MB Connect Line mbNET MDH 810 Instruction manual

Technical Data
MDH800 - MDH859 (from HW 02) - V 6.0 - DE
.

1 Technical data
mbNET®Industrial router
MDH 810, MDH 811, MDH 814, MDH 815, MDH 816, MDH 819, MDH 830, MDH 831, MDH 834, MDH 835,
MDH 841, MDH 849, MDH 850 EU, MDH 850 AT&T, MDH 855 EU, MDH 855 AT&T, MDH 858 EU, MDH 858
AT&T, MDH 859 EU, MDH 859 AT&T - from hardware version: HW 02
You can find the hardware version on the device rating plate.
Housing dimensions
Image 1: Devices and interfaces vary depending on the device type.
Page 2 von 7 | MDH800 - MDH859 (from HW 02) - V 6.0 - DE | June 4th, 2019

General Data
Performance data
Voltage V (DC) 10 – 30 V DC (ext. power supply or SELV power supply, 10-30 V DC, Max. 40A)
Current consumption max. 1300 mA @ 24 V
Random access mem-
ory Devices with hardware version HW03: 512 MB Devices with hardware version HW02: 256 MB
IP Protection class IP 30* * at full occupancy of all connections and interfaces. Alternatively, unused interfaces can be
covered with dust protection plugs.
Area of use Dry environment
Temperature (operat-
ing) -40 – +75 °C
Temperature (storage) -40 – +85 °C
Humidity 0 – 95% non-condensing
Real-time clock In the event of a power failure, the date and time are maintained for up to 7 days
(depending on the ambient temperature).
Dimensions (max.) 48 mm x 137 mm x 140 mm (W x D x H)
Weight (max.) 650 g
Housing/material Metal
Installation DIN-top hat rail mounting
I/Os and standard interfaces
Digital inputs 4-piece, 1030 V DC (electrically isolated), (low 0 – 3.2 V DC, high 8 – 30 V DC)
Digital Outputs 2-piece, 10-30 V DC (electrically isolated), to a maximum of 1.5 A per output
LAN interfaces 4-piece, 10/100MBit/s full and half duplex operation, automatic detection patch ca-
ble/cross-over cable (auto detection)
USB interfaces USB Host 2.0
SD card slot For SD cards (32.0 mm × 24.0 mm × 2.1 mm) SDHC max. 32 GB; FAT/FAT32
NOTICE
As of firmware version 6.0.5, all mbNET routers, as of hardware version HW03, can use the optional
mbEDGE function.
VPN
VPN protocol IPsec/PPTP/OpenVPN,
64 Tunnel
Encryption method Blowfish, AES,
DES/3DES
MDH 810, MDH 811, MDH 814, MDH 830,
MDH 831, MDH 834, MDH 850 EU, MDH 850
AT&T, MDH 855 EU, MDH 855 AT&T
VPN protocol OpenVPN, 1 Tunnel
Encryption method Blowfish
MDH 815, MDH 816, MDH 819, MDH 835,
MDH 841, MDH 849, MDH 858 EU, MDH 858
AT&T, MDH 859 EU, MDH 859 AT&T
Encryption algorithms MD5, SHA1
Authentication Pre-Shared-Key, X.509
*can only be operated with mbCONNECT24, mymbCONNECT24.hosted, -.virtual, -.mini, -.midi or -.maxi.
Technical data | Page 3 of 7

