SERVICE MANUAL
MVD4540C
Design and specifications are subject to change without notice.
ORIGINAL
MFR'S VERSION A
DVD VIDEO PLAYER & VHS VIDEO CASSETTE RECORDER

CAUTION
THIS DIGITAL VIDEO PLAYER EMPLOYS ALASER SYSTEM.
TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ THIS SERVICE MANUAL CARE-
FULLYAND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE,
CONTACTAN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.
USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
TO PREVENT DIRECT EXPOSURE TO LASER BEAM, DO NOT TRY TO OPEN THE ENCLOSURE.
VISIBLE LASER RADIATION MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO NOT
STARE INTO BEAM.
A1-1
Location of the required Marking
The rating sheet and the safety caution are on the rear of the unit.
PREPARATION OF SERVICING
The laser diode used for a pickup head may be destroyed with external static electricity.
Moreover, even if it is operating normally after repair, when static electricity discharge is received at the
time of repair, a life of product may become short.
Please perform the following measure against static electricity, be careful of destruction of a laser diode
enough at the time of repair, and work.
• It works on the desk which performed measures against static electricity, such as conductive mat.
• Soldering iron with ground wire or ceramic type is used.
• A worker needs to use a ground conductive wrist strap for body.
CERTIFICATION: COMPLIES WITH FDARADIATION PERFORMANCE
STANDARDS, 21 CFR SUBCHAPTER J.

IMPORTANT SERVICE SAFETY INFORMATION
Safety precautions to be followed during servicing:
1.
2.
Parts marked with an are critical parts for safety. Replace only with the one described in the parts
list.
Before returning the DVD product to the customer, make the appropriate leakage current check or
resistance measurements to ensure that exposed parts are properly insulated from the supply circuit.
A leakage current check is recommended for this unit. Plug the AC line cord directly into a 120V 60Hz AC
outlet (do not use an isolation transformer for this check). Use a leakage current tester (Fig. 1) or a
metering system which complies with Underwriters Laboratories (UL 1409). Measure for current from all
exposed metal parts of the cabinet to a known earth ground: particularly, any exposed metal part having a
return path to the chassis. Any current measured must not exceed 0.5mA. Any measurement not within
the limits outlined above are indicative of a potential shock hazard and corrective action must be taken
before returning the unit to the customer.
KNOWN EARTH
GROUND
1.5K ohm
0.15 µF
(Reading should not be above 0.5mA)
Leakage Current Tester
TEST PROBE
Test all exposed
metal surfaces
PRODUCT UNDER TEST
2-Blade polarized
type cord set
Fig. 1 AC Leakage Test
A1-2

A1-3
IMPORTANT SAFEGUARDS
1.
2.
3.
4.
5.
6.
7.
8.
8A.
9.
10.
11.
12.
13.
14.
15.
16.
READ INSTRUCTIONS
All the safety and operating instructions should be read before the unit is operated.
RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
HEED WARNINGS
All warnings on the unit and in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
CLEANING
Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
ATTACHMENTS
Do not use attachments not recommended by the unit’s manufacturer as they may cause hazards.
WATER AND MOISTURE
Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool.
ACCESSORIES
Do not place this unit on an unstable cart, stand, tripod, bracket, or table. The
unit may fall, causing serious injury, and serious damage to the unit. Use only
with a cart, stand, tripod, bracket, or table recommended by the manufacturer.
An appliance and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the appliance and cart
combination to overturn.
VENTILATION
Slots and openings in the cabinet and in the back or bottom are provided for ventilation, to ensure reliable
operation of the unit, and to protect it from overheating. These openings must not be blocked or covered. The
openings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface. This unit
should never be placed near or over a radiator or heat source. This unit should not be placed in a built-in
installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions
have been adhered to.
POWER SOURCES
This unit should be operated only from the type of power source indicated on the rating plate. If you are not sure
of the type of power supply to your home, consult your appliance dealer or local power company. For units
intended to operate from battery power, or other sources, refer to the operating instructions.
GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug
fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the polarized plug. If your unit is equipped with a 3-wire
grounding-type plug, a plug having a third (grounding) pin, this plug will only fit into a grounding-type power
outlet. This too, is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.
POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they
exit from the appliance.
LIGHTNING
To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit
due to lightning and power line surges.
POWER LINES
An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits, as contact with them might be
fatal.
OVERLOADING
Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
OBJECT AND LIQUID ENTRY
Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out
parts that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.
PORTABLE CART WARNING
(symbol provided by RETAC)
S3125A

