Maytag Amana PTC A Series Operating instructions

RS4200003Rev.5
April2009
Service Instructions
®isaregisteredtrademark ofMaytag Corporationor itsrelated companiesand isused underlicense toGoodman Company,L.P., Houston,TX. All rightsreserved.
Package Terminal
AirConditioners & Heat Pumps
This manual is to be used by qualified, professionally trained HVAC technicians only.
Goodman does not assume any responsibility for property damage or personal injury
due to improper service procedures or services performed by an unqualified person.
©2000 - 2009 Goodman Company, L.P.

2
Prideandworkmanshipgointoeveryproducttoprovideourcustomerswithqualityproducts. Itispossible,however,that
duringitslifetimea product mayrequireservice. Productsshouldbeserviced only byaqualifiedservicetechnicianwho
is familiar with the safety procedures required in the repair and who is equipped with the proper tools, parts, testing
instruments and the appropriate service manual. REVIEW ALL SERVICE INFORMATION IN THE APPROPRIATE
SERVICE MANUAL BEFORE BEGINNING REPAIRS.
IMPORTANT NOTICES FOR CONSUMERS AND SERVICERS
RECOGNIZE SAFETY SYMBOLS, WORDS AND LABELS
WARNING
IMPORTANT INFORMATION
WARNING
GOODMAN WILL NOT BE RESPONSIBLE FOR ANY INJURY OR PROPERTY DAMAGE ARISING FROM
IMPROPER SERVICE OR SERVICE PROCEDURES. IF YOU INSTALL OR PERFORM SERVICE ON THIS UNIT,
YOU ASSUME RESPONSIBILITY FOR ANY PERSONAL INJURY OR PROPERTY DAMAGE WHICH MAY
RESULT. MANY JURISDICTIONS REQUIRE A LICENSE TO INSTALL OR SERVICE HEATING AND AIR
CONDITIONING EQUIPMENT.
INDEX
PRODUCT IDENTIFICATION ........................................................................................................ 4
SPECIFICATIONS ......................................................................................................................... 6
PROPER INSTALLATION ........................................................................................................... 17
WALL SLEEVE INSTALLATION ........................................................................................................................... 16
FRONT REMOVAL ................................................................................................................................................ 18
CHASSIS INSTALLATION .................................................................................................................................... 19
WIRING ................................................................................................................................................................. 19
OPERATING CONTROLS ..................................................................................................................................... 20
SCHEMATICS BASED ON 1 STAGE COOL,
2 STAGE HEAT MECHANICAL THERMOSTATS.................................................................................21
WIRELESS COMMUNICATIONS.............................................................................................................26
CONFIGURATION SETTINGS .............................................................................................................................. 32
MAINTENANCE........................................................................................................................... 33
OPERATIONS .............................................................................................................................. 36
SEQUENCE OF OPERATION ............................................................................................................................... 36
SERVICING ................................................................................................................................. 41
DIGITAL BOARD DIAGNOSTICS ........................................................................................................................ 49
DISASSEMBLY ........................................................................................................................... 59
SCHEMATICS ............................................................................................................................. 62

3
WARNING
THIS AIR CONDITIONER IS NOT MEANT TO PROVIDE
UNATTENDED COOLING OR LIFE SUPPORT FOR
PERSONS OR ANIMALS WHO ARE UNABLE TO
REACT TO THE FAILURE OF THIS PRODUCT.
THE FAILURE OF AN UNATTENDED AIR CONDITION-
ER MAY RESULT IN EXTREME HEAT IN THE COND-
ITIONED SPACE CAUSING OVERHEATING OR
DEATH OF PERSONS OR ANIMALS.
PRECAUTIONS MUST BE TAKEN TO WARN OF OR
GUARD AGAINST SUCH AN OCCURENCE.
Tolocateanauthorizedservicer,pleaseconsultyourtelephonebookorthedealer
from whom you purchased this product. For further assistance, please contact:
CONSUMER INFORMATION LINE -
AMANA®BRAND PRODUCTS TOLL FREE
1-877-254-4729 (U.S. only)
email us at: hac.consumer[email protected]
fax us at: (931) 438- 4362
(Not a technical assistance line for dealers.)
Outside the U.S., call 1-931-433-6101.
(Not a technical assistance line for dealers.)
Your telephone company will bill you for the call.
WARNING
WARNING
INSTALLATION AND REPAIR OF THIS UNIT SHOULD BE PERFORMED ONLY BY INDIVIDUALS MEETING THE
REQUIREMENTS OF AN “ENTRY LEVEL TECHNICIAN” AS SPECIFIED BY THE AIR-CONDITIONING, HEATING
AND REFRIGERATION INSTITUTE (AHRI). ATTEMPTING TO INSTALL OR REPAIR THIS UNIT WITHOUT SUCH
BACKGROUND MAY RESULT IN PRODUCT DAMAGE, PERSONAL INJURY OR DEATH.

4
PRODUCT IDENTIFICATION
PT C 07 3 B 35 A M BM
BASIC MODEL TYPE MAJOR/MINOR DESIGN REV.
PT = Standard PTAC
GM = Goodman PTAC
DRY = Dehumid PTAC
REFRIGERATION CYCLE
C = Cooler Only
H = Heat Pump
COOLING CAPACITY
07 = 7000 BTUH
09 = 9000 BTUH
10 = 10000 BTUH
12 = 12000 BTUH
15 = 15000 BTUH
RATED VOLTAGE
2 = 115V 60Hz 1Ph
3 = 230/208V 60Hz 1Ph
4 = 265V 60Hz 1Ph
5 = 240/220V 50Hz 1Ph SPEACIAL FEATURE CODE CONTROL FEATURE
A = Standard Model ENGINEERING DESIGN REV
DESIGN STYLE B = Power Vent A = PAC-10
Old MAJOR DESIGN SERIES C = Seacoast Protection B =
A = 3/8" Slab Cond. Coil Unit D = Conensated Disposal Pump C = PAC-20
B = Bent Condenser Coil Unit F = H & B D = +EER, PAC-20
C = Sound Reduction G = H & J E = w/ "B" Design Series
D = 5/16" Slab Cond.Coil Unit H = Hydronic F = +EER w/ "B" Design Series
J = Power Door G = M60
K = D & B H = +EER, M60 (old)
L = D & J H = M61S, Rechi
HEATER SIZE M = STC J = PAC-20, LCDI
00 = no electric heat N = C & J K = M60, LCDI
15 = 1.5 kW P = C & H & B L = +EER, M60, LCDI
25 = 2.5 kW R = Added Drain Valve (PTC) M = M61
35 = 3.5 kw(230/208V) T = Aux Transformer N = +EER, M61
= 3.7kW (265V) X = Hard Wired Only P = M61S
50 = 5.0 kW Y = 230V Fuse Holder Kit Q = Mechanical Control
U = open R = M61, Rechi
V = open S = open
W = open T = M61, 7-Button
Z = C & D U = M61, Alt Panasonic
V = open
W = M61 Wireless Ready DT01A
Out of Production X = ope
n
Y = M61, 7-Button, & DT01A
Z = M61, DT01A, Rechi

5
PRODUCT IDENTIFICATION
NT E 12 A 35 A 3 A
Engineering
Revision
Model Type Voltage
E - Cooler 3 = 230/208-1-60
P - Heat Pump 4 = 265-1-60
Option Code
07: 7,000 Btuh A = Standard Model
09: 9,000 Btuh C = Seacoast Model
12: 12,000Btuh
15: 15,000Btuh Electric Heat
25 = 2.5 kW
Design Series
Nominal Cooling Capacity
Package
Terminal Units

