Mellanox Technologies Spectrum SN2700 User manual

Exported on Apr/20/2020 07:09 PM
https://docs.mellanox.com/x/Cw1p
Mellanox Technologies
Mellanox Spectrum® 1U Switch
Systems Hardware User Manual
10/25/40/50/100GbE Open Ethernet Switch Systems Models: SN2700, SN2740, SN2410, SN2100, SN2010

2
Mellanox Technologies
NOTE:
THIS HARDWARE, SOFTWARE OR TEST SUITE PRODUCT (“PRODUCT(S)”) AND ITS RELATED DOCUMENTATION
ARE PROVIDED BY MELLANOX TECHNOLOGIES “AS-IS” WITH ALL FAULTS OF ANY KIND AND SOLELY FOR THE
PURPOSE OF AIDING THE CUSTOMER IN TESTING APPLICATIONS THAT USE THE PRODUCTS IN DESIGNATED
SOLUTIONS. THE CUSTOMER'S MANUFACTURING TEST ENVIRONMENT HAS NOT MET THE STANDARDS SET BY
MELLANOX TECHNOLOGIES TO FULLY QUALIFY THE PRODUCT(S) AND/OR THE SYSTEM USING IT. THEREFORE,
MELLANOX TECHNOLOGIES CANNOT AND DOES NOT GUARANTEE OR WARRANT THAT THE PRODUCTS WILL
OPERATE WITH THE HIGHEST QUALITY. ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND
NONINFRINGEMENT ARE DISCLAIMED. IN NO EVENT SHALL MELLANOX BE LIABLE TO CUSTOMER OR ANY
THIRD PARTIES FOR ANY DIRECT, INDIRECT, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES OF ANY
KIND (INCLUDING, BUT NOT LIMITED TO, PAYMENT FOR PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;
LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF
LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE)
ARISING IN ANY WAY FROM THE USE OF THE PRODUCT(S) AND RELATED DOCUMENTATION EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGE.
Mellanox Technologies
350 Oakmead Parkway Suite 100
Sunnyvale, CA 94085, U.S.A.
www.mellanox.com
Tel: [phone]
Fax: [phone]
© Copyright 2020. Mellanox Technologies Ltd. All Rights Reserved.
Mellanox® and the Mellanox logo are registered trademarks of Mellanox Technologies, Ltd.
Additional trademarks used in this document are listed under http://www.mellanox.com/page/trademarks.
All other trademarks are property of their respective owners.

3
Mellanox Technologies
Table of Contents
1 Ordering Information ............................................................................................................................................... 7
1.1 SN2700 Ordering Part Numbers ........................................................................................................................7
1.2 SN2410 Ordering Part Numbers ........................................................................................................................7
1.3 SN2100 Ordering Part Numbers ........................................................................................................................8
1.4 SN2010 Ordering Part Numbers ........................................................................................................................9
2 Introduction............................................................................................................................................................ 10
2.1 Speed and Switching Capabilities .................................................................................................................... 11
2.2 Management Interfaces, PSUs and Fans ........................................................................................................12
2.3 Features ...........................................................................................................................................................12
2.4 Certifications.....................................................................................................................................................12
3 Installation ............................................................................................................................................................. 13
3.1 System Installation and Initialization ................................................................................................................13
3.2 Safety Warnings ...............................................................................................................................................13
3.3 Air Flow ............................................................................................................................................................16
3.4 Package Contents ............................................................................................................................................17
3.5 19” System Mounting Options ..........................................................................................................................17
3.6 SN2700 Static Rail Kit ......................................................................................................................................17
3.6.1 Removing the System from the Rack......................................................................................................... 21
3.7 SN2700 Telescopic Rail Kit ..............................................................................................................................21
3.7.1 Removing the System from the Rack......................................................................................................... 24
3.8 SN2740/SN2410 Static Rail Kit ........................................................................................................................25
3.9 SN2100/SN2010 Side by Side Mounting Rail Kit.............................................................................................27
3.10 SN2100/SN2010 Static Single Switch Rail Kit .................................................................................................31
3.11 Cable Installation..............................................................................................................................................33
3.11.1 Splitter (Breakout) Cables and Adapters .................................................................................................... 35
3.11.1.1 Using Splitter (Breakout) Cables with Mellanox Onyx (MLNX-OS)....................................................... 35
3.11.1.2 Using Splitter (Breakout) Cables with Cumulus Linux........................................................................... 35
3.11.1.3 SN2700 and SN2740 Splitting Options ................................................................................................. 35
3.11.1.4 SN2410 Splitting Options ...................................................................................................................... 36
3.11.1.5 SN2100 Splitting Options ...................................................................................................................... 36
3.11.1.6 SN2010 Splitting Options ..................................................................................................................... 36
3.12 Initial Power On ................................................................................................................................................37
3.13 System Bring-Up ..............................................................................................................................................38
3.13.1 Configuring Network Attributes Using Mellanox Onyx (MLNX-OS)............................................................ 38
3.13.1.1 Manual Host Configuration.................................................................................................................... 38
3.13.1.2 Disable Dynamic Host Configuration Protocol (DHCP)......................................................................... 41

