Memorex MSBW240BDL User manual

2-Pack Bundle Bluetooth With Removable Stakes Speakers
User’s Guide for Model MSBW240BDL v2953-01
Overview
Using the Stakes
The stakes allow you to stabilize
these speakers on the ground for use
outdoors.
1. Remove the stakes from the casing
2. Insert the stakes into the bottom of
the casing as shown below.
3. Insert the stakes into the bottom
of the speakers and stick the stake
into the ground.
1. Mode: Press to change source modes to Bluetooth,
Aux in or FM radio.
2. Volume/Skip+/Prev- : Press to adjust volume level.
Press and hold to previous / next track. Press and
hold for 5 seconds to turn voice prompts ON/OFF.
3. Charging/Mode Indicator LED: Light will turn
solid red when charging and will turn off when fully
charged. Flashing red when low battery. Solid blue
when in Aux in mode. Flashing blue in every other
mode.
4. : Press and hold to enter into pairing mode
manually.
5. Power/Play/Pause: Press and hold to power ON or
OFF. Press to play/pause audio. Press to answer phone
calls.
1
2
4
5
3
Controls
Features
• IPX6 waterproof protection
• Bluetooth 5.0
• Wireless range: 59 ft.
• Party Plus Mode
• 360 degree sound
• Built-in microphone
• Solar Panel
• Built-in rechargeable battery: approximately 20 hrs
playtime at 50% volume
• USB-C port for battery recharge
Battery Charging
To charge the internal battery, plug the USB charging cable
into the DC Power Input on the speaker and a powered
on computer or USB power adapter (not included) and
standard power outlet. Charging time is approximately
3 hours. Battery life is approximately 20 hours at 50%
volume.
When the battery is low a voice will announce “Low
Battery,” then the unit will automatically power OFF.
While the unit is charging it will display a solid red light.
When the battery is fully charged the light will turn off.
Aux In & Micro SD
Aux In
Requires a 3.5mm audio cable (included).
1. Connect a 3.5mm audio cable to the Aux In on the
unit and the audio output on an audio device. The
unit will automatically change to Aux in mode.
2. Use the controls on the connected device to
select and play audio. Be sure the volume on your
connected device is audible when you begin playing.
Solar Panel
Note: The solar
panel charges
at a VERY slow
rate. Therefore
it is best as a
supplemental
charging
method.
Micro SD
1. Load a Micro SD memory card into the Micro SD
port.
2. The speaker will automatically switch to SD mode.
3. Use the controls on your device to select and play
audio from the connected drive.
Micro SDAux In
AUXIN
DCIN
Includes
• 3.5mm audio cable
• USB-C to USB charging cable
• 2 stakes
AUXIN
DCIN
AUX IN
DC IN
msbw240-2953-01-manaul.indd 1msbw240-2953-01-manaul.indd 1 4/29/2022 11:30:19 AM4/29/2022 11:30:19 AM

International Support
To download this User’s Guide in English, Spanish, and
French, or to get answers to frequently asked questions,
visit the support section at: www.memorex.com
Para descargar este Manual del Usuario en inglés,
español y francés, o para obtener respuestas a preguntas
frecuentes, visite la sección de apoyo en: www.memorex.
com
Pour télécharger ce guide de l’utilisateur en anglais,
espagnol ou français, ou pour obtenir des réponses à des
questions fréquemment posées, consultez la rubrique
d’assistance sur: www.memorex.com
Contact Information
Website: www.memorex.com
Email Support: [email protected]
Email Parts: [email protected]
Phone Support: 1-888-999-4215
Warranty
For warranty information and the most up-to-date version of
this User’s Guide, go to: www.memorex.com
FCC WARNINGS
WARNING: Changes or modications to this unit not
expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
ADDITIONAL WARNINGS
• WARNING: To prevent re or shock hazards, do not expose this
unit to rain or moisture.
• WARNING : Where the mains plug or appliance coupler is used as
the disconnect device, such disconnect device shall remain readily
operable.
• Lithium batteries, like all rechargeable batteries, are recyclable
and should be recycled or disposed of according to state and local
guidelines. They should never be disposed of in normal household
waste and they should never be incinerated, as they might explode.
Contact your local government for disposal or recycling practices
in your area.
WARNING: This product can expose you to chemicals
including lead, which is known to the State of California to
cause cancer and birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov.
This product meets and complies with required Federal
product guidelines.
Party Plus Mode
If you have another MSBW240 speaker, you can pair
and play the two speakers together for a surround sound
effect, or have two speakers playing in different rooms.
1. To enter Party Plus Mode, Power ON both speakers
and make sure both units are in Bluetooth mode.
2. Press and hold the Mode button on one of the units
(this is now the primary unit), and the speakers will
attempt to pair to each other.
3. When the two speakers are paired together a voice
will announce the connection.
4. Connect Bluetooth device to speakers using the
steps from the “Pairing and Playing Bluetooth Audio”
section below.
5. Use your device to select and play tracks. The audio
will now be heard through both speakers.
6. The primary unit will control both speakers when
connected. To disconnect the speakers, press the
Mode button on the primary unit.
Note: To use Party Plus Mode, please make sure
that you connect the speakers before pairing to your
Bluetooth device. You will not be able to connect
the speakers if you are already paired to a Bluetooth
device.
Pairing & Playing Bluetooth Audio
1. When rst powered on, the speaker defaults to
Bluetooth Mode, indicated by a voice prompt. When
pairing, remain within 3 feet of the Bluetooth device.
2. Using the controls on your Bluetooth device, select
MSBW240 in the Bluetooth settings to pair. If need
be, refer to the user’s manual for your specic device
for more information.
3. When successfully paired, a voice prompt will
announce the connection. Your Bluetooth device will
now be heard through the speaker.
4. Use the controls on the connected Bluetooth device
to select and play audio. Use the speaker controls or
the connected Bluetooth device to play, pause, and
adjust the volume level.
5. After initial pairing, the speaker will automatically
connect to the last Bluetooth device used whenever
it is in Bluetooth Mode. Note: If your device
should become unpaired or you nd it is unable to
connect, press and hold the button to enter to
Pairing Mode. A voice will announce, “Bluetooth is
connecting,” and you can connect to the speaker
manually.
If after you have connected the two speakers,
you decide you want to use one of the speakers
independently:
1. Press and hold the Mode button on the speaker you
want to use to disconnect the two speakers.
2. Press and hold button on the speaker, the speaker
will then enter into pairing mode. You can now
connect to the speaker manually.
If you want to connect the speakers together again:
1. Access your device’s Bluetooth settings menu and
select all MSBW240s.
2. Select “forget this device” and follow the Party
Plus mode connection procedure listed in the user
manual.
FM Radio
An FM receiver is built into the speakers. Adjust the
position of the speaker to improve FM radio reception.
1. Once powered ON, press the Mode button to switch
to FM Radio Mode.
2. Press and hold Pair button for 2 seconds to scan
and save radio stations automatically.
3. Press and hold the +/- buttons to cycle through
saved stations.
Copyright © 2022 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their
respective owners. Specications are subject to change without notice.
