VESSELVIEW MOBILE MODULE
IMPORTANT: This document guides our dealers, boatbuilders, and company service personnel in the proper installation or
service of our products. If you have not been trained in the recommended servicing or installation procedures for these or
similar Mercury Marine products, have the work performed by an authorized Mercury Marine dealer technician. Improper
installation or servicing of the Mercury product could result in damage to the product or personal injury to those installing or
operating the product. Always refer to the appropriate Mercury Marine service manual for component removal and installation
instructions.
NOTE: After completing installation, place these instructions with the product for the owner's future use.
Components Contained in Kit
ab
c
d
e
62811
Ref. Qty. Description Part Number
a 1 Cable clip 23567
b 2 Screw 69013
c 1 VesselView Mobile module with harness NSS
d 1 Weather cap 859318T2
e 4 Cable tie 816311T
VesselView Mobile Module Connection
Engine‑Mounted Module
NOTE: The location of the engine harness 10‑pin connector and terminator will vary depending on the engine model.
1. Depending on the engine model and rigging configuration, the engine harness 10‑pin connector will be equipped with a
purple weather cap, a yellow terminator, or a red terminator.

VESSELVIEW MOBILE MODULE
Page 2 / 5 © 2019 Mercury Marine 90-8M0168272 eng DECEMBER 2019
IMPORTANT: 859318T1 must be purchased separately if the engine is not equipped with a yellow or red terminator
resistor.
1 - Weather cap
2 - Yellow terminator
3 - Red terminator
2. Locate and remove the terminator or weather cap by pressing the retaining latch and pulling it from the engine harness
10‑pin connector. If removing a terminator, retain the terminator for use with the VesselView Mobile harness.
Yellow terminator shown
a - Terminator retaining latch
b - Terminator
c - Engine harness 10‑pin connector
3. After the terminator or weather cap is removed from the engine harness, plug the VesselView Mobile harness 10‑pin
connector into the engine harness 10‑pin connector.
a - VesselView Mobile harness 10‑pin connector
b - Engine harness 10‑pin connector
69256
123
ab
c
69257
ab
69258

VESSELVIEW MOBILE MODULE
90-8M0168272 eng DECEMBER 2019 © 2019 Mercury Marine Page 3 / 5
4. Remove the weather cap from the VesselView Mobile harness terminator connector and install the removed yellow or red
terminator into the VesselView Mobile harness terminator connector.
a - Weather cap
b - VesselView Mobile harness terminator connector
c - Yellow terminator
IMPORTANT: The VesselView Mobile harness must not contact the flywheel, throttle and shift components, or other
moving parts. Care must be taken to assure that the module and its wiring harness are not in close proximity to the high
voltage ignition leads and do not interfere with the throttle or shift mechanisms.
5. Identify an appropriate location and routing path on the engine for the VesselView module and harness. Secure the
module and harness to the engine at the selected location with cable ties.
a - Engine harness terminator
connector
b - Terminator
c - VesselView Mobile module
Helm‑Mounted Module
The VesselView Mobile module can be mounted at the helm if the vessel is equipped with a junction box and open
connection point. The module can also be mounted on the engine.
IMPORTANT: Multiple engine applications may be equipped with more than one junction box. Always connect the
VesselView Mobile module to the multiwake junction box on vessels equipped with multiple engines. The multiwake junction
box has unswitched 12 V power from the starboard battery.
69261
a
b
c
62813
ab
c

VESSELVIEW MOBILE MODULE
Page 4 / 5 © 2019 Mercury Marine 90-8M0168272 eng DECEMBER 2019
1. Locate the multiwake junction box.
a - Multiwake junction box
b - Weather cap
c - Cable clip
d - VesselView Mobile module with
harness
2. Select a suitable location for mounting the VesselView Mobile module and harness.
3. Use a 3/32 drill bit to drill two pilot holes to mount the VesselView Mobile module and the harness cable clip.
4. Install the VesselView Mobile harness 10‑pin connector into the multiwake junction box.
IMPORTANT: The harness cable clip should be positioned on the harness and slid up close to the module. It may then
be secured to the surface with a screw. The cable tie straps should be used to secure the main harness and terminator
extension.
5. Mount the VesselView Mobile module with the supplied mounting screws, cable clip, and cable ties.
Bluetooth Pairing
1. Download the VesselView Mobile app from Apple® iTunes® or the Google Play™ store.
2. Turn the key switch(es) to the ON position.
3. Verify the SmartCraft LED on the module goes solid green shortly after key up. The Bluetooth LED should be flashing
letting you know the module is ready to pair. If the SmartCraft LED is off, this means no engine data is detected by the
module which is commonly caused by incorrect termination resistor placement.
4. Open the app and follow the on‑screen instructions to connect.
Electrical Specifications
IMPORTANT: The documentation must be consulted in all cases where the symbol !, is marked.
IMPORTANT: !Always refer to the Operation Manual included with each engine for fuse holder location, fuse rating, and
electrical system overload protection.
This equipment is only intended for connection to 9–16 Vdc, low voltage, electrical systems of boats or similar marine vessels.
Do not connect this equipment to any circuit rated in excess of 16 Vac rms, 22.6 Vpk or 35 Vdc, and only connect to boat
electrical systems powered by batteries or alternators or otherwise only to circuits separated from main voltages by at least
double or reinforced insulation.
Overload and Fuse Protection
IMPORTANT: !Always refer to the Operation Manual included with each engine for fuse holder location, fuse rating, and
electrical overload protection.
ab
62814
c
d

VESSELVIEW MOBILE MODULE
Products of Mercury Marine © MERCURY MARINE. All rights reserved. Reproduction in whole or in part without permission is prohibited.
Alpha, Axius, Bravo One, Bravo Two, Bravo Three, Circle M with Waves Logo, GO BOLDLY, K-planes, Mariner,
MerCathode, MerCruiser, Mercury, Mercury with Waves Logo, Mercury Marine, Mercury Precision Parts, Mercury
Propellers, Mercury Racing, MotorGuide, OptiMax, Pro XS, Quicksilver, SeaCore, Skyhook, SmartCraft, Sport-Jet,
Verado, VesselView, Zero Effort, Zeus, #1 On the Water and We're Driven to Win are registered trademarks of
Brunswick Corporation. Mercury Product Protection is a registered service mark of Brunswick Corporation. All
other marks are the property of their respective owners.
W6250 Pioneer Road
Fond du Lac, WI 54936-1939
90-8M0168272 eng DECEMBER 2019 © 2019 Mercury Marine Page 5 / 5
Electrical Specifications
Electrical rating 9–16 V
Maximum fuse size Mechanical ‑ 15 A
DTS ‑ 5 A
Maximum rate input current 200 mA
IP rating IP4X
Environmental conditions
Altitude <3000 m
Operating temperature ‑20–85 ○C (‑4–185 ○F)
Overvoltage Category 1
For use in pollution degree 4 (outdoor use)
Battery Connections
IMPORTANT: !Always refer to the Installation Manual included with each engine for battery specifications and battery
installation procedures.
a - Positive cranking circuit
b - Negative cranking circuit
NOTE: After completing installation, place these instructions with the product for the owner's future use.
