MERLYN MB3 2 Panel Curved Bath Screen User manual

Two panel curved Bath screen
Important
Any parts missing or damaged must be reported to your supplier within 5 days of purchase.
Inspect fitting area before fitting. No claims will be accepted after product had been installed.
Please familiarise yourself with the fitting instructions before
commencing fitting.
1Check that you have the tools required
2Check that the installation site is compatible
with size of screen supplied
3 Check all the bath screen components
4Check that the installation kit is complete
DO NOT attempt to install the product unless you can tick ALL 4
boxed as satisfactory.
The wall plugs supplied with the installation kit are for use in solid walls.
Hollow or “stud - patrition” walls will require alternative fixings. Please
consult a hardware supplier for the correct type.
It may also be necessary to consult you tiling supplier about the
correct method for drilling your tiles.
USE SAFETY EYEWEAR WHEN DRILLING
Installation Guide

No. Description Qty Part No. No. Description Qty Part No.
1 1
6
2 1
7
3
82BSYS021L/R
3 2SY50
1
3
COMPONENTS AND BOX CONTENTS
2SDB3
×1
3.9 × 30
2SY51
×5
4 × 16
2SY50
×3
2SP12
×5
2SS009
×3
2SS008
×3
Tape measure
3mm
Clear Seal MOBY003
Moving Glass Panel A
Towel rail BSYS025C
Wall Profile LR8387C
Screw(3.9 x 30mm) 2SY51
Wall Plug 2SP12
Bracket
Screw (4x16mm)
Screw Cover Cap 2SS008
Screw Cover Cap Clip 2SS009
4
5
9
10
1
5
3
3
Wall profile cover MOBY002L/R
11
2
1. Ensure your bath is level before fitting.This screen is not designed
to fit on baths with stepped fronts, roll top rims or integral soap dishes.
2.The tiling or other wall finishing should be effectively sealed at the bath edges.
FIXING KIT COMPONENTS,TOOLS REQUIRED,SITE CONDITIONS
Fixing Kit components
pats shown are not to scale
1
2
10
8
9
5
3
4
6
7
12
1
Fixed Glass Panel B
11
12
13 2
Perspex shelf MOBY004
14 2
Shelf glass bracket MOBY005
15 2
Shelf wall bracket MOBY006
No. Description Qty Part No.
14
15
13
MOBY002L
×1
MOBY002R
×1
MOBY004C
×2
MOBY005
×2
MOBY006
×2

1. Position the wall profile LR8387C so the seal on the moving panel Asits on the inside edge of the bath.Fig 2
2.
INSTALLATION
Plumb the wall profiles LR8387C using the vertical element of the spirit level. Mark 3 holes, drill with 6mm masonry
bit and fit wall plugs 2SP12. Using the 3 Screw 2SY51, fix wall profiles to wall. Fig 3.
NOTE: Only silicone the wall profile after fixing to the wall (see sealing section).
Do not silicone on the back of the wall profile before fixing to the wall.
FIG 2
3.
4.
Insert Fixed panel Binto the wall profile (do not fix it to the wall profile).
Remove the top bracket BSYS021 by loosening the screw.Insert moving panel Band reattach the top hinge bracket. Fig 3.
5. Ensure the bottom seal on the moving panel Ais parallel to the top surface of the bath. Drill 3 holes through the wall profile
and fixed panel using a 3mm steel drill bit. Using the Screws 2SY50 and cover caps 2SS008 and clips 2SS009, fix the hinge
upright to the wall profile in 3 places.Fig 4.
screen
inside
bath edge
FIG 3
Inside
Ensure the deflector on the seal is positioned on the inside. Make a cut on one of the bottom corners of the seal to ensure
a correct fit against the hinge bracket – see circled area in. Fig 5
FIG 5
6.
Inside
FIG 4
Outside

(dashed line):
8. Fix the wall profile cover MOBY002L/R.FIG 8
FIG 8
www.merlynshowering.com
7. Fit shelf glass bracket to glass, level shelf in both directions and mark fixing point on wall.Use 6mm masonry bit and then insert
the 2 wall plugs 2SP12 and fix the shelf wall brackets MOBY006 to the wall with screws 2SY51. Tighten shelf glass bracket
MOBY005 onto the glass.Insert the perspex shelf MOBY004 into the shelf wall bracket and shelf glass bracket.Then tighten
grubscrews.Fig 6.
FIG 6
Sealing. Fig 6
Inside
When installation is complete seal the joint between the wall profile and the wall, top to bottom on the
inside only. DO NOT SEAL where the wall profile sits on the Bath.
Outside (full line)
From outside the screen, SEAL where the wall profile and hinge bracket sit on the bath. Seal 50mm up
where the wall profile meets the wall and where the hinge upright and the wall profile over lap.
FIG 6
FIG 7
8. Fix the towel rail BSYS025C. Fig 7
Top view
