KPH802/1602
1U Rackmount USB Hub KVM Switch
User Manual
KPH802/1602: 1U rackmount USB Hub KVM switch
8/16-port with 2 user console

14628 Central Ave,
Chino, CA 91710
tel:[phone], fax:[phone]
© Copyright 2013 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
KPH802/1602
1U Rackmount USB Hub KVM Switch
Legal Information
First En glish printing , October 2002
Inform ation in this document has be en carefully che cked for accuracy; ho weve r, no g uara ntee is given to th e correctness of the
con ten ts. The information in this docu ment is sub je ct to change without notice. W e are not liable fo r any injury o r loss th at
results from the use o f th is eq uipment.
Safety Instructions
Please read all of these instructions carefully before you use the device. Save this manual for future reference.
¦ Un plug equipment bef ore cleaning. Do n’t use liquid or spray d eterge nt; use a moist clo th.
¦ Kee p equipme nt away from excessive h umidity and he at. Prefe rabl y, keep it in an a ir -conditioned environm ent with
tempe ratures not exceeding 40º Celsius (10 4º Fah renheit).
¦ Wh en installing, place th e equipme nt on a sturd y, level surface t o pre ven t it from accidenta lly falling and causin g dam
age to ot her equipme nt or in ju ry to persons nearb y.
¦ Wh en t he equipme nt is in an ope n po sition, do not cove r, block or in an y way obstru ct the gap between it an d the
power sup pl y. Proper air convection is ne cessary to keep it from o verheating.
¦ Arrang e the eq uipme nt ’s p owe r cord in such a way th at others wo n’t trip or fa ll over it.
¦ If you a re using a power cord th at d idn’t sh ip with th e equipment, ensure that it is rate d for the voltage and curre nt
lab eled on th e eq uipme nt ’s electrical ra tings label. The volta ge ra tin g on the cord should be higher than the one listed
on the eq uipme nt ’s rat in gs label.
¦ Observe a ll precautions and warnings attached to the e quipm ent .
¦ If you don’t intend o n u sing the e quipm ent for a long t im e, disconn ect it from the pow er outlet to prevent being dam
aged by transient over -voltage.
¦ Kee p all liquids aw ay from the equ ip ment to minimize the risk of a ccidental spillage. Liquid spilled on to th e p ower
sup ply or on o the r h ardwa re m ay cause dama ge, fire or electrical sho ck.
¦ Only qua lified se rvice person nel should ope n the chassis. Op ening it you rself cou ld dam age the equipment and invali
date its wa rrant y.
¦ If any part of the equ ip ment be comes dama ged or stops fun ction ing, h ave it checked by qualified service personne l.
What the w arranty does not cover
¦ Any pro duct, on w hich the serial numb er has b een def aced, mod if ied or rem oved.
¦ Da mag e, deteriorat ion or malfun ction resulting from :
? Accide nt, m isuse, ne glect, fire , wate r, lightn in g, or o the r acts of n ature, un auth orized prod uct mo dification, or
failure to follo w instruction s supplied with the product.
? Repair or attemp ted repa ir by anyone not authorized by us.
? Any damag e o f th e prod uct due t o shipme nt.
? Removal or installation of th e product.
? Causes exte rnal to the pro duct, su ch as electric po wer fluctu ation or failure.
? Use of supplies or p arts not mee ting o ur specifications.
? Norm al wea r and tea r.
? Any other causes which doe s not re late to a p ro duct defect.
¦ Re mo val, insta llation, and set -up service charge s.
R egulatory Notice s Federal Communications C om mission (FCC)
Th is equipme nt has be en te sted and found t o com ply with the limits for a Class B digital device, p ursuant to P art 15 of the F CC
rules. The se lim its a re designed to provide reason able prote ction again st harm ful interfe rence in a residential instal - lation.
Any chan ges o r mod ifications m ade to this equipm ent ma y void the u ser’s authority to operate th is e quipm ent. This e quipm ent
generates, u ses, and can ra dia te rad io freq uency en ergy and, if n ot installed a nd u sed in a ccorda nce w ith the instructions, m ay
cau se harmful interfe rence to radio com munications.
H owever, t here is no guarantee th at interference will not occur in a particular installation. If this equip ment does cause
harmful interference to radio or television recept ion, which can be determined by turn ing the e quipme nt of f and on, the use r
is encouraged to try to correct th e interference by one or mo re of the following m easures:
¦ Re -position or relocate the receiving ante nna.
¦ In crease th e sep aration b etwe en the equipm ent and receive r.
¦ Co nne ct the equ ipmen t into an o utlet on a circuit di fferent from that to w hich the receiver is conn ected.

