McIntosh MVP891 User manual

McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903-2699 Phone: [phone] www.mcintoshlabs.com
MVP891
Audio Video Player
Owner’s Manual

2
The lightning ash with arrowhead, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s en-
closure that may be of sufcient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING - TO REDUCE RISK
OF FIRE OR ELECTRICAL
SHOCK, DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR
MOISTURE.
NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO
QUALIFIED PERSONNEL.
To prevent the risk of electric
shock, do not remove cover or
back. No user-serviceable parts
inside.
CAUTION - Invisible Laser Radiation when open.
DO NOT stare into the beam or view
directly with optical instruments. Use
of controls or adjustments or per-
formance of procedures other than
those specified in the Owners Manual
may result in Hazardous Radiation
Exposure.
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
VAROITUS!
VARNING!
Laitteen kayttaminen muulla kuin
tassa kayttoohjeessa mainitulla
tavalla saattaa altistaa kayttajan
turvallisuusluokan 1 ylittavalle
nakymattomalle lasersateiiylle.
Om apparaten anvands pa annat
satt an i denna bruksanvisning
specificerats, kan anvandaren
utsattas for osynbg laserstrain-
ing, som overskrider gransen for
laserklass 1.
This product incorporates an embedded
CLASS 3R Laser (IEC60825-1).

3
17. The mains plug of the power supply cord shall
remain readily operable.
18. Do not expose batteries to excessive heat such
as sunshine, re or the like.
19. Connect mains power supply cord only to a
mains socket outlet with a protective earthing
connection.
20. Warning: The Ethernet connector of this
equipment must not be directly connected
to a public network. Connection is to be
made only by way of a modem or router ap-
proved for this purpose.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install
in accordance with the manufacturer’s instruc-
tions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other appa-
ratus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polar-
ized or grounding-type plug. A polarized plug
has two blades with one wider than the other.
A grounding type plug has two blades and a
third grounding prong. The wide blade or the
third prong are provided for your safety. If
the provided plug does not t into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11. Only use attachments/accessories specied by
the manufacturer.
12. Use only with the cart, stand,
tripod, bracket, or table speci-
ed by the manufacturer, or sold
with the apparatus. When a cart
is used, use caution when moving the cart/
apparatus combination to avoid injury from
tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualied service person-
nel. Servicing is required when the apparatus
has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
15. Do not expose this equipment to dripping or
splashing and ensure that no objects lled
with liquids, such as vases, are placed on the
equipment.
16. To completely disconnect this equipment from
the a.c. mains, disconnect the power supply
cord plug from the a.c. receptacle.
IMPORTANT SAFETY
INSTRUCTIONS!
PLEASE READ THEM BEFORE
OPERATING THIS EQUIPMENT.

4
Trademark and License Information
Trademark and License Information
The McIntosh MVP891 incorporates copyright protec-
tion technology that is protected by U.S. patents and
other intellectual property rights.
Trademark Logo License Information
Blu-ray Disc and “ ” are trademarks.
“Blu-ray 3D™” and “Blu-ray 3D™” logo are-
trademarks of Blu-ray Disc Association.
is a trademark of the DVD Format /Logo licens-
ing Corporation.
HIGH-DEFINITION MULTIMEDIA INTERFACE TM
HDMI, the HDMI logo and High- Denition
Multimedia Interface are trademarks or regis-
tered trademarks of HDMI Licensing LLC.
Java and all other trademarks and logos are
trademarks or registered trademarks of Sun
Microsystems, Inc. in the United States and/or
other countries.
Manufactured under license from Dolby Labo-
ratories. Dolby, Pro Logic and the double-D
symbol are trademarks of Dolby Laboratories.
Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,226,616;
6,487,535; 7,392,195; 7,272,567; 7,333,929;
7,212,872 & other U.S. and worldwide
patents issued & pending. DTS-HD, the Sym-
bol, & DTS-HD and the Symbol together are
registered trademarks & DTS-HD Master Audio
Essential is a trademark of DTS, Inc.
© DTS, Inc. All Rights Reserved.
Trademark Logo License Information
Windows Media and the Windows logo are
trademarks or registered trademarks of Micro-
soft Corporation in the United States and/or
other countries.
“AVCHD” and “AVCHD” logo is the trademark
of Panasonic Corporation and Sony Corpora-
tion.
“BONUSVIEW” is the trademark of Blu-ray
Disc Association.
“BD-LIVE” logo is trademark of Blu-ray Disc
Association.
DivX®, DivX Certied®, DivX Plus® HD and
associated logos are trademarks of Rovi Cor-
poration or its subsidiaries and are used under
license.
Covered by one or more of the following U.S.
patents:
7,295,673; 7,460,668; 7,515,710; 7,519,274
VIDEOS
YouTube and the YouTube logo are the
registered trademarks of Google Inc.
This item incorporates copy protection technology
that is protected by U.S. patents and other intellectual
property rights of Rovi Corporation. Reverse engi-
neering and disassembly are prohibited.
The MVP891 uses the following Technologies:

5
Table of Contents
Thank You
Your decision to own this McIntosh MVP891 Au-
dio Video Player ranks you at the very top among
discriminating music listeners. You now have “The
Best.” The McIntosh dedication to “Quality,” is assur-
ance that you will receive many years of visual and
musical enjoyment from this unit.
Please take a short time to read the information in
this manual. We want you to be as familiar as pos-
sible with all the features and functions of your new
McIntosh.
Please Take A Moment
The serial number, purchase date and McIntosh Dealer
name are important to you for possible insurance
claim or future service. The spaces below have been
provided for you to record that information:
Serial Number: ______________________________
Purchase Date: ______________________________
Dealer Name: _______________________________
Technical Assistance
If at any time you have questions about your McIntosh
product, contact your McIntosh Dealer who is familiar
with your McIntosh equipment and any other brands
that may be part of your system. If you or your Dealer
wish additional help concerning a suspected problem,
you can receive technical assistance for all McIntosh
products at:
McIntosh Laboratory, Inc.
2 Chambers Street
Binghamton, New York 13903
Phone: [phone]
Fax: [phone]
Customer Service
If it is determined that your McIntosh product is in
need of repair, you can return it to your Dealer. You
can also return it to the McIntosh Laboratory Service
Department. For assistance on factory repair return
procedure, contact the McIntosh Service Department
at:
McIntosh Laboratory, Inc.
2 Chambers Street
Binghamton, New York 13903
Phone: [phone]
Fax: [phone]
Copyright 2012 © by McIntosh Laboratory, Inc.
Safety Instructions.................................................. 2-3
Trademark and License Information ......................... 4
Thank You and Please Take a Moment...................... 5
Technical Assistance and Customer Service ............. 5
Table of Contents ....................................................... 5
General Information .................................................. 6
USB Memory Drive Information............................... 6
Disc Information........................................................ 7
Connector and Cable Information ............................. 7
Introduction................................................................ 8
Performance Features ................................................ 8
Dimensions ................................................................ 9
Installation ................................................................10
Connections:
Rear Panel Connectors..............................................11
Making Connections.................................................12
Remote Control:
Remote Control Push-buttons...................................14
How to Use the Remote Control ...............................15
Front Panel Features:
Front Panel Displays, Push-buttons
and USB Memory Drive...........................................16
Front Panel Information Display...............................17
Setup:
Introduction to the MVP891 Setup Mode............18-19
Default Settings........................................................ 20
System and Language Settings.................................21
Rating, NetworkVideo and Other Settings ............. 22
TV, HDMI and 3D Settings ..................................... 23
Audio and Speaker Settings................................ 24-25
Operation:
How to Operate MVP891 ....................................26 -31
MVP891 Audio/Video Settings
and Adjustments ..................................................32-35
Firmware Update ................................................ 36-37
Additional Information:
Specifications............................................................38
Packing Instruction...................................................39

6
General Information
1. For additional connection information, refer to the
owner’s manual(s) for any component(s) connected
to the MVP891 Audio Video Player.
2. When the MVP891 HDMI Output is connected
to a TV/Monitor there is no signal present at the
Component Video Output Jacks, unless the HDMI
resolution is set to 480i.
3. The Super Audio Compact Discs (SACD) Audio
Signals are converted internally from Digital to
Analog.
4. When the MVP891 is playing back a SACD Disc
the DSD Signal from the disc is converted to a
PCM Signal and is available at the HDMI Out
Connection.
5. A PCM version of the decoded MP3 Signal is
available at the Digital Audio Outputs.
6. The MVP891 has built-in 192kHz 32-Bit DACs
(Digital to Analog Converter) to allow playing of
Discs recorded with a higher bit and sample rate,
by using the Analog Audio Outputs.
7. Some Multichannel BD (Blu-ray), DVD, DVD-
Video, DVD-Audio and Super Audio Compact
Discs might contain Low Frequency Audio Signals
(below 80Hz) in the Center and/or Surround Chan-
nels. If the Loudspeakers in your Sound System
are not capable of reproducing those Low Fre-
quencies, distortion and/or possible damage to the
Loudspeakers may occur. For additional infor-
mation, consult with your Dealer or refer to the
Owner’s Manual for your Loudspeakers.
8. The DVD-Audio and Super Audio Compact Discs
Digital Audio Signal is available via the HDMI
Output. The MVP891 also internally decodes the
Digital Audio from DVD-Audio and Super Audio
Compact Disc and the Eight Channel Analog Sig-
nals are available at the UNBALANCED AUDIO
OUTPUTS (7.1CH).
9. The MVP891 is designed to playback 3D Blu-
ray Discs. The 3D Digital Video Signal from the
MVP891 is available at the HDMI Out connector.
It is extremely important for all A/V Compo-
nents and the HDMI cables used for connections
between the MVP891 and the TV/Monitor, meet
or exceed the HDMI High Speed Standards for
proper 3D Video Playback.
10. HDMI Cable lengths between MVP891 and the
Audio/Video Control Center should not exceed
25ft (8.3meters). If there is need to use HDMI
Cables longer than 25ft (8.3meters), a high quality
in-line HDMI Buffer/Converter would be required
for reliable digital signal transmission via the
HDMI Connections.
11. The MVP891 basic transport functions may also
be controlled by using other McIntosh Remote
Controls or Keypads thru a McIntosh Control
Center or Preamplifier. Refer to the owner’s
manual(s) supplied with those component(s) for
additional operation information.
12. PCM (Pulse Code Modulation) is the name given
to a specific type of Digital Audio Signal. The
CD Audio Disc and the supplemental audio track
found on some Blu-ray Discs use the PCM format.
13. Sound Intensity is measured in units called Deci-
bels and “dB” is the abbreviation.
14. When discarding the unit, comply with local rules
or regulations. Batteries should never be thrown
away or incinerated but disposed of in
accordance with the local regulations
concerning battery disposal.
15. For additional information on the
MVP891 and other McIntosh Products
please visit the McIntosh Web Site at
www.mcintoshlabs.com.
General and USB Memory Drive Information
USB Memory Drive Information
The MVP891 has a Front Panel Slot for accepting
USB Memory Drives only. The USB Memory Drive
is used in BD-Live and Bonus View Mode when the
storage requirements exceeds the internal memory.
The USB Drive provides the memory storage needed
for the additional program content which is down-
loaded from the Movie Studio/Record Company via
the MVP891 internet connection. It may also be used
for playback of Audio and Video Files.
1. Before switching On the MVP891 insert the USB
Memory Drive into the Front Panel Slot.
2. Do not remove the USB Memory Drive until the
MVP891 has been switched Off. Removing the
USB Memory Drive while the MVP891 is On
could result in malfunction or loss of the USB
Memory Drive’s data.
3. USB Memory Drives need to have a storage capac-
ity of 1GB (Gigabit) or greater.
4. Before using the USB Memory Drive for storage in
the MVP891, it first must be formated on a com-
puter using the FAT32 File System.
5. The MVP891 will display Photos using the JPEG
File Format.
6. The MVP891 will playback music files such as
MP3, WMA and AAC.
7. Read and follow all instructions provided by the
USB Memory Drive manufacturer to prevent dam-
age to the Drive and to the files contained on the
Drive.

