Metabo HPT C 18DSL Troubleshooting guide

Designed for operating in USA & Canada only.
When this product is used in areas other than the USA & Canada,
we cannot guarantee the product quality and performance.
SAFETY INSTRUCTIONS AND INSTRUCTION MANUAL
WARNING
IMPROPER OR UNSAFE use of this power tool can result in death or serious bodily injury!
This manual contains important information about product safety. Please read and understand
this manual BEFORE operating the power tool. Please keep this manual available for other
users and owners before they use the power tool. This manual should be stored in safe place.
INSTRUCTIONS DE SECURITE ET MODE D’EMPLOI
AVERTISSEMENT
Une utilisation INCORRECTE OU DANGEREUSE de cet outil motorisé peut entraîner la mort
ou de sérieuses blessures corporelles!
Ce mode d’emploi contient d’importantes informations à propos de la sécurité de ce produit.
Prière de lire et de comprendre ce mode d’emploi AVANT d’utiliser l’outil motorisé. Garder ce
mode d’emploi à la disponibilité des autres utilisateurs et propriétaires avant qu’ils utilisent
l’outil motorisé. Ce mode d’emploi doit être conservé dans un endroit sûr.
INSTRUCCIONES DE SEGURIDAD Y MANUAL DE INSTRUCCIONES
ADVERTENCIA
¡La utilización INAPROPIADA O PELIGROSA de esta herramienta eléctrica puede resultar
en lesiones de gravedad o la muerte!
Este manual contiene información importante sobre la seguridad del producto. Lea y
comprenda este manual ANTES de utilizar la herramienta eléctrica. Guarde este manual para
que puedan leerlo otras personas antes de utilizar la herramienta eléctrica. Este manual debe
ser guardado en un lugar seguro.
Model
Modèle
Modelo C 18DSL
Cordless Circular Saw
Scie circulaire sans fil
Sierra circular a batería
000BookC18DSLmetabo.indb1000BookC18DSLmetabo.indb1 2018/10/299:18:582018/10/299:18:58

IMPORTANT SAFETY INFORMATION
Read and understand all of the safety precautions, warnings and operating instructions in the Instruction Manual before
operating or maintaining this power tool.
Most accidents that result from power tool operation and maintenance are caused by the failure to observe basic safety
rules or precautions. An accident can often be avoided by recognizing a potentially hazardous situation before it occurs,
and by observing appropriate safety procedures.
Basic safety precautions are outlined in the “SAFETY” section of this Instruction Manual and in the sections which
contain the operation and maintenance instructions.
Hazards that must be avoided to prevent bodily injury or machine damage are identified by WARNINGS on the power
tool and in this Instruction Manual.
NEVER use this power tool in a manner that has not been specifically recommended by metabo HPT.
MEANINGS OF SIGNAL WORDS
WARNING indicates a potentially hazardous situations which, if ignored, could result in death or serious injury.
CAUTION indicates a potentially hazardous situations which, if not avoided, may result in minor or moderate injury, or
may cause machine damage.
NOTE emphasizes essential information.
SAFETY
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and matching outlets will reduce
risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will increase the risk
of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts.
Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the
risk of electric shock.
2
English
000BookC18DSLmetabo.indb2000BookC18DSLmetabo.indb2 2018/10/299:18:582018/10/299:18:58

f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication.
A moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection.
Protective equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal
injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool.
Carrying power tools with your finger on the switch
or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on.
A wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times.
This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts.
Loose clothes, jewellery or long hair can be caught
in moving parts.
g) If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used.
Use of dust collection can reduce dust-related
hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application.
The correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off.
Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools.
Such preventive safety measures reduce the risk
of starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool.
Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation.
If damaged, have the power tool repaired
before use.
Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier
to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed.
Use of the power tool for operations different
from those intended could result in a hazardous
situation.
5) Battery tool use and care
a) Recharge only with the charger specified by
the manufacturer.
A charger that is suitable for one type of battery
pack may create a risk of fire when used with
another battery pack.
b) Use power tools only with specifically
designated battery packs.
Use of any other battery packs may create a risk of
injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects like paper clips,
coins, keys, nails, screws, or other small
metal objects, that can make a connection
from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water.
If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery
may cause irritation or burns.
3
English
000BookC18DSLmetabo.indb3000BookC18DSLmetabo.indb3 2018/10/299:18:582018/10/299:18:58

