Medify Air MA-112-PRO Instruction Manual

MA-112-PRO
AIRPURIFIER
MA-112-PRO
Rev: 08/24/23
READ AND SAVE THESE INSTRUCTIONS
INSTRUCTION MANUAL AND WARRANTY INFORMATION
Lifetime warranty if replacing filters on time

2
IMPORTANT SAFETY INSTRUCTIONS:
WHEN USING ELECTRICAL PRODUCTS, ESPECIALLY WHEN CHILDREN ARE PRESENT, BASICSAFETY PRECAUTIONS
SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:
IF THE POWER CORD OR UNIT DOES NOT WORK, CONTACT MEDIFY CUSTOMER SERVICE IMMEDIATELY.
READ ALL INSTRUCTIONS BEFORE USING.
DANGER – TO REDUCE THE RISK OF ELECTRICAL SHOCK:
• Always unplug the airpurifier from the electrical outletimmediatelyafter using itand before cleaning or
replacing filters.
• Keep the cord away from heated surfaces.
• Always place the airpurifieron a firm, leveled surface.
• Always place the airpurifieratleast6 inches away from walls and 3 feet from heat sources such as stoves,
radiators, orheaters.
• DO NOT reach for an appliance thathas fallen into water. Unplug itimmediately.
• DO NOT place orstore appliance where itcan fall orbe pulled into a tub orsink.
• DO NOT place in ordrop into water orotherliquid.
• Keep dry — DO NOT operate in wet ormoistconditions.
• Check yourairpurifiercord and plug connections. Faulty wall outletconnections or loose plugs can cause
the outletorplug to overheat. Be sure the plug fits tightly in the outlet.
NOTE: This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of shock,
this plug is intended to fit only one way in a polarized outlet. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician.
DO NOT attemptto defeat this safety feature. To do so could result in an electrical shock hazard.
WARNING – TO REDUCE INJURY TO PERSONS:
• Always unplug the airpurifier when notin use.
• Do notoperate the airpurifier with a damaged cord orplug, orafter the airpurifiermalfunctions, or
has been dropped ordamaged in anymanner. Contact www.medifyair.com for examination, electrical or
mechanical adjustment, or repair.
• Prohibited use beyond power. Can onlyuse a 220v unit with a 220v power supply. Can only use a 110v
unit with a 110v power supply. You can break or ruin the circuitboards if you plug a 110v plug into a 220v
power supply.
• This air purifieris notintended for use in bathroom, laundry areas, and similarmoistindoor locations.
• Do notrun the cord undercarpeting. Do notcover the cord with throw rugs, runners, or similar coverings.

Noise Levels
Model No. Noise level for
speed 1 (dB)
Noise level for
speed 2 (dB)
Noise level for
speed 3 (dB)
Noise level for
speed 4 (dB)
MA-112-PRO 33.1 dB 35.4 dB 46.6 dB 62.0 dB
3
• Do notroute cord under furniture orappliances. Arrange the cord away from traffic areas where it can be
tripped over.
• To disconnect the airpurifier, first turn controls to the off position, then remove the plug from outlet.
• Do nottiltormove the airpurifier while itis in operation. Shutitoff and remove the plug from the outlet
before moving it.
• Do notinsertorallow foreign objects to enter anyventilation orexhaustopening as this may cause an
electrical shock orfire, ordamage the airpurifier.
• Do notblock airintakes orexhaustin anymanner. Do notuse on anysoft surface, like a bed, where
openings maybecome blocked.
• Use this air purifieronly for its intended use as described in this manual. Anyotheruse not recommended
by the manufacturer maycause fire, electrical shock, orinjury to persons.
• DO NOT use outdoors.
• WARNING : To Reduce The Risk Of Fire, Electric Shock Or Injury To Persons, Do Not Use Replacement Parts
That Have Not Been Recommended By The Manufacturer (e.g. Parts Made At Home Using A 3D Printer).
• WARNING : To Reduce The Risk Of Fire Or Electric Shock, Do Not Use This Fan With Any Solid-State Speed
Control Device.
• Appliance is used on the oor.
SAVE THESE IMPORTANT INSTRUCTIONS FOR EASY REFERENCE.
UNIQUE FEATURES & SPECIFICATIONS
GENUINE MEDIFY TRUE HEPA H13 FILTRATION SYSTEM
•TRUE HEPA H13 FILTRATION
Removes 99.9% of airborne particles as small as 0.1 microns, such as allergens, pollen, dust, pet
dander, odor, mold spores, and smoke from the air that passes through the filter.
•CARBON ODOR FILTRATION
Reduces household odors and VOCs (volatile organic compounds)/gases as shown by independent
laboratory testing.
• PRE-FILTER
Captures large particles.
4 SPEEDS
1, 2, 3 and 4 speeds.
BUILT-IN TIMER
Choose from 2, 4, 8 or 12 hours.
REPLACE FILTER INDICATOR
Illuminates when it is time to replace the filter.