A1-4
IMPORTANT SAFEGUARDS (CONTINUED)
OUTDOOR ANTENNA GROUNDING
If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded
so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National
Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and support-
ing structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
SERVICING
Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service personnel.
DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following
conditions:
REPLACEMENT PARTS
When replacement parts are required, be sure the service technician uses replacement parts specified by the
manufacturer or those that have the same characteristics as the original parts.
Unauthorized substitutions may result in fire, electric shock or other hazards.
SAFETY CHECK
Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to
determine that the unit is in proper operating condition.
WALL OR CEILING MOUNTING
The product should be mounted to a wall or ceiling only as recommended by the manufacturer.
HEAT
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
DISC TRAY
Keep your fingers well clear of the disc tray as it is closing. It may cause serious personal injury.
CONNECTING
When you connect the product to other equipment, turn off the power and unplug all of the equipment from the
wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's manual of
the other equipment carefully and follow the instructions when making any connections.
SOUND VOLUME
Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume sound
may cause hearing or speaker damage.
SOUND DISTORTION
Do not allow the product output distorted sound for a longtime. It may cause speaker overheating and fire.
HEADPHONES
When you use the headphones, keep the volume at a moderate level. If you use the headphones continuously
with high volume sound, it may cause hearing damage.
LEASER BEAM
Do not look into the opening of the disc tray or ventilation opening of the product to see the source of the laser
beam. It may cause sight damage.
DISC
Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal
injury and product malfunction.
NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer’s attention toArticle 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as practical.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
a.
b.
c.
d.
e.
f.
When the power-supply cord or plug is damaged.
If liquid has been spilled, or objects have fallen into the unit.
If the unit has been exposed to rain or water.
If the unit does not operate normally by following the operating instructions. Adjust only those controls that
are covered by the operating instructions, as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to restore the unit to its normal
operation.
If the unit has been dropped or the cabinet has been damaged.
When the unit exhibits a distinct change in performance, this indicates a need for service.

A1-5
EXAMPLE OF ANTENNA GROUNDING AS PER THE NATIONAL ELECTRICAL CODE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ANTENNA LEAD
IN WIRE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND
CLAMP
ELECTRIC SERVICE
EQUIPMENT
NEC-NATIONAL ELECTRICAL CODE
S2898A
IMPORTANT SAFEGUARDS (CONTINUED)

Before removing Pick Up PCB and DVD PCB connector, make the short circuit on the position as
shown Fig. 1 using a soldering. If you remove the DVD Deck with no soldering, the Laser may be
damaged.
WHEN REPLACING DVD DECK
[ When the removal of the DVD Deck ]
[ When the installation of the DVD Deck ]
Remove all the soldering on the short circuit position after the connection of Pick Up PCB and DVD
PCB connector.
Fig. 1
Make the sort circuit
using a soldering.
Pick Up PCB
A1-6

TAPE REMOVAL METHOD AT NO POWER SUPPLY
Fig. 1
Fig. 2
PARENTAL CONTROL - RATING LEVEL
4 DIGIT PASSWORD CANCELLATION
If the stored 4 digit password in the Rating Level menu needs to be cancelled, please follow the steps below.
Turn Unit ON.
Press and hold the '7' key on the remote control unit.
Simultaneously press and hold the 'STOP' key on the front panel.
Hold both keys for more than 3 seconds.
The On Screen Display message 'PASSWORD CLEAR' will appear.
The 4 digit password has now been cleared
1.
2.
3.
4.
5.
6.
Remove the Top Cabinet, Front Cabinet and DVD Block. (Refer to item 1 of the
DISASSEMBLY INSTRUCTIONS.)
Remove the screw 1of the Deck Chassis and remove the Loading Motor. (Refer to Fig. 2)
Rotate the Pinch Roller Cam in the direction of the arrow by hand to slacken the Video Tape.
Rotate the Clutch Ass'y either of the derections to wind the Video Tape in the Cassette Case.
Repeat the above step 3~4. Then take out the Video Cassette from the Deck Chassis. Be careful not to
scratch on the tape.
1.
2.
3.
4.
5.
Main Cam Clutch Ass'y
Main Chassis (Front Side)
Loading Motor
Capstan DD Unit
Pinch Roller Cam
Screw 1
A1-7
1.
2.
3.
Remove the Back Cabinet and TV//DVD/VCR Block. (Refer to item 1 of the DISASSEMBLY
INSTRUCTIONS.)
Rotate the Main Gear in the direction of the arrow by hand.
(Refer to Fig. 1)
Draw the Tray.
DISC REMOVAL METHOD AT NO POWER SUPPLY
Fig. 1
DVD DeckMain Gear