– if the blade becomes twisted or misaligned in the cut, the
teeth at the back edge of the blade can dig into the top
surface of the wood causing the blade to climb out of the
kerf and jump back toward the operator.
Kickback is the result of saw misuse and/or incorrect
operating procedures or conditions and can be avoided by
taking proper precautions as given below.
a) Maintain a firm grip with both hands on the saw
and position your arms to resist kickback forces.
Position your body to either side of the blade,
but not in line with the blade.
Kickback could cause the saw to jump backwards,
but kickback forces can be controlled by the operator,
if proper precautions are taken.
b) When blade is binding, or when interrupting a
cut for any reason, release the trigger and hold
the saw motionless in the material until the blade
comes to a complete stop.
Never attempt to remove the saw from the work
or pull the saw backward while the blade is in
motion or kickback may occur.
Investigate and take corrective actions to eliminate
the cause of blade binding.
c) When restarting a saw in the workpiece, centre
the saw blade in the kerf and check that saw
teeth are not engaged into the material.
If saw blade is binding, it may walk up or kickback
from the workpiece as the saw is restarted.
d) Support large panels to minimise the risk of
blade pinching and kickback.
Large panels tend to sag under their own weight.
Supports must be placed under the panel on both
sides, near the line of cut and near the edge of the
panel.
e) Do not use dull or damaged blades.
Unsharpened or improperly set blades produce
narrow kerf causing excessive friction, blade binding
and kickback.
f) Blade depth and bevel adjusting locking levers
must be tight and secure before making cut.
If blade adjustment shifts while cutting, it may cause
binding and kickback.
g) Use extra caution when sawing into existing
walls or other blind areas.
The protruding blade may cut objects that can cause
kickback.
Lower guard function
a) Check lower guard for proper closing before each
use. Do not operate the saw if lower guard does
not move freely and close instantly. Never clamp
or tie the lower guard into the open position.
If saw is accidentally dropped, lower guard may be
bent.
6) Service
a)Have your power tool serviced by a
qualified repair person using only identical
replacement parts.
This will ensure that the safety of the power tool is
maintained.
CIRCULAR SAW SAFETY WARNINGS
Cutting procedures
a) DANGER: Keep hands away from cutting
area and the blade. Keep your second hand on
auxiliary handle, or motor housing.
If both hands are holding the saw, they cannot be cut
by the blade.
b) Do not reach underneath the workpiece.
The guard cannot protect you from the blade below
the workpiece.
c) Adjust the cutting depth to the thickness of the
workpiece.
Less than a full tooth of the blade teeth should be
visible below the workpiece.
d) Never hold piece being cut in your hands or
across your leg. Secure the workpiece to a stable
platform.
It is important to support the work properly to minimize
body exposure, blade binding, or loss of control.
e) Hold the power tool by insulated gripping
surfaces only, when performing an operation
where the cutting tool may contact hidden wiring.
Contact with a “live” wire will also make exposed
metal parts of the power tool “live” and could give the
operator an electric shock.
f) When ripping always use a rip fence or straight
edge guide.
This improves the accuracy of cut and reduces the
chance of blade binding.
g) Always use blades with correct size and shape
(diamond versus round) of arbour holes.
Blades that do not match the mounting hardware of
the saw will run eccentrically, causing loss of control.
h) Never use damaged or incorrect blade washers
or bolt.
The blade washers and bolt were specially designed
for your saw, for optimum performance and safety of
operation.
Kickback causes and related warnings
– kickback is a sudden reaction to a pinched, bound or
misaligned saw blade, causing an uncontrolled saw to lift
up and out of the workpiece toward the operator;
– when the blade is pinched or bound tightly by the kerf
closing down, the blade stalls and the motor reaction
drives the unit rapidly back toward the operator;
4
English
000BookC18DSLmetabo.indb4000BookC18DSLmetabo.indb4 2018/10/299:18:582018/10/299:18:58

