage to the device for which the Distributor will not assume any liability.
Electrical Connection
−A mains voltage of 220-230V is required to operate this training device.
−The training device is only to be connected to the mains with the mains cable supplied using a 16A individually fused and earthed
socket installed by a qualied electrician.
− The training device is only to be switched on and o󰀨 using the ON/OFF switch.
−Always remove the electric plug from the socket before moving the training device.
−Remove the electric plug from the socket before commencing any cleaning, maintenance or other works.
−Do not connect the mains plug to a socket on a socket strip or on a cable drum.
−If using a cable extension please ensure that this complies with DIN standards, VDE regulations and guidelines, technical rules
issued by other European Union states.
−Always place the mains cable so it cannot be damaged or cause a tripping hazard.
−In operating or standby mode, electrical devices such as mobile phones, PCs, Televisions (LCD, plasma, tube, etc.), game con-
soles etc. will emit electro-magnetic radiation. For this reason, all these types of devices should be kept away from your training
device as they could lead to malfunction, disturbances or false outputs being shown in heart rate measurements.
−For safety reasons, always remove the electrical plug from the socket when the device is not in use.
Training Environment
−Select a suitable space for your training device to provide an optimum amount of free space and highest level of safety. You
should leave a free space measuring a minimum of 200 cm long and at least the width of the treadmill behind the device. A free
space measuring a minimum of 50cm long and at least the width of the treadmill should be left in front of the device.
−Make sure that the area is well ventilated and that an optimum amount of oxygen is available during training. Avoid draughts.
−Your training device is not suitable for outside use and so storage and training can only take place in a temperate, clean dry room.
−The temperature range to operate or store this device is between a minimum of 10° and maximum of 30°
−Do not operate or store your training device in wet areas such as in swimming pools, saunas etc.
− Make sure that your training device is kept on at, hard, clean ground both in operation and at rest. Any uneven surfaces must be
removed or made good.
− It is recommended that a oor covering (carpet, mat, etc.) should be placed under the device to protect damageable oors such as
wood, laminates, oor tiles etc. Please ensure that this underlay cannot slip or slide.
−Do not put this training device on pale or white coloured carpets or rugs as the feet of the device may leave marks.
−Make sure that your training device and mains cable are kept out of contact with hot surfaces and are kept at a safe distance from
any sources of heat e.g. central heating, hot stoves, furnaces, ovens or open res.
Personal Safety Instructions for Training
−The safety key must be inserted correctly before each training session can begin.
−Remove the safety key and mains cable from the training device when not in use to avoid inappropriate or uncontrolled use by any
other third party, e.g. children.
−You should have a health check carried out by your doctor before you start any training
− Stop training immediately if you feel physically unwell or are experiencing any breathing di󰀩culties.
−Always start your training session at a low workload increasing it slowly but steadily throughout. Reduce the workload again to-
wards the end of your training session.
−Suitable sports shoes and clothes should always be worn during training sessions. Make sure that loose clothes do not get caught
up in the treadmill belt or rollers.
−Your training device is only to be used by one person at a time.
−Check each time before a training session to see if your device is in perfect condition. Never use your training device if it is faulty
or defective.
−You are only permitted to carry out repairs to the device yourself after having contacted our Service Department and on receipt of
explicit permission to do so. Only original spare parts may be used at any time.
−Your training device must be cleaned after each use. Remove all dirt including body sweat or any other liquids.
−Always make sure that liquids (drinks, body sweat, etc.) do not get onto the vibrating plate or into the cockpit as this can cause
damage to the mechanical and electronic components.
−Your training device is not suitable for use by children.
−Third parties, especially children and animals, must be kept at an appropriate safety distance during training.
−Check if there are any items underneath the training device before each training session and remove them without fail. Never use
the training device when items are underneath it.
−Do not allow children to use your training device as a toy or climbing frame at any time.
−Ensure that no body parts of your own or of third parties ever come in contact with any of the moving mechanisms.
Warning for pulse and heart rate measurement
Pulse and heart rate monitoring systems may be inaccurate. Excessive training can lead to serious injury or lead to death. If you feel
unwell and / or faint, you must stop training immediately. Make sure that all persons using this exercise device are familiar with and
understand this information and abide by it without fail.
The construction of this training device is based on state-of-the-art technology and highest modern technical safety standards. This
training device is to be used by adults only! Extreme misuse and/or unplanned training can cause damage to your health!