CONTENTS
CAUTION ....................................................................................................................................
PREPARATION OF SERVICING ...............................................................................................
IMPORTANT SERVICE SAFETY INFORMATION ....................................................................
IMPORTANT SAFEGUARDS.....................................................................................................
WHEN REPLACING DVD DECK ...............................................................................................
TAPE REMOVAL METHOD AT NO POWER SUPPLY ............................................................
DISC REMOVAL METHOD AT NO POWER SUPPLY .............................................................
PARENTAL CONTROL-RATION LEVEL ..................................................................................
CONTENTS .................................................................................................................................
GENERAL SPECIFICATIONS ...................................................................................................
DISASSEMBLY INSTRUCTIONS
1. REMOVAL OF MECHANICAL PARTS AND P. C. BOARDS............................................
2. REMOVAL OF VCR DECK PARTS ...................................................................................
3. REMOVAL OF DVD DECK PARTS ...................................................................................
4. REMOVAL AND INSTALLATION OF FLAT PACKAGE IC ...............................................
KEY TO ABBREVIATIONS ........................................................................................................
SERVICE MODE LIST ................................................................................................................
PREVENTIVE CHECKS AND SERVICE INTERVALS..............................................................
WHEN REPLACING EEPROM (MEMORY) IC ..........................................................................
SERVICING FIXTURES AND TOOLS .......................................................................................
PREPARATION FOR SERVICING.............................................................................................
MECHANICAL ADJUSTMENTS ................................................................................................
ELECTRICAL ADJUSTMENTS..................................................................................................
BLOCK DIAGRAMS
DVD..........................................................................................................................................
Y/C/AUDIO/CCD/HEAD AMP .................................................................................................
SYSTEM CONTROL ..............................................................................................................
OPERATION/DISPLAY ..........................................................................................................
Hi-Fi/DEMODULATOR ...........................................................................................................
TUNER/JACK .........................................................................................................................
POWER ..................................................................................................................................
PRINTED CIRCUIT BOARDS
DVD..........................................................................................................................................
VCR/OPERATION ..................................................................................................................
LOADING MOTOR/SW ..........................................................................................................
SCHEMATIC DIAGRAMS
MPEG/MICON/DSP.................................................................................................................
MEMORY .................................................................................................................................
RF AMP/DSP ...........................................................................................................................
AUDIO/VIDEO .........................................................................................................................
Y/C/AUDIO/CCD/HEAD AMP ................................................................................................
SYSCON.................................................................................................................................
TUNER/JACK .........................................................................................................................
OPERATION/DISPLAY ..........................................................................................................
Hi-Fi/DEMODULATOR ...........................................................................................................
POWER ..................................................................................................................................
OPERATION/LED....................................................................................................................
LOADING MOTOR/SW ...........................................................................................................
INTERCONNECTION DIAGRAM ...............................................................................................
WAVEFORMS .............................................................................................................................
MECHANICAL EXPLODED VIEW .............................................................................................
CHASSIS EXPLODED VIEWS ...................................................................................................
DVD DECK EXPLODED VIEW...................................................................................................
MECHANICAL REPLACEMENT PARTS LIST .........................................................................
CHASSIS REPLACEMENT PARTS LIST..................................................................................
DVD DECK REPLACEMENT PARTS LIST...............................................................................
ELECTRICAL REPLACEMENT PARTS LIST...........................................................................
A1-1
A1-1
A1-2
A1-3~A1-5
A1-6
A1-7
A1-7
A1-7
A2-1
A3-1~A3-7
B1-1, B1-2
B2-1~B2-6
B3-1~B3-3
B4-1, B4-2
C1-1, C1-2
C2-1
C3-1, C3-2
C4-1
D1-1
D1-1
D2-1~D2-4
D3-1, D3-2
E-1, E-2
E-3, E-4
E-5, E-6
E-7, E-8
E-9, E-10
E-11, E-12
E-13, E-14
F-1, F-2
F-3~F-6
F-7, F-8
G-1, G-2
G-3, G-4
G-5, G-6
G-7, G-8
G-9, G-10
G-11, G-12
G-13, G-14
G-15, G-16
G-17, G-18
G-19, G-20
G-21, G-22
G-23, G-24
G-25, G-26
H-1~H-3
I1-1
I2-1, I2-2
I3-1
J1-1
J2-1
J3-1
J4-1, J4-2
A2-1

