Mercedes-Benz A 85 User manual
A 85 -
A 85 - 0302
CONTENTS
Safety Warnings.............................................................................................04
Before You Begin..........................................................................................06
Assembly and Set-up...................................................................................07
Pre-Ride Checklist and Usage..................................................................09
Repair and Maintenance...............................................................................11
Warranty ............................................................................................................11
SYMBOL
The Safety Alert symbol with the exclamation point in the
triangle means Attention!
BE ALERT! YOUR SAFETY CAN BE AFFECTED.
Read the manual before use.
Get CONFORMITE EUROPEENEE certification.
Passed AMERICAN SOCIETY FOR TESTING AND
MATERIALS test.
No Littering
Recyclable
Recyclable
En 14619:2015 (class A):
Roller sports equipment - kick scooters - Safety and test methods
A 85 - - 0504
-
Read this manual carefully: Read and understand this entire manual before using
the product!
PLEASE BE SAFE WHEN RIDING ALWAYS WEAR A HELMET AND OBEY ALL LAWS!
MAKE SURE THE KICKSTAND IST ASSEMBLED AND SECURED STURDILY BEFORE EACH USE.
The Owner‘s Manual contains important information on safety, ope-
ration and maintenance of your Scooter, anyone who operates your
scooter should carefully read and understand the contents of this
manual before using the Scooter.
NOTE: Manual illustrations are for demonstration purposes only.
Illustrations may not reflect exact appearance of actual product.
Specifications subject to change without notice.
Failure to follow instructions associated with a warning symbol could
result in severe injury or death to the rider, a passenger, a bystander
or a person inspecting or repairing the scooter.
Scooter riding can be a hazardous activity. Scooters can, and are intended to mo-ve and it
is therefore possible to get into dangerous situations and/or lose control and/or fall. lf such
things occur you can be seriously injured or died.
BE CAREFUL!
You will see people on TV and maybe even people you know doing tricks and
stunts. These are people who have been practicing on scooters for a very lo-ng
time. Don‘t try something until you are ready. Avoid steep inclines and don‘t ride too
fast - you can lose control and fall. Skateboard parks are not designed for scooters.
DO NOT USE NON MERCEDES-BENZ PRODUCTS WITH YOUR SCOOTER
Mercedes-Benz scooters have been built to certain design speci fications. The ori-
ginal equipment supplied at the time of sale was selected on the basis of its com-
patibility with the frame, fork and all other parts. Certain aftermarket products may not be
compatible and will void the warranty.
LIKE ANY OTHER MOVING PRODUCT, USING A SCOOTER CAN BE A DANGEROUS
ACTIVITY AND MAY RESULT IN INJURY OR DEATH EVEN WHEN USED WITH PROPER
SAFETY PRECAUTIONS. USE AT YOUR OWN RISK AND USE COMMON SENSE.
• Obey all local trac and scooter laws and regulations.
• Always check over your scooter prior to riding, and make certain that all clamps,
folding handles, bolls and screws are tightened properly, also check the wheels
for wear and tightness and make sure that the steering column is securely held in
the proper position.
• Never operate this scooter without a helmet.
• Do not exceed 220 lb (100 kg) total weight on the scooter.
• Brake will get hot from continuous use. Do not touch after braking.
• A parent‘s decision to allow his or her child to ride this product should be based
on the child‘s maturity, skill and ability to follow rules.
• Do not allow children under age fourteen (14) to use the scooter. All children and
preteens should ride with adult supervision at all times.
• Do not allow your child to ride a scooter in any areas where vehicle trac is pre-sent.
• Adults must assist children in the initial assembly and/or adjustment procedures to
fold/unfold scooter, and adjust handlebar and steering to height.
• Rider weight does not necessarily mean a child‘s size is appropriate to fit or mai-
ntain control of the scooter.
• Parent supervision is required.
• Must maintain a hold on the handlebars at all times. Never allow more than one
child at a time to ride a scooter.
• Avoid excessive speed associated with downhill rides.
• Avoid streets and surfaces with water, sand, gravel, oily, dirt, leaves, and other debris.
• Do not ride in wet weather. Wet weather impairs traction, braking, visibility.
• Ride on smooth, paved surfaces away from motor vehicles.
• Watch out for pedestrians.
• Scooters are meant to be used only in controlled environments free of potential
A 85 - - 0706
trac hazards and not on public streets.
• Do not ride at dusk or night.
• Avoid excessive speed associated with downhill rides.
• Do not stunt ride - know your abilities and limits and always ride with control.
• Do not apply any alterations to your scooter which would aect your safety.
• Always wear safety equipment, such as helmet, knee pads and elbow pads.
• A helmet may be legally required by local law, we advise you to check with your
local law enforcement.
• Should always wear shoes and keep shoe laces-tied and out of the way of the wheels.
FAILURE TO USE COMMON SENSE AND HEED THE ABOVE WARNINGS FURTHER INCREA-
SES RISK OF SERIOUS INJURY. USE AT YOUR OWN RISK AND WITH APPROPRIATE AND
SERIOUS ATTENTION TO SAFE OPERATION. USE CAUTION.