7
XLR Connectors
Below is the Pin configuration for the XLR Balanced
Output Connectors on the MVP891. Refer to the dia-
gram for connection:
PIN 1: Shield/Ground
PIN 2: + Output
PIN 3: - Output
Power Control Connector
The MVP891 Power Control Input/Output Jacks
receive/send Power On/Off Signals
when connected to other McIntosh
Components. A 1/8 inch stereo mini
phone plug is used for connection to
the Power Control Input/Output on the MVP891.
Data and IR Input Port Connectors
The MVP891 Data In Port receives
Remote Control Signals. A 1/8 inch
stereo mini phone plug is used for
connection. The IR Ports also use a
1/8 inch stereo mini phone plug and
allow the connection of other brand
IR Receivers to the MVP891.
RS232 DB9 Connector Pin Layout
1. N/C 6. N/C
2. Data Out (TXD) 7. N/C
3. Data In (RXD) 8. N/C
4. N/C 9. N/C
5. Gnd.
Connector and Cable Information
PIN 1 PIN 2
PIN 3
Power
Control
Ground
N/C
Data
Signal
N/C
Data
Ground
IR Data
Control
Ground
N/C
1. Compact Discs that are not round (e.g. Novelty
discs with octagonal or heart shapes) will not play
properly in the MVP891 and should not be tried,
as possible damage may occur.
2. The MVP891 Audio Video Player is designed to
play all standard CD Audio Discs that conform
to the Official Compact Disc Standards which is
indicated by the Symbol .
3. The MVP891 will play most of the following
discs, however some recorded discs may not be
able to play due to the condition of the recording:
BD-Video, BD-3D Video, Super Audio CD
(SACD), CD-R, CD-RW, Picture CD (Kodak),
Fujicolor CD, WMA(Windows), DVD-Audio,
DVD-Video, DVD-R, DVD+R, DVD-RW,
DVD+RW, and DVD-AVCHD.
4. CD Audio Discs recorded in the MP3, WMA,
AAC or LPCM Format will playback on the
MVP891 except discs that contain multi-session
recordings.
5. The MVP891 will display Photos in the JPEG File
Format from a Disc.
6. The CD audio side of the Dual Disc does not meet
the Compact Disc Digital Audio specifications
found in the industry “Redbook”; the MVP891
may not read the CD side of a Dual Disc.
7. Several of the DVD, DVD-Audio and SACD
performance features available on the MVP891
are active only if the Disc includes the supporting
encoded information.
8. BD-Video and DVD-Video Discs are designed
to only play in certain region(s) of the world. A
region may be a single country or a group of coun-
tries. Usually on the back cover of the Video Disc
container is a Symbol with either a “Character”
or “Number(s)” or the word “All” inside it. The
Disc Information
Disc Information, Connector and Cable Information
MVP891 is designed to play discs for Regions “A”,
“1” and “All”.
9. Certain Dolby Digital and DTS Encoded Discs
display their own unique Audio Mode Selection
menu, every time the disc is loaded into the player.
If you do not make a choice from this menu, the
disc will revert to its default Audio Mode when
play is started.