Raise the lower guard with the retracting handle and
make sure it moves freely and does not touch the
blade or any other part, in all angles and depths of cut.
b) Check the operation of the lower guard spring.
If the guard and the spring are not operating
properly, they must be serviced before use.
Lower guard may operate sluggishly due to damaged
parts, gummy deposits, or a build-up of debris.
c) Lower guard should be retracted manually
only for special cuts such as “plunge cuts” and
“compound cuts”.
Raise lower guard by retracting handle and as soon
as blade enters the material, the lower guard must be
released.
For all other sawing, the lower guard should operate
automatically.
d) Always observe that the lower guard is covering
the blade before placing saw down on bench or
floor.
An unprotected, coasting blade will cause the saw to
walk backwards, cutting whatever is in its path.
Be aware of the time it takes for the blade to stop after
switch is released.
SPECIFIC SAFETY RULES
1. NEVER hold piece being cut in your hands or
across your leg. It is important to support the work
properly to minimize body exposure, blade binding, or
loss of control.
2. Hold tool by insulated gripping surfaces when
performing an operation where the cutting tool
may contact hidden wiring. Contact with a “live”
wire will also make exposed metal parts of the tool
“live” and shock the operator.
3. When ripping always use a rip fence or straight
edge guide. This improves the accuracy of cut and
reduces the chance for blade binding.
4. Always use blades with correct size and shape
(diamond vs. round) arbor holes. Blades that do
not match the mounting hardware of the saw will run
eccentrically, causing loss of control.
5. Never use damaged or incorrect blade washers
or bolts. The blade washers and bolt were specially
designed for your saw, for optimum performance and
safety of operation.
6. Hold tools by insulated gripping surfaces when
performing an operation where the cutting tool
may contact hidden wiring or its own cord.
Contact with a “live” wire will make exposed metal
parts of the tool “live” and shock the operator.
7. Never touch moving parts.
Never place your hands, fingers or other body parts
near the tool’s moving parts.
8. Never operate without all guards in place.
Never operate this tool without all guards or safety
features in place and in proper working order. If
maintenance or servicing requires the removal of a
guard or safety feature, be sure to replace the guard
or safety feature before resuming operation of the
tool.
9. Use right tool.
Don’t force small tool or attachment to do the job of a
heavy-duty tool.
Don’t use tool for purpose not intended —for
example— don’t use circular saw for cutting tree
limbs or logs.
10. Never use a power tool for applications other
than those specified.
Never use a power tool for applications other than
those specified in the Instruction Manual.
11. Handle tool correctly.
Operate the tool according to the instructions provided
herein. Do not drop or throw the tool. Never allow the
tool to be operated by children, individuals unfamiliar
with its operation or unauthorized personnel.
12. Definitions for symbols.
V ............ volts
—
---
......... direct current
n
o........... no load speed
---/min.... revolutions or reciprocation per minute
13. Keep all screws, bolts and covers tightly in place.
Keep all screws, bolts, and plates tightly mounted.
Check their condition periodically.
14. Do not use power tools if the plastic housing or
handle is cracked.
Cracks in the tool’s housing or handle can lead to
electric shock. Such tools should not be used until
repaired.
15. Blades and accessories must be securely
mounted to the tool.
Prevent potential injuries to yourself or others. Blades,
cutting implements and accessories which have been
mounted to the tool should be secure and tight.
16. Never use a tool which is defective or operating
abnormally.
If the tool appears to be operating unusually, making
strange noises, or otherwise appears defective, stop
using it immediately and arrange for repairs by a
metabo HPT authorized service center.
17. Carefully handle power tools.
Should a power tool be dropped or struck against
hard materials inadvertently, it may be deformed,
cracked, or damaged.
18. Do not wipe plastic parts with solvent.
Solvents such as gasoline, thinner benzine, carbon
tetrachloride, and alcohol may damage and crack
plastic parts. Do not wipe them with such solvents.
Wipe plastic parts with a soft cloth lightly dampened
with soapy water and dried thoroughly.
5
English
000BookC18DSLmetabo.indb5000BookC18DSLmetabo.indb5 2018/10/299:18:582018/10/299:18:58