93 105 106 107
108 109 117
4
Overview of the Device & Scope of Delivery
No. Description QTY
93 Lock nut M8 3
105 Allen screw M8x30 4
106 Pan head screw M5x12 6
107 Allen screw M6x15 6
No. Description QTY
108 Allen screw M10x20 8
109 Allen screw M6x10 4
117 Corrugated washer M10 4
Handlebars
Stabiliser
with Transport Rollers
Stabiliser
Transport Handle
Seat
Foot Rest
Cockpit
Pedal

1 40 44 51 (L) / 58 (R)
48 75 74 38 (L) / 39 (R)
83 84 85 113
5
ENG
Overview of the Device & Scope of Delivery
No. Description Qty.
1 Base Frame 1
40 Stabiliser, front 1
44 Stabiliser, rear 1
51 (L) Handle, left 1
58 (R) Handle, right 1
48 Cockpit frame 1
75 Spacer washer 2
No. Description Qty.
74 Mounting plate 2
38 (L) Pedal, left 1
39 (R) Pedal, right 1
83 Foot rest 2
84 Cap, round 2
85 Cockpit 1
113 Bottle holder 1
Special spanner Allen key 4 mm
Spanner 14/17 mm Allen key 5 mm
Phillips screwdriver Allen key 6 mm

44
108
108
112
1
112
6
Assembly
Carefully unpack all parts of the delivery. Two people are required because some parts of your exercise ma-
chine are bulky and heavy. Before mounting, check the completeness of the assembling hardware (screws,
nuts, etc.) and the components in the parts and fastening materials list on the previous pages of this manual.
Carefully carry out the installation, as damage or defects that have arisen due to assembly errors are not
covered by the warranty under any circumstances. Read the instructions carefully before starting, follow the
sequence of the installation steps exactly and follow the instructions for the individual assembly steps. The
installation of the training device must be carried out by responsible adults.
Carry out the installation of your exercise equipment with two adults in a location that is level, clean and free
of obstruction during assembly. Only after assembly of the training device has been completed can training be
started.
Step 1: Assembling the Rear Stabiliser
Loosen and remove the screws holding the transport lock on the rear mount of the base frame (1) and then
remove the transport lock.
Then attach the rear stabiliser (44) using four Allen screws M10x20 (108) and four corrugated washers M10
(112) to the rear mount of the base frame (1).
Transport Lock

7
ENG
Assembly
Step 2: Assembling the Front Stabiliser
Loosen and remove the transport lock on the front mount of the base frame (1) and then remove the transport
lock.
Then attach the front stabiliser (40) using four Allen screws M10x20 (108) and four corrugated washers M10
(112) to the front mount of the base frame (1).
Step 3: Assembling the Pedals
Loosen the screw (109) on the left pedal arm (24). Then insert the thread of the left pedal (38) into the mount of
the left pedal arm and screw it tight in an anticlockwise direction. Now tighten the screw (109) again. Proceed
in the same way with the right pedal (39). Make sure that this pedal is tightened in a clockwise direction. The
pedals are easy to identify because they are marked “R” for right and “L” for left.
Transport Lock
108
108
112
112
1
40

8
Step 4: Assembling the Handlebars
Step 4.1
Insert the right handle (58) into the right axle of the base frame (1).
Then push the footrest (83) onto the axle of the base frame (1) and tighten it clockwise with the special spanner
– see circular exploded illustration.
Finally, push on the cover cap (84) on the end of the footrest (83).
Step 4.2
Now attach the connecting tube (29) of the base frame to the mount at the bottom of the handlebar (58). To do
this, use the mounting plate, right (74), a spacer washer (75), an Allen screw M8x30 (105) and a lock nut M8
(93). Do not completely tighten the Allen screw M8x30 (105) yet!
Step 4.3
Secure the mounting plate, right (74) to the connecting rod (29) with three Allen screws M6x15 (107). Now also
Step 4.4
Now repeat the procedure as described in steps 4.1 to 4.3 on the left side of the device.
Assembly
Special spanner
51
58
83
83
84
84
105
105
107
29
26
107
74
74 75
93

