Meijer Jumbo RBK User manual
round bale grab Jumbo RBK –EN 3
Content
1. Introduction ....................................................................................................................... 4
2. Technical specifications..................................................................................................... 5
3. Safety precautions............................................................................................................. 6
4. The functioning of the bale grab ........................................................................................ 7
5. Installation, starting up, adjustment ................................................................................... 8
6. Operation and use............................................................................................................. 9
7. Maintenance.....................................................................................................................10
8. Problems and solutions....................................................................................................11
9. Environment and disposal ................................................................................................12
CE-Declaration of conformity................................................................................................13
round bale grab Jumbo RBK –EN 4
1. Introduction
The round bale grab Jumbo RBK of Meijer Holland is designed to be attached to a telescopic
handler, front loader, wheel loader or forklift (hereinafter referred to as ‘vehicle’) in order to
grab and transport one wrapped round bale of max. 500 kg over a short distance. The
hydraulic hoses of the bale grab are to be attached to the hydraulic system of the vehicle.
It is important to read the manual carefully before using the machine. Should this
not be the case, there can be the risk of serious injury or death for the user and
damages to the environment. Moreover, there is the risk of damage to the materials
or to the machine. Therefore it is essential that you follow the instructions of this
manual.
round bale grab Jumbo RBK –EN 5
2. Technical specifications
Feature
Jumbo RBK
Height
133 cm
Width
80 cm
Weight
150 kg
Volume hydraulic circuit
2 litres
Max. load
1 wrapped round bale, 500 kg
Diameter of bale
80 to 150 cm
Max. pressure hydraulic circuit
180 bar
When using a vehicle with a pressure higher than 180 bar, it is strongly
recommended to use a pressure relief valve.
This is available at Meijer Holland.
CE-marking
This machine is certified with the CE-marking. This means that the machine meets the
requirements of the applicable EC-directives on safety and health. These directives are
specified in the attached declaration of conformity.
The non-observance of the rules and instructions stated in this manual is to be
considered as serious negligence which leads to the extinguishment of any
liability on the part of Meijer Holland concerning the resulting consequences. In
this case, the risk lies exclusively with the user.
Meijer Holland is constantly busy with the improvement of its products.
Therefore it also reserves the right to make any changes that are considered
necessary. There is no obligation to apply these changes to earlier delivered
machines.
round bale grab Jumbo RBK –EN 6
3. Safety precautions
The following precautions are important to prevent injuries and damages.
1.
Read the manual before use.
2.
Only experts should (dis)mount the bale grab.
3.
Only experts should operate the bale grab.
4.
Use the bale grab only for bales.
5.
Check whether the hydraulic system is working well right after having mounted the
bale grab.
6.
Follow the instructions for use (chapter 6).
7.
The working are of the machine is 5 metres:
no persons are allowed within that range!
8.
Operate the bale grab exclusively from the cabin of the vehicle.
9.
Mind the rules for max. load (chapter 2).
10.
Be aware of oil leakage:
check the hydraulic hoses and cylinders at least once per day.
11.
Replace damaged or worn wires and cylinders immediately.
12.
Follow the instructions for maintenance (chapter 7).
13.
When driving longer distances or on a public road:
no bales are permitted in the bale grab!
14.
Drive straight backwards after having placed the bale.
make sure that there are no people behind the vehicle.
Build the stack of straw and hay bales in a stable way so that it cannot fall over.
The driver must be aware of the rules that apply to the lifting and hoisting of
heavy loads.
round bale grab Jumbo RBK –EN 7
4. The functioning of the bale grab
Mount the bale grab to a vehicle with a hydraulic system. The bale grab only works when it is
attached correctly to the hydraulic system of the vehicle.
One movement is possible with the bale grab:
The clamping of wrapped bales takes place with the help of the clamp arm that is powered
by a hydraulic cylinder.
round bale grab Jumbo RBK –EN 8
5. Installation, starting up, adjustment
Check if the bale grab is undamaged and in good condition on delivery. Please
contact Meijer Holland if you notice any damages. Use the grab only if it is found
to be in good order and after this manual has been read.
5.1 After delivery
Place the bale grab on a solid and even ground.
5.2 Before moving the bales
1. Drive the vehicle in such a way to the bale grab that the mounting surface falls against the
mounting point of the bale grab.