6
SPECIFICATIONS
NOTES:
1.All 265Vmodels mustuse Amana®brand’ssubbase(PTSB4**C)orAmana®brand’shardwire kit(PTPWHWK4).
2.Minimum branchcircuitampacityratingconformtotheNational ElectricCode. However, localcodesshouldapply.
3.Minimumvoltageon230/208voltmodelsis197volts;maximumis253volts.Minimumvoltageon265volt modelsis238.5volts; maximumis291.5
volts.
4.Overcurrent protectionfor allunits withoutelectricheatersis15 amps.Overcurrent protectionon 265volt modelsmust becartridge-style time
delayfuses (includedand factoryinstalledonAmana®brand chassis).
5.Heating capacityandefficiency arebased onunitoperationwithoutcondensate pump.Unit automaticallyswitchesto electricheat at25°F
outdoorcoiltemperature.
6.Totalwattsfor15,000Btuh models;subtract 30wattsfor PT12*A**AAand 70wattsfor PT07/09*A**AA.
7.Pleasespecify2-digitheater kWsizeto completemodelnumber.
8.Totalampsfor12,000and15,000Btuhmodels;subtract0.2ampsforPT07/09*A*AA.
PTH073A**AA PTH074A**AA PTH093A**AA PTH094A**AA PTH123A**AA PTH124A**AA PTH153A**AA PTH154A**AA
Voltage1&3 230/208 265 230/208 265 230/208 265 230/208 265
Capacity (BUTH) 7,400/7,200 7,400 9,000/8,800 9,000 12,000/11,600 12,000 14,000/13,800 14,000
Amps 2.5/2.6 2.0 3.5/3.8 3.0 4.6/5.0 3.7 7.4/7.9 6.5
Watts 625/610 625 810/790 810 1,145/1,125 1,145 1,490/1,470 1490
EER 11.5 11.5 11.1 11.1 10.6 10.6 9.4 9.4
UNIT WITHOUT
ELECTRIC HEATER
Minimum Circuit Ampacity2&4 4.0 3.3 4.8 4.1 7.3 5.7 8.4 7.7
CFM
HIGH 220/215 220 220/215 220 290/270 290 325/315 325
LOW 175/155 175 175/155 175 220/190 220 250/220 250
HIGH 235/230 235 235/230 235 310/290 310 345/335 345
LOW 185/165 185 185/165 185 235/205 235 265/235 265
35 35 35 35 45 45 50 50
Dehumidification
(pints/hr) 1.9 1.9 2.7 2.7 3.8 3.8 4.4 4.4
Net Weight 110 110 120 120 130 130 140 140
Shipping Weight (approx.
lbs.) 130 130 140 140 150 150 160 160
Cool, Wet Coil
COOLING DATA (HEAT PUMP)
Ventilated Air
Dry Coil
PTC073A**AA PTC074A**AA PTC093A**AA PTC094A**AA PTC123A**AA PTC124A**AA PTC153A**AA PTC154A**AA
Voltage1&3 230/208 265 230/208 265 230/208 265 230/208 265
Capacity (BUTH) 7,500/7,400 7,500 9,000/8,800 9,000 12,200/12,000 12,200 14,200/14,000 14,200
Amps 2.5/2.6 2.0 3.5/3.8 3.0 4.6/5.0 3.7 7.4/7.9 6.5
Watts 625/610 625 810/790 810 1,145/1,125 1,145 1,510/1,490 1,510
EER 11.6 11.6 11.1 11.1 10.8 10.8 9.4 9.4
UNIT WITHOUT
ELECTRIC HEATER
Minimum Circuit Ampacity2&4 4.0 3.3 4.8 4.1 7.3 5.7 8.4 7.7
CFM
HIGH 220/215 220 220/215 220 290/270 290 325/315 325
LOW 175/155 175 175/155 175 220/190 220 250/220 250
HIGH 235/230 235 235/230 235 310/290 310 345/335 345
LOW 185/165 185 185/165 185 235/205 235 265/235 265
35 35 35 35 45 45 50 50
Dehumidification
(pints/hr) 1.9 1.9 2.7 2.7 3.8 3.8 4.4 4.4
Net Weight 110 110 120 120 130 130 140 140
Shipping Weight (approx.
lbs.) 130 130 140 140 150 150 160 160
Cool, Wet Coil
COOLING DATA (COOLING with ELECTRIC HEAT)
Ventilated Air
Dry Coil
EER - EnergyEfficiency Ratioper TheAir-Conditioning,
Heating,and RefrigerationInstitute (AHRI)Test
ProceduresandCanadian StandardsAssociation
(CSA)Test Procedures
COP - Coefficientof PerformanceperAHRITest
Procedures

7
SPECIFICATIONS
NOTES:
1.All 265Vmodels mustuse Amana®brand’ssubbase(PTSB4**C)orAmana®brand’shardwire kit(PTPWHWK4).
2.Minimum branchcircuitampacityratingconformtotheNational ElectricCode. However, localcodesshouldapply.
3.Minimumvoltageon230/208voltmodelsis197volts;maximumis253volts.Minimumvoltageon265volt modelsis238.5volts; maximumis291.5
volts.
4.Overcurrent protectionfor allunits withoutelectricheatersis15 amps.Overcurrent protectionon 265volt modelsmust becartridge-style time
delayfuses (includedand factoryinstalledonAmana®brand chassis).
5.Heating capacityandefficiency arebased onunitoperationwithoutcondensate pump.Unit automaticallyswitchesto electricheat at25°F
outdoorcoiltemperature.
6.Totalwattsfor 15,000Btuhmodels; subtract30 wattsfor PT12*A**AAand 70wattsfor PT07/09*A**AA.
7.Pleasespecify2-digitheater kWsizeto completemodelnumber.
8.Totalampsfor12,000and15,000Btuhmodels;subtract0.2ampsforPT07/09*A*AA.
EER - EnergyEfficiency Ratioper TheAir-Conditioning,
Heating,and RefrigerationInstitute (AHRI)Test
ProceduresandCanadian StandardsAssociation
(CSA)TestProcedures
COP - Coefficientof PerformanceperAHRI Test
Procedures
PTH073A**AA PTH074A**AA PTH094A**AA PTH123A**AA PTH124A**AA PTH153**AA PTH154A**AA
2.6/3.0 2.2 2.6 4.5/5.1 3.9 5.0/5.6 4.1
575/565 575 770 1,020/1,000 1,020 1,350/1,320 1,350
6,800/6,700 6,800 8,500 11,200/11,100 11,200 13,400/13,100 13,400
3.3 3.3 3.2 3.1 3.1 2.9 2.9
235/230 235 234 310/290 310 345/335 345
Outd oor A mbi ent
ºF
Heating BTUH
Note 5
Heating BTUH
Note 5
Heating BTUH
Note 5
Heating B TU H
Note 5
Heating BTUH
Note 5
H eatin g BT UH
No te 5
Heating BTUH
Note 5
62 8,500/8,400 8,500 10,600/10,500 10,600 13,200/13,000 16,500/16,200 16,500
57 7,900/7,800 7,900 10,000/9,900 10,000 12,400/12,200 15,500/15,200 15,500
52 7,200/7,100 7,200 9,300/9,200 9,300 11,600/11,400 14,400/14,100 14,400
47 6,500/6,400 6,500 8,400/8,300 8,400 10,800/10,600 13,400/13,100 13,400
Ra tin g
Point (COP) 3.3/3.3 3.3 32./3.2 3.2 3.1/3.1 2.9/2.9 2.9
452 5,800/5,700 5,800 7,600/7,500 7,600 10,000/9,800 12,300/12,100 12,300
37 5,200/5,100 5,200 6,800/6,700 6,800 9,200/9,000 11,400/11,200 11,400
32 4,600/4,500 4,600 6,000/5,900 6,000 8,400/8,200 10,300/10,100 10,300
Outd oor A mbi ent
ºF Wa tts Wat ts Watts Watts Watts Watts Watts
62 600/650 660 860 860 1,120/1,100 1,500/1,470 1,500
57 635/625 635 830 830 1,090/1,070 1,450/1,420 1,450
52 600/590 600 800 800 1,050/1,030 1,400/1,380 1,400
47 575/565 575 770 770 1,020/1,000 1,350/1,320 1,350
42 550/540 550 840 740 990/970 1,290/1,265 1,290
37 525/515 525 710 710 950/930 1,225/1,200 1,225
32 500/490 500 680 680 920/900 1,170/1,140 1,170
HEATING PERFORMANCE - REVERSE CYCLE
BTUH 5
COP5
CFM (Dry)
Heating Capacity
Reverse Cycle1&7
Amp s
Wa tts
PTC073A**AB
PTC073A**AC
PTC074A**AB
PTC074A**AC
PTC093A**AB
PTC093A**AC
PTC094A**AB
PTC094A**AC
PTC123A**AB
PTC123A**AC
PTC124A**AB
PTC124A**AC
PTC153A**AB
PTC153A**AC
PTC154A**AB
PTC154A**AC
Voltage1&3 230/208 265 230/208 265 230/208 265 230/208 265
Capacity (BUTH) 7,100/7,000 7,100 9,100/8,900 9,100 12,000/11,900 12,000 14,200/14,000 14,200
Amps 2.8/3.0 2 3.7/3.8 3 4.6/5.0 4.3 6.3/6.9 5.9
Watts 610/600 610 805/785 805 1,120/1,110 1,130 1,545/1,520 1,525
EER 11.6 11.6 11.3 11.3 10.7 10.7 9.2 9.3
UNIT WITHOUT
ELECTRIC HEATER
Minimum CircuitAmpacity2&4 4.0 3.6 5.1 4.4 6.4 5.7 8.4 7.4
CFM
HIGH 245/240 245 245/240 245 325/315 325 325/315 325
LOW 220/205 220 220/205 220 250/229 250 250/220 250
HIGH 265/260 265 265/260 265 345/335 345 345/335 345
LOW 230/215 230 230/215 230 265/235 265 265/235 265
FAN ONLY* 65* 65* 65* 65* 70* 70* 70* 70*
COMPRESSOR & FAN* 65* 65* 65* 65* 70* 70* 70* 70*
Dehumidific ation
(pints/hr) 1.6 1.6 2.6 2.6 3.5 3.5 4.4 4.4
Net Weight 90 90 95 95 105 105 110 110
Shipping Weight (approx.
lbs.) 105 105 110 110 120 120 125 125
Cool, Wet Coil
COOLING DATA (CO OL ING with ELECTRIC HEAT)
Ventilated Air
Dr y Co il