4
Mellanox Technologies
3.13.1.3 Remote Connection with Mellanox Onyx (MLNX-OS) .......................................................................... 42
3.13.2 Configuring Network Attributes Using Cumulus Linux................................................................................ 42
3.13.2.1 Remote Connection with Cumulus Linux .............................................................................................. 42
3.14 FRU Replacements ..........................................................................................................................................42
3.14.1 Power Supply ............................................................................................................................................. 42
3.14.2 Fans ........................................................................................................................................................... 43
4 Interfaces............................................................................................................................................................... 45
4.1 Data Interfaces .................................................................................................................................................45
4.1.1 Supported Passive Cables in SN2010bM .................................................................................................. 46
4.2 Speed ...............................................................................................................................................................46
4.3 RS232 (Console)..............................................................................................................................................46
4.4 Management ....................................................................................................................................................46
4.5 USB ..................................................................................................................................................................47
4.6 Reset Button.....................................................................................................................................................47
4.7 Status and Port LEDs.......................................................................................................................................47
4.8 LED Notifications..............................................................................................................................................47
4.8.1 System Status LED .................................................................................................................................... 48
4.8.2 Fan Status LED .......................................................................................................................................... 50
4.8.3 Power Supply Status LEDs ........................................................................................................................ 51
4.8.4 Unit Identification LED................................................................................................................................ 53
4.8.5 Bad Port LED ............................................................................................................................................. 53
4.8.6 Port LEDs ................................................................................................................................................... 54
4.9 Inventory Information........................................................................................................................................55
5 Software Management .......................................................................................................................................... 57
5.1 Upgrading Software..........................................................................................................................................57
5.1.1 Mellanox Onyx (MLNX-OS) Software Upgrade.......................................................................................... 57
5.1.2 Switch Firmware Update ............................................................................................................................ 57
5.1.3 Cumulus Linux Software Upgrade.............................................................................................................. 57
6 Troubleshooting..................................................................................................................................................... 58
7 Specifications ........................................................................................................................................................ 60
7.1 SN2700 Series .................................................................................................................................................60
7.2 SN2740 Series .................................................................................................................................................61
7.3 SN2410 Series .................................................................................................................................................62
7.4 SN2100 Series .................................................................................................................................................64
7.5 SN2010 Series .................................................................................................................................................65
8 Appendixes............................................................................................................................................................ 67
8.1 Accessory and Replacement Parts ..................................................................................................................67
8.2 Thermal Threshold Definitions .........................................................................................................................68

5
Mellanox Technologies
8.3 Interface Specifications ....................................................................................................................................68
8.3.1 QSFP28 Pin Description ............................................................................................................................ 68
8.3.2 SFP28 Pin Description ............................................................................................................................... 71
8.3.3 RJ45 to DB9 Harness Pinout ..................................................................................................................... 72
8.3.4 RJ45 to RJ45 Harness .............................................................................................................................. 73
8.4 Disassembly and Disposal ...............................................................................................................................73
8.4.1 Disassembly Procedure ............................................................................................................................. 73
8.4.2 Disposal...................................................................................................................................................... 74
9 Document Revision History ................................................................................................................................... 75

6
Mellanox Technologies
Relevant for Models: SN2700, SN2740, SN2410, SN2100 and SN2010
About this Manual
This manual describes the installation and basic use of Mellanox Ethernet switches based on the Mellanox Spectrum IC device.
Ordering Information
See Ordering Information.
Intended Audience
This manual is intended for IT managers and system administrators.
Related Documentation
Document Description
Mellanox Onyx (MLNX-OS) User Manual This document contains information regarding the configuration and
management of the Mellanox Onyx (MLNX-OS) software. See http://
www.mellanox.com/page/mlnx_onyx.
Cumulus Linux User Guide This document contains information regarding the configuration and
management of the Cumulus® Linux® software. See https://
docs.cumulusnetworks.com/display/DOCS.
Open Network Install Environment (ONIE) Quick Start
Guide
See https://github.com/opencomputeproject/onie/wiki/Quick-Start-
Guide/.
Hands-on workshops Cumulus on-site/remote training: https://academy.mellanox.com/en/
cumulus-linux/
Mellanox Onyx on-site/remote training: https://
academy.mellanox.com/en/network-pro-private/
On-site/remote services http://www.mellanox.com/globalservices/index.php/project-delivery-
services-on-site-ethernet-kick-start-package/
For any tailor-made service, contact [email protected].
Revision History
A list of the changes made to this document are provided in Document Revision History.