IMPORTANT SAFETY INSTRUCTIONS
FOR BATTERY CHARGER
WARNING
Death or serious bodily injury could result from
improper or unsafe use of battery chargers.
To avoid these risks, follow these basic safety
instructions:
READ ALL INSTRUCTIONS
1. This manual contains important safety and operating
instructions for battery charger Model UC18YRSL/
UC18YFSL.
2. Before using battery charger, read all instructions
and cautionary markings on (1) battery charger, (2)
battery, and (3) product using battery.
3. To reduce risk of injury, charge metabo HPT
rechargeable battery type BSL18 series. Other type
of batteries may burst causing personal injury and
damage.
4. Use of an attachment not recommended or sold by
the battery charger manufacturer may result in a risk
of fire, electric shock, or injury to persons.
5. To reduce risk of damage to electric plug and cord,
pull by plug when disconnecting battery charger.
6. Make sure cord is located so that it will not be stepped
on, tripped over, or otherwise subjected to damage or
stress.
7. An extension cord should not be used unless
absolutely necessary. Use of improper extension
cord could result in a risk of fire and electric shock.
If extension cord must be used make sure:
a. That blades of extension cord are the same
number, size, and shape as those of plug on
battery charger:
b. That extension cord is properly wired and in good
electrical condition; and
c. That wire size is large enough for AC ampere
rating of battery charger as specified in Table 1.
IMPORTANT SAFETY INSTRUCTIONS FOR
USE OF THE CORDLESS CIRCULAR SAW
WARNING
Death or serious bodily injury could result from
improper or unsafe use of the cordless circular
saw. To avoid these risks, follow these basic
safety instructions:
1. Wear ear plugs when using the tool for extended
periods. Prolonged exposure to high intensity noise
can cause hearing loss.
2. Never wedge or tie lower guard open. Check
operation of lower guard before each use. Do not use
if lower guard does not close briskly over saw blade.
CAUTION
If saw is dropped, safety cover may be bent
restricting full return.
3. For this mode, the saw blades should be 165 mm.
4. Never place hands or other body parts near the saw
blade during operation. Hold the circular saw by its
handle only.
5. Because the cordless circular saw operates by
battery power, be aware of the fact that it can begin to
operate at any time.
6. Wear eye and ear protection at all times.
7. When working at elevated locations, clear the area of
other people and aware of conditions below you.
8. It is important to support the work properly and to hold
the saw firmly to prevent loss of control which could
cause personal injury.
9. Guard against kickback: Kickback occurs when the
saw stalls rapidly and is driven back towards the
operator. Release switch immediately if blade binds
or saw stalls.
• Keep blades sharp.
• Support the panel near the cut.
• Use guide when ripping.
• Don’t force tool.
• Stay alert exercise control
• Don’t remove saw from work during a cut while the
blade is moving.
10. In operating, keep hold main body firmly.
11. Keep the light ON during cutting operation only. If
it is lit ON in other cases, the main body switch can
be inadvertently turned ON, resulting in unexpected
accidents.
6
English
000BookC18DSLmetabo.indb6000BookC18DSLmetabo.indb6 2018/10/299:18:582018/10/299:18:58

Table 1
RECOMMENDED MINIMUM AWG SIZE FOR
EXTENSION CORDS FOR BATTERY CHARGERS
AC Input Rating Amperes* AWG Size of Cord
Equal to or
greater than but less than
Length of Cord, Feet (Meter)
25 (7.5) 50 (15) 100 (30) 150 (45)
0 2 18 18 18 16
2 3 18 18 16 14
3 4 18 18 16 14
* If the input rating of a battery charger is given in watts
rather than in amperes, the corresponding ampere
rating is to be determined by dividing the wattage
rating by the voltage rating–for example:
1,250 watts = 10 amperes
125 volts
8. Do not operate battery charger with damaged cord or
plug-replace them immediately.
9. Do not operate battery charger if it has received a
sharp blow, been dropped, or otherwise damaged in
any way; take it to a qualified serviceman.
10. Do not disassemble battery charger; take it to a
qualified serviceman when service or repair is
required. Incorrect reassembly may result in a risk of
electric shock or fire.
11. To reduce risk of electric shock, unplug charger from
receptacle before attempting any maintenance or
cleaning. Removing the battery will not reduce this
risk.
12. This battery charger might be attached to metabo HPT
battery operated tools as a standard accessory. In
this case, please confirm instruction Manual of the
metabo HPT battery operated tools before using the
battery charger.
IMPORTANT SAFETY INSTRUCTIONS
FOR USE OF THE BATTERY AND
BATTERY CHARGER
You must charge the battery before you can use the power
tool. Before using the model UC18YRSL/UC18YFSL
battery charger, be sure to read all instructions and
cautionary statements on it, the battery and in this manual.
CAUTION
USE ONLY metabo HPT BATTERY TYPE BSL18
SERIES. OTHER TYPES OF BATTERIES MAY
BURST AND CAUSE INJURY!
Follow these instructions to avoid the risk of injury:
WARNING
Improper use of the battery or battery charger
can lead to serious injury. To avoid these injuries:
1. NEVER disassemble the battery.
2. NEVER incinerate the battery, even if it is damaged or
is completely worn out. The battery can explode in a
fire.
3. NEVER short-circuit the battery.
4. NEVER insert any objects into the battery charger’s
air vents. Electric shock or damage to the battery
charger may result.
5. NEVER charge outdoors. Keep the battery away
from direct sunlight and use only where there is low
humidity and good ventilation.
6. NEVER charge when the temperature is below 32°F
(0°C) or above 104°F (40°C).
7. NEVER connect two battery chargers together.
8. NEVER insert foreign objects into the hole for the
battery or the battery charger.
9. NEVER use a booster transformer when charging.
10. NEVER use an engine generator or DC power to
charge.
11. NEVER store the battery or battery charger in places
where the temperature may reach or exceed 104°F
(40°C) such as inside metal box or car.
12. NEVER expose the battery or battery charger to rain
or wet conditions.
13. ALWAYS operate charger on standard household
electrical power (120 volts). Using the charger on any
other voltage may overheat and damage the charger.
14. ALWAYS wait at least 15 minutes between charges to
avoid overheating the charger.
15. ALWAYS disconnect the power cord from its
receptacle when the charger is not in use.
CAUTION ON LITHIUM-ION BATTERY
To extend the lifetime, the lithium-ion battery equips with
the protection function to stop the output.
In the cases of 1 to 3 described below, when using this
product, even if you are pulling the switch, the motor may
stop. This is not the trouble but the result of protection
function.
7
English
000BookC18DSLmetabo.indb7000BookC18DSLmetabo.indb7 2018/10/299:18:582018/10/299:18:58