GENERAL SPECIFICATIONS
G-1 Outline of the product DVD VIDEO PLAYER & VHS Player / Recorder
G-2 DVD System Color System NTSC
Disc DVD, CD-DA, CD-R/RW
Disc Diameter 120 mm , 80 mm
Deck Disc Loading System Front Disc Loading
Motor 3 Motors
Pick up 1-Lens 2-Beams System
Playback time (Max) DVD 1-Layer 135min (4.7GB)
DVD 2-Layer 245min (8.5GB)
CD 74min
VIDEO CD --min
Search speed Fwd 4 steps
Actual 2-45 times (DVD)
4-40 times (CD)
Rev 4 steps
Actual 2-45 times (DVD)
4-40 times (CD)
Slow speed Fwd 1/7-1/2 times
Actual --
Rev --
Actual --
G-3 VCR System VHS Player / Recorder
System Video System NTSC
Hi-Fi STEREO Yes
NTSC PB(PAL60Hz) No
Deck DECK OVD-7
Loading System Front
Motor 3
Heads Video Head 4Head
FM Audio Head 2Head
Audio / Control Mono/Yes
Erase (Full Track Erase) Yes
Erase (Normal Audio Track Erase) No
Tape Rec PAL -
Speed NTSC SP/SLP
Play PAL -
NTSC SP/LP/SLP
Fast Forward / Rewind Time (Approx.) at 25oC FF:4'50"/REW:2'30"
with Cassette T-120
Forward/Reverse NTSC or PAL-M SP/LP/SLP = 3x,5x / 7x,9x / 9x,15x
Picture Search PAL or SECAM -
Frame Advance Yes
Slow Speed 1/10
G-4 Tuning Broadcasting System US System M
System Tuner and System 1Tuner
Receive CH Destination US (w/CATV)
Tuning System F-Synth
Input Impedance VHF/UHF 75 OHM
CH Coverage 2-69,4A,A-5~ A-1,A~I,
J~ W, W+1-W+84
Intermediate Picture (FP) 45.75 MHz
Frequency Sound (FS) 41.25 MHz
FP-FS 4.50 MHz
Preset CH -
RF Converter Output Yes
Channel 3 or 4 ch
Level / Impedance 66 dBu / 75 Ohm
Sound Selector No
Stereo / Dual TV Sound US-ST
Tuner Sound Muting Yes
A3-1

GENERAL SPECIFICATIONS
G-5 Power Power Source AC 120V 60Hz
DC -
Power Consumption 18 W at 120V 60Hz
Stand by 2 W at 120V 60Hz
Per Year -- W
Protector Power Fuse Yes
Safety Circuit Yes
IC Protector(Micro Fuse) No
G-6 Regulation Safety UL
Radiation FCC
Laser DHHS
G-7 Temperature Operation 5oC - 40oC
Storage -20oC - 60oC
G-8 Operating Humidity Less than 80% RH
G-9 Signal Video Signal Output Level 1 V p-p/75 ohm (DVD,VCR)
S/N Ratio (Weighted) 65 dB(DVD) 50 dB(VCR)
Horizontal Resolution 500 Lines (DVD) 230 Lines(VCR Mode)
RGB Signal Output Level -
Audio Signal Input Level Microphone -
Input Level Line -8 dBm/ 50k ohm (VCR, 0dBm=0.775Vrms)
Output Level Line -
8
dB
m
/
1k
o
h
m
(VCR
,
0dBm=0.775Vrms)
-12dBm/ 1k ohm (DVD, -20dBFs
0dBFs=2 0Vrms)
Digital Output Level 0.5 V p-p / 75 ohm(DVD)
S/N Ratio at (Weighted) 90dB(DVD), 42dB(VCR at SP)
Harmonic Distortion (1KHz) Typical 0.02% (1KHz) (DVD) , 1.5% (1KHz) (VCR)
Frequency Response : DVD Mode at DVD 4 Hz - 22 KHz
DVD Mode at VIDEO CD -
DVD Mode at CD 4 Hz - 20 KHz
VCR Mode at SP 100Hz - 10 KHz
VCR Mode at LP -
VCR Mode at SLP 100Hz - 4 KHz
Hi-Fi Audio Signal Dynamic Range : More than 90dB
Frequency Response 20Hz ~20kHz
Wow And Flutter : Less than 0.01 %Wrms
Channel Separation : More than 60 dB
Harmonic Distortion : Less than 0.01
A3-2