7
Mellanox Technologies
1 Ordering Information
The following table lists ordering information for the available systems.
Please pay attention to the airflow direction when ordering your system. For more details, see Air Flow.
1.1 SN2700 Ordering Part Numbers
OPN Marketing Description
MSN2700-
BS2F
Mellanox Spectrum based 40GbE, 1U Open Ethernet Switch with Mellanox Onyx (MLNX-OS), 32 QSFP28
ports, 2 Power Supplies (AC), x86 CPU, Standard depth, P2C airflow, Rail Kit, RoHS6
MSN2700-
BS2FC
Mellanox Spectrum 40GbE 1U switch w/Cumulus Linux, 32 QSFP28 ports, 2 AC PSUs, x86 2-core, standard
depth, P2C airflow, Rail Kit, RoHS6, (Cumulus License Key is required)
MSN2700-
BS2FO
Mellanox Spectrum based 40GbE 1U Open Switch with ONIE, 32 QSFP28 ports, 2 Power Supplies (AC),
Standard depth, x86 CPU, P2C airflow, Rail Kit, RoHS6
MSN2700-
BS2R
Mellanox Spectrum based 40GbE, 1U Open Ethernet Switch with Mellanox Onyx (MLNX-OS), 32 QSFP28
ports, 2 Power Supplies (AC), x86 CPU, Standard depth, C2P airflow, Rail Kit, RoHS6
MSN2700-
BS2RC
Mellanox Spectrum 40GbE 1U switch w/Cumulus Linux, 32 QSFP28 ports, 2 AC PSUs, x86 2-core, standard
depth, C2P airflow, Rail Kit, RoHS6, (Cumulus License Key is required)
MSN2700-
CS2F
Mellanox Spectrum based 100GbE, 1U Open Ethernet Switch with Mellanox Onyx (MLNX-OS), 32 QSFP28
ports, 2 Power Supplies (AC), x86 CPU, Standard depth, P2C airflow, Rail Kit, RoHS6
MSN2700-
CS2FC
Mellanox Spectrum 100GbE 1U switch w/Cumulus Linux, 32 QSFP28 ports, 2 AC PSUs, x86 2-core, standard
depth, P2C airflow, Rail Kit, RoHS6, (Cumulus License Key is required)
MSN2700-
CS2FO
Mellanox Spectrum based 100GbE 1U Open Switch with ONIE, 32 QSFP28 ports, 2 Power Supplies (AC),
Standard depth, x86 CPU, P2C airflow, Rail Kit, RoHS6
MSN2700-
CS2R
Mellanox Spectrum based 100GbE, 1U Open Ethernet Switch with Mellanox Onyx (MLNX-OS), 32 QSFP28
ports, 2 Power Supplies (AC), x86 CPU, Standard depth, C2P airflow, Rail Kit, RoHS6
MSN2700-
CS2RC
Mellanox Spectrum 100GbE 1U switch w/Cumulus Linux, 32 QSFP28 ports, 2 AC PSUs, x86 2-core, standard
depth, C2P airflow, Rail Kit, RoHS6, (Cumulus License Key is required)
MSN2700-
CS2RO
Mellanox Spectrum based 100GbE 1U Open Ethernet switch with ONIE, 32 QSFP28 ports, 2 power supplies
(AC), x86 CPU, standard depth, C2P airflow, Rail Kit
MSN2700-
CBBFO
Mellanox Spectrum based 100GbE, 1U Open Ethernet Switch with ONIE, 32 QSFP28 ports, 2 power-supplies
(DC), x86 CPU, short depth, P2C airflow, Rail Kit
1.2 SN2410 Ordering Part Numbers
OPN Marketing Description
MSN2410-
BB2FC
Mellanox Spectrum 10GbE/100GbE switch w/Cumulus Linux, 48 SFP28 ports + 8 QSFP28 ports, 2 AC PSUs, x86
2-core, short depth, P2C air flow, Rail Kit, (Cumulus License Key is required)