1. When the battery power remaining runs out, the motor
stops.
In such case, charge it up immediately.
2. If the tool is overloaded, the motor may stop. In this
case, release the switch of tool and eliminate causes
of overloading. After that, you can use it again.
3. If the battery is overheated under overload work, the
battery power may stop.
In this case, stop using the battery and let the battery
cool. After that, you can use it again.
Furthermore, please heed the following warning and
caution.
WARNING
In order to prevent any battery leakage, heat generation,
smoke emission, explosion and ignition beforehand,
please be sure to heed the following precautions.
1. Make sure that swarf and dust do not collect on the
battery.
○ During work make sure that swarf and dust do not fall
on the battery.
○ Make sure that any swarf and dust falling on the power
tool during work do not collect on the battery.
○ Do not store an unused battery in a location exposed
to swarf and dust.
○ Before storing a battery, remove any swarf and dust
that may adhere to it and do not store it together with
metal parts (screws, nails, etc.).
2. Do not pierce battery with a sharp object such as a
nail, strike with a hammer, step on, throw or subject
the battery to severe physical shock.
3. Do not use an apparently damaged or deformed
battery.
4. Do not use the battery in reverse polarity.
5. Do not connect directly to an electrical outlets or car
cigarette lighter sockets.
6. Do not use the battery for a purpose other than those
specified.
7. If the battery charging fails to complete even when a
specified recharging time has elapsed, immediately
stop further recharging.
8. Do not put or subject the battery to high temperatures
or high pressure such as into a microwave oven,
dryer, or high pressure container.
9. Keep away from fire immediately when leakage or foul
odor are detected.
10. Do not use in a location where strong static electricity
generates.
11. If there is battery leakage, foul odor, heat generated,
discolored or deformed, or in any way appears
abnormal during use, recharging or storage,
immediately remove it from the equipment or battery
charger, and stop use.
12. Do not immerse the battery or allow any fluids to flow
inside. Conductive liquid ingress, such as water, can
cause damage resulting in fire or explosion. Store your
battery in a cool, dry place, away from combustible
and flammable items. Corrosive gas atmospheres
must be avoided.
CAUTION
1. If liquid leaking from the battery gets into your eyes,
do not rub your eyes and wash them well with fresh
clean water such as tap water and contact a doctor
immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well with
clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using
the battery for the first time, do not use and return it to
your supplier or vendor.
WARNING
If an electrically conductive foreign object enters the
terminals of the lithium ion battery, a short-circuit may
occur resulting in the risk of fire. Please observe the
following matters when storing the battery.
○ Do not place electrically conductive cuttings,
nails, steel wire, copper wire or other wire in the
storage case.
○ Either install the battery in the power tool or store
by securely pressing into the battery cover until
the ventilation holes are concealed to prevent
short-circuits (See Fig. 1).
SAVE THESE INSTRUCTIONS
AND
MAKE THEM AVAILABLE TO OTHER USERS
AND
OWNERS OF THIS TOOL!
8
English
000BookC18DSLmetabo.indb8000BookC18DSLmetabo.indb8 2018/10/299:18:582018/10/299:18:58

FUNCTIONAL DESCRIPTION
NOTE
The information contained in this Instruction Manual is designed to assist you in the safe operation and maintenance
of the power tool.
NEVER operate, or attempt any maintenance on the tool unless you have first read and understood all safety
instructions contained in this manual.
Some illustrations in this Instruction Manual may show details or attachments that differ from those on your own
power tool.
NAME OF PARTS
1. Cordless Circular Saw (C18DSL)
Wing-bolt
Bevel plate
Inclined gauge
Switch lock
Lock lever
Housing
Switch trigger
Battery
Wing-nut
Saw blade
Guide Washer (B2)
Left-hand bolt
Lower guard
Nameplate
Base
Light cover
Light bulb
Cover
Screw
○ Battery (BSL1830)
Latch
Ventilation holes
Terminals
Battery cover
Fig. 1
9
English
000BookC18DSLmetabo.indb9000BookC18DSLmetabo.indb9 2018/10/299:18:582018/10/299:18:58

