Instruction for Installation and Utilization of HELIUS L
1- For proper utilization of this product and safety, it is mandatory to closely
comply with the directions and notes in this instruction and guide.
2- Earth connection as provided is mandatory.
3- Do not directly touch or impact LED module.
4- Do not stare at LED light source.
5-
The light source contained in this luminaire shall only be replaced by the
manufacturer or his service agent or a similar qualified person. Always switch
off the power prior to installa-tion, maintenance or repair activities.
8
Close!
7
Close!
Close!
5 Nm
400 160
760
Ø48/60
M314LU3LED7730-S
M314LU3LED7740-S
M314LU4LED9730-S
M314LU4LED9740-S
M314LU5LED10730-S
M314LU5LED10740-S
10.3
10.3
10.8
10.8
11.3
11.3
W
(kg)
Cat. No.
Mounting Height
Cx. S = 0.074 m2
max: 15 m