8
Mellanox Technologies
OPN Marketing Description
MSN2410-
BB2FO
Mellanox Spectrum based 10GbE/100GbE 1U Open Ethernet switch with ONIE, 48 SFP28 ports, 8 QSFP28 ports,
2 power supplies (AC), x86 dual core, Short depth, P2C airflow, Rail Kit, RoHS6
MSN2410-
BB2R
Mellanox Spectrum based 10GbE/100GbE 1U Open Ethernet switch with Mellanox Onyx (MLNX-OS), 48 SFP28
ports, 8 QSFP28 ports, 2 power supplies (AC), x86 dual core, Short depth, C2P airflow, Rail Kit, RoHS6
MSN2410-
BB2RO
Mellanox Spectrum based 10GbE/100GbE 1U Open Ethernet switch with ONIE, 48 SFP28 ports and 8 QSFP28
ports, 2 power supplies (AC), x86 CPU, short depth, C2P airflow, Rail Kit
MSN2410-
BB2RC
Mellanox Spectrum based 10GbE/100GbE 1U Open Ethernet switch with Cumulus Linux, 48 SFP28 ports and 8
QSFP28 ports, 2 power supplies (AC), x86 CPU, short depth, C2P airflow, Rail Kit
MSN2410-
BBBFC
Mellanox Spectrum based 10GbE/100GbE 1U Open Ethernet switch with Cumulus Linux, 48 SFP28 ports and 8
QSFP28 ports, 2 power supplies (DC), x86 CPU, short depth, P2C airflow, Rail Kit
MSN2410-
CB2F
Mellanox Spectrum based 25GbE/100GbE 1U Open Ethernet switch with Mellanox Onyx (MLNX-OS), 48 SFP28
ports, 8 QSFP28 ports, 2 power supplies (AC), x86 dual core, Short depth, P2C airflow, Rail Kit, RoHS6
MSN2410-
CB2FC
Mellanox Spectrum 25GbE/100GbE switch w/Cumulus Linux, 48 SFP28 ports + 8 QSFP28 ports, 2 AC PSUs, x86
2 core, short depth, P2C air flow, Rail Kit, (Cumulus License Key is required)
MSN2410-
CB2FO
Mellanox Spectrum based 25GbE/100GbE 1U Open Ethernet switch with ONIE, 48 SFP28 ports, 8 QSFP28 ports,
2 power supplies (AC), x86 dual core, Short depth, P2C airflow, Rail Kit, RoHS6
MSN2410-
CB2R
Mellanox Spectrum based 25GbE/100GbE 1U Open Ethernet switch with Mellanox Onyx (MLNX-OS), 48 SFP28
ports, 8 QSFP28 ports, 2 power supplies (AC), x86 dual core, Short depth, C2P airflow, Rail Kit, RoHS6
MSN2410-
CB2RC
Mellanox Spectrum 25GbE/100GbE switch w/Cumulus Linux, 48 SFP28 ports + 8 QSFP28 ports, 2 AC PSUs, x86
2 core, short depth, C2P air flow, Rail Kit, (Cumulus License Key is required)
MSN2410-
CB2RO
Mellanox Spectrum based 25GbE/100GbE 1U Open Ethernet switch with ONIE, 48 SFP28 ports, 8 QSFP28 ports,
2 power supplies (AC), x86 dual core, Short depth, C2P airflow, Rail Kit, RoHS6
MSN2410-
CBBRC
Mellanox Spectrum based 25GbE/100GbE 1U Open Ethernet switch with Cumulus Linux, 48 SFP28 ports and 8
QSFP28 ports, 2 power supplies (DC), x86 CPU, short depth, C2P airflow, Rail Kit
1.3 SN2100 Ordering Part Numbers
OPN Marketing Description
MSN2100-
BB2FC
Mellanox Spectrum 40GbE 1U switch w/Cumulus Linux, 16 QSFP28 ports, 2 AC PSUs, x86 2 core, short depth,
P2C airflow, Rails to be purchased separately, (Cumulus License Key is required)
MSN2100-
BB2FO
Mellanox Spectrum based 40GbE 1U Open Switch with ONIE, 16 QSFP28 ports, 2 AC PSUs, x86 2-core, short
depth, P2C airflow, Rail Kit must be purchased separately, RoHS6
MSN2100-
BB2R
Mellanox Spectrum based 40GbE, 1U Open Ethernet Switch with Mellanox Onyx (MLNX-OS), 16 QSFP28 ports,
2 AC PSUs, x86 2-core, short depth, C2P airflow, Rail Kit must be purchased separately, RoHS6
MSN2100-
BB2RC
Mellanox Spectrum 40GbE 1U switch w/Cumulus Linux, 16 QSFP28 ports, 2 AC PSUs, x86 2-core, short depth,
C2P airflow, Rails to be purchased separately, (Cumulus License Key is required)