GENERAL SPECIFICATIONS
G-10 On Screen Menu Yes
Display (DVD) Menu Type Character
Language Yes
Menu Yes
Subtitle Yes
Audio Yes
Picture Yes
TV Screen Size Yes
OSD Display On/Off Yes
JPEG Interval No
Select Files No
E.B.L. (Enhanced Black Level) No
Sound Yes
DRC (Dynamic Range Control) Yes
Dialogue On:DRC(TV)/ Off:DRC(Std) No
dts Decode No
Output (5.1ch/2ch) No
Surround On/Off No
Center On/Off No
Sub Woofer On/Off No
Parental Yes
Password Lock/Unlock Yes
Rating Level Yes
Other Yes
OSD Language (Set up Language) Yes
Output (RGB / Composite) No
Open Yes
Close Yes
No disc Yes
Reading Yes
Play Yes
Still/Pause Yes
Stop Yes
Prohibit Mark Yes
Step Yes
Skip (>>|) Yes
Skip (|<<) Yes
Random Yes (CD, MP3)
Repeat Yes
Slow+ ## Yes
Slow- ## No
Search+ ## Yes
Search- ## Yes
Jump Yes
Resume Yes
Title No. Yes
Chapter No. Yes
Track No. Yes
Time Yes
Subtitle No. Yes
Angle No. Yes
Vocal On/Off Yes
Audio No. Yes
Audio Stereo L/R No
Zoom Yes
Marker No. Yes
Spatializer (N-2-2) No
Program Play Back Yes (CD, MP3)
MP3 Folder Name Yes
File Name Yes
File No Yes
Time Yes
Track No Yes
Progressive Scan Out ON/OFF Yes
A3-3

GENERAL SPECIFICATIONS
On Screen Menu Yes
Display(VCR) Menu Type Character
Timer Rec Set Yes
Auto Repeat On/Off Yes
SAP On/Off Yes
CH Set-Up Yes
TV/CABLE Yes
Auto CH Memory Yes
Add/Delete Yes
System Set Up Yes
Clock Set Yes (Calendar 12H)
Language Yes
No Noise Back Ground Yes
Auto Clock Yes
Standard Time Yes
Daylight Saving Time Yes
G-CODE(or SHOWVIEW or PLUSCODE)No. Entry No
Stereo, Audio Output, SAP Yes
P
lay/
S
top/FF/Rew/Rec/
O
TR/
P
ause/Eject/Tape In/Repeat
(Sy
m
bo
l M
a
rk
)
Yes
CH/AV(LINE) Yes
Clock Yes
Repeat Yes
Tape Counter Yes
Index Yes
Tape Speed Yes
ATR / Manual Tracking Yes
ZERO Return Yes
Hi-Fi Yes
G-11 OSD Language DVD OSD English / French / Spanish
VCR OSD English / French / Spanish
G-12 Clock,Timer Calendar 1990/1/1 ~ 2081/12/31
and Timer Timer Events 8 Program/ 1 Month
Back-up One Touch Recording Max Time 6 Hours
OTPB Valid Time No
Timer Back-up (at Power Off Mode) 5sec
G-13 Display DISPLAY Yes
DISPLAY type LED Module (Green, "Rec" &Timer symbol = Red)
C
lock/
C
ounter,
C
H,Timer Rec,
O
TR,
P
lay
R
ec,
FF
(Cue),
R
e
w
(
R
e
v
),Stop,
ATR
,
E
ject
No
VCR Yes
DVD Yes
CD Yes
Clock Yes (12h)
AM No
PM Yes
Counter VCR Yes (hour:min)
DVD Yes (hour:min)
CD Yes (min:sec)
Eject Yes
Counter Remain No
Play Yes
Stop No
Rec Yes
FF / Cue No
REW / Review No
Pause / Still Yes
OTR (ITR) No
T-Rec Yes
Chapter No
TITLE No
TRACK Yes
Repeat No
Hi-Fi No
SP No
LP No
SLP No
CH Yes
RF Output CH Yes
Tape In Yes
Remocon Custom Code No
Progressive Scan Out Yes
A3-4

