Maytag LDGA300AGE Manual

Repair
Parts
List
MODEL NUMBER
LDGA300AGE
When requesting service or ordering parts, always
provide the following information:
- Product Type - Part Number
- Model Number - Part Description
DRYER
©2005 Maytag Services

Section: CONTROL PANEL
LD11-52
Model: LDGA300AGE
1

CONTROL PANEL
No. Part No. Description
Section:
Series Qty
1 N 53-2563 PANEL, CONTROL Note: PANEL, CONTROL (WHT) 10 1
2 25-7649 SCREW Note: SCREW, SPEEDNUT 10 2
3 25-7702 SPEEDCLIP, END CAP TO CTRL PNL Note: SPEEDNUT, END CAP 10 2
4 31001055 TRIM, ENDCAP (LT WHT) Note: (LT-WHT) 10 1
4 31001054 TRIM, ENDCAP (RT WHT) Note: TRIM, END CAP (RT-WHT) 10 1
5 N 25-7760 SCREW Note: SCREW, END CAP TRIM 10 4
- 25-3092 SCREW Note: SCREW, END CAP 10 4
6 35-2668 CAP, END (RT)(WHT) Note: END CAP, CNTRL. PANEL (RT-WHT) 10 1
6 35-2669 CAP, END (LT)(WHT) Note: (LT-WHT) 10 1
- 53-2504 SPACER, CONTROL SHIELD Note: SPACER, CONTROL SHIELD 10 2
- 31001193 PAD, SHIELD Note: PAD, CONTROL SHIELD 11 2
7 31001128 SHIELD, CONTROL 10 1
8 N 53-1814 TIMER 10 1
9 31001119 SCREW Note: SCREW, TIMER 10 2
10 31001129 SWITCH, TEMPERATURE Note: SWITCH, SELECTOR 10 1
10 31001236 SWITCH, TEMPERATURE Note: SWITCH, SELECTOR 11 1
11 31001195 KNOB & SKIRT ASSY. (WHT) Note: KNOB & BEZEL ASSY. (WHT) 10 1
- 25-3457 SCREW, SEMS Note: SCREW, SHIELD/CNTRL. PANEL 10 2
- 25-3092 SCREW Note: SCREW, SHIELD/END CAP 10 3
12 35-2688 SHIELD, CONTROL PANEL (REAR) 10 1
13 25-7851 SPEEDCLIP, END CAP TO TOP Note: SPEEDNUT, END CAP 10 2
14 21001239 KNOB, SELECTOR (WHT) 10 1
15 N 53-2540 TRANSFORMER & TERMINAL ASSY Note: TRANSFORMER 10 1
- 31001008 MANUAL, USE & CARE 10 1
- 31001030 MANUAL, USE & CARE 10 1
- N 16002079 GUIDE, QUICK REF - ADMIRAL Note: GUIDE, QUICK REFERENCE 10 1
2
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: CABINET
LD12-17
Model: LDGA300AGE
3

CABINET
No. Part No. Description
Section:
Series Qty
1 N 53-2435 TOP, CABINET Note: TOP, CABINET (WHT) 10 1
2 53-2147 CABINET & BASE ASSY Note: CABINET & BASE ASSY. (WHT) 10 1
- 25-3092 SCREW Note: SCREW, HINGE 10 2
3 63-5712 HINGE, CABINET TOP 10 2
4 LA-1008 RR ROLLER KIT Note: (REAR) 10 1
4 LA-1007 FRONT ROLLER KIT Note: ROLLER KIT (FRT.) 10 1
5 25-3034 CLIP, WIRING 10 3
6 33-2653 BUMPER, CABINET Note: BUMPER, CABINET 10 4
7 53-0643 PIN, LOCATOR 10 2
8 25-0224 NUT, LOCATOR PIN Note: NUT, LOCATOR PIN 10 2
- 53-0200 SLEEVE, LOCATOR PIN 10 2
9 53-0136 COVER, SUPPLY CORD Note: COVER, POWER CORD 10 1
- 25-7857 SCREW Note: SCREW, COVER 10 2
10 53-0284 COVER, TERMINAL Note: COVER, TERMINAL BLOCK 10 1
- 25-7857 SCREW Note: SCREW, COVER 10 2
11 63-5834 LEG, LEVELING 10 4
12 53-0120 CLIP, FRONT PANEL 10 2
13 25-7027 CLIP, WIRING 10 5
14 N 53-1921 SHIELD, WIRING 10 1
- 25-7733 SCREW Note: SCREW, SHIELD 10 1
15 35-1011 SERVICE CORD Note: CORD, POWER 10 1
- 35-1007 STRAIN RELIEF 10 1
4
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: DOOR
LD17-5
Model: LDGA300AGE
5