9
Mellanox Technologies
OPN Marketing Description
MSN2100-
BB2RO
Mellanox Spectrum based 40GbE 1U Open Ethernet switch with ONIE, 16 QSFP28 ports, 2 power supplies (AC),
x86 CPU, short depth, C2P airflow. Rail Kit must be purchased separately
MSN2100-
CB2F
Mellanox Spectrum based 100GbE, 1U Open Ethernet Switch with Mellanox Onyx (MLNX-OS), 16 QSFP28
ports, 2 AC PSUs, x86 2-core, short depth, P2C airflow, Rail Kit must be purchased separately, RoHS6
MSN2100-
CB2FC
Mellanox Spectrum 100GbE 1U switch w/Cumulus Linux, 16 QSFP28 ports, 2 AC PSUs, x86 2-core, short depth,
P2C airflow, Rails to be purchased separately, (Cumulus License Key is required)
MSN2100-
CB2FO
Mellanox Spectrum based 100GbE 1U Open Switch with ONIE, 16 QSFP28 ports, 2 AC PSUs, x86 2-core, short
depth, P2C airflow, Rail Kit must be purchased separately, RoHS6
MSN2100-
CB2R
Mellanox Spectrum based 100GbE, 1U Open Ethernet Switch with Mellanox Onyx (MLNX-OS), 16 QSFP28
ports, 2 AC PSUs, x86 2-core, short depth, C2P airflow, Rail Kit must be purchased separately, RoHS6
MSN2100-
CB2RC
Mellanox Spectrum 100GbE 1U switch w/Cumulus Linux, 16 QSFP28 ports, 2 AC PSUs, x86 2-core, short depth,
C2P airflow, Rails to be purchased separately, (Cumulus License Key is required)
MSN2100-
CB2RO
Mellanox Spectrum based 100GbE 1U Open Ethernet switch with ONIE, 16 QSFP28 ports, 2 power supplies
(AC), x86 CPU, short depth, C2P airflow. Rail Kit must be purchased separately
1.4 SN2010 Ordering Part Numbers
OPN Marketing Description
MSN2010-
CB2F
Mellanox Spectrum-based 25GbE/100GbE, 1U Open Ethernet Switch with Mellanox Onyx, 18 SFP28 and 4
QSFP28 ports, 2 Power Supplies (AC), short depth, x86 quad core, P2C airflow, Rail Kit must be purchased
separately
MSN2010-
CB2FC
Mellanox Spectrum-based 25GbE/100GbE 1U switch w/Cumulus Linux, 18 SFP28 and 4 QSFP28 ports, 2 AC
PSUs, x86 4-core, short depth, P2C airflow, Rails to be purchased separately, (Cumulus License is provided at no
cost with purchase of SUP-SN2010-CL-XX)
MSN2010-
CB2FO
Mellanox Spectrum-based 25GbE/100GbE, 1U Open Ethernet Switch with ONIE, 18 SFP28 ports and 4 QSFP28
ports, 2 Power Supplies (AC), x86 quad core, short depth, P2C airflow, Rail Kit must be purchased separately
MSN2010-
CB2R
Mellanox Spectrum-based 25GbE/100GbE, 1U Open Ethernet Switch with Mellanox Onyx, 18 SFP28 ports and 4
QSFP28 ports, 2 Power Supplies (AC), short depth, x86 quad core, C2P airflow, Rail Kit must be purchased
separately
MSN2010-
CB2RC
Spectrum-based 25GbE/100GbE 1U switch w/Cumulus Linux, 18 SFP28 and 4 QSFP28 ports, 2 AC PSUs, x86
4-core, short depth, C2P airflow, Rails to be purchased separately, (Cumulus License is provided at no cost with
purchase of SUP-SN2010-CL-XX)
MSN2010-
CB2RO
Mellanox Spectrum based 25GbE/100GbE 1U Open Ethernet switch with ONIE, 18 SFP28 ports and 4 QSFP28
ports, 2 power supplies (AC), x86 CPU, short depth, C2P airflow. Rail Kit must be purchased separately

10
Mellanox Technologies
2 Introduction
Mellanox Spectrum® based 1U switch systems are an ideal spine and Top of Rack (ToR) solution, allowing maximum flexibility, with
port speeds spanning from 10Gb/s to 100Gb/s per port, and port density that enables full rack connectivity to any server at any speed.
The uplink ports allow a variety of blocking ratios that suit any application requirement. Powered by the Mellanox Spectrum ASIC,
the systems carry whopping switching and processing capacities in a compact 1U form factor.
Keeping with the Mellanox tradition of setting performance record switch systems, the Mellanox Spectrum-based systems introduce
the world’s lowest latency for 100GbE switching and routing elements, and do so while having the lowest power consumption in the
market. They enable the use of 10, 25, 40, 50 and 100GbE in a large scale without changing power infrastructure facilities.
The Mellanox Spectrum-based 1U switch systems are a part of Mellanox’s complete end-to-end solution, which provides 10GbE
through 100GbE interconnectivity within the data center. Other devices in this solution include ConnectX®-4 based network interface
cards, and LinkX® copper or fiber cabling/transceivers. This end-to-end solution is topped with NEO, a management application that
relieves some of the major obstacles standing in the way when deploying a network. NEO enables a fully certified and interoperable
design, speeds up time to service and RoI. The systems introduce hardware capabilities for multiple tunneling protocols that enable
increased reachability and scalability for today’s data centers. Implementing MPLS, NVGRE and VXLAN tunneling encapsulations in
the network layer of the data center allows more flexibility for terminating a tunnel by the network, in addition to termination on the
server endpoint.
While Mellanox Spectrum provides the thrust and acceleration that powers the switch systems, they get yet another angle of
capabilities, running with a powerful x86-based processor, which allows them to not only be the highest performing switch fabric
elements, but also grants them the ability to incorporate a Linux running server into the same device. This opens up multiple
application aspects of utilizing the high CPU processing power and the best switching fabric, to create a powerful machine with
unique appliance capabilities that can improve numerous network implementation paradigms. The Mellanox Spectrum-based 1U
switch systems support the Open Network Install Environment (ONIE) for zero touch installations of network operating systems.
While all Ethernet systems can be purchased preloaded with Mellanox Onyx (MLNX-OS), the SN2000 switches (in both the 100GbE
and the 40GbE versions) are offered, in addition, with Cumulus Linux support, as an alternative operating system. For a full list of all
available ordering options, see Ordering Information.
SN2700 Front View
SN2740 Front View
SN2410 Front View
SN2100 Front View