-
Box contents
Dimension
Max loading
Age for
scooter
allen wrenches
instruction manual
unfolding size: 910*520*1080m m
folding size: 885*145*325m m
N.W. : 6.5kg
100kg
above 14 years old
1 - Handle bar
2 - Quick release lever
3 - Clamp
4 - Folding mechanism
5 - Folding button
6 - Brake
7 - Kick stand
1
2
3
5
4
7
6
③
④
⑤
⑧
⑦
⑥
Rotate handles
upward.
Allow locks
to snap in.
Ensure locks hold
Open quick
release lever.
Adjust to desire height.
Adjust barrel nut and fully
close quick release lever
A 85 - - - - 0908
WARNING
Risk of pinching!
Hands can get hurt if get touch inside the folding mechanism.
Keep hands and fingers away from folding mechanism when folding/unfolding
scooter.
WARNING
Risk of hitting someone!t
People may be hit by scooter when stand nearby.
Make sure others are standing clear when folding/unfolding scooter.
UNFOLDING THE SCOOTER FOR FIRST TIME USE.
1. To release the folding mechanism, place the scooter on the ground, put one foot on the
deck plate and pull the folding button down. Raise handle bar up un-til it is securely
locked in the upright position. (As shown in figure 1 and 2).
①
②
TO FOLD
①
②
TO UNFOLD
WARNING
Risk of losing control!
Riders might lose control the handlebar when handle are not fully upright.
Make sure both handles are properly locked onto the handlebar. Stop riding if fol-
ding handlebar do not fully upright or do not lock.
HANDLEBAR ASSEMBLY
HANDLEBAR ADJUSTMENT
A 85 - - -- - 1110
CLAMP
WARNING
Risk of skew!
Loose screws will cause the front wheel or T-bar to skew.
Stop riding when the screw of the clamp is loose or the front wheel and T-bar skew.
make sure the screws thightened securely. See examples in figure 9 and 10.
REQUIRED TOOLS
5 mm Allen wrenches
Using a 5 mm Allen wrench, check that the collar clamp bolt(s) is tightened securely. Loose
screws will cause the front wheel or T-bar to skew. Please check and follow illustrations
11-16 to operate, redress and tighten the screws.
LOOSE PARTS
Check and secure all fasteners before every ride. Make sure the collar clamp, quick release
lever, and handlebar spring sleeves are locked properly in place before riding. (As shown in
figure 5,8 and 11)
: self-locking nuts and other self-locking fixings may lose their eectiveness
after being used several times and may need replacing.
SAFETY GEAR
Always wear proper protective equipment, such as an approved safety helmet, elbow pads
and kneepads. Always wear shoes (lace-up with rubber soles) and keep shoelaces tied and
out of the way of the wheels. Never ride bare-footed or in sandals.
HOW TO RIDE
Place one foot on the baseboard, push forward with the other foot. Steer with both hands on
the handlebars. For enhanced conering, lean slightly into the direction of the turn. For control-
led stops, apply the brake by stepping on the rear brake.
Mercedes-Benz recommends that you practice applying the brake at various speeds and in an
open area free from obstructions before riding your scooter around others.
10
09
14 15 16
13
1211
A 85 - // - 1312
WARNING
Risk of pinching!
Hands can get hurt if get touch inside the folding mechanism.
Keep hands and fingers away from folding mechanism when folding/unfolding scooter.
CLEANING YOUR SCOOTER
Wipe with a damp cloth to remove dirt and dust. Do not use industrial cleaners or solvents
as they may damage the surfaces. Do not use alcohol, alcohol-based or ammonia-based
cleaners as they may damage or dissolve the plastic components or soften the decals or
decal adhesive.
WHEELS AND BEARINGS
Under normal circumstances and conditions, Mercedes-Benz wheels and wheel bearings
are maintenance free. Nonetheless, it is the responsibility of the owner or guardian to
periodically inspect the wheels for wear and tear, the axle for proper tightness, and bea-
rings for side-to-side play, and loose parts. When a wheel or wheel bearing develops play,
this is an indication of excess wear and replacement is necessary. Replace immediately
with only genuine Mercedes-Benz wheels. Worn wheels/bearings are considered normal
wear-and-tear and are not covered by the Mercedes-Benz Warranty. Wheels other than
genuine Mercedes-Benz wheels may not be compatible with your Mercedes-Benz scooter.
The use of anything other than genuine Mercedes-Benz replacement parts may aect your
safety and will viod your warranty.
LIMITED WARRANTY
The manufacturer warranties this product to be free of manufacturing defects for a period of
6 months from date of purchase.
This Limited Warranty does not cover normal wear and tear, or any damage, failure or loss
caused by improper assembly, maintenance, or storage. This Limited Warranty will be void if
the product is ever:
• used in a manner other than for recreation
• modified in any way
• rented
The manufacturer is not liable for incidental or consequential loss or damage due directly or
indirectly to the use of this product. Mercedes-Benz does not oer an extended warranty.If
you have purchased an extended warranty, it must be honored by the store at which it was
purchased. For your records, save your original sales receipt with this manual.
Daimler AG
616 / HPC Z402
70546 Stuttgart
Germany
Phone +49-(0)711/17-0
version MBE 2019/01
warning
En 14619:2015 (class A)