8
SPECIFICATIONS
NOTES:
1.All 265Vmodels mustuseAmana®brand’ssubbase(PTSB4**C) oran Amana®brandhard wirekit (PTPWHWK4).
2.Minimum branchcircuitampacityratingsconformtotheNational ElectricCode. However,localcodesshould apply.
3.Minimumvoltage on230/208voltmodels is197volts;maximumis253volts. Minimumvoltageon265 voltmodelsis238.5volts;maximumis 291.5volts.
4.Overcurrent protectionfor all unitswithout electric heaters is15amps. Overcurrentprotectionon265voltmodelsmustbecartridge-style timedelay fuses(included
andfactory installedon Amana® brandall265 voltchassis).
5.Heatingcapacityandefficiency arebasedon unitoperationwithout condensatepump. Unitautomaticallyswitches toelectricheatatapproximately 24°Foutdoorambient.
6.Totalwattsfor12,000and15,000Btuh models.Subtract70 wattsforPT07/09*B*AE.
7.Pleasespecify2-digitheater kWsizeto completemodelnumber.
9.Refrigerant usedin allsystemsis R-22.
8.Totalampsfor12,000and15,000Btuhmodels;subtract0.2ampsforPT07/09*B*AE.
10.Allunitsmeetor exceedASHRAE90.1standards..
PTH073A**AB
PTH073A**AC
PTH74A**AB
PTH074A**AC
PTH093A**AB
PTH093A**AC
PTH094A**AB
PTH094A**AC
PTH123A**AB
PTH123A**AC
PTH124A**AB
PTH124A**AC
PTH153A**AB
PTH153A**AC
PTH154A**AB
PTH154A**AC
Voltage1&3 230/208 265 230/208 265 230/208 265 230/208 265
Capacity (BUTH) 7,100/7,000 7,100 9,000/8,800 9,000 12,000/11,800 12,000 14,000/13,800 14,000
Amps 2.8/3.0 2.3 3.5/3.8 3.0 4.6/5.0 4.3 6.3/6.9 5.9
Watts 651/610 615 805/785 805 1,120/1,110 1,120 1,505/1,485 1,505
EER 11.5 11.5 11.2 11.2 10.7 10.7 9.3 9.3
UNIT WITHOUT
ELECTRIC HEATER
Minimum Circuit Ampacit
y
2&4 4.0 3.6 5.1 4.4 6.4 5.7 8.4 7.4
CFM
HIGH 245/240 245 245/240 245 325/315 325 325/315 325
LOW 220/205 220 220/205 220 250/229 250 250/220 250
HIGH 265/260 265 265/260 265 345/335 345 345/335 345
LOW 230/215 230 230/215 230 265/235 265 265/235 265
FAN ONLY* 65* 65* 65* 65* 70* 70* 70* 70*
COMPRESSOR & FAN* 65* 65* 65* 65* 70* 70* 70* 70*
Dehumidification
(pints/hr) 1.6 1.6 2.6 2.6 3.5 3.5 4.4 4.4
Net Weight 95 90 100 100 110 110 115 115
Shipping Weight
(approx. lbs.) 110 110 115 115 125 125 130 130
Cool, Wet Coil
COOLING DATA (HEAT PUMP)
Ventilated Air
Dry Coil
PTH073A**AB
PTH073A**AC
PT H074A ** AB
PT H074A ** AC
PTH093A**AB
PTH093A**AC
PTH094A**AB
PTH094A**AC
PTH123A**AB
PTH123A**AC
PTH124A**AB
PTH124A**AC
PTH153A**AB
PTH153A**AC
PTH154 A**AB
PTH154 A**AC
2.6/3.0 2.2 3.2/3.6 2.6 4.5/5.1 3.9 5.7/6.3 5.4
570/550 570 740/730 740 1,020/1,000 1,020 1,390/1,380 1,390
6,400/6,200 6,400 8,100/8,000 8,100 10,800/10,600 10,800 13,300/13,200 13,300
3.3 3.3 3.2 3.2 3.1 3.1 2.8 2.8
235/230 235 235/230 230 310/290 310 345/335 345
O
ut
d
oor
Ambient
º
F
Heating BT UH
No te 5
Heating BTUH
Note 5
Heati ng B TU H
Note 5
Heati ng B TU H
Note 5
Heating BT UH
Note 5
Heati ng BT UH
Note 5
Heatin g BT UH
Note 5
Heati n g BT UH
Note 5
62 8,400/8,200 8,400 10,300/10,200 10,300 13,200/13,000 13,200 16,400/16,300 16,400
57 7,800/7,600 7,800 9,700/9,600 9,700 12,400/12,200 12,400 15,400/15,300 15,400
52 7,100/6,900 7,100 9,000/8,900 9,000 11,600/11,400 11,600 14,300/14,200 14,300
47 6,400/6,200 6,400 8,100/8,000 8,100 10,800/10,600 10,800 13,300/13,200 13,300
Ra tin g
Point (COP) 3.3/3.3 3.3 32./3.2 3.2 3.1/3 .1 2.9/2.9 2.9 * * *
452 5,700/5,500 5,700 7,300/7,200 7,300 10,000/9,800 10,000 12,300/12,200 12,300
37 5,100/4,900 5,100 6,500/6,400 6,500 9,200/9,000 9200 11,300/11,200 11,300
32 4,500/4,300 4,500 5,700/5,600 5,700 8,400/8,200 8400 10,200/10,100 10,200
O
ut
d
oor
Ambient
ºF
Watts Wat ts Watts Watts Watts Watts Watts Watts
62 645/625 645 835/825 835 1,151/1,095 1,115 1,540/1,530 1,540
57 630/610 630 805/795 805 1,085/1,065 1,085 1,500/1,490 1,500
52 595/575 595 780/770 780 1,055/1,035 1,055 1,450/1,440 1,450
47 570/550 570 740/730 740 1,020/1,000 1,020 1,390/1,380 1,390
42 540/520 540 710/700 710 985/965 985 1,335/1,325 1,335
37 515/505 515 675/665 675 945/925 945 1,250/1,240 1,250
32 495/485 495 630/620 630 915/895 915 1,170/1,160 1,170
27 460/450 460 590/580 590 885/865 885 1,110/1,090 1,100
HEAT IN G PERF OR MAN CE - REVERSE CYC LE
BTUH5
COP 5
CFM (Dry)
Heating Capacity
Reverse Cycle1& 7
Amp s
Watts