4
SUGGESTED ROOM SIZE
Up to 1102 sf every 15 min and up to 2205 sf every 30 min. Portable air purifiers will be more effective in
rooms where all the doors and windows are closed.
AIR CHANGES PER HOUR
This air purifier will purify the air up to 1102 sf every 15 min and up to 2205 sf every 30 min (assuming an 8
FT/2.43 M ceiling) on high speed in a closed room.
EPA Est. No.:88959-CHN-1
GRILLE COVER
GRILLE COVER
TRUE H13 HEPA / CARBON FILTER
TRUE H13 HEPA / CARBON FILTER
CONTROL PANEL

5
FILTER PURIFICATION
1. TRUE HEPA H13 FILTER
The high-efficiency H13 TRUE HEPA filter is tested to remove 99.9% of particles down to 0.1 microns.
This higher grade of HEPA filter catches pollen, dust mites, and other tiny airborne particles you can’t
see.
ACTIVATED CARBON FILTER
Substantial carbon filter with carbon pellets remove odors and smoke.
To purchase genuine Medify replacement filters, visit www.medifyair.com.
¹
²
TRUE HEPA H13 FILTER
catches 99.9% of particles to
0.1 microns including pet dander
and pollen
ACTIVATED CARBON FILTER
absorbs odors
2.

6
HOW TO USE
BEFORE TURNING THE UNIT ON
• Take the air purifier out of the box.
• Place the air purifier on a firm, level surface.
• Plug the power cord into a standard AC outlet.
POWER BUTTON AND FAN SPEED SETTINGS
• To turn the air purifier on, press the power button.
• This air purifier has 4 fan speed settings: 1, 2, 3 and 4. The higher the fan speed setting, the faster
the air will be purified. To select or change fan speed, press the fan speed button until the desired
setting is reached.
TIMER
Press the timerbutton until the desired timersetting is liton the display. The timerbutton will cycle
through the following settings: 2 hours, 4 hours, 8 hours, 12 hours and off. To cancel the timeratany time, press
the timerbutton until all timerLEDs are off. The airpurifier will run continuously when the timer function is off.
DIMMER
Press the dimmer button to change the backlight to desired brightness, there are 4 brightness levels to
change for all buttons' backlight LEDs. The dimmer button backlight will turn off for 1 second when the
dimmer button has been pressed.
CHILD-LOCK BUTTON
Press the child-lock button and hold it down for 3 seconds and all functional buttons will be locked.
Press and hold down again the child-lock button for 3 seconds and all functional buttons will be unlocked.
CONTROL PANEL

7
FILTER REPLACEMENT
REPLACE FILTER LIGHT
The replace filter light illuminates when it is time to replace the True HEPA H13 filter based on the air
purifier’s hours of use.
REPLACING THE TRUE HEPA H13 FILTER
For optimal performance, replace every 2,500 hours under normal usage conditions. Once the filter has been
replaced, press and hold the dimmer button for 3 seconds to reset the indicator.
1. Unplug the air purifier. Open the filter grille covers on
the left and right of the unit by pushing the lock tabs on
the top of the covers.
2. Remove the grille covers from the unit.
3. Pull the tabs to remove the old filter.
To purchase genuine Medify replacement True HEPA H13 filters, for model MA-112-PRO visit www.medifyair.com.

8
To purchase genuine Medify replacement filters, visit www.medifyair.com.
4. Install a new genuine Medify replacement filter with the
filter tabs facing out.
5. Align the tabs at the bottom of the grille covers with the
unit. Gently push the grille covers until they snap back
into place.
6. Plug the power cord into a standard AC outlet. Press and
hold the dimmer button for 3 seconds to reset the
indicator.