8
has Component Video and Composite Video Outputs
for a variety of applications.
•Advanced Video Circuitry
The MVP891 uses the Anchor Bay Technologies VRS
ultra performance ABT-2015 processor. The Analog
Devices 12-bit/297MHz video D/A provides conver-
sion with Noise Shaped Video processing, Digital
Noise Reduction and 14/12Bit Digital to Analog Video
Conversion for High Definition and Standard Defini-
tion Signals.
•32 Bit Audio DAC
The MVP891 has ve two channel Digital to Analog
Converters capable of sampling rates up to 192kHz
with 32 Bits of resolution.
•Balanced Outputs
The MVP891 has Balanced Outputs for the Left and
Right Channels when playing a CD/SACD. When a
Multichannel Disc is playing, the Balanced Left and
Right Outputs provide a two channel mix down of the
Multichannel Recording.
•Built-in Dolby True HD and DTS-DH Master
Decoders
The MVP891 also provides built-in decoding of the
Dolby Pro Logic IIx and DTS Neo6 Sound Tracks.
•Digital Audio Outputs
There is HDMI and Coaxial Digital Audio Outputs for
external decoding of the various Dolby Digital, DTS
Digital Signals, PCM or MP3 Signals from CDs.
•On Screen Setup and Calibration
Loudspeaker Size, Level and Time Delay Adjustments
Introduction
Performance Features
The McIntosh MVP891 Audio Video Player offers the
latest in audio/video technology, providing state of the
art reproduction of digital video and audio program
sources. A full complement of performance features
allows for the enjoyment of 3D Blu-ray, Blu-ray, DVD,
SACD, DVD-Audio and Audio CD discs. Special
Audio and Video formats are also reproduced with
flawless realism. The advanced mechanical design of
the transport ensures many years of smooth trouble
free operation.
•Triple Laser Pickup
The MVP891 incorporates three laser elements, with
different wavelengths, that are focused through one
lens assembly. This unique design allows reading
many different types of Audio and Video Disc For-
mats.
•Advanced Transport
The MVP891 has a new vibration-resistant transport
with an advanced digital servo for faster, quieter
and accurate operation. The Video Disc Data is read
into memory from the disc at twice the normal rate.
Likewise, CD Audio Data is read into memory at
four times the normal rate. The fast read speeds help
to insure better disc tracking and error correction
processing.
•1080p/24frame Video Output
The MVP891 has the highest video resolution avail-
able, 1080p/24frames per second image quality via the
HDMI Video Output.
•Video Outputs
Along with the HDMI Video Output the MVP891 also
are available for Dolby Digital, DTS Digital, DVD-
Audio and SACD Disc Signals and effects the multi-
channel analog audio outputs.
• Power Control
The Power Control Input connection provides conve-
nient Turn-On/Off of the MVP891 when connected to
a McIntosh System with Power Control.
• Remote Control
The Remote Control with illuminated push-buttons,
provides control of the MVP891 operating functions.
A Data Port Connection to a McIntosh A/V Control
Center or Preamplifier allows for convenient system
operation using one Remote Control. An External IR
Sensor Input allows for remote operation when the
MVP891 is located behind closed doors.
• Special Power Supply
A fully regulated Power Supply, with a special R-Core
Power Transformer, ensures stable noise free opera-
tion even though the power line varies.
• Extruded Side Panels
The sides of the MVP891 are extruded aluminum
panels with a bead blast textured surface and a black
anodized finish.
• Fiber Optic Solid State Front Panel Illumination
The Illumination of the Glass Front Panel is accom-
plished by the combination of custom designed Fiber
Optic Light Diffusers and extra long life Light Emit-
ting Diodes (LEDs). This provides even Front Panel
Illumination and is designed to ensure the pristine
beauty of the MVP891 will be retained for many
years.
Introduction and Performance Features

9
Dimensions
The following dimensions can assist in determining
the best location for your MVP891. There is additional
information on the next page pertaining to installing
the MVP891 into cabinets.
Dimensions
17-1/2"
44.45cm
6"
15.24cm
Front View of the MVP891
5-3/8"
13.69cm
4-5/8"
11.75cm
13-1/4"
33.65cm
17"
43.18cm
Rear View of the MVP891
12"
30.5cm
13-3/8"
34cm
3/16"
0.48cm
4-13/16"
12.22cm
9-1/16"
23.3cm
Side View of the MVP891
13/16"
2.06cm
1-5/8"
4.1cm
1-5/16"
3.3cm

10
Installation
Installation
The MVP891 can be placed upright on a table or
shelf, standing on its four feet. It also can be custom
installed in a piece of furniture or cabinet of your
choice. The four feet may be removed from the bottom
of the MVP891 when it is custom installed as out-
lined below. The four feet together with the mounting
screws should be retained for possible future use if the
MVP891 is removed from the custom installation and
used free standing. The required panel cutout, ventila-
tion cutout and unit dimensions are shown.
Always provide adequate ventilation for your
MVP891. Cool operation ensures the longest possible
operating life for any electronic instrument. Do not
install the MVP891 directly above a heat generat-
ing component such as a high powered amplifier. If
all the components are installed in a single cabinet, a
quiet running ventilation fan can be a definite asset in
maintaining all the system components at the coolest
possible operating temperature.
A custom cabinet installation should provide the fol-
lowing minimum spacing dimensions for cool opera-
tion.
Allow at least 6 inches (15.24cm) above the top, 2
inches (5.08cm) below the bottom, 3 inches (7.62cm)
behind the rear panel and 2 inch (5.08cm) on each
side of the Audio Video Player, so that airflow is not
obstructed. Do not block the ventilation holes on the
top and bottom cover; also do not block the rear
panel fan opening. Allow 1 inch (2.54 cm) in front
of the mounting panel for clearance. When the DISC
Tray is opened, the panel clearance required in front
of mounting panel is 6-3/4 inches (17.2cm). Be sure to
cut out a ventilation hole in the mounting shelf ac-
cording to the dimensions in the drawing.
MVP891 Front Panel
Custom Cabinet Cutout
8"
20.3cm
14"
35.56cm
13-1/4"
33.7cm
3/4"
1.9cm
Cutout Opening
for Ventilation
Cutout Opening for Ventilation
Support
Shelf
Cabinet
Front
Panel
Chassis
Spacers
MVP891 Side View
in Custom Cabinet
MVP891 Bottom View
in Custom Cabinet
2-5/8"
6.7cm
7"
17.8cm
3-1/8"
7.9cm
Note: Center the cutout Horizontally on the unit.
For purposes of clarity, the above
illustration is not drawn to scale.
Opening
for Ventilation
6"
15.24cm
10-7/8"
27.62cm
17-1/16"
43.34cm
Cutout Opening for Custom Mounting
Cabinet Front Panel
Opening for Ventilation
Opening for Ventilation