11
Mellanox Technologies
SN2010 Front View
SN2700 and SN2410 Rear View
SN2740 Rear View
SN2100 Rear View
SN2010 Rear View
2.1 Speed and Switching Capabilities
The table below describes maximum throughput and interface speed per system model.
System Model 10/25GbE SFP28 Interfaces* 40/50/56/100GbE QSFP28 Interfaces* Max Throughput
SN2700 64
(using QSFP to SFP splitter
cables)
32 6.4Tb/s

12
Mellanox Technologies
System Model 10/25GbE SFP28 Interfaces* 40/50/56/100GbE QSFP28 Interfaces* Max Throughput
SN2740 64
(using QSFP to SFP splitter
cables)
32 6.4Tb/s
SN2410 Total 64, 48SFP+16
(using QSFP to SFP splitter
cables)
8 4Tb/s
SN2100 64
(using QSFP to SFP splitter
cables)
16
(or 32 50GbE interfaces when using
QSFP to 2xQSFP splitter cables)
3.2Tb/s
SN2010 34
(using QSFP to SFP splitter
cables)
4
(or 8 50GbE interfaces when using
QSFP to 2xQSFP splitter cables)
1.7Tb/s
*The system can support different interfaces and speed rates using QSFP+ to SFP+ adapters or hybrid cables. For further information,
see Splitter (Breakout) Cables and Adapters.
2.2 Management Interfaces, PSUs and Fans
The table below lists the various management interfaces, PSUs and fans per system model.
System Model USB MGT Console PSU Fan
SN2700 Rear Rear (2 ports) Rear 2 units 4 units
SN2740 Front Front (1 port) Front 2 units 4 units
SN2410 Rear Rear (2 ports) Rear 2 units 4 units
SN2100 Front (mini USB) Front (1 port) Front 2 units (non-
replaceable)
4 units (non-
replaceable)
SN2010 Front Front (1 port) Front 2 units (non-
replaceable)
4 units (non-
replaceable)
2.3 Features
For a full feature list, please refer to the system’s product brief. Go to http://www.mellanox.com. In the main menu, click on Products
> Ethernet Switch Systems, and select the desired product page.
2.4 Certifications
The list of certifications (such as EMC, Safety and others) per system for different regions of the world is located on the Mellanox
website at http://www.mellanox.com/page/environmental_compliance.

13
Mellanox Technologies
3 Installation
3.1 System Installation and Initialization
Installation and initialization of the system require attention to the normal mechanical, power, and thermal precautions for rack-
mounted equipment.
The installation procedure for the system involves the following phases:
Step Procedure See
1 Follow the safety warnings Safety Warnings
2 Pay attention to the air flow consideration within the system
and rack
Air Flow
3 Make sure that none of the package contents is missing or
damaged
Package Contents
4 Mount the system into a rack enclosure 19" System Mounting Options
5 Power on the system Initial Power On
6 Perform system bring-up System Bring-Up
7 [Optional] FRU replacements FRU Replacements
3.2 Safety Warnings
Prior to the installation, please review the safety warnings. Note that not all warnings may apply to all models.
Safety Warnings (English)
Installation Instructions
Read all installation instructions before connecting the equipment to the power source.
Bodily Injury Due to Weight
The rack mounting holes conform to the EIA-310 standard for 19-inch racks. Take precautions to guarantee proper
ventilation in order to maintain good airflow at ambient temperature.

Unless otherwise specified, Mellanox products are designed to work in an environmentally controlled data center with low
levels of gaseous and dust (particulate) contamination.
The operation environment should meet severity level G1 as per ISA 71.04 for gaseous contamination and ISO 14644-1
class 8 for cleanliness level.

Safety warnings are provided here in the English language. For safety warnings in other languages, refer to the 1U Switch
Installation Safety Instructions document available on mellanox.com.