14628 Central Ave,
Chino, CA 91710
tel:[phone], fax:[phone]
© Copyright 2013 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
KPH802/1602
1U Rackmount USB Hub KVM Switch
Contents
< Part 1 > USB Hub DB-15 2-console KVM
KPH802 KPH1602
1.1 Package contents
1.2 KVM port connection
1.3 IP & Local console connection
1.4 IP console setting
1.5 Built-in USB hub usage & connection
1.6 Specifications
P.1
P.2
P.2
P.3
P.4
P.5
< Part 2 > Usage
2.1 KVM Button
2.2 Password
2.3 KVM OSD
2.4 KVM Hotkey & Remote Console Hotkey
2.5 DC power 12V, 24V, 48V Input
P.6
P.7
P.8
P.9
P.10

14628 Central Ave,
Chino, CA 91710
tel:[phone], fax:[phone]
© Copyright 2013 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
KPH802/1602
1U Rackmount USB Hub KVM Switch
Before Installation
¦It is very important to mount the equipment in a suitable cabinet or on a stable surface.
¦Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive
dust, dirt, heat, water, moisture and vibration.
Unpacking
The equipment comes with the standard parts shown in package content. Check and make sure they are
included and in good condition. If anything is missing, or damaged, contact the supplier immediatel y.
Installation for standalone KVM
Screw A: 2 pcs Screw B: 8 pcs
M3.2 x 4.5 mm M4 x 10 mm
¦Install each bracket using screws
AB provided shown in Figure 1.
¦Fix the KVM into the rack
Figure 1.

14628 Central Ave,
Chino, CA 91710
tel:[phone], fax:[phone]
© Copyright 2013 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
KPH802/1602
1U Rackmount USB Hub KVM Switch
< Part 1 > USB Hub DB-15 KVM
< 1.1 > Package Contents
KPH802 / KPH1602
KVM unit
• KPH802 or KPH1602 KVM unit x 1
• Mounting set w/ bracket & screws x 1
• Power adapter w/ power cord ( for KVM ) x 1
Local Console KPH802
Flash 12VDC
8
2 x USB 2.0
7 6 5 4 3 2 1
( USB hub for device connectio n )
KPH1602
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
Daisy-chain feature for this model is NOT available.

< 1.2 > KVM port connection
CB-6 / CB-10 / CB-15
¦6 / 10 / 15 ft USB KVM cable
¦Support USB server
USB Servers
USB KVM port
16 15 14 13 12 11 10 9
8 7 6 5 4 3 2 1
USB Servers
USB KVM cable
support USB server
< 1.3 > IP & Local console connection
Local
USB
console
1 6 15 14 13 12 11 10 9
8 7 6 5 4 3 2 1
CAT 5 / 6 cable
max. 100m
Network device
hub or router

< 1.4 > IP console setting
After the cable connection, please take the following steps to configure the IP KVM :
1. Download IPKVMsetup.exe
2. Double click IPKVMsetup.exe to configure the IP KVM by device setup as below.
3. Click Refresh Device to search the connected IP KVM
4. Select the M.A.C. address, which you want to setup, then click Query Device
5. Enter Super user login. The default is super
6. Enter Super user password. The default is pass
7. Enter the new super user password
8. Re-enter the new password
9. Change the desired IP address / Subnet mask / Gatewa y, then click Setup Device to confirm the setting to IP KVM
10. The default address is as below:--
¦The single IP KVM model, such as KPH1602 - http://192.168.1.22
11. Open Internet Explorer ( I.E. ), version 6.0 or above
12. Enter the IP KVM address into the address bar
- For Single IP - http://192.168.1.22
13. Enter username ( default is super )
Password ( default is pass )
14. After successful login to IP KVM, the user will enter the main page of IP KVM

< 1.5 > Built-in USB Hub Usage & Connection
16 15 14 13 12 11 10 9
8 7 6 5 4 3 2 1
2 x USB 2.0 ( USB hub for device connection )
Flash Disk
Hard disk storage
Keyboard / Mouse
Scanner
Printer
Camer a