2. Battery Charger
Pilot lamp
Cord
Nameplate
Guide rail
Pilot lamp
Cord
Nameplate Guide rail
<UC18YRSL>
<UC18YFSL>
Fig. 2
SPECIFICATIONS
1. Cordless Circular Saw (C18DSL)
Motor DC motor
No-load speed 3,400/min
Max. Cutting Depth 2-1/4" (57 mm)
Blade Size 6-1/2" (165 mm) D × 5/8" (15.9 mm) H × 1/16" (1.6 mm) T
Battery
Model BSL1830
Type Lithium – ion battery
Voltage DC 18 V
Capacity 3 Ah
Light Bulb 12 V, 5 W
Weight 7.1 lbs. (3.2 kg)
2. Battery Charger
Model UC18YRSL UC18YFSL
Input power source Single phase: AC120V 60Hz
Charging time
(At a temperature of 68°F (20°C)) Approx. 45 min.
Charging voltage DC 14.4V 18V
Charging current DC 3.5A
Weight 1.3 lbs. (0.6 kg) 1.1 lbs. (0.5 kg)
NOTE: The charging time may vary according to ambient temperature and power source voltage.
10
English
000BookC18DSLmetabo.indb10000BookC18DSLmetabo.indb10 2018/10/299:18:582018/10/299:18:58

ASSEMBLY AND OPERATION
2. Insert the battery to the battery charger.
Insert the battery into the battery charger as shown in
Fig. 4.
<UC18YRSL>
Battery
Charger
Pilot lamp
<UC18YFSL>
Charger
Battery
Pilot lamp
Fig. 4
3. Charging
When the battery is connected to the battery charger,
charging will commence and the pilot lamp will light in
red. (See Table 2)
NOTE
If the pilot lamp flikers in red, pull out the plug from
the receptacle and check if the battery is properly
mounted.
When the battery is fully charged, the pilot lamp will
blink in red slowly.(At 1-second intervals) (SeeTable 2)
(1) Pilot lamp indication
The indications of the pilot lamp will be as shown in
Table 2, according to the condition of the charger or
the rechargeable battery.
APPLICATIONS
○
Cutting various types of wood.
REMOVAL AND INSTALLATION METHOD
OF BATTERY
1. Battery removal
Hold the handle tightly and push the battery latch to
remove the battery (see Fig. 3).
CAUTION
Never short-circuit the battery.
2. Battery installation
Insert the battery while observing its polarities (see
Fig. 3).
Latch
Battery
Pull out
Insert
Push
Handle
Fig. 3
CHARGING METHOD
NOTE
Before plugging into the receptacle, make sure the
following points.
○ The power source voltage is stated on the
nameplate.
○ The cord is not damaged.
WARNING
Do not charge at voltage higher than indicated
on the nameplate.
If charged at voltage higher than indicated on the
nameplate, the charger will burn out.
1. Connect the charger’s power cord to a receptacle.
When the power cord is connected, the charger’s pilot
lamp will blink in red. (At 1-second intervals)
WARNING
Do not use the electrical cord
if damaged. Have it repaired
immediately.
11
English
000BookC18DSLmetabo.indb11000BookC18DSLmetabo.indb11 2018/10/299:18:592018/10/299:18:59

