Medion AKOYA E6232 User manual

N26968
MSN 4004 4819
15.6" Notebook
MEDION®AKOYA E6232 (MD 99222)
Instruction Manual
04/2013
MEDION Australia Pty Ltd
St Leonards, NSW 2065
Australia
Hotline: [phone]
Opening hours: Mon - Fri 08:30AM to 06:00PM EST
Internet
www.medion.com.au
E-mail Support
[email protected]
99222 E6232 Aldi AUS RC1 Cover.indd 199222 E6232 Aldi AUS RC1 Cover.indd 1 04.02.2013 09:59:0204.02.2013 09:59:02

Notebook Front View
Front View Closed Position Right-Hand Side
Left-Hand Side
Descriptions
1
2
345
6
7
8
910 11 12 13 14 14a
18 19 20 21 22 23 24
15 16 17
* See the instruction manual for more information
** Ports with dual function. Conguration is set with the
included software.
1 TFT Display
2 Keyboard
3 Device Indicators
4 Integrated Touchpad Buttons
5 Touchpad
6 Palmrest
7 Webcam
8 Microphone
9 Kensington®Lock
10 Power Socket
11 External monitor port VGA
12 LAN Port (RJ-45)
13 HDMI Connector
14 USB Port 3.0
14a USB Port 3.0 with charging function for mobile
phones*
15 Loudspeaker
16 Multimedia Card Reader
17 Loudspeaker
18 Microphone**
19 Audio Out**/Digital Audio Out (S/P-DIF, optical)
20 USB Port 2.0
21 Optical Drive
22 Disc Eject Button
23 Emergency Ejection
24 Power ON/OFF
C
M
Y
CM
MY
CY
CMY
K
99222 E6232 Final MSN 4004 4819 Cover inside.ai 1 29.01.2013 09:29:5999222 E6232 Final MSN 4004 4819 Cover inside.ai 1 29.01.2013 09:29:59

Notebook Front View
Front View Closed Position Right-Hand Side
Left-Hand Side
Descriptions
1
2
345
6
7
8
910 11 12 13 14 14a
18 19 20 21 22 23 24
15 16 17
* See the instruction manual for more information
** Ports with dual function. Conguration is set with the
included software.
1 TFT Display
2 Keyboard
3 Device Indicators
4 Integrated Touchpad Buttons
5 Touchpad
6 Palmrest
7 Webcam
8 Microphone
9 Kensington®Lock
10 Power Socket
11 External monitor port VGA
12 LAN Port (RJ-45)
13 HDMI Connector
14 USB Port 3.0
14a USB Port 3.0 with charging function for mobile
phones*
15 Loudspeaker
16 Multimedia Card Reader
17 Loudspeaker
18 Microphone**
19 Audio Out**/Digital Audio Out (S/P-DIF, optical)
20 USB Port 2.0
21 Optical Drive
22 Disc Eject Button
23 Emergency Ejection
24 Power ON/OFF
C
M
Y
CM
MY
CY
CMY
K
99222 E6232 Final MSN 4004 4819 Cover inside.ai 1 29.01.2013 09:29:5999222 E6232 Final MSN 4004 4819 Cover inside.ai 1 29.01.2013 09:29:59

1 of 78
Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
Table of Contents
1. About these Instructions............................................................................. 6
1.1. Symbols and Keywords used in these Instructions.................................... 6
1.2. Proper Use ................................................................................................................. 7
1.3. Declaration of Conformity................................................................................... 7
2. Safety Instructions....................................................................................... 8
2.1. Disclaimer - Children and Persons with Reduced Abilities......................8
2.2. Operational Safety.................................................................................................. 8
2.3. Do Not Repair Yourself .......................................................................................10
2.4. Data Backup............................................................................................................10
2.5. Setup Location.......................................................................................................10
2.6. Environmental Requirements ..........................................................................11
2.7. Ergonomics .............................................................................................................12
2.8. Connecting..............................................................................................................12
2.9. Cabling......................................................................................................................13
2.10. How to Operate the Touchpad.........................................................................14
2.11. Battery Mode..........................................................................................................14
3. Included with your Notebook................................................................... 15
4. Notebook Details....................................................................................... 16
4.1. Notebook Front View...........................................................................................16
4.2. Left-Hand Side .......................................................................................................17
4.3. Front View Closed Position................................................................................17
4.4. Right-Hand Side ....................................................................................................18
4.5. Operating and Status LEDs................................................................................19
5. Preparation for Starting-Up...................................................................... 20
6. Power Supply ............................................................................................. 21
6.1. On/Off Switch.........................................................................................................21
6.2. Mains Power ...........................................................................................................22
6.3. Battery Mode..........................................................................................................24
6.4. Power Management (Power Options)...........................................................27
7. Display ........................................................................................................ 27
7.1. Opening and Closing the Display...................................................................27
7.2. Screen Resolution.................................................................................................27
7.3. Appearance and Customisation......................................................................28
7.4. Connecting an External Monitor.....................................................................29
8. Data Input................................................................................................... 30
8.1. The Keyboard .........................................................................................................30
9. The Touchpad............................................................................................. 32
99222 E6232 Aldi AUS RC2 Content.indd 199222 E6232 Aldi AUS RC2 Content.indd 1 29.01.2013 09:26:1829.01.2013 09:26:18