1
85
85A
85B
48
106
48
118
106
Position A
Position B
9
ENG
Step 5: Assembling the Cockpit Frame
Connect the cable (85B) protruding from the cockpit frame (48) to the cable (85C) protruding from the base
frame (1). Then push the rest of the protruding cable back into the base frame (1) and then secure the cockpit
frame (48) to the base frame using two Allen screws M8x30 (105).
Step 6: Assembling the Cockpit and Bottle Holder
Connect the cockpit cable (85A) to the cable (85B) protruding from the cockpit frame (48).
Then secure the cockpit (85) to the cockpit frame (48) with four M5x12 pan-head screws (106).
Finally attach the bottle holder (118) to the cockpit frame (48) with two pan-head screws M5x12 (106).
Make sure that your exercise equipment is always level. In order to compensate for minor bumps or slopes,
adjustable feet are tted right and left on the front and rear stands and on the sliding. To ensure that the device
stands level, rst turn all feet to the lowest position (position A). If necessary, adjust the feet so that the training
device is level and stable.
If the adjustment range of the adjustable feet is not su󰀩cient to allow level standing of the training device,
please check the surface of the location. If necessary choose a di󰀨erent location where a safe and level position
of the training device is ensured.
Assembly
Levelling
Adjustable Foot Adjustable Foot

10
Horizontal Adjustment
You can adjust your saddle horizontally to set your optimum distance to the handlebars. Loosen the hand lever
(B37) below the saddle by turning it anti-clockwise. Move the saddle to the desired horizontal position and
retighten the hand lever clockwise.
Vertical Adjustment
You can adjust the saddle position vertically, i.e. in height. This allows you to set the optimum distance to the
pedals. To do this, loosen the hand lever located underneath the saddle on the back of the seat tube. Then set
the desired saddle height and secure the set position by pressing the hand lever again.
Saddle Adjustment
Hand Lever
Hand Lever
WARNING:
Please note that the knob operates a quick-release system. You only have to turn it
anti-clockwise 2-3 times to unlock it, then pull on the knob to quick release the saddle
support. Hold the knob in this pulled position and then set the desired saddle height. Let
go of the knobl to engage the locking mechanism again. To do this, you may need to
move the seat tube slightly up or down to engage the mechanism in the corresponding
seat support hole. Tighten the knob clockwise again.
Setting the optimum saddle height:
Make sure you are wearing the shoes you want to wear during your workout. Comfort-
able running shoes or sports shoes are ideal. Adjust the pedal position so that the right
pedal arm is pointing vertically down and the right pedal is at the lowest point of its radius
of motion. Now sit on the saddle and place the heel of your right foot on the right pedal.
Your leg should be almost completely straight. Adjust the saddle height until your right
leg is almos t fully extended and then put the ball of the foot on the pedal. Now your leg
should be slightly bent. This is the ideal height adjustment for your saddle.
WARNING:
Never train with a seat height adjustment that fully extends your legs at the lowest posi-
tion of the pedals.