DOOR
No. Part No. Description
Section:
Series Qty
1 N 53-0727 PANEL, FRONT (WHT)GAS Note: PANEL, FRONT (WHT) 10 1
- 25-7820 SCREW, FRONT PANEL TO CABINET Note: SCREW, FRONT PANEL 10 2
2 N 25-7817 CLIP, U-TYPE Note: CLIP, FRONT PANEL 10 2
3 25-7220 CLIP, CABINET TOP 10 2
4 53-0643 PIN, LOCATOR 10 2
- 53-0200 SLEEVE, LOCATOR PIN 10 2
5 25-0224 NUT, LOCATOR PIN 10 2
- 25-7810 SCREW 8-18X1/2 TRUSS H Note: SCREW, COLLECTOR DUCT 10 1
6 53-1299 COLLECTOR DUCT Note: DUCT, COLLECTOR 10 2
7 53-0204 SEAL Note: SEAL, COLLECTOR DUCT (FRT.) 10 1
8 N 53-0123 CLIP Note: CLIP, LINT FILTER 10 1
9 53-0918 FILTER, LINT 10 1
10 53-1756 FRONT SEAL SEAL (WHITE) Note: SEAL, TUMBLER (FRT.) 10 1
11 53-0154 PANEL, OUTER DOOR (WHT) Note: PANEL, DOOR (OUTER-WHT) 10 1
- 25-7770 SCREW, OUTER TO INNER DOOR Note: SCREW, DOOR PANEL 10 4
12 53-0912 PANEL, INNER DOOR (WHT) Note: PANEL, DOOR (INNER-WHT) 10 1
13 53-0119 CLIP, HINGE 10 2
14 53-1490 DOOR PAD Note: PAD, DOOR 10 1
15 53-1491 DOOR PAD Note: PAD, DOOR 10 2
16 53-0648 DOOR SEAL Note: SEAL, DOOR 10 1
17 25-7889 PLUG BUTTON Note: PLUG BUTTON, DOOR 10 1
- 25-7810 SCREW 8-18X1/2 TRUSS H Note: SCREW, HANDLE 10 2
18 53-0927 HANDLE, DOOR (WHT) Note: HANDLE, DOOR (WHT) 10 1
19 53-1492 HINGE, DRYER DOOR Note: HINGE, DOOR 10 2
- 25-7809 SCREW, #6-20 1/2 FLTHD TORX Note: SCREW, HINGE 10 4
20 53-0121 TWIN NUT 10 2
- LA-1003 DOOR CATCH KIT (INCL. 21 & 22) Note: CATCH KIT, DOOR (INCL. ITEM # 21 & 22) 10 1
21 53-2364 STRIKE, DOOR Note: STRIKE, DOOR 10 1
22 53-0187 CATCH, DOOR 10 1
23 53-0147 SWITCH, DOOR Note: SWITCH, DOOR 10 1
24 63-5990 CLIP, SWITCH 10 1
25 33-2653 BUMPER, CABINET Note: BUMPER, CABINET 10 4
26 53-0203 SEAL, BLOWER HOUSING Note: SEAL, COLLECTOR DUCT (REAR) 10 1
27 LA-1005 SWITCH KIT (INCL. 23 & 24) Note: SWITCH KIT, DOOR (INCL. ITEM # 23 & 24) 10 1
28 N 53-0155 PLUG, GAS ACCESS (WHT) 10 1
29 N 53-0156 BUTTON, GAS ACCESS (WHT) 10 1
6
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: TUMBLER
LD13-20
Model: LDGA300AGE
7

TUMBLER
No. Part No. Description
Section:
Series Qty
1 LA-1054 DRYER BULKHEAD KIT Note: BULKHEAD 10 1
- 25-7733 SCREW Note: SCREW, BULKHEAD 10 8
2 53-0281 SEAL ASSY (WHITE) Note: SEAL, TUMBLER (REAR) 10 1
3 53-1250 CYLINDER (W/BAFFLE) Note: TUMBLER ASSY. (W/BAFFLES) 10 1
4 02100002 BAFFLE (WHT) 10 3
- N 25-7759 SCREW Note: SCREW, BAFFLE 10 12
5 31531589 BELT, CYLINDER Note: BELT, TUMBLER 10 1
6 53-0197 SUPPORT ASSY.-CYLINDER REAR Note: SUPPORT ASSY. (REAR) 10 2
- 25-7101 SCREW Note: SCREW, SUPPORT ASSY. 10 4
7 31001096 ROLLER (REAR) Note: ROLLER, TUMBLER (REAR) 10 2
8 25-7813 SPACER Note: SPACER, ROLLER 10 2
9 25-7814 WASHER Note: WASHER, ROLLER 10 2
10 25-7854 RING, RETAINING Note: RING, RETAINER 10 2
11 LA-1008 RR ROLLER KIT Note: ROLLER KIT (REAR) 10 1
8
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: MOTOR & DRIVE
LD14-24
Model: LDGA300AGE
9