Table 2
Indications of the pilot lamp
The pilot
lamp lights
or blinks.
Before
charging Blinks (red)
Lights for 0.5 seconds. Does not light for 0.5
seconds. (offfor 0.5 seconds)
While
charging Lights (red) Lights continuously
Charging
complete Blinks (red)
Lights for 0.5 seconds. Does not light for 0.5
seconds. (offfor 0.5 seconds)
Charging
impossible Flickers (red)
Lights for 0.1 seconds. Does not light for 0.1
seconds. (offfor 0.1 seconds) Malfunction in the battery
or the charger
Overheat
standby
Lights
(green)
<UC18YRSL>
Lights continuously
Battery overheated.
Unable to charge
(Charging will commence
when battery cools).
Blinks
(red)
<UC18YFSL>
Lights for 1 second. Does not light for 0.5
seconds. (offfor 0.5 seconds)
(2) Regarding the temperature of the rechargeable
battery.
The temperatures for rechargeable batteries are
as shown in the Table 3, and batteries that have
become hot should be cooled for a while before being
recharged.
Table 3 Recharging ranges of batteries
Rechargeable
batteries Temperatures at which the
battery can be recharged
BSL1830 32°F–104°F
(0°C–40°C)
(3) Regarding recharging time
Table 4 Charging time (At 68°F (20°C))
Charger
Battery UC18YRSL / UC18YFSL
BSL1830 Approx. 45 min.
NOTE
The charging time may vary according to temperature
and power source voltage.
4. Disconnect battery charger from the receptacle.
CAUTION
●
Do not pull the plug out of the receptacle by
pulling on the cord.
Make sure to grasp the plug when removing from
receptacle to avoid damaging cord.
5. Remove the battery from the battery charger.
Supporting the battery charger with hand, pull out the
battery from the battery charger.
How to make the batteries perform longer
(1) Recharge the batteries before they become
completely exhausted.
When you feel that the power of the tool becomes
weaker, stop using the tool and recharge its battery.
If you continue to use the tool and exhaust the electric
current, the battery may be damaged and its life will
become shorter.
(2) Avoid recharging at high temperatures.
A rechargeable battery will be hot immediately after
use. If such a battery is recharged immediately after
use, its internal chemical substance will deteriorate,
and the battery life will be shortened. Leave the
battery and recharge it after it has cooled for a while.
CAUTION
●
When the battery charger has been continuosly
used, the battery charger will be heated, thus
constituting the cause of the failures. Once the
charging has been completed, give 15 minutes
rest until the next charging.
● If the battery is rechraged when it is warm due
to battery use or exposure to sunlight, the pilot
lamp may light in green.
The battery will not be recharged. In such a case,
let the battery cool before charging.
12
English
000BookC18DSLmetabo.indb12000BookC18DSLmetabo.indb12 2018/10/299:18:592018/10/299:18:59

● When the pilot lamp flikers rapidly in red (at
0.2–second intervals), check for and take out
any foreign objects in the charger’s battery
installation hole. If there are no foreign objects,
it is probable that the battery or charger is
malfunctioning. Take it to your authorized
Service Center.
BEFORE USE
1. Check the work area environment
Check the work area to make sure that it is clear of
debris and clutter.
Clear the area of unnecessary personnel. Ensure that
lighting and ventilation is adequate.
2. Check if saw blade is tightened
While the saw blade is tightened securely for
immediate use when it is assembled at the factory, be
sure to check it out again for caution’s sake. A bolt
can be tightened when it is turned clockwise. Use the
provided box wrench to check it out.
For further details, refer to the item of [MOUNTING
AND DISMOUNTING THE SAW BLADE] on Page 16.
3. Check if wing nut is tightened
If the wing nut to adjust cutting depth (Fig. 6) is loose,
injury can result. Make sure that it is tightened
securely.
4. Check performance of lower guard
WARNING
Make absolutely sure that the lower guard is
not fixed. Also, check and see if it can move
smoothly. If the saw blade is kept exposed,
injury can result.
The lower guard (refer to Fig. 1) serves to protect your
body from coming into contact with the saw blade.
Make absolutely certain that the cover smoothly
performs to cover the saw blade. If the lower guard
should not move smoothly, never use it without
repairing it.
In such a case, get in touch with the store where
you bought the circular saw or the metabo HPT
AUTHORIZED SERVICE CENTER for necessary
repair.
5. Check battery insertion
WARNING
If the battery is inserted while the power switch
is in the ON position, the power tool will start
operating immediately, inviting serious accident.
CAUTION
Until the battery locks in place with a little click, if
not, it may accidentally fall out of the tool causing
injury to you or someone around you.
6. Check for proper operation of the brake
This circular saw features an electric brake that
functions when the switch is released. Before using
the circular saw, ensure that the electric brake
functions properly. If it does not, bring the tool to a
metabo HPT AUTHORIZED SERVICE CENTER.
7. Prepare a wooden work bench (Fig. 5)
Since the saw blade will extend beyond the lower
surface of the lumber, place the lumber on a work
bench when cutting. If a square block is utilized
as a work bench, select level ground to ensure it is
properly stabilized. An unstable work bench will result
in hazardous operation.
Base
Lumber
Work bench Saw blade
Fig. 5
CAUTION
To avoid possible accident, always ensure that
the portion of lumber remaining after cutting is
securely anchored or held in position.
ADJUSTING THE SAW PRIOR TO USE
1. Adjusting the cutting depth (Fig. 6)
WARNING
If the wing-nut is loose, injury can result. Tighten
it securely after adjustment.
To adjust cutting depth, loosen the Wing-nut and,
while holding the base with one hand, move the main
body up and down to obtain the prescribed cutting
depth.
After adjusting to the prescribed cutting depth, tighten
the Wing-nut securely.
Wing-nut
Base
Handle
Fig. 6
13
English
000BookC18DSLmetabo.indb13000BookC18DSLmetabo.indb13 2018/10/299:18:592018/10/299:18:59