11
ENG
Transport
In order to transport your training device simply and safely, the front stand is equipped with transport rollers.
To move the exerciser, stand behind the device and grab the transport handle with both hands. Lift the training
device until the main weight of the device is resting on the front transport rollers. Now you can simply push or
pull the device along on the transport rollers and place it in the desired position. When lifting, transporting and
positioning the device always make sure that you have a secure footing.
Location & Storage
This training device was designed for exclusive use in dry, well-ventilated indoor areas. Use or storage in damp
or wet areas, such as saunas, swimming pools, etc. and in outdoor areas, such as balconies, terraces, gardens,
garages, etc. is excluded.
These locations may give rise to electronic defects, corrosion and rust due to the high humidity and low temper-
atures prevailing there. Under no circumstances will any claims for damages of this kind be accepted under the
warranty.
Please choose a dry, level and warm place to store your training device. For your own sake, also make sure that
you choose a training area which is su󰀩ciently ventilated to ensure optimum oxygenation during training. Before
putting your training device back into operation after a long period of non-use, make sure that all fastenings are
secure.
Cleaning
Clean your exerciser after each workout. Use a damp cloth and soap.
Never use solvents. Regular cleaning contributes signicantly to the preservation and longevity of your training
device.
Damage caused by sweat or other liquids is not covered by the warranty under any circumstances. During train-
ing, make sure that no uid can enter the exercise machine or the computer.
Maintenance
Sealed bearings are used in your training device, lubrication of the bearings is not required.
Checking the Fastenings
Check tightness of nuts and bolts at least once a month and re-tighten them if necessary
Checking the Components
Before each workout, check that the saddle, seat support, handlebars and pedals are securely fastened.
WARNING:
Never train if one or more of these components are loose.
Transport, Location & Storage
Care, Cleaning & Maintenance
Transport Rollers
Transport Handle

12
Switching on the Cockpit
Switch on the cockpit by pressing any button on the cockpit or by starting to pedal.
Switching o󰀨 the Cockpit
Depending on the selected program, the cockpit switches o󰀨 automatically after 60 to 90 seconds of inactivity.
Inserting the Batteries
The cockpit of your training device is powered by two AA 1.5V batteries.
To replace or insert the batteries, open the battery compartment on the back of the
cockpit and insert the batteries as shown in the diagram below.
WARNING: Never dispose of batteries in the household waste. Please observe the
disposal instructions in this manual.
Cockpit

13
ENG
The cockpit continuously informs about the following, current training values:
TIME - Indication of the training time.
If the training time is set, the computer counts down the time to “00:00”. The
The training time can be set from “01:00” to “1:59:00” minutes. If the training time is not set, the computer counts
the training time from “00:00” to a maximum of “1:59:00” minutes.
DISTANCE - The training distance in kilometres.
If the training distance is set, the computer counts down the distance back to “0.00”.
The training distance can be set from 0.1 to 999.5 kilometres. If the training distance is not set, the computer
counts the distance from 0.0 to a maximum of 999.9 kilometres.
Calorie consumption - CALORIES* - Calorie consumption in Kcal.
If the calorie consumption is set, the computer counts down the calories back to 0.
The calorie consumption can be set from 10 to 990 calories. If the calorie consumption is not set, the computer
counts the calories from 0 to a maximum of 999 calories.
Heart rate display - ♥ - Displays the current heart rate in beats/minute.
Only when using an optionally available transmitter chest belt (not included).
SPEED - indication of the current speed in km/h
RPM - indicates the current number of revolutions per minute (RPM).
Power WATT** - Indication of the power output in relation to the speed in watts (WATT).
*Note on calorie measurement
The energy consumption is calculated using a general formula. It is not possible to determine an individual’s energy consumption exactly, as this
requires a large amount of personal data. The energy consumption displayed is therefore an approximation and not an exact value.
**Note on the watt display
As this is an exercise device that is suitable for non-therapeutic purposes, the displayed wattage is not a calibrated value. This means that the
displayed power may di󰀨er from the actual power.
Keypad
START key
START function: starts the selected training program or training prole.
Activates the QUICKSTART function
STOP key
PAUSE/STOP function: If the STOP key is pressed during training, the display of the training values
stops and the pause mode is activated. This allows you to interrupt training.
To end the pause, press the STOP button again.
RESET function: Press and hold the button in STOP or Pause mode for more than 3 seconds
to reset all values to zero.
ENTER key Conrmation of settings and defaults
keys To set the training values
Entering data (e.g. age)
Program keys
TARGET TIME - training program with target: time
TARGET DISTANCE - training program with target: distance
Cockpit

