Medeli MZ528 User manual

Assemble the Drum Stand
Check the included items
Attach the Pad, Hi-hat and Cymbal Holders
CYMBAL PAD DRUM PAD
KICK PAD KICK PEDAL MODULE
DRUM STAND
RideCrashHi-hat
Kick Pad BeaterKick Pedal
ACCESSORIES
Tom 1 / Tom 2 / Tom 3
( x 3 )
Pillar
[ A ]
Pillar
[ B ]
立管
Center Pipe [ E ]
Pillar
[ A ]
Pillar
[ B ]
Pillar
[ C ]
Pillar
[ D ]
Center Pipe [ F ]
Cymbal Holder x 2
Hi-hat Holder
Side Pipe [ I ]
Side Pipe [ H ]
Side Pipe [ G ]
Center Pipe [ E ]
Center Pipe [ G ]
Hand Bolt
DrumsticksL-Rod Holder
Cable Clip
Drum Key
AC Adaptor
Setup Guide
( This document )
Owner’s
Manual
Snare
Connection Cable
Drum Module
PEDAL
Pedal ( Hi-hat )
Pillar
[ C ]
Pillar
[ D ]
Side Pipe [ I ]
Side Pipe [ H ]
Side Pipe [ F ]
Cymbal Holder Cymbal Holder
Hi-hat Holder
L-Rod Holder
Step Step
Setup Guide
WARNING:
• Drum key may pinch your fingers. Be careful when adjusting clamps with drum key.
• Mind the sharp ends, such as pipe ends and screw ends. They may injure your fingers.

Attach the Kick PadAttach the Module
Attach the Cymbal PadAttach the Drum Pad
Connect the Pads to the Module with labelled cables.
Ride
Crash
Hi-hat
Snare
Module
Kick Pad
Tom 3
Tom 1 / Tom 2
Pedal (Hi-hat)
Hand Bolt
Connection Cable
Kick Pad
Beater
Kick Pedal
MZ528_SG01EN
Connect the Pads
Please adjust the head tension before you start to perform. By adjusting
the head tension, you can make the pad respond to your strikes, just like
playing an acoustic drum.
1. Follow the order indicated in the image. Turn each tension bolt around
the head little by little.
2. Adjust the tightness of each bolt so as to make the pad tension even.
Notes:
1. Always adjust each tension bolt little by little. Turning the bolts too much at one step may result in uneven head tension.
2. The head tension may change after using for some time. Please adjust the head tension whenever it is necessary.
Adjust the Head Tension
StepStep
Step Step
Crash
Hi-hat
Snare
Module
Kick
Ride
Tom 1 Tom 2
Tom 3
Hi-hat Control