GENERAL SPECIFICATIONS
G-14 Remote Unit RC-JN
Control Glow in Dark Remocon No
Format NEC
Custom Code 71-8E
Power Source Voltage(D.C) 3V
UM size x pcs UM-4 x 2 pcs
Total Keys 46 Keys
Keys Power Yes
DISPLAY Yes
1 Yes
2 Yes
3 Yes
4 Yes
5 Yes
6 Yes
7 Yes
8 Yes
9 Yes
0 Yes
Input Select No
Input Select / PROGRESSIVE Yes
UP/CH+ Yes
DOWN/CH- Yes
LEFT/ SET- / TRACKING- Yes
RIGHT/ SET+ / TRACKING+ Yes
VCR/DVD Yes
TV/VCR Yes
DVD MENU Yes
TOP MENU Yes
SETUP MENU/VCR MENU Yes
ENTER Yes
CANCEL Yes
RETURN Yes
PLAY Yes
STOP Yes
PAUSE/STILL/STEP Yes
FF(Cue)/SEARCH+ Yes
REW(Review)/SEARCH- Yes
REC/OTR Yes
SKIP+ / INDEX+ Yes
SKIP- / INDEX- Yes
AUDIO / AUDIO SELECT Yes
ANGLE/COUNTER RESET Yes
SUBTITLE/ATR Yes
PLAY MODE/SPEED Yes
T-REC Yes
CLOCK / COUNTER Yes
JUMP/ZERO RETURN Yes
ZOOM Yes
REPEAT A-B Yes
SLOW (Forward) Yes
MARKER Yes
OPEN/CLOSE Yes
EJECT Yes
G-15 Features Auto Power Off No
(DVD) Parental Lock Yes
Video CD Playback No
MP3 Playback Yes
WMA Playback No
JPEG Playback No
Progressive Scan Out Yes
Digital Out Dolby Digital Yes
MPEG Yes
PCM Yes
DTS Yes
Down Mix Out (Dolby Digital) Yes
(DTS) No
Spatializer (N-2-2) No
Screen Saver No
Tray Lock No
Auto Stop No
Audio DAC 192kHz / 24bit
A3-5

GENERAL SPECIFICATIONS
Features Auto Head Cleaning Yes
(VCR) Auto Tracking Yes
HQ (VHS Standard High Quality) Yes
Auto Power On, Auto Play, Auto Rewind, Auto Eject Yes
Auto Power Off No
Forward/Reverse Picture Search Yes
VIDEO PLUS+ (SHOWVIEW, G-CODE) No
One Touch Playback No
Auto CH Memory Yes
AREA CODE No
Auto Clock Set Yes
Index Search Yes
SQPB No
CATV Yes
Energy Star No
MTS (SAP) Yes
CM Skip (30sec x 6 Times) No
Copy (Disc to Tape) No
G-16 Accessories Owner's Manual Language English / Spanish
w/Guarantee Card Yes
Remote Control Unit Yes
Guarantee Card No
Registration Card No
Warning Sheet No
Service Station List No
Important Tag No
AC Plug Adapter No
Quick Set-up Sheet No
Battery No
UM size x pcs --
AC Cord No
AV Cord (1.2m) Yes
75 Ohm Coaxial Cable (0.9m) Yes
S-Video Cable No
21pin cable No
800 No Sticker No
Toll Free Insert Sheet No
Safety Tip No
A3-6