14
TARGET CALORIES - Training program with target: calorie consumption
TARGET HEART-RATE - training program with target: heart rate
Note: An optionally available transmitter chest belt is required to use this program.
Interval 10/20 - interval training with time change 10 seconds / 20 seconds
Interval 20/10 - interval training with time change 20 seconds / 10 seconds
Interval Custom - individual interval training
Quick Start
Step 1 - Switching on the Cockpit
Switch on the cockpit by pressing any key
Step 2 - Entering the User Age
The value “30” ashes in the display. Now enter the user age by pressing the keys. Entries from 1 to 99
years are possible.
Step 3 – Training Start
Press the START key to start training.
Training End
As no target value is set for this program, the user has to end the program themselves. To do this, press the
STOP key. After 30 seconds, the cockpit will switch to stand-by mode and after 60 seconds the cockpit will
switch o󰀨 automatically.
Training programme with target time (Target Time)
Step 1 – Program Selection
Press the Target Time program key.
Step 2 - Target Time
The time “0:00” will ash in the display. Now enter the desired training time from 1:00 to 1:00 by pressing the
keys.
Step 3 – Training Start
Press the ENTER key to conrm your entry. Training will start automatically.
Training End
When the training target has been reached, the display automatically ends the training. After 30 seconds the
cockpit switches to stand-by mode and after 60 seconds the cockpit switches o󰀨 automatically.
Cockpit

15
ENG
Training programme with target time (Target Distance)
Step 1 – Program Selection
Press the Target Distance program key.
Step 2 - Target Time
The time “0:0” will ash in the display. Now enter the desired training time from 0,5 to 999,5 by pressing the
keys.
Step 3 – Training Start
Press the ENTER key to conrm your entry. Training will start automatically.
Training End
When the training target has been reached, the display automatically ends the training. After 30 seconds the
cockpit switches to stand-by mode and after 60 seconds the cockpit switches o󰀨 automatically.
Training Program with Target Calories (Target Calories)
Step 1 - Program Selection
Press the Target Calories program key.
Step 2 – Setting the Target Calories
The calorie value “0” will ash in the display. Now enter the desired calorie consumption from 10 to 990 calories
by pressing the keys. Press the ENTER key to conrm your entry. Training will start automatically.
Training End
When the training target has been reached, the display will automatically end training. After 30 seconds the
cockpit will switch to stand-by mode and after 60 seconds it will switch o󰀨.
Heart Rate Program (Target Heart Rate)
The heart rate program is a pre-set program. The program monitors your pulse and indicates with an acoustic
signal and arrows if the pulse is outside the threshold (65% or 85% of the maximum heart rate). This program
can only be used with an optionally available chest belt.
Step 1 - Program Selection
Press the Target Heart Rate program key.
Step 2 - Setting the Target Heart Rate
The value “30” will ash in the display. Now enter the user age by pressing the keys. Entries from 1 to 99
years are possible.
Step 3 – Training Start
Press the ENTER key to conrm your entry. Training will start automatically.
Training Sequence
Depending on the user’s age, the Cockpit will calculate the values for 65% and 85% of the user’s maximum
heart rate (see also the notes on heart rate measurement in this manual). If the user’s current heart rate value
falls below 65% of their maximum heart rate during the training session, the “up” arrow and the calculated
65% value will start ashing. In addition, every 10 seconds, an audible warning will sound. As soon as the user
reaches the value of 65% or more their maximum heart rate, the warning signal stops and the arrow and the
value will stop ashing.
If the user’s current heart rate value rises above 85% of the user’s maximum heart rate during the training
session, the “down” arrow and the calculated 85% value will start ashing. In addition, an audible warning will
sound every 10 seconds. As soon as the user, has reached the value of 85% or less of their maximum heart
rate by reducing their training power, the warning signal will stop and the arrow and value will stop ashing.
If the value remains between 65 % and 85 %, only the current heart rate ashes.
Cockpit