14
Mellanox Technologies
•
•
Use enough people to safely lift this product.
Heavy Equipment
This equipment is heavy and should be moved using a mechanical lift to avoid injuries.
Risk of Electric Shock!
With the fan module removed power pins are accessible within the module cavity.
Do not insert tools or body parts into the fan module cavity.
For AC powered switch systems: Disconnecting one power supply only disconnects one module. To isolate the unit
completely, all connected power supplies must be disconnected.
Over-temperature
This equipment should not be operated in an area with an ambient temperature exceeding the maximum recommended: 45°C
(113°F). Moreover, to guarantee proper ventilation, allow at least 8cm (3 inches) of clearance around the ventilation openings.
Stacking the Chassis
The chassis should not be stacked on any other equipment. If the chassis falls, it can cause bodily injury and equipment damage.
Redundant Power Supply Connection - Electrical Hazard
This product includes a redundant power or a blank in its place. In case of a blank power supply, do not operate the product with
the blank cover removed or not securely fastened.
Double Pole/Neutral Fusing
This system has double pole/neutral fusing. Remove all power cords before opening the cover of this product or touching any
internal parts.
Multiple Power Inlets
Risk of electric shock and energy hazard. The PSUs are all independent. Disconnect all power supplies to ensure a powered
down state inside of the switch platform.
During Lightning - Electrical Hazard
During periods of lightning activity, do not work on the equipment or connect or disconnect cables.
Copper Cable Connecting/Disconnecting
Copper cables are heavy and not flexible, as such they should be carefully attached to or detached from the connectors. Refer to
the cable manufacturer for special warnings/instructions.

15
Mellanox Technologies
Rack Mounting and Servicing
When this product is mounted or serviced in a rack, special precautions must be taken to ensure that the system remains stable.
In general you should fill the rack with equipment starting from the bottom to the top.
Equipment Installation
This equipment should be installed, replaced, and/or serviced only by trained and qualified personnel.
Equipment Disposal
Disposal of this equipment should be in accordance to all national laws and regulations.
Local and National Electrical Codes
This equipment should be installed in compliance with local and national electrical codes.
Installation Codes
This device must be installed according to the latest version of the country national electrical codes. For North America,
equipment must be installed in accordance to the applicable requirements in the US National Electrical Code and the Canadian
Electrical Code.
Battery Replacement
Warning: Replace only with UL Recognized battery, certified for maximum abnormal charging current not less than 4mA. There
is a risk of explosion should the battery be replaced with a battery of an incorrect type. Dispose of used batteries according to the
instructions.
UL Listed and CSA Certified Power Supply Cord
For North American power connection, select a power supply cord that is UL Listed and CSA Certified, 3 - conductor, [16
AWG], terminated with a molded plug rated at 125 V, [13 A], with a minimum length of 1.5m [six feet] but no longer than 4.5m.
For European connection, select a power supply cord that is internationally harmonized and marked “<HAR>”, 3 - conductor,
minimum 1.0 mm2 wire, rated at 300 V, with a PVC insulated jacket. The cord must have a molded plug rated at 250 V, 10 A.
Installation codes
This device must be installed according to the latest version of the country national electrical codes. For North America,
equipment must be installed in accordance to the applicable requirements in the US National Electrical Code and the Canadian
Electrical Code.
Interconnection of Units
Cables for connecting to the unit RS232 and Ethernet Interfaces must be UL certified type DP-1 or DP-2. (Note- when residing
in non LPS circuit)
Overcurrent Protection
A readily accessible Listed branch circuit overcurrent protective device rated 20 A must be incorporated in the building wiring.
Do Not Use the Switch as a Shelf or Work Space
Caution: Slide/rail mounted equipment is not to be used as a shelf or a work space. The rails are not intended for sliding
the unit away from the rack. It is for permanent installation at final resting place only, not used for service and maintenance

16
Mellanox Technologies
•
•
WEEE Directive
According to the WEEE Directive 2002/96/EC, all waste electrical and electronic equipment (EEE) should be collected
separately and not disposed of with regular household waste. Dispose of this product and all of its parts in a responsible
and environmentally friendly way.
Country of Norway Power Restrictions
This unit is intended for connection to a TN power system and an IT power system of Norway only.
3.3 Air Flow
Mellanox systems are offered with two air flow patterns:
Power (rear) side inlet to connector side outlet - marked with blue power supplies/fans FRUs’ handles.
Air Flow Direction Marking - Power Side Inlet to Connector Side Outlet
Connector (front) side inlet to power side outlet - marked with red power supplies/fans FRUs’ handles.
Air Flow Direction Marking - Connector Side Inlet to Power Side Outlet
The table below provides an air flow color legend and respective OPN designation.
Direction Description and OPN Designation
Connector side inlet to power side outlet. Red latches are placed on the power inlet
side.
OPN designation is “-R”.
The following information does not apply to SN2100/SN2010. In the SN2100/SN2010 systems, the fan units are non-
replaceable.