9
SPECIFICATIONS
NOTES:
1.All 265VmodelsmustuseAmana®brand’s subbase(PTSB4**E) oran Amana®brandhardwirekit (PTPWHWK4).
2.Minimum branchcircuitampacityratingsconformtotheNational ElectricCode. However,localcodesshould apply.
3.Minimumvoltage on230/208voltmodels is197volts;maximumis253volts. Minimumvoltageon265 voltmodelsis238.5volts;maximumis 291.5volts.
4.Overcurrent protectionfor allunits withoutelectric heatersis15 amps.Overcurrent protectionon 265volt modelsmust becartridge-style timedelay fuses(included
andfactory installedon Amana® brandall265 voltchassis).
5.Heatingcapacityandefficiency arebasedon unitoperationwithout condensatepump. Unitautomaticallyswitches toelectricheatatapproximately 24°Foutdoorambient.
6.Totalwattsfor12,000and15,000Btuh models.Subtract70 wattsforPT07/09*B*AE.
7.Pleasespecify2-digitheater kWsizeto completemodelnumber.
9.Refrigerant usedin allsystemsis R-22.
8.Totalampsfor12,000and15,000Btuhmodels;subtract0.2ampsforPT07/09*B*AE.
10.Allunitsmeetor exceedASHRAE90.1standards..
PTC073B***
E - Y
PTC074B***
E - Y
PTC0 93B***
E - Y
PTC09 4B***
E - Y
PTC1 23B***
E - Y
PTC124B***
E - Y
PTC153B***
E - Y
PTC154B***
E - Y
Voltage1&3 230/208 265 230/208 265 230/208 265 230/208 265
Capacity (BUTH) 7,100/6,900 7,100 9,100/8,900 9,100 12,000/11,900 12,000 14,000/13,900 14,000
Amps 2.8/3.0 2 3.7/3.8 3 4.6/5.0 4.3 6.3/6.9 5.9
Watts 610/595 610 790/775 790 1,110/1,100 1,130 1,470/1,450 1,470
EER 11.6 11.6 11.5 11.5 10.8 10.8 9.5 9.5
UNIT WITHOUT
ELECTRIC HEATER
Minimum Circuit Ampacity2&4 4.0 3.6 5.1 4.4 6.4 5.7 8.8 7.7
CFM
HIGH 245/240 245 245/240 245 325/315 325 325/315 325
LOW 220/205 220 220/205 220 250/229 250 250/220 250
HIGH 265/260 265 265/260 265 345/335 345 345/335 345
LOW 230/215 230 230/215 230 265/235 265 265/235 265
COMPRESSOR & FAN* 65 65 65 65 70 70 70 70
Deh umi di fic ation
(pints/hr) 1.6 1.6 2.6 2.6 3.5 3.5 4.4 4.4
Net Weight 90 90 95 95 105 105 110 110
Shipping Weight
(approx. lbs.) 105 105 110 110 120 120 125 125
Cool, Wet Coil
COOLING DATA (COOLING with ELECTRIC HEAT)
Ventilated Air
Dr y Co il
PTH073B***
E - Y
PTH074B***
E - Y
PTH0 93B***
E - Y
PTH09 4B***
E - Y
PTH1 23B***
E - Y
PTH124B***
E - Y
PTH153B***
E - Y
PTH154B***
E - Y
Voltage1&3 230/208 265 230/208 265 230/208 265 230/208 265
Capacity (BUTH) 7,000/6,800 7,000 9,100/8,900 9,100 12,000/11,800 12,000 14,000/13,900 14,000
Amps 2.8/3.0 2 3.5/3.8 3 4.6/5.0 4.3 6.3/6.9 5.9
Watts 605/585 605 790/775 790 1,110/1,090 1,110 1,505/1,495 1,505
EER 11.6 11.6 11.5 11.5 10.8 10.8 9.3 9.3
UNIT WITHOUT
ELECTRIC HEATER
Minimum Circuit Ampacity2&4 4.0 3.6 5.1 4.4 6.4 5.7 8.8 7.7
CFM
HIGH 245/240 245 245/240 245 325/315 325 325/315 325
LOW 220/205 220 220/205 220 250/229 250 250/220 250
HIGH 265/260 265 265/260 265 345/335 345 345/335 345
LOW 230/215 230 230/215 230 265/235 265 265/235 265
COMPRESSOR & FAN* 65 65 65 65 70 70 70 70
Deh umi dific ation
(pints/hr) 1.6 1.6 2.6 2.6 3.5 3.5 4.4 4.4
Net Weight 95 95 100 100 110 110 115 115
Shipping Weight
(approx. lbs.) 110 110 115 115 125 125 130 130
Cool, Wet Coil
COOLING DATA (COOLING with ELECTRIC HEAT)
Ventilated Air
Dr y Co il
*Approximately95 CFMwith optionalpower ventkit. Actualvent CFMperformance willvary dueto applicationand installationconditions.

10
SPECIFICATIONS
NOTES:
1.All 265VmodelsmustuseAmana®brand’s subbase(PTSB4**E) oran Amana®brandhardwirekit (PTPWHWK4).
2.Minimum branchcircuitampacityratingsconformtotheNational ElectricCode. However,localcodesshould apply.
3.Minimumvoltage on230/208voltmodels is197volts;maximumis253volts. Minimumvoltageon265 voltmodelsis238.5volts;maximumis 291.5volts.
4.Overcurrent protectionfor all unitswithout electric heaters is15amps. Overcurrentprotectionon265voltmodelsmustbecartridge-style timedelay fuses(included
andfactory installedon Amana® brandall265 voltchassis).
5.Heatingcapacityandefficiency arebasedon unitoperationwithout condensatepump. Unitautomaticallyswitches toelectricheatatapproximately 24°Foutdoorambient.
6.Totalwattsfor12,000and15,000Btuh models.Subtract70 wattsforPT07/09*B*AE.
7.Pleasespecify2-digitheater kWsizeto completemodelnumber.
9.Refrigerant usedin allsystemsis R-22.
8.Totalampsfor12,000and15,000Btuhmodels;subtract0.2ampsforPT07/09*B*AE.
10.Allunitsmeetor exceedASHRAE90.1standards.
11.Some unitsless than250voltshavea LeakCurrent DetectorInterrupter (LCDI)powercord andmeeat UL484standards.
12.Refertoelectricheat performancedatafortotalMCAandrecommendedovercurrentprotection.AmpsandWattsnotationreferstocompressoronly.
230V 208V 265V
230/208 2.5/2.0 1 8,500 6,800 --- 2,650/2,140 11.6/10.5 14.5 15 6 - 15 P
230/208 3.5/2.9 1 12,000 9,900 --- 3,650/3,040 15.9/14.5 19.9 20 6 - 20 P
230/208 5.0/4.1 1* 17,100 14,000 --- 5,150/4,240 22.4/20.4 28.1 30 6 -30 P
265 2.5 1 --- --- 8,500 2,650 10.1 12.7 15 7 - 20 P
265 3.7 1 --- --- 12,600 3,850 14.7 18.3 20 7 - 20 P
265 5.0 1* --- --- 17,100 5,150 19.6 24.5 25 7 - 30 P
* PTH/PTC09*B50*G/K have the same airflow as a PTC/PTH12*B***G (not available on 7,000 BTU/h models).
HEAT PERFORMANCE (ELECTRIC HEAT) EL ECTRIC DATA
(A LL BTUH SI ZES, ALL MO DELS)
Nominal Heating
(BTUH)
Number
of
Stages
Electric Heater Size
(kW)
Voltage Total
Watts
Total
Amps
Minimum
Ampacity1
Overcurrent
Protection5
Power
Co r d1
PTH073B***
E - Y
PTH074B***
E - Y
PTH093B***
E - Y
PTH094B***
E - Y
PTH123B***
E - Y
PTH124B***
E - Y
PTH153B***
E - Y
PTH154B***
E - Y
6,200/6,00 6200 8,200/8,000 8200 10,800/10,600 10800 13,300/13,200 13,300
2.6/3.0 2.2 3.2/3.6 2.6 4.5/5.1 3.9 5.7/6.3 5.4
550/530 550 750/730 750 1020/1,000 1020 1,340/1,330 1,340
3.3 3.3 3.2 3.2 3.1 3.1 2.9 2.9
235/230 235 235/230 230 310/290 310 345/335 345
Outdoor
Ambient
ºF
Heatin g BTUH
No te 5
Heating BTUH
Note 5
Heating BTUH
Note 5
Heati ng B TU H
Note 5
Heating BT UH
Note 5
Heati ng BT UH
Note 5
Heatin g BTUH
Note 5
Heati n g BT UH
Note 5
62 7,200/7,000 7,200 9,800/9,600 9,800 13,000/12,800 13,000 15,800/15,700 15,800
57 6,900/6,700 6,900 9,300/9,100 9,300 12,300/12,100 12,300 15,000/14,900 15,000
52 6,500/6,300 6,500 8,700/8,500 8,700 11,600/11,400 11,600 14,200/14,100 14,200
47 6,200/6,000 6,200 8200/8,000 8,200 10,800/10,600 10,800 13,300/13,200 13,300
Ra tin g
Point (COP) 3.3/3.3 3.3 3.2/3.2 3.2 3.1/3.1 3.1 2.9/2.9 2.9
452 5,900/5,700 5,900 7,700/7,500 7,700 10,100/9,900 10,100 12,500/12,400 12,500
37 5,600/5,400 5,500 7,200/7,00 7,200 9,400/9,200 9,400 11,700/11,600 11,700
32 5,300/5,100 5,200 6,700/6,500 6,700 7,900/7,700 7,900 10,000/9,900 10,000
Outdoor
Ambient
ºF
Watts Wat ts Wa tts Watts Watts Watts Watts Watts
62 580/560 580 810/790 810 1,120/1,100 1,120 1,465/1,455 1,465
57 575/555 575 800/780 800 1,090/1,075 1,090 1,440/1,430 1,440
52 555/535 555 775/755 775 1,060/1,045 1,060 1,405/1,395 1,405
47 550/530 550 750/730 750 1,020/1,005 1,020 1,340/1,330 1,340
42 540/525 560 730/710 730 985/970 985 1,325/1,315 1,325
37 530/515 545 705/685 705 950/935 950 1,285/1,275 1,285
32 515/500 535 690/670 690 900/885 900 1,240/1,230 1,190
HEAT IN G PERF OR MANC E - REVERSE CYC L E
BTUH5
COP 5
CFM (Dr y)
Heating Capacity
Reverse Cycle1& 7
Amps12
Watts