16
Individual Interval Training (Interval Custom)
This program allows the user to create their own individual interval training.
Tip:
Warm up at least 10 minutes before using this program for example with the Target Time or Quick Start pro-
gram. After interval training, you should also have a recovery phase of 10 minutes at a low intensity, using either
the Target Time or Quick Start program.
Step 1: Program Selection
Press the Interval Custom key to select the program.
Step 2: Selecting the Repetitions
“00/01” will ash in the display. Press the keys to select the desired number of repetitions from 1 to 99.
Conrm your entry by pressing the ENTER key.
Step 3: Setting the Training Time
Press the key to select the desired time for the intensive training phase.
Entries from 1 second to 9:59 minutes are possible. Conrm your entry by pressing the ENTER key.
Step 4: Setting the recovery time
Set the desired time for the recovery phase by pressing the keys.
Entries from 1 second to 9:59 minutes are also possible. Conrm your entry by pressing the ENTER key.
Step 5: Start training
After you have pressed the ENTER key in step 4, the program will start automatically.
Training End
The program ends automatically after the pre-set interval phases have elapsed.
If you want to end the program prematurely, press the STOP key. After 30 seconds the cockpit will switch to
stand-by mode and after 60 seconds it will automatically switch o󰀨.
General Functions
Changing the Display from Kilometres to Miles.
The display of the distance and speed can be set to kilometres or miles. To change the display, press the
START and ENTER keys simultaneously. The display shows the current setting “KM” for kilometres or “M” for
miles. You can select the desired display by pressing the keys. Conrm your selection by pressing the
ENTER key.
Inactivity
If the user stops pedalling during an active training program, the cockpit switches to inactive mode after 30 sec-
onds of inactivity. After a further 30 seconds of inactivity, the cockpit switches o󰀨 completely.
Pause Training
To pause an active program, press the START key. An acoustic signal will be heard every 30 seconds and every
2 seconds all values will be shown on the display. To start the program again, press the START key. The cockpit
will switch automatically to standby mode after 5 minutes of inactivity. After another 30 seconds of inactivity, the
cockpit will switch o󰀨 completely.
Note on the Braking Resistance
The resistance of this training device is generated by air resistance. If the user pedals faster, the air resistance
increases and the resistance to be overcome by the user increases. If the user reduces their cadence, the air
resistance will be is reduced and the resistance to be overcome by the user becomes less. Mechanical adjust-
ment of the braking resistance is not possible with this training device.
Cockpit

17
ENG
Training End
To end training, press the STOP key. After 30 seconds, the cockpit will switch to stand-by mode and after 60
seconds the cockpit will switch o󰀨 automatically.
Interval Training with 10 Second / 20 Second Time Intervals (Interval 10/20)
This HIT training (HIT = High-Intensity-Training) is a particularly intensive form of interval training. Interval train-
ing is characterised by alternating load and recovery phases. Short, intensive exercise is followed by an active
break during which the user continues to exercise at a lower intensity. This program consists of 8 intensive
phases of 10 seconds each and 7 recovery phases of 20 seconds each. The total training time is 3:40 minutes.
Tip:
Warm up at least 10 minutes before using this program for example with the Target Time or Quick Start pro-
gram. After interval training, you should also have a recovery phase of 10 minutes at a low intensity, using either
the Target Time or Quick Start program.
Step 1: Program Selection & Training Start
Press the “Interval 10/20” key to select the program. As soon as you have pressed the key the program will start
automatically.
Training End
The program will end automatically after 15 interval phases. If you want to end the program prematurely, press
the STOP key. After 30 seconds the cockpit will switch to stand-by mode and after 60 seconds it will automati-
cally switch o󰀨.
Interval Training with 20 Second / 10 Second Time Intervals (Interval 20/10)
This HIT training (HIT = High-Intensity-Training) is a particularly intensive form of interval training. Interval train-
ing is characterised by alternating load and recovery phases. Short, intensive exercise is followed by an active
break during which the user continues to exercise at a lower intensity. This program consists of 8 intensive
phases of 20 seconds each and 7 recovery phases of 10 seconds each. The total training time is 3:50 minutes.
Tip:
Warm up at least 10 minutes before using this program for example with the Target Time or Quick Start pro-
gram. After interval training, you should also have a recovery phase of 10 minutes at a low intensity, using either
the Target Time or Quick Start program.
Step 1: Program Selection & Training Start
Press the “Interval 20/10” key to select the program. As soon as you have pressed the key the program will start
automatically.
Training End
The program will end automatically after 15 interval phases. If you want to end the program prematurely, press
the STOP key. After 30 seconds the cockpit will switch to stand-by mode and after 60 seconds it will automati-
cally switch o󰀨.
Cockpit
Current User Heart Rate
Changing display of 65
and 85% of the calculated
target heart rate
If the “up” arrow is ashing,
the heart rate is too low
If the “down” arrow is ash-
ing, the heart rate is too high