GENERAL SPECIFICATIONS
G-17 Interface Switch Front Power Yes
Play Yes
Eject (VCR) Yes
Stop Yes
Rec/OTR Yes
Open/Close (DVD) Yes
CH + Yes
CH - Yes
FF/ Search(>>) Yes
Rew/Search(<<) Yes
Still/Pause No
Shuttle (Search/REV/FWD) No
DVD/VCR Yes
Main Power SW No
Rear Attenuator No
S-Video/Component Video Selector Yes
RF Out (Slide SW) No
Main Power SW No
Volume Phones Volume No
Mic Volume No
Echo Volume No
Rec/OTR No
Terminals Front Video In RCA x1 (Yellow)
Audio In RCA x 2 (Stereo, White/Red)
Rear Video Output RCA x1 (Yellow)
S-Video x 1 (DVD Signal Only)
Component x1 (RCA 3pin,DVD Signal Only)
Audio Output RCA x 4 (Stereo, White/Red)
Coaxial x 1 (Digital Audio,DVD Signal Only)
Optical Out (Option) Yes (Digital Audio,DVD Signal Only)
Video Input (Option) No
Audio Input (Option) No
RF Input / Output Yes
Euro Scart No
AC Inlet No
Indicator LED Power No
Rec No
T-Rec No
TV/VCR No
DVD Yes (RED)
VCR Yes (RED)
Surround No
Level Meter No
G-18 Set Size Approx. W x D x H (mm) 430 x 227 x 99
G-19 Weight Net (Approx.) 3.5 kg( 7.7lbs)
Gross (Approx.) 4.5 kg( 9.9lbs)
G-20 Carton Master Carton No
Content --- Sets
Material --- / ---
Dimensions W x D x H(mm) ---
Description of Origin ---
Gift Box Yes
Material Double / Brown
W/Color Photo Label No
Dimensions W x D x H(mm) 497 x 340 x 180
Design As Per BUYER 's
Description of Origin Yes
Drop Test Natural Dropping At 1 Corner / 3 Edges / 6 Surfaces
Height (cm) 80 cm
Container Stuffing 2,011 Sets/40' container
G-21 Material Cabinet Front PS 94V2 or More / DECABROM
PCB Non-Halogen Demand No
Eyelet Demand No
G-22 Environment Pb Free Lead-free Solder No
Other No
Cd Free No
A3-7

DISASSEMBLY INSTRUCTIONS
B1-1
1.
1-1:
REMOVAL OF MECHANICAL PARTS
AND P.C. BOARDS
TOP CABINET/FRONT CABINET/OPERATION PCB
(Refer to Fig. 1-1)
1.
2.
3.
4.
5.
6.
7.
Remove the 5 screws 1.
Remove the Top Cabinet in the direction of arrow (A).
Disconnect the following connector: (CP651).
Unlock the 8 supports 2.
Remove the Front Cabinet in the direction of arrow (B).
Remove the 2 screws 3.
Remove the Operation PCB in the direction of arrow (C).
1.
2.
Open Flap to 90˚ and flex in direction of arrow (A), at
the same time slide in direction of arrow (B).
Then lift in direction of arrow (C).
1-3: DVD DECK/DVD PCB (Refer to Fig. 1-3)
1-2: FLAP (Refer to Fig. 1-2)
Fig. 1-1
Fig. 1-2
(A)
Flap
(B)
(C)
Fig. 1-3
1
1
1
1
(A)
2
(B)
1
Top Cabinet
Front Cabinet
2
2
2
2
2
Operation PCB
(C)
2
3
3
2
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Make the short circuit on the position as shown Fig. 1-3
using a soldering. If you remove the DVD Deck with no
soldering, the Laser may be damaged.
Unlock the support 1and remove the Deck Top Holder
in the direction of arrow (A).
Remove the 2 screws 2.
Remove the 2 screws 3.
Disconnect the following connectors:
(CP501, CP8001).
Remove the DVD Deck in the direction of arrow (B).
Remove the 2 screws 4.
Remove the DVD PCB in the direction of arrow (C).
Remove the 3 screws 5.
Remove the Front Angle in the direction of arrow (D).
NOTE
When the installation of the DVD Deck, remove all the
soldering on the short circuit position after the connection
of Pick Up PCB and VCR PCB connector.
2
1
Deck Top Holder
2
3
(A)
3
4
DVD Deck
5
4
(B)
DVD PCB
(C)
5
Front Angle
5
Make the sort circuit
using a soldering.
Pick Up PCB
(D)

DISASSEMBLY INSTRUCTIONS
B1-2
1
FE Head
2
VCR Deck
2
3
3
1-4: VCR DECK (Refer to Fig. 1-4)
Do not remove the cable at the FE Head section. The FE
Head may be damaged if you remove the cable by force.
NOTE
1.
2.
3.
4.
5.
6.
7.
Remove the screw 1.
Remove the FE Head.
Move the Cassette Holder Ass’y to the back side.
Remove the 2 screws 2.
Remove the 2 screws 3.
Disconnect the following connectors:
(CP101, CP102, CP3001).
Remove the VCR Deck in the direction of arrow.
Fig. 1-4
1
2
3
2
2
2
2
3pin Shield
VCR PCB
3
1-5: VCR PCB (Refer to Fig. 1-5)
1.
2.
3.
4.
5.
Remove the screw 1.
Remove the 5 screws 2.
Remove the 2 screws 3.
Remove the 3pin Shield.
Remove the VCR PCB in the direction of arrow.
Fig. 1-5