11
SPECIFICATIONS
NOTES:
1.All 265Vmodels mustuseAmana®brand’ssubbase(PTSB4**D) oran Amana®brand hardwirekit(PTPWHWK4).
2.Minimum branchcircuitampacityratingsconformtotheNational ElectricCode. However,localcodesshould apply.
3.Minimumvoltage on230/208voltmodels is197volts;maximumis253volts. Minimumvoltageon265 voltmodelsis238.5volts;maximumis 291.5volts.
4.Overcurrent protectionfor allunits withoutelectric heatersis15 amps.Overcurrent protectionon 265volt modelsmust becartridge-style timedelay fuses(included
andfactory installedon Amana® brandall265 voltchassis).
5.Heatingcapacityandefficiency arebasedon unitoperationwithout condensatepump. Unitautomaticallyswitches toelectricheatatapproximately 24°Foutdoorambient.
6.Totalwattsfor12,000and15,000Btuh models.Subtract70 wattsforPT07/09*B*AE.
7.Pleasespecify2-digitheater kWsizeto completemodelnumber.
9.Refrigerant usedin allsystemsis R-22.
8.Totalampsfor12,000and15,000Btuhmodels;subtract0.2ampsforPT07/09*B*AE.
10.Allunitsmeetor exceedASHRAE90.1standards..
*Approximately95 CFMwith optionalpower ventkit. Actualvent CFMperformance willvary dueto applicationand installationconditions.
NTE07A**A3A NTE07A**A4A NTE09A**A3A NTE09A**A4A NTE12A**A3A NTE12A**A4A NTE15A**A3A NTE15A**A4A
Voltage1&3 230/208 265 230/208 265 230/208 265 230/208 265
Capacity (BUTH) 7,100/6,900 7,100 9,100/8,900 9,100 11,900/11,700 11,900 13,700/13,500 13,700
Amps 2.8/3.0 2.3 3.7/3.8 3.0 4.9/5.3 4.3 6.3/6.9 5.9
Watts 655/640 655 830/810 830 1,165/1,145 1,165 1,540/1,515 1,540
EER 10.8 10.8 11 11 10.2 10.2 8.9 8.9
UNIT WITHOUT
ELECTRIC HEATER
Minimum Circuit Ampacity2&4 4.0 3.6 5.1 4.4 6.4 5.7 8.4 7.4
CFM
HIGH 245/240 245 245/240 245 325/315 325 325/315 325
LOW 220/205 220 220/205 220 250/229 250 250/220 250
HIGH 265/260 265 265/260 265 345/335 345 345/335 345
LOW 230/215 230 230/215 230 265/235 265 265/235 265
FAN ONLY* 65* 65* 65* 65* 70* 70* 70* 70*
COMPRESSOR & FAN* 65* 65* 65* 65* 70* 70* 70* 70*
Dehumidification
(pints/hr) 1.6 1.6 2.6 2.6 3.5 3.5 4.4 4.4
Net Weight 90 90 95 95 105 105 110 110
Shipping Weight (approx.
lbs.) 105 105 110 110 120 120 125 125
Cool, Wet Coil
COOLING DATA (ELECTRIC HEAT)
Ventilated Air
Dry Coil
NTP07A**A3A NTP07A**A4A NTP09A**A3A NTP09A**A4A NTP12A**A3A NTP12A**A4A NTP15A**A3A NTP15A**A4A
Voltage1&3 230/208 265 230/208 265 230/208 265 230/208 265
Capacity (BUTH) 7,000/6,800 7,000 8,900/8,700 8,900 11,600/11,400 11,600 13,700/13,500 13,700
Amps 2.8/3.0 2.3 3.5/3.8 3.0 4.6/5.0 4.3 6.3/6.9 5.9
Watts 655/635 655 825/805 825 1,160/1,140 1,160 1,540/1,515 1,540
EER 10.7 10.7 10.8 10.8 10.0 11.0 8.9 8.9
UNIT WITHOUT
ELECTRIC HEATER
Minimum Circuit Ampacity2&4 4.0 3.6 5.1 4.4 6.4 5.7 8.4 7.4
CFM
HIGH 245/240 245 245/240 245 325/315 325 325/315 325
LOW 220/205 220 220/205 220 250/229 250 250/220 250
HIGH 265/260 265 265/260 265 345/335 345 345/335 345
LOW 230/215 230 230/215 230 265/235 265 265/235 265
FAN ONLY* 65* 65* 65* 65* 70* 70* 70* 70*
COMPRESSOR & FAN* 65* 65* 65* 65* 70* 70* 70* 70*
Dehumidification
(pints/hr) 1.6 1.6 2.6 2.6 3.5 3.5 4.4 4.4
Net Weight 95 95 100 100 110 110 115 115
Shipping Weight (approx.
lbs.) 110 110 115 115 125 125 130 130
Cool, Wet Coil
COOLING DATA (HEAT PUMP)
Ventilated Air
Dry Coil

12
SPECIFICATIONS
1. All265V modelsmustuse Amana®brand’ssubbase(PTSB4**E)or anAmana®
brandhardwire kit (PTPWHWK4).
2. Minimumcircuit ampacityratingsconformtothe NationalElectric Code.
However,localcodesshould apply.Minimumvoltageon230/208volt modelsis
197volts;maximumis 253volts.
3. Minimumvoltage on265voltmodels is238.5volts;maximum is291.5volts.
4. Overcurrentprotection forall units without electric heaters is15 amps.
Overcurrentprotectionon265volt modelsmustbecartridge-styletime delay
fuses(included andfactory installedon Amana®brandall 265volt chassis).
Seeheaterperformancefortotal MCA.
5. Heatingcapacity andefficiencyarebasedon unitoperationwithoutcondensate
pump.Unitautomaticallyswitchesto electricheatat approximately24°F
outdoorambient.
6. Totalwattsfor12,000and15,000 Btuhmodels.Subtract 70wattsforPT07/09
7. Pleasespecify 2-digitheaterkWsizeto completemodel serialnumber.
8. Totalampsfor12,000and 15,000Btuhmodels;subtract 0.2ampsforPT07/09
9. Refrigerantused inallsystems isR-22.
10. AllunitsmeetorexceedASHRAE 90.1standards..
11. Allunits less than250 voltshave aLeakCurrent DetectorInterrupter (LCDI)
powercordand meeatUL484 standards.
12. RefertoelectricheatperformancedatafortotalMCAandrecommended
overcurrentprotection.AmpsandWattsnotationrefersto compressormodels
only.
PTC****A*
* Approximately 95 CFM with optional power vent kit. Actual vent
CFM performance will vary due to application and installation
conditions.
NOTES:
Model 1, 7 , 9 , 10 , 12 PTC
094D****
PTC
124C**AM
PTC
154D****
Voltage 1, 3, 11 265 265 265
Capacity (BUTH) 9100 11,600 14000
Am p s 3.6 4.7 6.1
Wat ts 790 1,055 1458
EER 11.5 11.0 9.6
UNIT WITHOUT
ELECTRIC HEATER
Minimum Circuit Ampacity2,4, 12 4.4 5.8 7.5
CFM
HIGH 220 225 210
LOW 195 200 240
HIGH 240 230 335
LOW 210 200 260
FAN ONLY* 65* 65* 70
COMPRESSOR & FAN* 65* 65* 70
Dehumidification
(pints/hr) 2.6 3.3 4.4
Net Weight 95 105 110
Shipping Weight
(approx. lbs.) 110 120 125
COOLING DATA (COOLING with ELECTRIC HEAT)
Cool, Wet Coil
Dry Coil
Ventilated Air
Model 1, 7 , 9 , 10 , 12 PTC
073D**AR
PTC
093D**AR
PTC
123C**AM
PTC
123D**AR
PTC
133D**AR
PTC
153D**AR
Voltage 1, 3, 11 230 / 208 230 / 208 230 / 208 230 / 208 230 / 208 230 / 208
Capacity (BUTH) 7,200/7,000 9,100 / 8,900 11,700 / 11,600 12,000 / 11,800 13,300 / 13,200 14,000/13,800
Am p s 3.5/3.5 4.4/4.4 4.8/5.2 5.4/5.4 5.9/6.4 6.7/6.7
Watts 625/600 790 / 775 1,070,/,1,040 1,120,/,1,100 1265/1235 1445/1420
EER 11.5/11.7 11.5 11.0/11.2 10.7 10.5/10.7 9.7
UNIT WITHOUT
ELECTRIC HEATER
Minimum Circuit Ampacity2,4, 12 4.2 5.4 6.4 6.6 7.8 8.2
CFM
HIGH 220/215 220/215 220/215 310/300 310/300 310/300
LOW 195/190 195/190 195/190 240/230 240/230 240/230
HIGH 240/235 240/235 240/235 335/325 335/325 335/325
LOW 210/205 210/205 210/205 260/250 260/250 260/250
FAN ONLY* 65* 65* 65* 70* 70* 70*
COMPRESSOR & FAN* 65* 65* 65* 70* 70* 70*
Dehumidificat ion
(pint s/hr) 1.6 2.6 3.3 3.3 3.3 4.4
Net Weight 90 95 105 105 105 110
Shipping Weight
(approx. lbs.) 105 110 120 120 120 125
Cool, Wet Coil
Dry Coil
Ventilated Air
COOLING DATA (COOLING with ELECTRIC HEAT)