2 of 78 Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
10. The Hard Drive ........................................................................................... 34
10.1. Important Directories..........................................................................................35
11. The Optical Drive ....................................................................................... 36
11.1. Inserting a Disc ......................................................................................................36
11.2. Playing/Reading Discs.........................................................................................37
11.3. Regional Playback Information for DVDs.....................................................37
11.4. Issues Relevant to the Burner...........................................................................38
12. The Sound System ..................................................................................... 39
12.1. External Audio Connections.............................................................................39
13. Network Operation.................................................................................... 40
13.1. What is a Network? ..............................................................................................40
13.2. Wireless LAN (Wireless Network) ....................................................................41
13.3. Bluetooth.................................................................................................................42
13.4. Flight Mode.............................................................................................................42
14. The Multi-Card Reader .............................................................................. 43
14.1. Inserting a Memory Card ...................................................................................43
14.2. Removing Memory Cards ..................................................................................43
15. The Webcam ............................................................................................... 43
16. The Universal Serial Bus Port ................................................................... 44
16.1. Charging function for Compatible Mobile Phones ..................................44
17. Securing Your Notebook ........................................................................... 45
17.1. Password Setting (Power-on) ...........................................................................45
17.2. Kensington Security Lock ..................................................................................45
18. Software ..................................................................................................... 46
18.1. Getting to Know Windows®8............................................................................46
18.2. Windows Activation.............................................................................................46
18.3. Windows®8 – What’s New .................................................................................47
18.4. Overview..................................................................................................................49
18.5. Linking a User Account to a LiveID.................................................................51
18.6. Windows®8 Start Screen....................................................................................52
18.7. Windows®8 Desktop ...........................................................................................53
18.8. Using the Search Function ................................................................................56
19. Control Panel.............................................................................................. 56
19.1. Windows®8 Power On/Off Functions............................................................58
19.2. Control Panel Settings.........................................................................................58
19.3. Resetting the Notebook to its Factory Settings.........................................59
19.4. UEFI Firmware Configuration ...........................................................................60
19.5. Kaspersky Internet Security ..............................................................................61
19.6. Windows®8 – Help and Support.....................................................................62
20. FAQ – Frequently Asked Questions .......................................................... 63
99222 E6232 Aldi AUS RC2 Content.indd 299222 E6232 Aldi AUS RC2 Content.indd 2 29.01.2013 09:26:5529.01.2013 09:26:55

3 of 78
Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
21. Customer Service....................................................................................... 64
21.1. What To Do In Case of Hardware Problems ................................................64
21.2. Find The Cause ......................................................................................................64
21.3. Do You Need More Help?...................................................................................66
21.4. Driver Support .......................................................................................................66
21.5. Transport..................................................................................................................67
21.6. Maintenance...........................................................................................................68
21.7. Care of the Display ...............................................................................................68
22. Upgrading/Modifying and Repair............................................................ 69
23. Recycling and Disposal.............................................................................. 71
24. European EN 9241-307 Class II Standard................................................. 72
24.1. Energy Star® .............................................................................................................................................................................................. 74
24.2. FCC Compliance Statement..............................................................................75
25. Index ........................................................................................................... 77
99222 E6232 Aldi AUS RC2 Content.indd 399222 E6232 Aldi AUS RC2 Content.indd 3 29.01.2013 09:26:5529.01.2013 09:26:55

