Dismantling Guide
OPNs MIS5024, MIS5023
Rev. 1.0

Dismantling Guide
Rev. 1.0
Mellanox Technologies Confidential
2 of 12
NOTE:
THIS INFORMATION IS PROVIDED BY MELLANOX FOR INFORMATIONAL PURPOSES ONLY
AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
ARE DISCLAIMED. IN NO EVENT SHALL MELLANOX BE LIABLE FOR ANY DIRECT,
INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES
(INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;
LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND
ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT
(INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF
THIS HARDWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Mellanox Technologies, Inc.
350 Oakmead Parkway Suite 100
Sunnyvale, CA 94085
U.S.A.
www.mellanox.com
Tel: [phone]
Fax: [phone]
Mellanox Technologies Ltd
PO Box 586 Hermon Building
Yokneam 20692
Israel
Tel: [phone]
Fax: [phone]
© Copyright 2011. Mellanox Technologies, Inc. All Rights Reserved.
Mellanox®, BridgeX®, ConnectX®, InfiniBlast®, InfiniBridge®, InfiniHost®, InfiniRISC®,
InfiniScale®, InfiniPCI®, PhyX® and Virtual Protocol Interconnect® are registered trademarks of
Mellanox Technologies, Ltd. CORE-Direct and FabricIT are trademarks of Mellanox Technologies, Ltd.
All other marks and names mentioned herein may be trademarks of their respective companies.
Contact Information
Should you have any questions regarding our Products, please feel free to contact us directly or contact our
local distributors.
Mellanox Technologies Call Center
Tel: +
Email: [e-mail]

Dismantling Guide
Rev. 1.0
Mellanox Technologies Confidential
3 of 12
Table of Contents
Revision .......................................................................................................................................... 4
Preface............................................................................................................................................. 4
Intended Audience .......................................................................................................................... 4
Switch OPNs................................................................................................................................... 4
Policy Statement ............................................................................................................................. 5
1Dismantling Instructions......................................................................................................... 6
1.1 InfiniBand switch systems - General.............................................................................. 6
1.2 General Preparations....................................................................................................... 6
1.3 Cover............................................................................................................................... 6
1.4 Extracting the Power Supply Unit .................................................................................. 7
1.5 Extracting the Fan Unit................................................................................................... 9
1.6 Extracting the Board ..................................................................................................... 11
List of Tables
Table 1: Revision............................................................................................................................ 4
Table 2: Switch OPNs for this Procedure....................................................................................... 4
List of Figures
Figure 1 Remove the Cover....................................................................................................... 7
Figure 2 PSU Location.............................................................................................................. 8
Figure 3 PSU Screw Locations ................................................................................................. 8
Figure 4 Fan Location ............................................................................................................... 9
Figure 5 Fan Bottom Side Screw Locations............................................................................ 10
Figure 6 Fan Top Side Screw Locations................................................................................. 10
Figure 7 Main Board Removal................................................................................................ 11
Figure 8 Main Board Screws................................................................................................... 12

Dismantling Guide
Rev. 1.0
Mellanox Technologies Confidential
4 of 12
Revision
Table 1: Revision
Revision
Date
1.0
January 2011
Preface
This manual is intended as a reference for dismantling MIS 502[34]Q switch
systems in preparation of meeting the requirements of WEEE recycling.
Intended Audience
This manual is intended for technicians who dismantle the switch systems as a
reference for WEEE recyclers.
Mellanox Technologies emphasizes the importance of carefully following all
procedures described in this guide to prevent personal injury.
Switch OPNs
This document is valid for all of the switch OPNs listed in Table 2.
Table 2: Switch OPNs for this Procedure
MIS5023Q-1BFR
MIS5023Q-1BRR
MIS5024Q-1BFR
MIS5024Q-1BRR

Dismantling Guide
Rev. 1.0
Mellanox Technologies Confidential
5 of 12
Policy Statement
Mellanox Technologies recognizes the importance of developing connectivity
solutions that not only enable our customers to optimize their data centers
performance, but also protect the environment and ensure that future generations
enjoy its bounties. Mellanox Technologies is committed, therefore, to meeting the
requirements of the European Union’s WEEE (waste electrical and electronic
equipment) directive. The directive mandates how the materials used in electrical
and electronic equipment must be disposed of.
Mellanox Technologies has worked closely with its suppliers to eliminate
hazardous materials from its products. There are instances, however, where it has
not proven possible to completely eliminate all hazardous materials.
Consequently, all applicable products are labeled with a crossed out “wheelie” bin
symbol, indicating that special care must be applied to their disposal and / or
recycling.

Dismantling Guide
Rev. 1.0
Mellanox Technologies Confidential
6 of 12
1Dismantling Instructions
This chapter provides detailed instructions for dismantling the InfiniBand switch
systems. Follow the instructions in the order they are presented.
1.1 InfiniBand switch systems - General
The InfiniBand switch system complies with RoHS directive under the exemption
known as RoHS-6.
The last digit of the product part number represents the RoHS type.
For example
MIS5024Q-1BRR —the last R = RoHS-6
InfiniBand switch system systems are comprised of:
Main Board
Fan unit
Harnesses
Power Supply Unit (PSU)
Cover
1.2 General Preparations
The InfiniBand switch system is assembled using Philips screws.
To disassemble the InfiniBand switch system you will need a small Philips
screwdriver.
The pictures displayed in the following pages provide visual guidance explaining
how to remove the modules from the mechanical base.
1.3 Cover
Unscrew the rear-side screws, and slide the cover to the back for opening it.

Dismantling Guide
Rev. 1.0
Mellanox Technologies Confidential
7 of 12
Figure 1 Remove the Cover
1.4 Extracting the Power Supply Unit
The power supply unit is located on the rear side of the switch unit.
Disassemble the 4 screws attaching the Power Supply to its mechanical base.

Dismantling Guide
Rev. 1.0
Mellanox Technologies Confidential
8 of 12
Figure 2 PSU Location
Figure 3 PSU Screw Locations
Power Supply Schema
Screws for disassembling the PS from the base

Dismantling Guide
Rev. 1.0
Mellanox Technologies Confidential
9 of 12
To extract a PSU:
1. Disconnect the ground from the power supply.
2. Disconnect, cut or unscrew the power supply cord from the power supply unit.
3. Unscrew the power supply from the mechanical enclosure.
1.5 Extracting the Fan Unit
The Fan unit is located in the middle of the system.
Figure 4 Fan Location
1. Disconnect the harnesses from the fan unit to the board.
2. Disassemble the 3 screws attaching the Fan wall to the bottom of the mechanical
enclosure base.

Dismantling Guide
Rev. 1.0
Mellanox Technologies Confidential
10 of 12
Figure 5 Fan Bottom Side Screw Locations
3. Disassemble the 2 screws attaching the Fan wall to the sides of the mechanical base.
4. Remove the fan unit.
5. Disconnect harness tie downs and remove harnesses from the base.
Figure 6 Fan Top Side Screw Locations

Dismantling Guide
Rev. 1.0
Mellanox Technologies Confidential
11 of 12
1.6 Extracting the Board
1. Unscrew the heat-sink screws to remove the heat-sink.
2. Unscrew the Philips screws and remove spacers to remove the main board.
Figure 7 Main Board Removal

Dismantling Guide
Rev. 1.0
Mellanox Technologies Confidential
12 of 12
Figure 8 Main Board Screws