2. Attach the bale grab to the vehicle.
3. Check the couplings for dirt. Only attach clean couplings to prevent dirt from entering the
system.
4. Connect the two correct hydraulic hoses of the vehicle to the two quick release couplings
above the mounting point of the bale grab. The upper hose is for clamping the bales and
the lower one is for releasing them.
5. Check for leakage.
6. Check the correct control of the cylinder from the hydraulic system.
7. Put the hydraulic system under pressure and test the bale grab by opening and closing
the hooks.
5.3 After having moved the bales
1. Place the bale grab with the vehicle on a solid and even ground.
2. Check whether the bale grab stands steady.
3. Disconnect the hydraulic hoses and check them for leakage.
4. Dismount the junction of the vehicle from the bale grab and drive away in reverse.
Store the grab in a dry and clean environment until the next use.
round bale grab Jumbo RBK –EN 9
6. Operation and use
1. Drive the vehicle to the bale and open the clamp arms by putting the hydraulic system in
‘return’.
2. Keep driving until the bale is located between the two clamp arms.
3. Clamp the bale by operating the hydraulic system.
4. When the bale is clamped, put the hydraulic system back into ‘neutral’.
5. Lift the bale and drive the bale to the destination.
6. Let the bale sink to the (loading) floor and put the hydraulic system in ‘return’. By doing so,
the hooks open and release the bale.
7. Drive the vehicle away from the bale in reverse.
8. The bale grab is ready to grab and move another bale.
round bale grab Jumbo RBK –EN 10
7. Maintenance
Regular maintenance extends the life span. The bale grab needs relatively few maintenance.
Maintenance schedule
Before every use
Check the bale collector for damages and wear. Replace damaged or
worn parts.
Check the hydraulic clutch, hoses and cylinders for leakage, wear and
damages. Let problems be fixed immediately by a competent mechanic.
At least once a week
Clean the collector of caked dirt and dust. When using a high pressure
washer, avoid the electrical parts.
Put grease on the grease nipples. At extensive use:
after every 8 working hours add a bit of grease (0,86 grams per grease
nipple).
round bale grab Jumbo RBK –EN 11
8. Problems and solutions
The bale grab has relatively few moveable parts and damages are unlikely to occur when
used properly. Repair or replace damaged and worn parts immediately. Spare parts are
available at Meijer Holland.
Turn off the engine of the vehicle while you are fixing one of the below-
mentioned problems.
Turn off the power supply during welding.
Hydraulic fluid is a poisonous liquid that is harmful to the environment. Never try
to shut a leak with your hand. Fluid under high pressure easily penetrates
through skin and clothing and can cause serious injuries.
Problem
Possible cause
Solution
The hooks are
not moving.
The hydraulic circuit of the bale grab is
not attached to the hydraulic system of
the vehicle.
Attach the two hoses.
The hydraulic circuit of the bale grab is
not attached correctly.
Exchange the wrongly attached
hydraulic hoses.
Malfunction in the hydraulic system of
the vehicle.
Consult the manual of the vehicle.
The clamp arm is blocked.
Look for the blockade and remove
it.
round bale grab Jumbo RBK –EN 12
9. Environment and disposal
The bale grab has a hydraulic circuit that contains hydraulic fluid, a poisonous liquid that is
harmful to the environment. Regularly check the bale grab for leakage and replace damaged
or worn parts immediately.
9.1 Disposal of the bale grab
Drain the hydraulic system and let the fluid be disposed by an authorised company.
The rest of the bale grab is made of coated steel and can be disposed of as crap.
round bale grab Jumbo RBK –EN 13
CE-Declaration of conformity
We, Meijer Holland
Bale handling systems
Duinkerkenstraat 11
NL-9723 BN GRONINGEN
The Netherlands
Tel: +31 (0)50 - 312 64 48
Fax: +31 (0)50 - 313 80 18
declare under our sole responsibility that:
1. we are the manufacturer of:
MH Jumbo RBK (model MHRBK)
2. the machine complies with the following applicable directives:
Machinery directive 2006/42/EG
3. the machine is designed and constructed according to European standards,
including:
EN 349:1993+A1:2008
EN-ISO 4413:2010
EN-ISO 12100:2010
The electrics and the control section are the responsibility of the customer.
Groningen, 11 August 2016
J.F. Lommerts, director