4 of 78 Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
15.6‘‘ Notebook
E6232 (MD 99222)
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts for a
period of 24 months from the date of purchase. Defects that occur within this
warranty period, under normal use and care, will be repaired, replaced or refunded
at our discretion. The benefits conferred by this warranty are in addition to all rights
and remedies in respect of the product that the consumer has under the
Competition and Consumer Act 2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and
for compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
99222 E6232 Aldi AUS RC2 Content.indd 499222 E6232 Aldi AUS RC2 Content.indd 4 29.01.2013 09:26:5529.01.2013 09:26:55

5 of 78
Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
Personal Information
Please append the following to your proof of ownership:
Serial number ................................................
Date of purchase ................................................
Place of purchase ................................................
You will find the serial number on the underside of the Notebook. Where applicable,
also copy the number on your warranty documents.
Our Target Group
This operating manual is intended to be read by both first-time and experienced
users. Regardless of any possible professional use, this Notebook is designed for use
in a private household. The entire family will be able to enjoy the wide variety of
applications it offers.
The Quality
We select our components with a close eye to functionality, ease of use, safety and
reliability. Thanks to our ideally balanced hardware/software concept we are able to
offer you a state of the art Notebook that you will enjoy whether you are working or
at play. Thank you for purchasing our products. We are delighted to welcome you as
our new customer.
Copying this Manual
This document contains legally protected information. All rights reserved.
Mechanical, electronic and any other form of reproduction is prohibited without the
written permission of the manufacturer.
Copyright © 2013
All rights reserved. This manual is protected by copyright. MEDION®is the owner of
the copyright.
Trademarks: MS-DOS®and Windows®8 are registered trademarks of the Microsoft®
corporation. Intel, the Intel Logo, Intel Inside, Intel Core, Notebook, and Core Inside
are trademarks of Intel Corporation in the U.S. and/or other countries.
®, the HDMI logo and the name High Definition Multimedia Interface are
registered trademarks of HDMI Licensing LLC.
Other trademarks are the property of their respective owners.
Subject to technical and optical changes as well as printing errors.
99222 E6232 Aldi AUS RC2 Content.indd 599222 E6232 Aldi AUS RC2 Content.indd 5 29.01.2013 09:26:5529.01.2013 09:26:55

6 of 78 Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
1. About these Instructions
Before using the device for the first time, please read these operating
instructions carefully, paying special attention to the safety notices.
This device should only be used as designated and as described in these
instructions.
Please keep these instructions in a safe place for future reference.
Always include these instructions if passing the device on.
1.1. Symbols and Keywords used in these Instructions
DANGER!
Warning of immediate risk of fatal injury!
WARNING!
Warning: possible mortal danger and/or serious
irreversible injuries!
CAUTION!
Warning: possible light or moderate injuries!
CAUTION!
Please follow the guidelines to avoid property damage.
PLEASE NOTE!
Additional information on using the device.
PLEASE NOTE!
Please follow the guidelines in the operating instructions.
WARNING!
Warning: danger of electric shock!
WARNING!
Warning: danger due to excessive volume!
• Bullet point/information on operating steps and results
Tasks to be performed
99222 E6232 Aldi AUS RC2 Content.indd 699222 E6232 Aldi AUS RC2 Content.indd 6 29.01.2013 09:26:5529.01.2013 09:26:55

7 of 78
Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
1.2. Proper Use
This device is designed for the use, management and editing of electronic
documents and multimedia content, as well as for digital communication. The
device is intended for private use only and not for industrial/commercial use.
Please note that we shall not be liable in cases of improper use:
• Do not modify the device without our consent and do not use any auxiliary
equipment which we have not approved or supplied.
• Use only spare parts and accessories which we have supplied or approved.
• Follow all the instructions in these operating instructions, especially the safety
information. Any other use is deemed improper and can cause personal injury or
damage to the product.
• Do not use the device in extreme environmental conditions.
1.3. Declaration of Conformity
This device is supplied with the following wireless features:
• Wireless LAN
• Bluetooth
MEDION AG hereby declares that this device conforms to the fundamental
requirements and the remaining relevant regulations of the 1999/5/EC R&TTE
Directive.
This product satisfies the basic requirements and relevant regulations of the
Ecodesign Directive 2009/125/EC. Full declarations of conformity are available at
http://www.medion.com/conformity.
N26968
99222 E6232 Aldi AUS RC2 Content.indd 799222 E6232 Aldi AUS RC2 Content.indd 7 29.01.2013 09:26:5529.01.2013 09:26:55