13
SPECIFICATIONS PTH********[M/R/Z]
- Denotes M or N Models
*Approximately 95 CFM with optional power vent kit.
Actual vent CFM performance will vary due to application and installation conditions.
NOTES:
1. All265V modelsmust useAmana®brand’ssubbase(PTSB4**E)oran Amana®brandhard wirekit (PTPWHWK4).
2. Minimumcircuit ampacityratings conformto theNationalElectricCode.However,localcodes shouldapply.
Minimumvoltageon230/208voltmodelsis197volts;maximumis253volts.
3. Minimumvoltage on265voltmodels is238.5volts;maximum is291.5volts.
4. Overcurrentprotection forall unitswithout electricheaters is15amps.Overcurrentprotectionon265 voltmodels mustbe cartridge-styletime delayfuses
(includedand factoryinstalled onAmana® brandall265 voltchassis). Seeheaterperformancefortotal MCA.
5. Heatingcapacity andefficiencyare basedonunitoperationwithout condensatepump.Unit automaticallyswitchestoelectricheat atapproximately24°Foutdoorambient.
6. Totalwattsfor12,000 and15,000Btuh models.Subtract70 wattsforPT07/09
7. Pleasespecify 2-digitheaterkWsizeto completemodel serialnumber.
8. Totalampsfor12,000and 15,000Btuhmodels;subtract 0.2ampsforPT07/09
9. Refrigerantused inallsystems isR-22.
10. AllunitsmeetorexceedASHRAE 90.1standards..
11. Allunitslessthan250voltshave aLeak CurrentDetector Interrupter(LCDI) powercord andmeet UL484 standards.
12. Refertoelectricheatperformancedatafor totalMCAandrecommendedovercurrent protection.Amps andWattsnotationrefers tocompressormodelsonly.
Model 1, 7, 9, 10, 12 PTH
073D***[R/Z]
PTH
093 D**AR
PTH
123C**AM
PTH
123D**AR
PTH
094D****
PTH
124 C**AM
Voltage 1, 3, 12 230 / 208 230 / 208 230 / 208 230 / 208 265 230 / 208
Capacity (BUTH) 7,000/6,800 9,000/8,800 11,500/11,200 11,700/11,500 9,100 11,300
Am p s 3.5/3.5 4.4/4.4 4.8/5.2 5.4/5.4 3.6 4.7
Wat ts 605/585 795/775 1,085/1,060 1,115/1,095 805 1,070
EER 11.3/11.8 11.3 10.6 10.5 11.3 10.6
UNIT WITHOUT
ELECTRIC HEATER
Minimum Circuit Ampacity2,4, 12 4.2 5.4 6.4 6.6 4.4 5.8
CFM
HIGH 220/215 220/215 220/215 310/300 210 225
LOW 195/190 195/190 195/190 240/230 195 200
HIGH 240/235 240/235 240/235 335/325 240 230
LOW 210/205 210/205 210/205 260/250 210 200
FAN ONLY* 65* 65* 65* 70* 65* 65*
COMPRESSOR & FAN* 65* 65* 65* 70* 65* 65*
Dehumidification
(p
int s/hr
)
1.6 2.6 3.3 3.3 2.6 3.3
Net Weight 95 100 110 110 100 110
Shipping Weight
(approx. lbs.) 110 115 125 125 115 125
COOLING DATA (HEAT PUMP)
Cool , We t Coil
Dry Coil
Ventilated Air

14
SPECIFICATIONS
NOTES:
1. All265V modelsmust useAmana®brand’s subbase(PTSB4**E)oranAmana®brand hardwire kit(PTPWHWK4).
2. Minimumcircuit ampacityratingsconform tothe NationalElectric Code.However, localcodes shouldapply.
Minimumvoltageon230/208voltmodelsis197volts;maximumis253volts.
3. Minimumvoltage on265voltmodels is238.5volts;maximum is291.5volts.
4. Overcurrentprotection forall unitswithout electricheaters is15amps.Overcurrentprotectionon265 voltmodels mustbe cartridge-styletime delayfuses
(includedand factoryinstalled onAmana® brandall265volt chassis).See heaterperformance fortotalMCA.
5. Heatingcapacity andefficiencyare basedonunitoperationwithout condensatepump.Unit automaticallyswitchestoelectricheat atapproximately24°Foutdoorambient.
6. Totalwattsfor12,000 and15,000Btuh models.Subtract70 wattsforPT07/09
7. Pleasespecify 2-digitheaterkWsizeto completemodel serialnumber.
8. Totalampsfor12,000and 15,000Btuhmodels;subtract 0.2ampsforPT07/09
9. Refrigerantused inallsystems isR-22.
10. AllunitsmeetorexceedASHRAE 90.1standards..
11. All unitsless than250 voltshave aLeak CurrentDetector Interrupter(LCDI) powercord andmeeat UL484 standards.
12. Refertoelectricheatperformancedatafor totalMCAandrecommendedovercurrent protection.AmpsandWattsnotationrefers tocompressor only.
PTH********[M/R/Z]
PTH
073D***[ R/Z]
PTH
093D**AR
PTH
123C**AM
PTH
123D**AR
PTH
094D****
PTH
124C**AM
3.5/3.5 4.4/4.4 4.8/5.2 5.4/5.4 3.6 4.7
550/530 760/740 1,010/960 1,035/1,015 750 1,010
6,200/6,000 8,300/8,100 10,000/9,500 10,600/10,400 8,200 10,000
3.2/3.3 3.2 2.9 3.0 3.2 2.9
--- --- --- --- --- ---
240/235 240/235 240/235 335/325 240 230
Outdoor
Ambient
ºF
Heating BTUH
Not e 5
Heating BTUH
Note 5
Heating BTUH
Note 5
Heating BTUH
Note 5
Heating BTUH
Not e 5
Heating BTUH
Note 5
62 7,200/7,000 9,900/9,700 12,200/11,700 12,800/12,600 9,800 12,200
57 6,900/6,700 9,400/9,200 11,500/11,000 12,100/11,900 9,300 11,500
52 6,500/6,300 8,800/8,600 10,800/10,300 11,400/11,200 8,700 10,800
47 6,200/6,000 8,300/8,100 10,000/9,500 10,600/10,400 8,200 10,000
Rating
Point
(COP)*
ºF 3.2/3.3 3 2.9 3 3.2 2.9
42 5,900/5,700 7,800/7,600 9,300/8,800 9,900/9,700 7,700 9,300
37 5,600/5,400 7,300/7,100 8,600/8,100 9,200/9,000 7,200 8,600
32 5,300/5,100 6,800/6,600 7,800/7,300 8,400/8,200 6,700 7,800
27 5,000/4,800 6,300/6,100 7,100/6,600 7,700/7,500 6,200 7,100
24 4,800/4,600 6,000/5,800 6,700/6,200 7,300/7,100 5,700 6,700
Outdoor
Ambient
ºF
Watts Watts Watts Watts W atts Watts
62 °F 585/570 820/800 1,110/1,065 1,135/1,110 810 1,110
57 °F 575/555 810/790 1,080/1,030 1,105/1,085 800 1,080
52 °F 560/545 785/765 1,050/1,000 1,075/1,055 775 1,050
47 °F 550/530 760/740 1,010/960 1,035/1,015 750 1,010
42 °F 540/525 740/720 975/925 1,000/980 730 975
37 °F 530/515 715/695 940/890 965/945 705 940
32 °F 515/500 700/680 890/840 915/895 690 890
27 °F 505/490 670/650 945/795 870/850 670 945
24 °F 500/485 650/630 900/770 845/825 650 900
BTUH5
N Models
CFM (Dry)
*COP = Coefficiency of Performance; per AHRI Test Procedures, units are rated for capacities and efficiencies.
COP5 M Models
Heating Capacity
Reverse Cycle1
Amps12
Watts12
HEATING PERFORMANCE - REVERSE CYCLE
230V 208V 265V
230/208 2.5/2.0 1 8,500 6,800 --- 2,650/2,140 11.6 / 10.5 14.5 15 6 - 15 P
230/208 3.5/2.9 1 12,000 9,900 --- 3,650/3,040 15.9/14.5 19.9 20 6 - 20 P
230/208 5.0/4.1 1* 17,100 14,000 --- 5,150/4,240 22.4/20.4 28.1 30 6 -30 P
265 2.5 1 --- --- 8,500 2,650 10.1 12.7 15 7 - 20 P
265 3.7 1 --- --- 12,600 3,850 14.7 18.3 20 7 - 20 P
265 5.0 1* --- --- 17,100 5,150 19.6 24.5 25 7 - 30 P
* PTH/PTC09*B50*G/K have the same airflow as a PTC/PTH12*B***G (not available on 7,000 BTU/h models).
HEAT PE RF ORMAN CE (ELE CT RIC H EAT ) EL EC TRI C DA TA
(ALL BTUH SIZES, ALL MODELS)
Nomina l Heatin g
(BTUH)
Number
of
Stages
Electric Heater Size
(kW)
Voltage To t al
Watts
To tal
Amps
Minimum
Ampacity1
Overcurrent
Protection5
Power
Cor d1