All servers and systems in the same rack should be planned with the same airflow direction.
All FRU components need to have the same air flow direction. A mismatch in the air flow will affect the heat dissipation.


17
Mellanox Technologies
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Direction Description and OPN Designation
Power side inlet to connector side outlet. Blue latches are placed on the power inlet
side.
OPN designation is “-F”.
3.4 Package Contents
Before installing your new system, unpack it and check against the parts list below that all the parts have been sent. Check the parts
for visible damage that may have occurred during shipping.
The SN2700 and SN2410 package content is as follows:
1 – System
1 – Rail kit
1 – Power cable for each power supply unit – Type C13-C14
1 – Cable retainer for each power supply unit
1 – DB9 to RJ-45 2m harness
1 - RJ-45 to RJ-45 2m harness
The SN2100/SN2010 package content is as follows:
1 – System
1 – Power cable for each power supply unit – Type C13-C14
1 – DB9 to RJ-45 2m harness
3.5 19” System Mounting Options
By default, the SN2700 systems are shipped with the static rail kit described SN2700 Static Rail Kit.
The SN2410 and SN2740 systems are shipped with the static rail kit described in SN2740/SN2410 Static Rail Kit.
For the telescopic rail kit installation instructions (can be used with SN2700 only), see SN2700 Telescopic Rail Kit.
The SN2100/SN2010 system is shipped without a rail kit and a designated rail kit can be purchased separately. For installation
instructions, see SN2100/SN2010 Side by Side Mounting Rail Kit.
SN2100/SN2010 Static Single Switch Rail Kit
3.6 SN2700 Static Rail Kit
Kit OPN Rack Size and Rack Depth Range
MTEF-KIT-A Short (17”-24”) or Standard (24”-34”)
The following parts are included in the static rail kit (see figure below):
2x Rack mount rails (A)
A designated rail kit for the SN2100/SN2010 systems can be purchased separately.

If anything is damaged or missing, contact your sales representative at [email protected].


18
Mellanox Technologies
•
•
•
•
•
•
•
2x Rack mount brackets (B)
2x Rack mount blades (C)
8x M6 Standard cage nuts¹ ² and 8x M6 Standard pan-head Phillips screws¹ (D)
4x Phillips100 DEG F.H TYPE-I ST.ST 6-32 X 1/4 screws with a round patch (E)
¹ Other threads are available by special order: M5, 10-32, 12-24. ² G-type cage-nut is available by special order.
Rack Rail Kit Parts
Prerequisites:
Before mounting the system to the rack, select the way you wish to place the system. Pay attention to the airflow within the rack
cooling, connector and cabling options.
While planning how to place the system, consider the two installation options shown in the figure below, and review the following
points:
Make sure the system air flow is compatible with your installation selection. It is important to keep the airflow within the rack
in the same direction.
Note that the part of the system to which you choose to attach the rails (the front panel direction, as demonstrated in Option 1
or the FRUs direction, as demonstrated in Option 2) will determine the system’s adjustable side. The system’s part to which
the brackets are attached will be adjacent to the cabinet.
The FRU side is extractable. Mounting the rack brackets inverted to the FRU side (Option 2) will allow you to slide the FRUs,
in and out.
Installation Option 1 & Option 2

19
Mellanox Technologies
1.
2.
To mount the system into the rack:
Attach the left and right rack mount rails (A) to the switch, by gently pushing the switch chassis’ pins through the slider key
holes, until locking occurs.
Secure the chassis in the rails by screwing 2 flat head Phillips screws (E) in the designated points with a torque of 1.5±0.2
Nm.
At least two people are required to safely mount the system in the rack.


20
Mellanox Technologies
3.
4.
5.
Attaching the Rails to the Chassis
Attach the left and right rack mount brackets (B) to the switch, by gently pushing the switch chassis’ pins through the slider
key holes, until locking occurs. Secure the system in the brackets by screwing the remaining 2 flat head Phillips screws (E) in
the designated points with a torque of 1.5±0.2 Nm.
Attaching the Brackets to the Chassis
Install 8 cage nuts in the desired slots of the rack: 4 cage nuts in the non-extractable side (in the top and bottom holes only)
and 4 cage nuts in the extractable side.
Installing the Cage Nuts
While your installation partner is supporting the system’s weight, perform the following steps:
Mount the system into the rack enclosure, and attach the brackets installed on the system to the rack’s posts. Secure the
brackets to the rack’s posts by inserting four M6 screws in the designated cage nuts, as described in the figure below. Do not
tighten the screws yet.
While each rack U (unit) consists of three holes, the cage nut should be installed vertically with its ears engaging the
top and bottom holes only.