200
150 195
130 146 190
110 127 143 185
107 124 139 180
105 120 135 175
102 117 131 170
99 114 128 165
96 111 124 160
94 107 120 155
91 104 116 150
88 101 113 145
85 98 109 140
83 94 105 135
80 91 101 100
77 88 98
74 85
72
20 25 30 35 40 45 50 55 60 65 70 75 80 85 90
18
Pulse & Heart Rate
Calculating your personal heart rate when training
Calculate your personal heart rate when training as follows:
220 - Age = maximum heart rate
This value represents your maximum heart rate and serves as a basis from which to calculate
your personal training heart rate. Set the calculated heart rate at 100%
Wellness and Health - target zones = 50 to 60% of the maximum heart rate.
This training zone is ideally suitable for people who are over-weight and/or older beginners, or people starting again after a longer
break from training. Training in this zone the body will burn approx. 4-6 calories per minute to produce energy.
The percentage ratio per calorie is approx. 70% fat, 25% carbohydrate, and 5% protein.
Fat burning - target zone = 60 to 70% of the maximum heart rate
This training zone is suitable for athletes and sports people who aim to lose weight.
Training in this zone the body will burn approx. 6-10 calories per minute to produce energy.
The percentage rate per calorie is approx. 85% fat,10% carbohydrate, and 5% protein.
Condition & Fitness - target zone = 70 to 80% of maximum heart rate
This training zone is ideally suitable for athletes and sports people who aim to improve their stamina and/or condition.
Training in this zone the body will burn approx. 10-12 calories per minute to produce energy.
The percentage rate per calorie is approx. 35% fat,60% carbohydrate, and 5% protein.
For optimum e󰀨ects in training results you should calculate the average value of the selected target zone (also see above table):
Wellness & Health - target zone average value = 55% of maximum heart rate
Fat burning - target zone average value = 65% of maximum heart rate
Kondition & Fitness - target zone average value = 75% of maximum heart rate
Heart Rate per Minute
Age
of maximum heart rate
of maximum heart rate
of maximum heart rate
of maximum heart rate
100%
75%
65%
55%

19
ENG
Warning about Pulse and Heart Rate Monitoring
CAUTION: Pulse and heart rate monitoring systems may be inaccurate. Excessive training can cause serious
injury or even death. If you feel unwell and / or faint, stop training immediately. Make sure all users of your exer-
cise device are familiar with this information, understand it and apply it unconditionally.
Pulse Rate Monitoring using Hand Sensors
Most exercise equipment is equipped with hand pulse sensors. These are mostly in the cockpit or integrated into
the handrails. These hand sensors are used for short-term determination of the pulse rate. To do this, you need
to cover the sensors with both hands at the same time. After a short while, the display shows the current pulse
rate. This measuring system is based changes in electrical skin resistance measured by the hand sensors due
to the heartbeat which causes blood pressure uctuations. These changes are summarized to a mean value
and shown in the display as the current pulse rate.
CAUTION.
For large parts of the population, the pulse-induced skin resistance change is so minimal that usable values
cannot be derived from the measurement results. Also callouses on the palms, damp hands and body shakes,
which in many forms of exercise inevitable, prevents correct measurement. In such cases, the pulse value is
displayed incorrectly or not at all.
Please check in the case of a faulty or failed measurement, whether this occurs only with one or with several
people. If the display of the pulse does not work only in individual cases, the device is not defective. In this case
we recommend the use of a chest belt to achieve a permanently correct pulse display. This is available as an
accessory
Heart Rate Measurement using a Chest Belt
Many MAXXUS® training devices are already tted with a receiver as standard.
Using a chest belt (we recommend the exclusive use of an uncoded POLAR® chest belt) allows you to wireless-
ly measure heart rate. The chest belt is available online as an accessory from www.maxxus.com.
This optimal, ECG-accurate type of measurement takes the heart rate by means of a transmitter chest belt
directly from the skin.
The chest belt then sends the pulse via an electromagnetic eld to the built-in cockpit receiver.
We recommend you always use a chest belt for heart rate measurement during heart rate-controlled programs.
CAUTION
The determination of the current heart rate by means of the chest belt serves only to display the current heart
rate during exercise. This value says nothing about the safety and e󰀨ectiveness of the training. Also, this type of
measurement is in no way designed or suitable for medical diagnostic purposes.
Therefore, discuss with your family doctor the most suitable procedure for you and create your exercise plan
before you start exercising.
This applies especially to those who:
−have not been physically active for a long period of time
−are overweight
−are older than 35 years
−have too high or too low blood pressure
−have heart problems
If you are wearing a pacemaker or similar device, discuss this with your medical specialist before using a heart
rate chest belt.
Pulse & Heart Rate

