Sanuvox S300 User manual

S300 VOC FOR SMOKING ROOM
INSTALLER INSTRUCTIONS
For a 2400 cubic feet maximum smoking room
Box contains:
• One (1) S300 VOC unit that includes:
o One (1) ‘’J’’ lamp UVC/UVV with yellow tips (part LMPHGXJ105-1 2’’ exposé)
o One (1) ‘’J’’ lamp all UVV with blue tips (part LMPHXJ105)
o Two (2) Multi voltage ballasts (part BST120/277GL) and 2 lamp-holding brackets
o One (1) Relay (part MSCELC16) connected to the all UVV lamp
o Twenty (20) feet of wire that can be inserted in BX shield.
o One (1) VOC controller (part MSC1A) factory’s pre-set
• Two (2) replacement pre-filters (part MSCFTR10)
LAMP INSTALLATION
1. Remove the 6 screws on the front cover (The one with
the SANUVOX logo). Put aside.
2. Remove the BLUE END CAP lamp from packaging. Use
the gloves provided.
3. Insert the lamp in the second clamp and tighten.
(furthest clamp from opening)
4. Holding the cap with one hand, plug the white
connector tightly on the lamp
5. Remove the YELLOW END CAP lamp from packaging.
Use the gloves provided.
6. Insert the lamp in the first clamp and tighten. (closest to
opening)
7. Holding the cap with one hand, plug the white
connector tightly on the lamp
8. Put the cover back on with the 6 screws
Controller
Casing
Wiring 20’
Relay

GENERAL INSTALLATION
Unit could be
• Suspended from ceiling with
angles and suspension rods (not
included).
• Hung on wall with supplied angle
iron (included).
Using 8’’ collars, attach rigid or flex duct to the return side of
the unit above the area where smoke accumulates in order to
remove as much smoke as possible. Attach duct (metal or flex)
to the supply side of the unit to discharge clean air over door
or entryway. This is done to prevent odors from escaping the
room. It is through recirculation that the odors will be
removed. If the room is longer , you may use multiple inlets
to pull the smoke to the unit.
The VOC controller should be installed on the wall, at 12 inches from the ceiling where the smoke
accumulates. The S300 VOC unit comes with 20ft of wire to link the controller box to the unit. If 20 ft
not long enough, you can replace it with BX wiring with 3 wires.
WORKING INSTRUCTION
The VOC controller analyzes the air every 90 seconds. A 20-foot power cord connects it via a relay to
the device to activate the second oxidizing lamp on demand.
The S300 unit runs continuously, so its regular lamp purifies the air constantly. This dual zone lamp
(UVC / UVV) is enough when there are only one or two smokers.
However, when the cigarette smoke increases in the room, the VOC controller that samples the air
at regular intervals, then triggers the 2nd UVV lamp for periods of 90 seconds. This cycle is repeated
if the controller detects smoke in the room: it then turns off the 2nd lamp, leaving the 1st lamp to
continue the cleaning cycle.
SIMPLIFIED PROCESS:
• Ashes in the “white” smoke will be trapped onto the filter
• Nicotine molecules will be dried by the UVC rays than trapped in the filters without the tar like
material that coats everything.
• VOC will be oxidised by the UVV, reducing substantially their olfactory perception.
Suggested installation

VOC CONTROLLER
Remove the cover.
Connect the 3 wires from the controller to the same color
wiring coming from the unit. Use the wire connectors
included.
The detector is factory set a t 3.0 V DC; If you wish to set up a
higher sensitivity, please proceed as follow.
SETTING (if necessary)
You will need a voltmeter with alligator type probes.
Place the probes one on the positive terminal, the other on
the neutral terminal.
Use a small screwdriver to turn the adjustment screw to increase the sensitivity of the controller.
The default setting is 3.0 v dc. The closer your setting is to 3.0 vdc, the faster the triggering of the lamp
will be.
CHECKING IF IT WORKS
1. Start the unit: inside the polycarbonate box, the GREEN LED flashes. It will take some time, so
the electronic board initializes itself.
2. After 5 minutes, the GREEN LED will turn solid. Blow some cigarette smoke into the controller. If
the other RED LED lights up, the relay triggers on the oxidizing lamp (all UVV). This sequence
reproduce itself every minute or so. When there is no more smoke (VOC), the RED LED is turned
off at the same time as the lamp.
MAINTENANCE INSTRUCTIONS
• MONTHLY: Change the pre-filter that protects the motor (part # MSCFTR10) to ensure the
optimal performance of the unit. Check the lamps: if there is a cloudy residue please clean then
off with denatured alcohol.
• YEARLY: Change lamps (parts -see below) to maintain performance: make sure to put the same
lamp in the same clamp. Do not interchange the lamps as the blue end cap lamp works only with
the VOC controller.
o LMPHGXJ105-1 lamp UVC/UVV 2’’ exposed (yellow end cap)
o LMPHXJ105 lamp all UVV (blue end cap)
• 3-5 years: Change VOC controller board
setting screw:
triggers at
3.0 V DC
Positive
Neutral
Sensor

S300 VOC FOR SMOKING ROOM
USER INSTRUCTIONS
MAINTENANCE
• MONTLY:
o Check filter: if filters are dirty, change them (part # MSCFTR10). This will help lower air
restrictions so to keep up the performance of the unit.
o Check if the lamps are covered with dust; in that case, clean them with denatured
alcohol and a clean cloth.
• ANNUALLY:
o Change lamps (parts -see below) to maintain performance: make sure to put the same
lamp in the same clamp. Do not interchange lamps as the blue end cap lamp works only
with the VOC controller.
§ LMPHGXJ105-1 lamp UVC/UVV 2’’ exposed (yellow end cap)
§ LMPHXJ105 lamp all UVV (blue end cap)
• 3-5 years: Change VOC controller board
WORKING INSTRUCTIONS
• The VOC controller analyzes the air every 90 seconds. A 20-foot power cord connects it via a
relay to the device to activate the second oxidizing lamp on demand.
• The S300 VOC unit runs continuously, so its regular lamp purifies the air constantly. This
dual zone lamp (UVC / UVV) is enough when there are only one or two smokers.
• However, if there is much smoke in the room, the VOC controller, that samples the air on a
regular basis, will then trigger the second all UVV lamp for a period of 90 seconds. This cycle
will repeat itself until there is no more smoke in the room: the second lamp will then shut
off, leaving the first lamp on doing the work
SIMPLIFIED PROCESS:
• Ashes in the “white” smoke will be trapped onto the filter
• Nicotine molecules will be dried by the UVC rays than trapped in the filters without the tar like
material that coats everything.
• VOC will be oxidised by the UVV, reducing substantially their olfactory perception.
It is very important that the fan processes the air rapidly.
Changing the filters regularly is a must.