< 1.5 > Specifications
KPH802 KPH1602
¯KVM Port
Number of ports: 8 or 16
Connector: Combo connector
Connectivity: Combo 2-in-1 VGA + USB KVM cable, 6, 10 or 15 feet
¯Local Console
Graphic connector: 1 x DB-15
Resolution: Up to 1920 x 1200
Input device: 2 x USB type A for keyboard & mouse
USB hub: 2 x USB type A for sharing other peripheral devices among the computers
¯IP Remote Console
Connector: RJ45 Ethernet
User management: 15-user login, 1 x active user
Network protocol: DHCP / BOOTP / DNS
Security: SSL v3, RSA, AES, HTTP / HTTPs, CSR
Resolution: Up to 1600 x 1200
Browser: IE, Firefox, Safari, Netscape
¯Compatibility
Multi-platform: Mix PCs, SUN and Mac G3 / G4 Mac / iMac
Support: Windows 7 / Vista / 2003 / XP, Linux, Unix
¯Power
Input: 100 or 240V AC at 50 or 60 Hz via IEC type cord
Option DC: 12V / 24V / 48V DC input
Consumption: Max. 12 Watt, Standby 5 Watt
¯Regulatory Approval: FCC, CE
¯Environmental
Operating: 0 to 50°C
Storage: -5 to 60°C
Relative humidity: 90%, non-condensing
Shock: 50G peak acceleration (11ms, half-sine wave)
Vibration: 58~100Hz / 0.98G (11ms / cycle)
¯Product Information
Dimension (W x D x H): 443 x 171 x 43.6 mm / 17.4 x 6.7 x 1.72 inch
Net weight: 3 kg / 6.5 lb
¯Packing Information
Dimension (W x D x H): 500 x 400 x 90 mm / 19.7 x 15.7 x 3.5 inch
Gross weight: 5 kg / 11 lb

14628 Central Ave,
Chino, CA 91710
tel:[phone], fax:[phone]
© Copyright 2013 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
KPH802/1602
1U Rackmount USB Hub KVM Switch
Part 2 . Usage
2.1 KVM Button
Power ON
¦Turn o ff all servers and KVM switches
¦Make sure all cables / connectors are properly connected
¦Recomm end Power ON sequence is m onito r, KVM switch finally computer
Front Panel - Port LED Indications
8 ports
Ban k no . P C port LED s Channel
button
Bank
button
16 ports
Ban k no. 7-Segmen t BAN K LED indication
PC port LED s On lin e :Blue LED on indicatin g a PC is connectin g to the port
Acti ve :Gree n LED on indicating a selected channel
Channe l button Press to selec t channe l from 01 to 16
Ban k button Selec t the ban k from 1 to 8

2.2 Password
The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on
number pad)
¦Enable password
1. Press the KVM hotkey Scroll Lock + Scroll Lock + U
2. Logout the KVM by pressing the hotkey Scroll Lock + Scroll Lock + P
3. In SUPERVISOR level, enter “00000000” eight zeros in user name & password field
(Do not use “0” on number pad)
4. In USER level, press Space bar +Enter in user name & password field
Remark: Automatic logout after 10 minutes of inactivity
¦Set your own user name & password
1. Login the KVM in SUPERVISOR level by pressing “00000000” eight zeros in user name & password
field
2. Call KVM OSD menu by pressing t he KVM hotkey Scroll Lock + Scroll Lock + Space Bar
3. Press F1 to the MAIN MENU
4. Select “USER SECURITY”
5. Set password in SUPERVISOR & USER level
a. In the left-top row “S” (SUPERVISOR), press Enter to set your own user name & password
b. In the row 1 to 8 (USER), press Enter to set your own user name & password
6. Press Enter to save the setting or press Esc to cancel the editing without any change
Remark: a. Blank has underscore, while SPACE doesn’t have
b. Press any alphanumeric key to move to next input item. SPACE is treated as a valid
character
¦Change your password
1. Login the KVM in SUPERVISOR level by pressing your own user name & password
2. Call KVM OSD menu by pressing the KVM hotkey Scroll Lock + Scroll Lock + Space Bar
3. Press F1 to the MAIN MENU
4. Select “USER SECURITY”
5. Change password in SUPERVISOR & USER level
a. In the left-top row “S” (SUPERVISOR), press Enter to change your user name & password
b. In the row 1 to 8 (USER), press Enter to change your user name & password
6. Press Enter to save the setting or press Esc to cancel the editing without any change
Remark: a. Blank has underscore, while SPACE doesn’t have
b. Press any alphanumeric key to move to next input item. SPACE is treated as a valid
character
¦Disable your password
1. Press the KVM hotkey Scroll Lock + Scroll Lock + U
2. Logout the KVM by pressing the KVM hotkey Scroll Lock + Scroll Lock + P
3. You don’t need user name & password to access the KVM OSD menu
¦Forget your password
Please contact your supplier for further support
Remark:
¦You must press the KVM hotkey within 2 seconds
¦A beep sound will be heard for successful entering KVM hotkey