15
SPECIFICATIONS
OPERATING VOLTAGES
WARNING
USE EXTREME CAUTION WHEN CHECKING HIGH VOLTAGE.
Use a voltmeter, check the voltage at the outlet.
Thereadingmustbewithin the minimums and maximums shown below for the operating voltage.
Operating Voltage Minimum Voltage Maximum Voltage
230/208 197 253
265 238 291
Operating Voltages
NOTE:
1. All 265 volt models must use subbase or hard wire kit.
2. Minimum branch circuit ampacity ratings conform to the National Electric Code. However, local codes should apply if in
conflict.
3. Minimumvoltageon230/208 volt models is 197volts;maximumis253volts. Minimumon265 volts is 238 volts; maximum
is 291 volts.
4. Overcurrentprotectionforall units without electric heaters is 15 amps. Overcurrentprotection on265 voltmodels must be
cartridge-style time delay fuses (included and factory installed on chassis).
5. Heating capacity and efficiency is based on unit operation without condensate pump. Unit automatically switches to
electric heat at 25° F outdoor coil temperature.
6. Totalwattsfor15,000 BTUH models; subtract 30 watts for PT*12*A**AAand70wattsforPT*07/09*A**AA.
7. Please specify 2-digit heater kW size to compete model number.
8. Totalampsfor12,000and 15,000 BTUH models; subtract 0.2 amps for PT*07/09*A**AA
•LCDI or AFCI Power Cords - Underwrites Laboratories and the National Electric Code (NEC) now require power cords that
sense current leakage and can open the electrical circuit to the unit on units rated at 250 volts or less. In the event that unit
does not operate, check the reset button located on or near the head of the power cord as part of the normal troubleshooting
procedure.
LCDI Power Cord

16
WALL SLEEVE INSTALLATION
Thewallsleeve must be installed before the air conditioneror
heat pump chassis can be set in place. Read the instructions
thoroughlybeforeproceeding.
Pre-installationConsiderations
Beforeproceedingwith the sleeve installation, ensure the fol-
lowingguidelinesforlocating the wall opening and sleeve are
met:
• Thewallopeningmustbe the correct size. Seethefigures
belowforwall sleeveDimensionsandminimum wallopen-
ing size.
161/16"
410mm
133/4"
350mm
Wall Receptacle Within 58" From
Bottom Right Side Corner on
208/230 VAC Units Only
Wall Sleeve Dimensions
Internal
Adjacent
Wall
Internal
A
djacent
Wall
Outside
Wall
Allow Front Clearance (See Table 1)
Minimum Unit Clearances
• The wall sleeve will need to be installed with minimum
clearances to the floor and adjacent walls. Minimum pro-
jections of the sleeve into and out of the room will also
have to be met. See Minimum Unit Clearances and Mini-
mum Interior and Exterior Projections Figures as well as
MinimumClearancesand Projections table for details.
• If installed in a concrete or masonry wall, a lintel must be
provided in the wall opening for support. Do not use the
wall sleeve as a lintel. See Framing with Lintel Figure
for a typical lintel construction.
Framing with Lintel
• When installed in the opening, the wall sleeve must be
horizontallylevelfromside to side and pitched (one quar-
ter bubble in the sight glass) to the outside. DO NOT IN-
STALLLEVEL(FRONTTOBACK)ORSLOPETHEWALL
SLEEVETOWARDTHEROOM.
• Theinstaller mustdetermineandsupplythemountingbolts
and/orscrews to attach the wallsleevetothe sides of the
wall opening. Make sure the wall opening is adequate for
strongsupport.
• Theinstallermust provideadequatesealingand insulation
around the sleeve after it is installed (air and water tight).
See Block and Brick Veneer Installation Figure for one of
many types of constructions.
Steel
Lintel
Caulk Top,
Bottom, and
Both Sides
13 1/2" (340 mm)
Maximum
(No Accessories)
Block and Brick Veneer Installation
PROPER INSTALLATION

17
Minimum Interior and Exterior Projections
in. mm in. mm in. mm
Wall Sleeve Only 3 75 0 0 0 0
Subbase Kit 3 75 3 1/4 85 2 3/4 70
Leveling Legs Kit 3 75 3 75 2 50
Duct Kit 3 75 0 0 1 3/8 35
Drain Kit 3 75 010100
Hard Wire Kit 3 75 1 1/4 30 0 0
Hydronic Heat Kit
"A" Series 9 230 0 to 3 1/430 to 85332 752
Hydronic Heat Kit
"J" Series 6 150 0 0 2 1/2 65
Option
MINIMUM CLEARANCES AND PROJECTIONS
ABC
Minimum
Clearances
Minimum
Projection
1If inside mounted then B = 1 1/2 inches (40 mm).
2To achieve a flush fit between the hydronic front and the finished wall,
Dimension “C” must be between 3” and 3 1/8”. If this dimension is more
than 3 1/8” there will be a gap between the front and the wall. This gap
could permit occupant access to hydronic lines or other dangerous parts.
3This dimension can be from 0” to 3-1/4”, but cannot exceed 3-1/4”. If this
dimension exceeds 3-1/4”, the skirt around the front will not reach the
floor.
• For installations in walls deeper than 13-1/2 inches, spe-
cialcareisnecessaryto prevent problems with rainwater,
condensatedrainageandintake/dischargeair.Underthese
circumstances, careful job site analysis and precautions
arerequired.Youmust consult with yourSalesRepresen-
tativeand receiveapprovalbeforeattemptingsuchinstalla-
tions.
• If used, a 230/208 volt wall receptacle must be located
within 58 inches of the lower right sleeve corner. Exten-
sioncordsmustnotbeusedwiththeunit.Seethenoteon
WallSleeveDimensionsFigure.
421/4"
1075mm
Minimum
161/4"
415mm
Minimum
Dimension "B"
in Table 1
Minimum Wall Opening Dimensions
When 230/208 volt units are to be installed, the power supply
maybeeither cordconnectedorpermanent wiring.Permanent
wiring may be done through the accessory hard wire junction
box, or the accessory subbase.
When265voltunitsaretobeinstalled,the power supply must
bepermanentwiring.Permanentwiringmaybe done through
the accessory hard wire junction box, or the accessory sub-
base.An exposed cord connection on 265 volt units is not
permitted.
The subbase accessory includes leveling legs. If added wall
sleeve support is required and the subbase is not to be used
as an accessory, leveling leg kit may be installed.
Drain Kit
An indoor/outdoor drain kit is available as an accessory item.
When a drain kit is to be installed, do so before installing the
wall sleeve in the wall. See the drain kit for actual installation
instructions.
Subbase, Leveling Legs, Main Duct, and Hydronic Heat
Kits
Installationof these kits requiresdrillingofmounting holes on
bothsidesof the wallsleeve.Theminimumrequired clearance
distance between the wall sleeve and wall is shown in Mini-
mum Clearances and Projections Table. If the distance be-
tweenwallsleeveandwallwill beator neartheminimumclear-
ancedistance,mountthesekits on the sleevebeforeinstalling
the sleeve in the wall. The kit installation instructions are in-
cluded with the accessory kits.
PROPER INSTALLATION