8 of 78 Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
2. Safety Instructions
2.1. Disclaimer - Children and Persons with Reduced
Abilities
• This device is not intended for use by people (including children)
with reduced physical, sensory or mental abilities or for those
without experience and/or knowledge, unless they are supervised
by a person responsible for their safety or they have been
instructed in its use.
• Children should be supervised to ensure that they do not play
with the device. Children should not be allowed to use this device
without supervision.
• Keep the device and its accessories out of the reach of children.
DANGER!
Keep plastic packaging out of the reach of children. There
is a risk of suffocation.
2.2. Operational Safety
Please read this section carefully and follow all instructions given. The
instructions will help you to operate the Notebook reliably and in-
crease its service life.
• Never open the housing of the Notebook, battery or mains
adapter! This could result in an electric shock or even ignite a fire
which will damage your Notebook.
• Optical drive (CD/CDRW/DVD) constitute class 1 laser equipment
providing these devices are contained in a sealed Notebook
housing. Do not remove the drive cover as invisible laser radiation
may escape.
• Do not insert anything into the Notebook through the slots and
openings. This could result in an electric shock or even ignite a fire
which will damage your Notebook.
• The slots and openings on the Notebook are for ventilation
purposes. Do not cover these openings as this could cause the
device to overheat.
99222 E6232 Aldi AUS RC2 Content.indd 899222 E6232 Aldi AUS RC2 Content.indd 8 29.01.2013 09:26:5629.01.2013 09:26:56

9 of 78
Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
• The Notebook is not intended for use by companies in the heavy
industry sector.
• To avoid damage from lightning strikes, do not operate the
Notebook during thunderstorms.
• Do not place any objects on top of the Notebook and do not exert
pressure on the display. Otherwise, there is a risk that the display
may break.
• If the screen breaks, there is a danger of injury. If this happens, pick
up the shattered pieces wearing protective gloves and send them
to your service centre for professional disposal. Finally, wash your
hands with soap, as the pieces may have been contaminated with
chemicals.
• Do not fold the display back by an angle of more than 120°.
Exceeding this value may damage the housing or the Notebook.
Always hold the display firmly by the middle when folding it back,
adjusting the position and closing it. Failure to do so may damage
the display. Never use force to open the display.
• To avoid damaging the screen, do not touch it with fingers or sharp
objects.
• Never lift the Notebook up by the display as this could break the
hinges.
• Switch the Notebook off immediately/do not switch the Notebook
on, disconnect the mains plug and contact customer services if ...
−the mains adapter or the attached power cable or plug is burnt
or damaged. Replace faulty mains cables/mains adaptors only
with original parts. These parts should not be repaired under
any circumstances.
−the Notebook housing is damaged or liquid has penetrated into
the device. Have the Notebook inspected by customer services.
Otherwise, it may not be possible to operate the Notebook
safely. There may be a risk of electric shock and/or harmful laser
radiation!
99222 E6232 Aldi AUS RC2 Content.indd 999222 E6232 Aldi AUS RC2 Content.indd 9 29.01.2013 09:26:5629.01.2013 09:26:56

10 of 78 Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
2.3. Do Not Repair Yourself
WARNING!
Never try to open or repair the device yourself. There is a
risk of electric shock.
• If there is a fault, contact the MEDION Help Desk.
2.4. Data Backup
CAUTION!
Back up your data on external storage media before
each update. We do not accept any liability for claims for
compensation arising from loss of data or any consequential
loss or damage.
2.5. Setup Location
• Keep your Notebook and all connected devices away from
moisture and avoid dust, heat and direct sunlight. Non-compliance
with these instructions can lead to faults or damage to the
Notebook.
• Do not use the Notebook outdoors because external elements,
such as rain, snow, etc., could damage it.
• Set up and operate all components on a stable, level and vibration-
free surface to prevent the Notebook from falling down.
• Do not operate the Notebook or power adaptor for long periods
on your lap or any other body part as the heat dissipation on the
underside can result in uncomfortable overheating.
• In the first few hours of use new devices can give off a typical,
unavoidable but totally harmless smell, which wears off with time.
Ventilate the room regularly to prevent odour build-up.
99222 E6232 Aldi AUS RC2 Content.indd 1099222 E6232 Aldi AUS RC2 Content.indd 10 29.01.2013 09:26:5629.01.2013 09:26:56