2.3 KVM OSD
OSD Menu
OSD operation
next to the system nam e The PC is powered on
next to the system name The PC is selected
F1 Access F1 MAIN MENU
F2 Logout the OSD menu
F3 Previous menu
Esc Cancel / Quit
Enter Complete / Switch to selected port
Switch to previous or next port
PgUp/PgDn Switch to previous bank or next bank
Display port 01 ~ 08 / 09 ~ 16 / 17 ~ 24 / 25 ~ 32
1 / 2 / 3 / 4 Remark: Display port 17 ~ 32 for 32 port model only
F1 Main Menu
01
LANGUAGE
OSD language change
02
PORT NAME EDIT
Define port name
03
PORT SEARCH
Quick searching by port name
04
USER SECURITY
Change password
05
ACCESS LIST
Define user access authority
06
HOTKEY
Change hotkey
07
TIME SETTINGS
Modify scan display time interval
08
OSD MOUSE
Modify OSD mouse speed

Scroll Lock +Scroll Lock +
Space Bar
Calling OSD menu
Right-button mouse +Esc
Calling OSD menu
+
Port no.
Switch to specific port
Turn the buzzer ON and OFF
* Default the buzzer is ON
Logout the KVM if password security is
ON. Show up the status windows
2.4 KVM Hotkey & Remote Console Hotkey
Local Console Hotkey Function
Scroll Lock
+
Scroll Lock
+
Switch to previous port
Scroll Lock
+
Scroll Lock
+
Switch to next port
Scroll Lock
+
Scroll Lock
+
PgUp / PgDn
Switch to previous bank or next bank
Scroll Lock +Scroll Lock + Bank no.
Scroll Lock +Scroll Lock +B
Scroll Lock +Scroll Lock +P
Advance hotkeys (for Supervisor login only)
Scroll Lock +Scroll Lock +S
Scroll Lock +Scroll Lock +R
Activate auto-scan mode for connected
servers
*Press any key to exit the auto-scan
mode
Reset all the KVM settings to factory
default
*Except User Security settings
Scroll Lock
+
Scroll Lock
+
U
Disable and enable password security
*Default security is ON
To enable / disable the screen saving
Scroll Lock
+
Scroll Lock
+
L
function and 10 minutes auto-logout
*Default the screen saving is OFF
Remarks:
¦Example of “Scroll Lock +Scroll Lock + Bank no. + Port no.”
-Bank No. : 1 to 8
-Port No. : 01 to 16
-e.g. Bank 1 Port 4 : Scroll Lock +Scroll Lock +1+0+4
-e.g. Bank 2 Port 16 : Scroll Lock +Scroll Lock +2+1+6
¦You must press the hotkey within 2 seconds
¦A beep sound will be heard for successful entering
¦The numeric keypad is not supported, while in OSD screen, the arrow keys, PgUp, PgDn, and Enter keys
are supports
Remote Console Hotkey Function
Scroll Lock +Scroll Lock +CToggle switch between remote & local port
Scroll Lock +Scroll Lock +QTurn the buzzer ON & OFF
*Default the buzzer is ON
Scroll Lock
+
Scroll Lock
+
S
Activate auto-scan mode for remote & local port
*The scan time interval is 5 seconds
Scroll Lock
+
Scroll Lock
+
A
Auto-adjust the video signal

14628 Central Ave,
Chino, CA 91710
tel:[phone], fax:[phone]
© Copyright 2013 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
KPH802/1602
1U Rackmount USB Hub KVM Switch
2.5 DC Power 12V, 24V, 48V Input
Model
12V
24V
48V
Input rating
Input voltage:
12-Volt
24-Volt
48-Volt
Input range:
9 ~ 18V
18 ~ 36V
36 ~ 75V
Input current
- No load
50 mA
50 mA
50 mA
- Full load
4950 mA
2450 mA
1220 mA
Output rating
Output voltage:
12-Volt
12-Volt
12-Volt
Output current:
4.16A
4.16A
4.16A
Efficiency
84%
85%
85%
Remarks:
¦Package does not include power cord