20
Training Recommendations
Preparation Before Training
Before you start training make sure that not only your training device is in perfect condition, your body must also
be prepared for training. Therefore, if you have not done any endurance training for some time, you should con-
sult your GP and undergo a tness check-up. Also discuss your training target; they will certainly be able to give
you valuable advice and information. This applies to people who are over 35, have problems with overweight,
heart or circulatory system problems.
Training Plan
Essential to e󰀨ective, target orientated, and motivating training is to have a forward-looking trainings plan.
Plan your tness training as an integral part of your daily routine. If you don’t have a xed plan, training can
easily interfere with regular commitments or continually be put o󰀨 to another unspecied time.
If possible, create a long term monthly plan and not just from day to day or week to week. A training plan should
also include su󰀩cient motivation and distraction during training sessions. An ideal distraction is to watch TV
during training as this diverts your attention both visually and acoustically. Make sure that you reward yourself
and set realistic targets such as to losing 1 or 2kgs in four weeks or to increase your training time by 10 minutes
within two weeks for example. If you reach your targets, then reward yourself with a favourite meal which you
have not allowed yourself till then.
Warm-Up Before Training
Warm-up on your training device for 3-5 minutes at minimum resistance. This will best prepare your body for the
up-coming exertion in training.
Cool-Down After Training
Do not just get o󰀨 your training device immediately the training session is nished. Like with the warm-up stage
you should continue for 3-5 minutes at minimum resistance to cool down. After training you should stretch your
muscles thoroughly.
Front Thigh Muscles
Support yourself with your right hand against the wall or on your training device. Bend
your knee and raise your left foot backwards so you can hold it with your left hand. Your
knee should be pointing straight down to the oor. Pull your leg backwards until you feel
a light pulling in your thigh muscles. Hold this position for 10 to 15 seconds. Let your foot
go and stand it back on the oor. Repeat the exercise with your right leg.
Inner Thigh Muscles
Sit on the oor. Pull the soles of your feet together in front of you raising your knees
slightly. Grasp the upper sides of your feet and place your elbows on your thighs. Press
your thighs down towards the oor with your arms until you feel a light pulling in your
thigh muscles. Hold this position for 10 to 15 seconds. Make sure to keep your upper
body straight throughout the exercise. Release the pressure from your thighs and slowly
stretch out your legs to the front. Stand up slowly steadily.
Legs, Calves and Buttocks
Sit on the oor. Stretch out your right leg and bend your left leg to place the sole of your
foot on your right thigh. Bend your top body over so you can stretch out your right hand
to touch your right toes. Hold this position for 10 to 15 seconds. Let go of your toes and
sit slowly and steadily up straight again. Repeat this exercise with your left leg.
Leg and Lower Back Muscles
Sit on the oor with your legs stretched out. Stretch forward with your hands and try to
grasp the tips of your toes with both hands. Hold this position for 10 to 15 seconds. Let
go of your toes and slowly and steadily sit back up straight again.