11
Rear Panel Connectors
Connect the
MVP891 power cord
to a live AC outlet.
Refer to information
on the back panel
of your MVP891 to
determine the correct
voltage for your unit
COAXIAL DIGITAL
AUDIO OUTput sends
signals to a Control Center
with a D/A Converter or a
decoder
Y OUTPUT connects to the Y Component Input of
the TV/Monitor or other video component.
PB/CBOUTPUT connects to the PB/CBComponent
Input of the TV/Monitor or other video component.
PR /CROUTPUT connects to the PR /CRComponent
Input of the TV/Monitor or other video component
HDMI OUT supplies digital
video and digital audio sig-
nals to an Input of an A/V
Control Center or other au-
dio/video component
POWER CONTROL IN
receives turn-on signals from
a McIntosh component and
POWER CONTROL OUT
sends turn-on signals on to
another McIntosh Component
IR INput for
connecting an
IR Receiver
DATA IN receives
operating data
from a McIntosh
Control Center
RS-232C connector
for connection to
a remote control
device
VIDEO OUTput supplies
video signals to connect
to a Composite Input of
an A/V Control Center or
other video component
UNBALANCED AUDIO
OUTPUTS supply Seven
Point One Channels of ana-
log audio and connects to
the 7.1 CH Input of an A/V
Control Center
UNBALANCED
AUDIO OUTPUTS
supply Two Channels
of Analog Audio and
connects to the Analog
Input of an A/V Con-
trol Center
BALANCED AUDIO
OUTPUTS supply two
channels of analog audio
to connect to Balanced In-
puts of other components
ETHERNET
Network Connector
for connecting
the MVP891 to a
Broadband Ethernet
Network

12
Making Connections
Making Connections
The MVP891 has the ability to be remotely switched
On/Off from a McIntosh Preamplifier or A/V Con-
trol Center via the Power Control connection. The
MVP891 Data Port Connection allows for the remote
operation of basic functions using the A/V Control
Center Remote Control. With an external sensor con-
nected to the MVP891, remote control operation is
possible from another room and/or when the MVP891
is located in a cabinet with the doors closed.
The connection instructions below, together with
the MVP891 Connection Diagram located on the
separate folded sheet “Mc1A”, is an example of an
audio/video system. Your system may vary from this,
however the actual components would be connected in
a similar manner. For additional information refer to
“Connector and Cable Information” on page 7.
Power Control Connections:
1. Connect a Control Cable from the A/V Control
Center PC (Power Control/Trigger) Jack to the
POWER CONTROL IN Jack on the McIntosh
MVP891 Audio/Video Player.
2. Optionally, connect a Control Cable from the
MVP891 Audio Video Player POWER CONTROL
OUT Jack to the next McIntosh Component Power
Control In Jack.
3. Connect any additional components in a similar
manner, as outlined in step 2.
Data Control Connections:
4. Connect a Control Cable from the A/V Control
Center Data Out 1 Jack to the McIntosh MVP891
Audio Video Player DATA IN Jack.
Sensor Connections:
5. Optionally, connect an external Sensor to the
McIntosh MVP891 Audio Video Player IR IN
Jack.
HDMI Connections:
6. Connect a HDMI Cable from the McIntosh
MVP891 Audio Video Player HDMI OUT to the
HDMI Input 1 BD on the A/V Control Center.
Digital Audio Connections:
7. Connect a Cable from the McIntosh MVP891
Audio Video Player DIGITAL OUT COAXIAL to
the Coaxial In 1 on the A/V Control Center.
Analog Audio Connections:
8. Connect Balanced Cables from the McIntosh
MVP891 Audio Video Player AUDIO OUTPUTS
BALANCED 2CH Connectors to the A/V Control
Center AUX Balanced Input 1 connectors.
9. Connect Audio Cables from the MVP891 Audio
Video Player UNBALANCED AUDIO OUTPUTS
10.1CH (all eight channels) Jacks to the A/V Con-
trol Center 7.1 CH Input Jacks.
10. Connect Cables from the McIntosh MVP891
Audio Video Player AUDIO OUTPUTS UNBAL-
ANCED 2CH Jacks to the A/V Control Center CD
Input Jacks.
Analog Video Connections:
11. Connect Cables from the McIntosh MVP891
Audio/Video Player COMPONENT VIDEO OUT
to the A/V Control Center Component Video In 2
(DVD) Inputs.
12. Connect a Cable from the McIntosh MVP891 Au-
dio Video Player VIDEO OUT to the A/V Control
Center Video In DVD Input.
Ethernet Connection:
13. Connect a CAT5 or CAT6 cable from the MVP891
ETHERNET connector to a Computer Network
with router providing High Speed Broadband In-
ternet Access or directly to a High Speed Modem
with Broadband Internet Access.
Note: For proper operation of the BD-Live feature
a High Speed Internet connection is required.
AC Power Cords Connections:
14. Connect the McIntosh MVP891 Audio Video
Player AC Power Cord to a live AC outlet.

