Medco ASPIRATOR IV User manual

Innovators of Lipoplasty
Since 1979
M A N U F A C T U R I N G
ASPIRATOR IV
MANUAL
&
PRIMARY MEDICAL
DEVICE LABEL
Medco Manufacturing
8319 Thora LN, Bldg. A1, Spring, TX 77379
[phone] . [phone] . [phone] Fax
www.MedcoManufacturing.com

*
ASPIRATOR IV
MEDCO
The MEDCO ASPIRATOR IV utilizes two advanced, state of the art
positive displacement pumps. These dual headed pumps relive back
pressure to allow each individual pump to pull against the patient so that a
deep vacuum is quickly reached and maintained. If one pump should go
down, the other three will continue to function independently.
The positive displacement pumps used in MEDCO ASPIRATORS are the
QUIETEST on the market! The Aspirator is made even quieter with 1”
shock mounts to eliminate vibration. This, combined with a super quiet
muffler and insulation system, make the MEDCO ASPIRATOR IV the
QUIETEST Aspirator on the market today!
*
Product# L0020
2000ML Disposable Liner
Box/10
Product# C0001
2000ML Reusable Hard Canister
Each
Product# B1540
Premium Suction Tubing 3/8" x 10' SOFT
Bx/10
Product# F006
Suction Filter
Bx/6
Pneumatic Foot Pedal
One Piece Autoclavable Cannula
Product# Specify Cannula Tip Style,
Diameter (mm), Length (cm)
and Type of Hub
MEDCO ASPIRATORS come with a limited
5 year warranty on all parts and labor
Specifications
Voltage 110V or 220V
Weight 64 pounds
Dimensions 17”x 18”x 18”
Max Vacuum 29+ inches Hg
Max Flow 7. 5= CFM
Sound Level 29+ -3db
Pump 2x2 Piston
Horsepower 2/3 hp
MAINTENANCE FREE, OILLESS
MEDCO MANUFACTURING
8319 THORA LANE , #A1 SPRING, TX 77379 • [phone] • [phone] • [phone] FAX

General Description:
The Medco Aspirator IV is a high powered suction system with two
oil-less piston vacuum motors and four pump heads. The system is
designed to pull a vacuum on any closed container or any open process
system. Vacuum is accomplished by mounting the vacuum pumps
parallel.
When the system is connected, the air flow will be from the tip of the
cannulae through the tubing, collection system, bacterial filter and finally
to the pumps that will evacuate the air from the lines, creating a vacuum
pulling aspirated material in the same direction as the air flow. Aspirated
material continues to the collection system under normal suction until
the cannulae is exposed to air again.
Specifications:
Voltage: 110V or 220V
Weight: 64 lbs.
Dimensions: 17” x 18” x 18”
Maximum Vacuum: 29+ inches of Hg
Maximum Flow Rate: 7.5 cfm
Overflow Protection: In-line Filter
Sound Level: 29 +/- 3db
Pump Type: 2 piston motors and 4 pump heads
Number of pumps: 4
Horsepower: 2/3 hp
PAGE 1
M A N U F A C T U R I N G

Check List:
Carefully unpack the Aspirator IV. Check that the following accessories
are included in the package and were received in good condition.
-Aspirator IV
-Canister Holder
-Vacuum Gauge
-Power Cord
-Foot Switch
*Sterile, Disposable Tubing – Product #1540 (Box/10pcs)
*Bacterial Filter -- Product #F006 (Box/10pcs)
*Permanent Canister – Product #C0001 (Each)
*Disposable Canister Liner – Product #L0020 (Box/10pcs)
User’s Manual
*À la carte item(s) – NOT INCLUDED AS AN ACCESSORY. Listed for
disposable(s) reorder reference.
Call Customer Service Immediately to report any damaged or
missing items: 800.953.2555.
Component Description:
Vacuum Pumps
The Aspirator IV uses two (2) 1/3 hp piston pumps
-Oil-less, non-lubricated piston and cylinder.
-Permanently lubricated ball bearings
-Stainless steel valves
-Lightweight aluminum components
-Long-life, high performance piston seals
-Twin-fan cooling system
-UL recognized motors
-Thermal protected
PAGE 2

-Balanced for low vibration operation
-Capacitor
Circuit Breaker:
To protect the equipment and reduce shock hazard, a re-settable circuit
breaker is installed on the right-side, near the power cord outlet. If there
is a voltage surge or the pump motor overheats, the circuit breaker will
pop out. To reset, turn the Aspirator IV off, push in the circuit breaker,
and turn the Aspirator IV on. If the unit fails to start, the Aspirator IV may
require a cool-down period or technical repairs.
Note: DO NOT LET TECHNICIANS BY-PASS THE CIRCUIT BREAKER!!
Control Valves:
Vacuum Control
Operate Vacuum Control by turning pointer between High and Low
(pressure is reduced). The vacuum gauge in the panel will indicate a
pressure change.
Note: The Aspirator IV system has been calibrated at 160 feet above sea
level to 29+ in Hg. For each additional increase of 1,000’, the vacuum
should drop by 1” Hg. And conversely, for each additional decrease of
1,000’, the vacuum should increase 1” Hg.
Foot Switch:
OPERATION WITH FOOT SWITCH
Plug the foot switch cord into the unit. Turn the Foot Switch and Power
switches to the ON position, press the pedal and the Aspirator IV will start.
Press the pedal again to stop the power of the unit.
Overflow Bacterial Filter: Product #F006
The Overflow Filter is designed to catch aspirated material which has
by-passed, or overflowed, from the main collection canister.
PAGE 3