9
CLEANING AND MAINTENANCE
CLEANING THE PRE-FILTER
NOTE: For the best performance, vacuum the pre-filter once a month under normal usage.
1. Unplug the air purifier.
2. Remove the True HEPA H13 filter as described in the Replacing
the True HEPA H13 Filter section.
3. Place the True HEPA H13 filter back into the air purifier and
close the grille.
4. Plug the power cord into a standard AC outlet.
FOR THE BEST PERFORMANCE
• NEVER use water or any household cleaners or detergents to clean the True HEPA H13 filter.
• Clean off the outside of the unit with a dry cloth as needed.
• NEVER use water, wax, polish, or any chemical solution to clean the outside of the unit.
• Clean off the grille cover using a damp cloth or the brush attachment of your vacuum as needed.
• Vacuum the pre-filter monthly under normal usage conditions.
• Replace the True HEPA H13 filter every 2,500 hours under normal usage conditions.
• Always use a genuine Medify replacement filter for optimal performance.

10
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
Unit will not operate
Unit is not plugged in Plug the unit in
Power button not pressed Press the power button to turn the
power on
No power to unit Check circuits, fuses, try a
different outlet
Reduced airflow
The back grille maybe blockedMake sure side intakes are not
blocked or the front outflow area
The filter needs to be replaced Replace the filter
Reduced odor removal The filter needs to be replaced Replace the filter
Excessive noise The unit is not level Place the unit on a flat and level
surface
Replace filter light remains lit
after filter replacement
The replace filter indicator needs
to be reset
Press and hold the DIMMER button
for 3 seconds until the replace
filter light turns off
This product earned the ENERGY STAR by meeting strict energy efficiency guidelines set by the US EPA.
US EPA does not endorse any manufacturer claims of healthier indoor air from the use of this product.
The energy efficiency of this ENERGY STAR qualified model is measured based on a ratio between the
model’s CADR for dust and the electrical energy it consumes, or CADR/Watt.

WARRANTY INFORMATION
If you have anyadditional questions, please contactcustomerservice. All names and trademarks are property
of MedifyAir. Ourcompany reserves the right to change the productatany time, withoutpriornotice, and the
company has no obligation to adjustanyproducts supplied earlier. Please refer to the detailed warranty terms
below. To register for the lifetime warranty, please fill out the attached form and mail it to:
Or complete the lifetime warranty registration available on our website (preferred method):
www.medifyair.com
LIFETIME WARRANTY
Medify guarantees your Medify AirPurifier to be free ofdefects in material or workmanship for a lifetime period,
provided you have completed and returned your warranty registration to Medify Air within the first 30 days of
purchase, and that the filters are replaced with original and genuine Medify Air replacement filters at least
once every three to four (3-4) months orafter 2,500 hours ofuse. Within the first 30 days, Medify Air will replace
the defective unitatno charge to you and reimburse you for anyshipping charges. After 30 days, Medify Air’s
obligation and liability under this Lifetime Warranty is dependenton youruse ofourgenuine filters, purchased
on ourwebsite or from ourauthorized resellers, which can be found on our website. Prohibited use beyond
power. Can onlyuse a 220v unit with a 220v power supply. Can onlyuse a 110v unitwith a 110v power supply.
You can break or ruin the circuitboards if you plug a 110v plug into a 220v power supply.
Our Lifetime Warranty remains in effect as long as:
1. You submit your warranty registration to Medify Air within 30 days of purchase.
2. You change filters with genuine and original Medify Air replacement filters at least once every three to four
(3-4) months or after 2,500 hours of use (whichever comes first).
3. You use a proper power supply based on voltage: 110-120V.
4. There is no evidence of tampering, mishandling, neglect, accidental damage, modification, and/or repair
done to the Medify Air purifier by anyone other than authorized Medify Air service personnel.
5. Your air purifieris operated in accordance with the provided instructions.
This Lifetime Warranty is provided by:
Medify Air
150 E Palmetto Park Road Suite 301
Boca Raton, FL 33432
www.medifyair.com
[e-mail]
[phone]
Please visit our website for
details on efficacy test data:
medifyair.com/pages/reports
Medify Air
150 E Palmetto Park Road Suite 301
Boca Raton, FL 33432