11 of 78
Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
2.6. Environmental Requirements
• The Notebook is most reliably operated at an ambient temperature
between 5° C (+41° F) and 30° C (+86° F) and at a relative humidity
between 20% and 80% (without condensation).
• When powered off, the Notebook can be stored at temperatures
between 0° C and 60° C (+32° F and 140° F).
• During a thunderstorm, disconnect the mains plug and the
antenna plug. For extra safety, we recommend using an
overvoltage protection device to prevent the Notebook from
sustaining damage as a result of power surges or lightning strikes.
• After transporting the Notebook, wait until the device has reached
room temperature before switching it on. Large changes in
temperature or fluctuations in humidity can cause moisture build
up within the Notebook due to condensation. This can cause an
electrical short circuit.
• Keep the original packaging in the event the device needs to be
sent in the post.
99222 E6232 Aldi AUS RC2 Content.indd 1199222 E6232 Aldi AUS RC2 Content.indd 11 29.01.2013 09:26:5629.01.2013 09:26:56

12 of 78 Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
2.7. Ergonomics
PLEASE NOTE!
Avoid dazzle, reflections and strong bright-dark contrast in order to
protect your eyes.
The Notebook should never be placed next to a window because this is the
brightest part of the room in daylight. This brightness can make it more difficult for
the eyes to adjust to the darker display. The Notebook should always be positioned
so that the direction of vision is parallel to the window front.
Setting up the Notebook with your back to the window is incorrect as reflections
from the bright window on the screen will then be unavoidable. A position looking
onto the window is also incorrect as the contrast between the dark screen and the
bright daylight can cause problems for the eyes to adjust and result in problems.
The parallel line of vision should also be maintained in relation to artificial lighting
equipment.
In other words, the same criteria and principles apply where the workspace is
illuminated with artificial light. Where space restrictions make it impossible to set up
the screen as described, then correct positioning (rotating, tilting) of the Notebook/
screen can prevent dazzling, reflections and excessive bright-dark contrast, etc. In
many cases, an improvement can also be achieved by using slats or vertical blinds
on the windows, partition walls or by changing the artificial lighting equipment.
2.8. Connecting
Follow the instructions below to connect your Notebook correctly and safely:
2.8.1. Power Supply
DANGER!
Do not open the housing of the mains adapter. There is a
risk of electric shock when the housing is open. It does not
contain any parts requiring maintenance.
The socket outlet must be close to the Notebook and easily accessi-
ble.
• To disconnect the power supply from your Notebook (via the
mains adaptor), pull the mains plug from the power outlet.
• Plug the Notebook’s mains adapter into AC 100–240 V~, 50/60 Hz
earthed sockets only. If you are not sure about the power supply at
the set-up location, please ask your power supplier.
• Use only the mains adapter and power cable supplied.
99222 E6232 Aldi AUS RC2 Content.indd 1299222 E6232 Aldi AUS RC2 Content.indd 12 29.01.2013 09:26:5629.01.2013 09:26:56

13 of 78
Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
• For extra safety, we recommend using an overvoltage protection
device to prevent your Notebook from sustaining damage as a
result of power surges or lightning strikes.
• If you want to disconnect the adapter from the mains, pull the
connector out of the wall socket first and then out of the socket
on the Notebook. The mains adapter or the Notebook may be
damaged if this process is carried out in the reverse order. Always
take hold of the plug when disconnecting the cable from the
socket. Never pull on the cable.
2.9. Cabling
• Position the cables so that they cannot be stepped on or tripped
over.
• To avoid damaging the cables, do not place any objects on them.
• Do not connect peripheral devices – such as keyboards, mouse
and monitor, etc. – when the Notebook is switched on to avoid
damage to the Notebook or the devices. Some devices may also be
connected while the computer is running. This is generally the case
for devices with a USB connection. In all cases, observe the relevant
operating instructions.
• Maintain a distance of at least one metre from sources of high-
frequency and magnetic interference (TV sets, loudspeakers,
mobile phones, DECT telephones, etc.) in order to avoid
malfunctions and data loss.
• Please note that only shielded cables that are shorter than 3
metres may be connected to the external interfaces of this
Notebook. Please only use double-shielded cables for printer cable
connections.
• Do not exchange the supplied cable for another one. Use only
the supplied cable as this cable has been extensively tested in our
laboratory.
• In addition, when connecting your peripherals only use the
connecting cables supplied with those devices.
• Ensure that all connection cables are connected to their
corresponding peripheral device to avoid any interference
radiation. Disconnect any cables that are not required.
99222 E6232 Aldi AUS RC2 Content.indd 1399222 E6232 Aldi AUS RC2 Content.indd 13 29.01.2013 09:26:5629.01.2013 09:26:56