DISASSEMBLY INSTRUCTIONS
B2-1
2. REMOVAL OF VCR DECK PARTS
2-1: TOP BRACKET (Refer to Fig. 2-1)
Extend the 2 supports 1.
Slide the 2 supports 2and remove the Top Bracket.
1.
2.
2-2: CASSETTE HOLDER ASS'Y (Refer to Fig. 2-2)
Move the Cassette Holder Ass'y to the front side.
Push the Locker R to remove the Cassette Side R.
Remove the Cassette Side L.
1.
2.
3.
Fig. 2-1
2
2
Main Chassis
Main Chassis
Top Bracket
Top Bracket
Main Chassis
Main Chassis
Cassette Side L
Cassette Side R Locker R
Fig. 2-2
2-3: CASSETTE SIDE L/R (Refer to Fig. 2-3-A)
Remove the Locker Spring.
Unlock the 4 supports 1and then remove the Cassette
Side L/R.
Unlock the support 2and then remove the Locker R.
1.
2.
3.
Link Unit
2-4: LINK UNIT (Refer to Fig. 2-4)
Set the Link Unit to the Eject position.
Unlock the support 1.
Remove the (A) side of the Link Unit first, then remove
the (B) side.
1.
2.
3.
Fig. 2-4
Fig. 2-3-A
Cassette Side L
Cassette Side R
1
1
1
Locker R
1
Cassette Holder
Locker Spring
2
(A)
Link Unit
Main Chassis
1
Link Unit
(B)
Main Chassis
11
NOTE
1. After the installation of the Top Bracket, bend the
support 1so that the Top Bracket is fixed.
NOTE
1.
2.
In case of the Locker R installation, check if the one
position of Fig.2-3-B are correctly locked.
When you install the Cassette Side R, be sure to move
the Locker R after installing.
Fig. 2-3-B
Check if this position
is locked.
Cassette Side R
Locker R
2-5: LINK LEVER/FLAP LEVER (Refer to Fig. 2-5)
Extend the support 1.
Remove the Link Lever.
Remove the Flap Lever.
1.
2.
3.
Fig. 2-5
Link Lever
Flap Lever
1

DISASSEMBLY INSTRUCTIONS
B2-2
2-6: LOADING MOTOR/WORM (Refer to Fig. 2-6-A)
Remove the screw 1.
Remove the Loading Motor.
Remove the Worm.
1.
2.
3.
Fig. 2-6-A
• Screw Torque: 3 ±0.5kgf•cm
Loading Motor
1
Main Chassis
Worm
2-7: TENSION ASS'Y (Refer to Fig. 2-7-B)
Turn the Pinch Roller Cam clockwise so that the
Tension Holder hook is set to the position of Fig. 2-7-A
to move the Tension Arm Ass'y.
Remove the Tension Spring.
Unlock the 2 supports 1and remove the Tension
Band.
Unlock the support 2and remove the Tension Arm
Ass'y.
Unlock the support 3and remove the Tension
Connect.
Float the hook 4and turn it clockwise then remove the
Tension Holder.
1.
2.
3.
4.
5.
6.
Fig. 2-7-A
Tension Arm Ass'y
Fig. 2-7-B
Fig. 2-7-D
Tension Band
Tension Spring
1
2
4
Tension Band
Tension Arm Ass'y
3
1
Tension Holder
Tension Connect
NOTE
1.
2.
3.
In case of the Tension Band installation, note the
direction of the installation. (Refer to Fig. 2-7-C)
In case of the Tension Band installation, install correctly
as Fig. 2-7-D.
In case of the Tension Connect installation, install as
the circled section of Fig. 2-7-E.
Tension Band
Tension Connect
Tension Connect
[OK]
[NG]
Fig. 2-7-E
Tension Connect
Main Chassis
Fig. 2-7-C
Tension Band
Tension Connect
NOTE
1.
2.
3.
In case of the Worm installation, check if the value of
the Fig. 2-6-B is correct.
In case of the Loading Motor installation, hook the wire
on the Cassette Opener as shown Fig. 2-6-C.
When installing the wires between Capstan DD Unit
and Loading Motor, connect them correctly as shown
Fig. 2-6-D.
Loading Motor Capstan DD Unit
-
+
L2
L1
Pink
Fig. 2-6-D
White
Fig. 2-6-B
19.2 ±0.1mm
Safety surface for pressing
of the insert.
Fig. 2-6-C
Loading Motor
Cassette Opener