13
Notes

14
HOME
Remote Control Push-Buttons
Note: Push-buttons whose function is not identified above are for use with other McIntosh Components
Use to Clear the last programmed track
Use to access the Setup Menu
Move forward to the next chapter or track, also
use to set the Still Video Image step rate
Return to the previous setup menu screen
Select a different picture Angle
Use to move the on-screen cursor up, down, left, right; also
use to select the highlighted on-screen menu item
Access the on-screen Top Menu from the disc (disc dependent)
To access Track Numbers on CDs and DVD-Audio
Discs greater than 10
Use to set a starting and ending time segment
on a disc for continuous repeat play
Use to access the standard or one of ve preset user dened
video settings
Press for random playback of tracks
from Video and Audio CDs
Use to select one of various repeat modes
Use to select various disc information including time. It is
displayed on-screen and on the Front Panel Alphanumeric
display
Press to select between various on-screen pages
of information on DVD-Audio Discs
Access any numbered operating function
Use to change the brightness of the Front Panel Alphanumeric
Display from bright to off
Use to switch power On to the MVP891
Use to view on-screen the current title, chapter, group or track
number along with direct access to change it using the number
push-buttons
Use to view and/or change the on-screen subtitle language
Use to view or change the current Audio Selection
Access the on-screen Disc Menu from a DVD disc
and the Media Player Edit Menu (“Pop Up” On-Screen
Push-button)
Use to preselect (program) from an audio disc the desired
tracks for playback
Use to review the preselected tracks from the disc on the Front
Panel Alphanumeric display, while in the program mode
Selects the SACD or CD Audio Layer from a hybrid disc
Selects the video signal output at the HDMI Output
Selects the video signal output resolution at the HDMI Output
Use to switch power Off to the MVP891
Move backward to the previous chapter or
track, also use to set the Still Video Image
step rate
Starts Playback of a disc
Moves backward in time through
a chapter or track rapidly
Moves forwards in time through a chapter or track rapidly
Use to quick stop or full stop
Use to pause the disc playback. Also use
to activate the Still Image Video Mode
Use to access menu items on some Blu-Ray Discs
Used to activate an on-screen menu to perform various Audio
and Video functions
Press PAGE (–) to activate
the Home On-Screen Menu

15
How to use the Remote Control
How to use the Remote Control
The Remote Control is capable of performing both
basic Operating Functions and Setup Options for the
MVP891 Audio Video Disc Player.
Notes: Refer to the “How to Operate” and “How to
Operate Setup Mode” Sections of this manual for
additional information using this Remote Control.
Play
With a disc loaded, press the PLAYPush-button to
start the disc playing.
Stop
Press the STOP<Push-button once to stop disc play-
back. Press PLAY and the disc will start playing again
from the disc time where Stop was pressed. Press
STOP<twice for a complete stop and return to the
beginning of a disc.
Numbered Push-buttons
Press 1 through 9 to directly access one of the first
nine Disc Tracks/Chapters using the On-screen Icon.
For track numbers greater than 10, press the +10 Push-
button first and then the required number. For example
to access Disc Track/Chapter 23, press +10 twice and
then 3.
Clear
Press the CLEAR Push-button to erase a selected
track or incorrect setting.
Pause
Press the PAUSE;Push-button to temporarily stop
disc playback at any time. When a DVD is playing,
each additional time the Pause Push-button is pressed,
the player will proceed to the next Still Video Image.
Note: The Still Video Image step rate may be changed by
using the7(Reverse) or8(Fast Forward) Push-
button.
Back and Next
Press the : (Next) Push-button to move forward or
the 9 (Back) Push-button to move backward one
chapter/track at a time on the disc.
Return
Press the RETURN Push-button to return to the previ-
ous setup menu.
Setup
Press the SETUP Push-button to access the Initial
Setup Menu.
Subtitle
Press the SUB (Subtitle) Push-button to access the
Subtitle menu and the Subtitle icon will appear at the
top of the screen.
Angle
If the DVD being played supports the Angle Feature,
press the ANGLE Push-button to select the desired
video picture angle.
Four Direction Arrows
Press an Arrow direction Push-button to move back-
ward, forward, up or down through an on-screen
menu.
Select
Press the SELECT Push-button to confirm and acti-
vate a setup option or options indicated by the on-
screen icons.
Note: The SELECT push-button is also referred to as
“Enter” when working within the Setup Mode.
Top Menu
When a disc is loaded in the player, press the TOP
MENU Push-button to access the main DVD Title
menu (disc dependent).
Display/Time
Press the DISPlay/TIME Push-button to access vari-
ous disc times, text information on SACD/CD and
audio modes displayed on-screen (disc dependent).
Audio
Press the AUDIO Push-button to access various audio
modes displayed on-screen (disc dependent).
REV and FF
Press a7 (Reverse) or8 (Fast Forward) Push-button
to start moving rapidly through a chapter or track on
a disc.
Note: Audio level is automatically muted during this
operating mode with a DVD disc.
A-B Repeat
Press the A-B (Repeat) Push-button once to establish
the starting point of the repeat loop and press the A-B
(Repeat) Push-button a second time for the ending
point, and that segment of a disc will be repeated
continuously.
Search
Press the SEARCH Push-button to activate vari-
ous search functions including Chapter, Title, Track
Group, Time and Marker. For additional information
refer to page 30.

