MediaWalker 948 User manual

MediaWalker 948
Quick Guide
20150215

1
Connecting Products:
1. Plug in the Power:
Use micro USB power cable to connect the +5V/1A adapter to MediaWalker 48 and
turn the power on.
2. Connect to S eaker and/or Am lify:
Use either 3.5mm stereo audio cable or SPDIF fiber optical cable to connect the
MediaWalker 48 with Speakers and/or Amplify.
3. Connect the u -link network:
You can use either wired Ethernet cable or Wireless WiFi to connect the up-link
network (WAN).
Default status to connect up-link (WAN) using the wired Ethernet port.
User can change the configuration of setup to use wireless WiFi to connect up-link
(WAN).
4. Storage:
Insert the SD card and/or the USB disk to perform the storage function of
MediaWalker. It will allow user to play music from the storage and share the content
through the FTP Server.


 . USB power adapter is not included in this package, you can use adapter form other smart devices.
Download APP:
Download and install MediaWalker apk form Google
Play or App store.
Scan QR code to download and install MediaWalker
apk.
Start the MediaWalker App after installed.

2
Play Music:
1. Connect the Power with MediaWalker 48 and switch
the power on.
Wait till both “PWR R” and “RDY G” LEDs light turn to
orange which indicate the system is ready to work.
2. Turn on your device such as iPhone, iPad, Android phone
and/or computer.
Turn on the WiFi setting on your device and search for
the AP with SSID name: “mw 48X_XXXXXX”. Default
password is “12345678”.
It will show the AP connected if the connection is
successful.
If neither can’t find the SSID of the MediaWalker 48 nor
can’t match the password, please press 5 seconds on the “RESET” button to
re-start the MediaWalker 48 to default setting.
3. Play the music wirelessly:
a. Use iPhone and iPad:
Start the music player of iPhone and iPad and slide the touch screen from
bottom to activate the Airplay.
Choose the mw 48X_XXXX device to start the WiFi Airplay music.
b. Windows / Mac User:
Install iTune to the Mac/PC from internet first.
Start the iTunes application and click on the middle of top command bar to
activate the Airplay.
Choose the mw 48X_XXXX device to start the WiFi Airplay music.

3
WiFi Setu :
Click the slide command tag at the upper left
corner and choose the Setup to start.
Choose WiFi for configuration setup of
MediaWalker 48.
Default login Name: admin
Default login Password: admin
Go to configuration page after successful login.
WAN Type: Select WIFI.
WAN IP Mode: Select DHCP.
Remote AP SSID: Click on the small triangle behind, select the
remote Router/AP from available list then connect.
WPA Passphrase: Enter the password then press “SUBMIT”.
Submit
Any changes made needs to press the “SUBMIT” button to
keep the changes. The changed parameter will take effect after system restart. Wait
until LEDs “PWR” turn to orange which indicate the system is ready, use your device
to re-connect WiFi and MediaWalker 48 to finish the setup.