18
Wall Receptacle Within 58" From
Bottom Right Side Corner on
208/230 VAC Units Only
Wall Sleeve Dimensions
OutsideEnclosurePanel Removal
The sleeve stiffener must be taken out before the enclosure
panelcanberemoved from the sleeve.
Theenclosurepanel can be removed by foldingthe fourflaps
up and downward and manipulating the front ends of the top
plusbottomtowardsthe center. Theentirepanelcanbe pulled
outdiagonallyfromone side.
Installthewallsleeve condenser air grille by using the screws
andholesprovided.
Installation (WS900B or WS900D)
After the wall opening is checked and approved for location,
size,andclearances,completethe following to install the wall
sleeve.
NOTE: CheckwithAmana®TechnicalService when achassis
is installed in any wall sleeve not supplied by Goodman.
1. Removetheoutsideenclosure panel from thewallsleeve.
2. Slide the wall sleeve into the wall opening. Do not distort
thecabinetshape to fit the wall opening. Theunitchassis
must fit snugly and uniformly into the wall sleeve.
3. Locatethesleeve withintherangeofminimumprojections,
asshownin MinimumWallOpeningDimensionsand Mini-
mum Interior and Exterior Projections Figures, so both
sides are at least the minimum projection from the wall.
4. Checkthelevel ofthewallsleeve. Forproperdrainage,the
sleeve should be level from side to side and one-quarter
bubble in the sight glass sloping to the outside.
5. Two holes will need to be drilled in both sides of the wall
sleeveformountingintothewall.Drillholesofpropersize
and in the proper location so the screws will engage into
strong supporting members of the wall. DO NOT DRILL
THROUGH BOTTOM OF SLEEVE. The following figure
showspossiblefasteningmethods.
Plastic
Anchor
Expansion
Anchor Bolt
Attaching Wall Sleeve to Opening
6. Checkthelevelofthewallsleeveandadjustifnecessary.
7. Caulkorsealaround the outside of the entire sleeve.
8. If the unit chassis will not be installed immediately, re-
place the enclosure panel on the outside opening of the
sleeve. This will prevent weather damage to the building
interior.
9. Recycleordispose ofpackagingmaterialsperlocalcodes.
OUTDOOR GRILLE
An outside grille must be installed to direct air flow for proper
unitoperationandalso protect theoutdoorcoil.Thegrillemust
beinstalledbeforeinstallingthe chassis. Refer to the Installa-
tion Instructions supplied with the outdoor grille kit for a com-
pletedescriptionoftheinstallationprocedure.
Thismodelrequires either a Stamped Grille Kit (Model SGK--
B)oranArchitecturalGrilleKit(ModelAGK--B).Whenreplac-
ing an old chassis with an existing grille, please check with
yoursalesrepresentativetodetermineifthenewchassisshould
be used with the old outdoor grille. An improper outdoor grille
can decrease cooling or heating capacity, increase energy
usageandshortencompressorlife.
FRONT REMOVAL
1. Graspthe cabinet front as shown.
2. Pullthebottomof the cabinet front away from the chassis
untilthe retaining clips disengage.
PROPER INSTALLATION

19
3. Lift the cabinet front off the chassis. Reverse this proce-
dure to reinstall the cabinet front.
CHASSIS INSTALLATION
1. Removethecabinetfront from thechassisasdescribedin
FrontRemoval.
2. Insert the chassis into the wall sleeve.
Chassis
Wall Sleeve
Outside
Wall
Slide Chassis In
3. Slide the chassis into the wall sleeve until the chassis
flangescontactthe front edge of the wall sleeve.
Chassis
Wall Sleeve
Outside
Wall
4. Secure the chassis to the wall sleeve using three screws
on each side of the chassis to ensure a proper seal be-
tween the chassis and the wall sleeve. The screws are
supplied in a plastic bag which is attached to the power
cord.
IMPORTANT NOTES:
1. Theunitisequippedwitharubber grommetmountedcom-
pressor. These grommets are factory set and require no
adjustment.
2. Ifastandardsubbaseisused,besuretherighthandsub-
base cover is removed before the chassis is installed in
thesleeve.
3. Checktheindoorandoutdoor grilles for obstructions toair
flow. The unit must be located where curtains, furniture,
trees, shrubs or other objects do not block the air flow to
andfromtheunit. If air is obstructedand/ordeflectedback
into the unit, the air conditioner’s compressor may cycle
onandoff rapidly. Thiscoulddamagethecompressor and
voidthewarranty.
Front Mounting Holes - Two mounting holes are provided to
give the owner the option of securing the front to the chassis.
The mounting holes are located behind the intake grille. The
owner must supply two 1/2 inch long #8 sheet metal screws
perunit.The two screwsmustberemovedbefore the frontcan
beremoved.
Mounting Screws
Location
Front Mounting Screws
WIRING
CAUTION
TO AVOID PROPERTY DAMAGE, PERSONAL INJURY
OR DEATH DUE TO ELECTRICAL SHOCK:
• DO NOT USE AN EXTENSION CORD WITH THIS UNIT.
• USE ONLY COPPER CONDUCTORS.
• WIRING TO THE UNIT MUST BE PROPERLY POLAR-
IZED AND GROUNDED.
Cord connection to a wall socket is not permitted for 265-volt
units. All265-voltunitsmust be hard wiredusingthehardwire
kit or make use of the plug-in receptacle in the standard sub-
base.
HeaterlessUnits
If a heaterless unit is ordered, field provisions must be made
for supplemental heat if desired. Refer to the Installation In-
structions supplied with the heater kit for a complete descrip-
tionof the installation procedures. All208/230voltheaterless
unitsareshippedwitha15 Amp power cord and all heaterless
265 volt units are shipped with a 20 Amp power cord.
When adding a heater kit to a unit, the power cord supplied
with the heater kit must be used in place of the power cord
suppliedwiththe unit. Thefollowingtablespecifies powercord
ratingrequirementsforthevariousheaterkits.
PROPER INSTALLATION

20
230/208 Volt Units 265 Volt Units
Power Cord Rating
(amp) Power Cord Rating (amp)
1.5 15 20
2.5 15 20
3.5 20 Not Applicable
3.7 Not Applicable 20
530 30
POWER CORD REQUIREMENTS
Heater Size
(kW)
NOTE:Heaterlessunitsareshippedwith anauxiliarydata label
onthefrontside of the mid-partitionpanel. Ifanelectricheater
kit is field installed, the installer must mark the appropriate
box on the label to indicate the electric heater capacity. If no
heater is installed, the box labeled “None” must be marked.
Refertotheunitnameplateforovercurrentprotectiondata.
CAUTION
DO NOT INSTALL A 5kW HEATER KIT IN ANY 7,000
OR 9,000 BTU CHASSIS.
OPERATING CONTROLS
UsersControls
Tworotaryknobscontrollingtemperatureandoperationalmode
are located behind the control door located to the top-right of
thecabinetfront.
Warm Cool Fan
Only
High
Heat
High
Cool
Thermostat Mode Switch
ThermostatSetting
Turningthe thermostat control clockwise willprovideacooler
room temperature; turning it counterclockwise will provide a
warmerroomtemperature. Adjusting thethermostattothemid
setting(vertical)willsettheroom temperatureatapproximately
75° F.
ModeSwitch
The table below describes the unit function corresponding to
the various mode switch settings.
Switch
Position Unit Function
OFF Unit is completely off. However, before servicing, open all
disconnects and/or remove plug.
FAN ONLY Unit operates on low fan speed to circulate room air.
LOW COOL Unit operates on the low fan speed to circulate air
for cooling.
HIGH COOL Unit operates on high fan speed to circulate air
for cooling.
LOW HEAT Unit operates on the low fan speed to circulate air
for heating.
HIGH HEAT Unit operates on the high fan speed to circulate air
for heating.
MODE SWITCH SETTINGS
AdditionalControlInputs (Not used on NTE orNTP Models)
The control inputs shown below provide addition unit control
andfeatures. Toaccessthese control inputs, thecabinetfront
mustberemoved(see Front Removal).
W2 Y\W1
ON/OFF
ON
LED1
EH IN LS FD1 FD2 TF1 TF2 C R GL W2 Y/W1B GH
RMT/STD
CONTROL FAN
C
B
A
ON/AUTO
LS TF-
Furthermore,toaccessthe24Vaccessoryinputconnections,
the terminal strip cover must be removed as shown (A and B
Series units only).
Terminal Strip
Cover
Mode Switch
MasterSwitch(Not used on NTE or NTP Models)
Themasterswitch disconnectspowertoallof thesystemcom-
ponents. Whenthis switch is intheoff position, the compres-
sor,fanmotor,reversing valve, and electric resistance heater
willallbede-energized.
PROPER INSTALLATION