14 of 78 Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
• The only devices which may be connected to the Notebook are
those that meet the requirements set out in the EN60950 standard
“Information Technology Equipment – Safety” or devices that
meet the EN60065 standard “Audio, video and similar electronic
apparatus – Safety requirements”.
2.10. How to Operate the Touchpad
• The touchpad is operated with the thumb or another finger and
reacts to the energy given out by the skin. Do not use pens or
other objects as these can damage your touchpad.
2.11. Battery Mode
To extend your battery’s performance and lifespan and ensure safe
operation, you should observe the guidelines below:
• Never expose the battery to direct sunlight or heat for extended
periods.
• Do not throw batteries into a fire.
• Failure to comply with these guidelines can result in damage and
possibly even the battery exploding.
• Never open the battery; it does not contain any serviceable parts.
• Avoid dirt and contact with electrically conductive materials or
chemical substances and cleaning agents.
• Use only the supplied mains adaptor to charge the battery.
• Make sure (via the Notebook display or acoustic signal) that the
battery is fully discharged before charging it again.
• Please note: There is a risk of explosion if batteries are incorrectly
replaced.
Only replace the battery with the same battery type or an
equivalent type recommended by the manufacturer.
• Always charge the battery until the battery charging light goes out.
Please also observe the information in “Charging the battery” on
page 31 to assess the charge status of your battery.
• Ensure the Notebook is switched off before replacing the battery.
• Batteries are special waste. Dispose of old batteries properly Your
customer service agent is the correct point of contact for this.
99222 E6232 Aldi AUS RC2 Content.indd 1499222 E6232 Aldi AUS RC2 Content.indd 14 29.01.2013 09:26:5629.01.2013 09:26:56

15 of 78
Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
3. Included with your Notebook
Please check that the contents are complete and notify us within 7 days of purchase
if any of the following components are missing:
• MD 99222 Notebook 15.6’’
• 6-Cell Li-Ion Battery
• AC Adapter with Power Cord (Model: FSP Group Inc., model:FSP065-RHC)
• Windows® 8 Recovery DVD
• MEDION Application and Support DVD
• Instruction Manual
• Warranty Certificate
• Warranty Stickers
DANGER!
Keep packaging material such as plastic film away from
children. There is a risk of suffocation if used improperly.
99222 E6232 Aldi AUS RC2 Content.indd 1599222 E6232 Aldi AUS RC2 Content.indd 15 29.01.2013 09:26:5629.01.2013 09:26:56

16 of 78 Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
4. Notebook Details
4.1. Notebook Front View
1
2
345
6
7
8
1) LCD Display
2) Keyboard
3) Device Indicators
4) Integrated Touchpad Buttons
5) Touchpad
6) Palmrest
7) Webcam
8) Microphone
99222 E6232 Aldi AUS RC2 Content.indd 1699222 E6232 Aldi AUS RC2 Content.indd 16 29.01.2013 09:26:5629.01.2013 09:26:56

17 of 78
Telephone: [phone]
Internet: www.medion.com.au
After Sales Support
4.2. Left-Hand Side
910 11 12 13 14 14a
9) Kensington® Lock
10) Power Socket
11) External monitor port VGA
12) LAN Port (RJ-45)
13) HDMI Connector
14) USB 3.0 Port
14a) USB 3.0 Port with charging function for mobile phones
CAUTION!
The charging function (“Symbols and Key words used in
these Instructions“ is available in sleep mode and when the
Notebook is switched off providing it is activated beforehand
in the UEFI firmware configuration.
4.3. Front View Closed Position
15 16 17
15) Stereo Speaker
16) Multimedia Card Reader
17) Stereo Speaker
99222 E6232 Aldi AUS RC2 Content.indd 1799222 E6232 Aldi AUS RC2 Content.indd 17 29.01.2013 09:26:5629.01.2013 09:26:56