Network/security
Firewall 1:1 NAT, IP-Filter, port forwarding, stateful inspection
IP router NAT-IP, TCP/IP routing, IP forwarding
Services DHCP server, DHCP client, DNS server, NTP client, PPP server, DynDNS
Time levelling NTP server
Optional Interfaces
WAN interfaces 10/100MBit/s full and half duplex operation, automatic detection patch ca-
ble/cross-over cable (auto detection)
Interface 1 (COM1) RS-232/485 (software-switchable)
Interface 2 (COM2) -
device-dependent - RS-232/485 (software-switchable) or MPI/PROFIBUS - 12 MBit/s
SIM card slots 2-piece SIM card reader with ejector (for mini-SIM)
Communication
Devices with analogue modem (MDH 810, MDH 815, MDH 830)
Countries where used 240 countries
Modulation types V.21, V.22, V22bis, V.23, V.32, V.32bis, V.34
Data compression V.42bis, MNP5
Error correction MNP 2-4, V.42 LAPM
Dialling procedure MFV/IWV
Modem port RJ11 socket
FCC Contains Part 15 & Part 68
Devices with UMTS (3G) modem (MDH 814, MDH 819, MDH 834, MDH 849)
Countries where used Global
GSM/GPRS/EDGE 850, 900, 1800, 1900 MHz; Downlink max.296 kbps, Uplink max. 236.8 kbps
HSxPA 800/850, 900, AWS 1700, 1900, 2100 MHz; Downlink max. 21 Mbps, Uplink max.
5.76 Mbps
Antenna connection 1-piece SMA socket
FCC Contains FCC ID: R17HE910
TAC 35613607
Devices with LTE (4G) modem EU (MDH 850 EU, MDH 855 EU, MDH 858 EU, MDH 859 EU)
Countries where used Europe, Australia
GSM/GPRS/EDGE 900, 1800 MHz; max. 236 kbps
HSxPA 850, 900, 2100 MHz; Downlink max. 42 Mbps, Uplink max. 5.76 Mbps
LTE 800 (B20), 1800 (B3), 2600 (B7) MHz; Downlink max. 100 Mbps, Uplink max. 50
Mbps
Antenna connections 2-piece SMA socket
Page 4 von 7 | MDH800 - MDH859 (from HW 02) - V 6.0 - DE | June 4th, 2019

Devices with LTE (4G) modem EU (MDH 850 EU, MDH 855 EU, MDH 858 EU, MDH 859 EU)
TAC 35985205
Devices with LTE (4G) modems - AT&T (MDH 850 AT&T, MDH 855 AT&T, MDH 858 AT&T, MDH 859
AT&T)
NOTICE
Device types MDH 850 AT&T, MDH 855 AT&T, MDH 858 AT&T, MDH 859 AT&T bear no CE marking and
may not be used or put into operation in the European economic area (EEA)!
Countries where used North America
GSM/GPRS/EDGE 850, 1900 MHz; max. 236 kbps
HSxPA 1900 (B2), 850 (B5) MHz; Downlink max. 21 Mbps, Uplink max. 5.76 Mbps
LTE 1900 (B2), AWS 1700 (B4), 850 (B5), 700 (B17) MHz; Downlink max. 100 Mbps,
Uplink max. 50 Mbps
Antenna connections 2-piece SMA socket
FCC Contains FCC ID: R17LE910NA
Devices with Wi-Fi modem (MDH 811, MDH 831, MDH 841)
Wi-Fi IEEE802.11b/g & 802.11n (1T1R mode), up to 150 MBit/s
Wi-Fi specification · EU (2.412 GHz-2.472 GHz, 1-13 Channel)
· USA (2.412 GHz-2.462 GHz, 1-11 Channel)
· WPA/WP2, 64/128/152bit WEP, WPS
· 802.11b: 1, 2, 5.5, 11 Mbps
· 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
· 802.11n: (20 MHz) MCS0-7, up to 72 Mbps
· 802.11n: (40 MHz) MCS0-7, up to 150 Mbps
Antenna connection 1-piece RP SMA socket
FCC Contains FCC ID: YWTWFXM05
PROG. CNTLR.
E482663
Certificates (CE, UL, etc.) can be downloaded at www.mbconnectline.com.
SIMPLIFIED EU DECLARATION OF CONFORMITY
MB connect line GmbH hereby declares that the radio system type MDH 811, MDH 814, MDH 819, MDH 831,
MDH 841, MDH 834, MDH 849, MDH 850 EU, MDH 855 EU, MDH 858 EU, MDH 859 EU corresponds to the
2014/53/EU directive.
A copy of the EU declaration of conformity is available at the following Internet address:
www.mbconnectline.com
Technical data | Page 5 of 7

2 Router Installation
Installation position/minimum clearances
The router is designed to be mounted on DIN top hat rails (in accordance
with DIN EN 50 022) and for installation in a control cabinet.
The installation and assembly must be carried out according to VDE
0100/IEC 364.
The router may be only mounted vertically as described.
NOTICE
Non-compliance with the minimum distances can destroy the device
at high
ambient temperatures!
Top hat rail mounting
Click the router into the DIN top hat rail. To do this, attach the upper guide to the top hat rail and then press
the router down against the top hat rail until it fully engages.
Page 6 von 7 | MDH800 - MDH859 (from HW 02) - V 6.0 - DE | June 4th, 2019
