MEM-9906 MEMPHIS FATS MOUNTING KIT FOR KAWASAKI VN750 VULCAN (86-99)
Read and follow these directions carefully.
During installation, make certain that when turning the
forks, there can be no interference with wiring or cables
AND, that the windshield can not hit the gas tank,
through the windshield's full range of adjustment.
This is a quick change kit, ALWAYS tighten all mounting
bolts after removing or installing the windshield!
The improper installation of this kit and related compo-
nents could result in serious injury or death.
IMPORTANT CARE AND CLEANING INSTRUCTIONS
Memphis Shades Windshields and Lowers are made of
Lucite® acrylic, and will last for years with proper care.
Clean your windshield with plenty of soapy water — mild
dishwashing liquid is best — and a soft cotton cloth. Use your
bare hand to feel and dislodge bugs, or cover with a wet soapy
towel and let it soak. Don't use paper towels and don't scrape
with anything. Small scratches can be removed with NOVUS
# 2.
NEVER use any glass cleaning products, petroleum based
chemicals, or cleaning agents with ammonia, bleach or any
other harsh chemicals. This includes (but not limited to)
RainX, brake fluid, acetone, paint thinner, benzene and
gasoline. "If it hurts your nose, it will hurt the plastic."
Glass cleansing agents will cause severe damage
to your windshield, and will void your warranty.
NOTE: At certain times of the day the Sunlight can reflect
off the curvature of a windshield and cause extreme heat
build-up on motorcycle instruments and instrument panel.
Take care when parking. Park facing the sun, place an opaque
object over the instruments or adjust the windshield to avoid
reflections.
MOUNTING INSTRUCTIONS
Fig. 3
Fig. 1 Anchor
Bolts
WARNING:
"Mounting clamps
backwards will cause
damage to your tank."
Side view. When installed correctly,
Allen bolts are tightened from the
back side of the fork, not the front.
CORRECT
Throttle side,
front of bike
INCORRECT
Throttle side,
front of bike
Fig. 2
Additional tools required that are not included in this kit.
7/16" or 11mm Wrench.
1.Cover gas tank and front fender with towels to avoid
damage during installation.
2. Install the two mounting plates onto the windshield, using
the bottom and third bolt up. Leave the nylon washers off.
The small tab goes to the bottom, big one at the top. Tabs
point out towards the edge of the windshield. (see fig. 1)
3. Loosely install the four Fork Clamps on the forks, approxi-
mately 2" apart. (see figure 2)
4. Loosen the four anchor bolts that are to hold the windshield
to the Fork Clamps, and slip the windshield mounting plates
and windshield onto the fork clamps. (see figure 3)
5. Adjust the height, angle and alignment of the windshield
and tighten ALL bolts.
Note: This is a quick change kit, ALWAYS tighten all
mounting bolts after removing or installing the wind-
shield!