16
Standby Power On
Indicator
IR Sensor receives commands
from a Remote Control
Disc Tray opens to
load and unload a disc
Front Panel Information Display
STANDBY/ON Push-button
switches the MVP891 ON or
OFF (Standby)
Opens and Closes the
disc tray for loading or
unloading a disc
Starts playback
of a disc or USB
Drive Card
Use to Pause during
playback of a disc or
USB Drive playback
Stops disc or
USB drive
playback
Selects the SACD
or CD Audio
Layer from a
hybrid disc
Selects the video
signal output at
the HDMI Output
Move backwards
one track, chapter
or photo at a time
Move forwards
one track, chapter
or photo at a time
Selects the video
signal output
resolution at the
HDMI Output
Selects between Disc and USB
Memory Drive Playback
Socket for connnecting
a USB Memory Drive
Front Panel Displays, Push-buttons and USB Memory Drive

17
Indicates when the
two digits below are
displaying the Track
or Chapter Number
Indicates when
the disc con-
tains multiple
viewing angles
Indicates the type of
media loaded; BD,
USB Memory Drive,
CD, DVD, DVD-Au-
dio, or DVD-Video
Indicates either two
or multi-channel
sound playback
Indicates
when the
Pause
Mode is
active
Indicates
when the
Play Mode
is active
Indicates the current Track
Time, Remaining Track
Time, Total Disc Playing
Time and various other
Information
Indicates Title
Number on the
Disc and the
Group Number
on DVD-Audio
Discs
Indicates Track or
Chapter Number
of the Disc
Indicates the current
Multi-Channel Sound
track is down mixed
and available at the
2CH Outputs as a
stereo audio signal
Indicates the Re-
peat Mode selected;
Repeat All, Repeat
1Track or Repeat
from point A to
point B on the disc
Indicates the Digital
Signal being decoded
is Dolby Digital or
Dolby True HD
Indicates when
the two digits be-
low are display-
ing the Group or
Title Number
Indicates the
programmed
Track/Group
Play Mode is
active
Indicates when the numeric dis-
play is indicating the Total Play-
ing Time of the disc, the current
Track Playing Time or the Re-
maining Playing Time of the disc
Note: Display items not identified above are for use with other McIntosh Components
When the indicator is On (Steady), actual com-
munication is occurring between MVP891 HDMI
Output and the TV/Monitor’s HDMI Input. When
the indicator is just ashing the HDMI Output is
selected with no communication occurring be-
tween components
Front Panel Information Display
Indicates the Digital
Signal being decoded
is DTS, DTS-HD or
DTS-HD Master
Indicates the Audio
Signal is being
processed using Dolby
Pro Logic IIx
Indicates the Digital
Signal being decoded
is MP3, WMA or
AAC
Indicates the Digital
Signal being decoded
is Linear PCM (Pulse
Code Modulation) or
Packed PCM
Indicates the
random Play
Mode is active

18
Your McIntosh MVP891 has been factory config-
ured for default operating settings that will allow you
to immediately enjoy superb video and high fidel-
ity audio from a Blu-ray 3D Disc. It also reproduces
Blu-ray Disc (2D), DVD-Audio, SACDs and CDs with
unparalleled sonic purity. If you wish to make changes
to the factory default settings perform the following
steps, if not proceed to “How to Operate the MVP891”
starting on page 26.
Power
The Red LED above the STANDBY/ON switch lights
to indicate the MVP891 is connected to AC Power.
To Switch ON the MVP891, press the STANDBY/
ON Push-button on the Front Panel or the (Power)
Push-button on the Remote Control. The STANDBY
Red LED will flash during the initialization process.
Refer to figures
1 and 2.
Note: When the MVP891 is switched On, it will take
from 20 to 30 seconds for initialization of
the internal circuitry to take place before the
player is ready to begin operation.
Adjustments and Setting changes
All of the adjustments and settings are performed by
using the extensive On-Screen Menu System. The
On-Screen Menuing System is interactive. The abil-
ity to change a menu item setting or have access to a
menu item setting (some may
be “grayed out”) is dependent
on the operational state of the
player and the choices made in
other menu items. Some menu
choices require more than one
step to complete.
The active selection in a list of
options is indicated by a dot
located to the left side of the
selection, e.g. ●ON. When a
disc is playing in the MVP891
and the STOP Push-button is
pressed once (the disc play-
back is paused), some but not
all menu items are available
for change. To make all of the
menu items available for pos-
sible change, the playback of
the disc must be stopped which
requires two presses of the
STOP Push-button.
Note: The MVP891 must
be connected to
a MONITOR/TV
either through an
A/V Control Center
or directly, for setup
and use. The Remote
Control supplied with the McIntosh MVP891
has several Push-buttons labeled differently
than as indicated on the On Screen Menu,
please refer to the Instructions in this Owner’s
Manual for the correct Push-button.
Checking the Network Connection
The following example will illustrate how to navigate
through the built-in MVP891 SETUP Mode and the
multiple On-Screen Menus.
One of the many features the MVP891 has is the
ability to display On-Screen Videos from "You Tube"
via the Internet Network Connection.
Occasionally, McIntosh might make available
Firmware Updates for the MVP891. These Updates
would be from the McIntosh Computer Server via a
Network Internet Connection. The MVP891 will au-
tomatically scan for an update when first switched On
(with no disc in the tray). If an update is available, the
MVP891 will display a message On-Screen for several
seconds. For more information about the MVP891 and
Network Connections refer to pages 22 and 36.
With the MVP891 connected to your Home
Network via a Network Router with an active Internet
Access Device connected, perform the following
steps:
1. If there is a disc playing in the MVP891 press the
STOP Push-button twice.
2. Press the SETUP Push-button on the Remote
Control and the last selected Setup Menu Item will
appear on the Monitor/TV screen. The figure 3
illustration is of the “General Settings” Menu and
options.
Introduction to the MVP891 Setup Mode
Figure 1
Figure 2
HOME
Figure 3
Select Confirm
ENTER Exit SETUP
System
General Setting
Language
Ratings
Network
Others

19
6. Press the SELECT Push-button on the Remote
Control.
The MVP891 will now check for a Network Con-
nection first. Second, it will check for access to the
Internet. A window will appear On-Screen indicating
“The Network is OK”. Refer to figure 6.
7. Press the SELECT Push-button on the Remote
Control and then press the SETUP Push-button to
exit the Setup Mode and return to normal opera-
tion.
Note: If when the above Connection Test was
performed and the message appearing in the
Window indicated “Network is FAILED”
proceed to Setup Mode, Network Settings on
page 22 to resolve the difficulty.
For the vast majority of MVP891 Owners the Default
Settings and Suggested Component Connections are
all one needs for full enjoyment of movies, still pho-
tos, videos and music.
The MVP891 Setup Mode has a number of ad-
ditional options allowing integration into your Home
Theater System. Usually, your McIntosh Dealer and/or
Custom Installer uses these additional capabilities.
Note: There are four Main Menu Icons located at
the top of the On-Screen Setup Display. The
Icon are , from left to right, General Settings,
Video Settings, Audio Settings and System
Information.
3. Using the DownDirectional Push-buttons on
the Remote Control select “Network”. Refer to
figure 4.
4. Press the SELECT Push-button on the Remote
Control.
5. Using the DownDirectional Push-buttons on the
Remote Control select “Connection Test”. Refer to
figure 5.
Introduction to the MVP891 Setup Mode
Select Confirm
ENTER Exit SETUP
System
General Setting
Language
Ratings
Network
Others
Internet Connecti...
Information
Connection Test
DHCP
BD-Live Connection
Enable
More...
More...
Auto
Permitted
Figure 4
Select Confirm
ENTER Exit SETUP
System
General Setting
Language
Ratings
Network
Others
Internet Connecti...
Information
Connection Test
DHCP
BD-Live Connection
More...
Figure 5
Select Confirm
ENTER Exit SETUP
System
General Setting
Language
Ratings
Network
Others
Internet Connecti...
Information
Connection Test
DHCP
BD-Live Connection
More...
Connection Test
The Network is OK
i
OK
Figure 6
The navigation and selection methods previously
illustrated also apply to the remainder of Setup Mode
Settings, which resume on page 20.
To begin enjoying the MVP891 Audio Video
Player proceed to page 26 and “How to Operate the
MVP891”.

20
Default Settings
MENU SELECTION SETTING PAGE
General Settings
System Setup
Screen Saver On 21
Auto Power Mode On 21
Power Saving Power Saving Standby 21
HDMI Control Off 21
HDMI Power Off Control On 21
Initialize --- 21
Firmware Update --- 21
Update Notification On 21
BD Data Utility --- 21
Language
GUI Language English 21
Disc Menus English 21
Dialog English 21
Subtitle Off 21
Ratings
Change Password 0000 22
BD Rating Level No Limit 22
DVD Rating Level No Limit 22
Country Code USA 22
Network
Internet Connection Enable 22
Information Variou s 22
Connection Test --- 22
DHCP Auto 22
BD-Live Permitted 22
Proxy Setting Disable 22
Others
Close Caption Off 22
Angle Mark Off 22
PIP Mark Off 22
Secondary Audio Mark Off 22
DivX®Registration Registration Code 22
1This mode is activate with a 480i/576i video source
MENU SELECTION SETTING PAGE
Video Settings
TV
TV Aspect (Aspect Ratio) 16:9 Squeeze Auto 23
Wallpaper Picture 23
Progressive Mode1Off 23
HDMI
Color Space YCbCr 23
HDMI Deep Color Auto 23
23
3D
3D Output Setting Auto 23
TV Screen Size Setting 046 23
Audio Setting
Audio Output
Coaxial Bitstream 24
HDMI Bitstream 24
Down Sampling 48kHz 24
DRC Auto 24
Speaker Setting
Configuration 7.1ch 25
Tes t Ton e --- 25
System
Information
MAC Address MAC : __ - __ - __ - __ - _ _ - _ _ ---