OPERATION
WARNING
● Never touch the moving parts.
● Never operate the circular saw with the saw
blade turned upward or to the side.
● Do not fix and secure the switch lock. Besides,
keep your finger offthe switch trigger when the
circular saw is being carried around. Otherwise,
the main body switch can be inadvertently turned
ON, resulting in unexpected accidents.
● Keep the light ON during cutting operation only.
If it is lit ON in other cases, the main body switch
can be inadvertently turned ON, resulting in
unexpected accidents.
● Do not use any abrasive wheels.
● Use only blade diameter specified on the product
nameplate.
CAUTION
●
Don’t remove circular saw from workpiece during
a cut while the saw blade is moving.
● Pull out the battery after completing operation.
NOTE
Take care not to lock the motor. If the motor is locked,
immediately turn the power off. If the motor is locked
for a while, the motor or battery may be burnt.
1. Operation of switch (Switch trigger and light switch)
For safe operation of the machine, a “switch lock” is
provided on the side of a handle.
If the “switch lock” is pulled in a state where it is
pressed in the direction of the arrow mark, the main
switch can be turned ON.
(1) Switch lock is used as the “light switch”. If the “switch
lock (light switch)” is pulled in a state, the light is
turned ON.
(2) After the switch is turned ON, even when you release
your hand from the switch lock, the body continues
running and the light continues being turned ON as
long as you keep on pulling the switch trigger.
(3) If you release the switch trigger, you can turn OFF
the switch and the “switch lock” returns to the original
position automatically and the light turns OFF too.
Switch trigger
Switch lock
* (It works as
switch lock
alone if the
machine is not
equipped with
light.)
Fig. 9
2. Adjusting the angle of inclination
WARNING
If the wing-nut is loose, injury can result. Tighten
it securely after adjustment.
As shown in Fig. 7 by loosening the wing-bolt on the
inclined gauge, the saw blade may be inclined to a
maximum angle of 50° in relation to the base. Always
insure that the wing-bolt is thoroughly tightened after
making the desired adjustment.
Inclined
gauge
Cutting line
(at 45 degrees)
Wing-bolt
Fig. 7
NOTE
Values of the inclined gauge provided on the base
merely serve as a rough guideline. For cutting
operation at an inclined posture, use the circular saw
after adjusting the angle between the base and the
saw blade with a protractor, etc.
3. Regulating the guide (Fig. 8)
The cutting position can be regulated by moving the
guide to the left or right after loosening its knob-bolt.
The guide may be mounted on either the right or left
side of the tool.
Knob-bolt
Guide
Fig. 8
14
English
000BookC18DSLmetabo.indb14000BookC18DSLmetabo.indb14 2018/10/299:18:592018/10/299:18:59

Wood Capacity
2 × 8 (Spruce-Pine-Fir) 75 cuts
Concreteform plywood
(1/2" (12 mm) t) 133 ft (40 m)
To improve working efficiency per single charge,
○ Minimize operation (no-load operation) other than
cutting;
○ Avoid any unreasonably forced pressure to the motor
during cutting operation by twisting or pressing the
circular saw forcibly;
○ Avoid any use of dull saw blade.
4. Cutting procedures
CAUTION
●
Recheck that the saw blade is securely clamped.
● Confirm that the wing-nut for adjusting the slot
depth, the wing-bolt for adjusting the angle of
inclination.
(1) Place the base on the material, then align the
premarked line and the saw blade with the notch at
the front of the base (Fig. 11).
(2) When the base is not inclined, use the large notch
(Fig. 11, Fig. 12).
If the base is inclined (45 degrees), use the small
notch (Fig. 11, Fig. 13).
Not inclined
Saw blade
Fig. 11 <Top View>
2. About Remaining Battery Indicator
When pressing the remaining battery indicator switch,
the remaining battery indicator lamp lights and the
battery remaining power can be checked. (Fig. 10)
When releasing your finger from the remaining battery
indicator switch, the remaining battery indicator lamp
goes off. The Table 5 shows the state of remaining
battery indicator lamp and the battery remaining
power.
Remaining battery
indicator lamp
Remaining battery
indicator switch
Fig. 10
Table 5
State of lamp Battery Remaining Power
The battery remaining power is
enough.
The battery remaining power
is a half.
The battery remaining power is
nearly empty.
Re-charge the battery soonest
possible.
As the remaining battery indicator shows somewhat
differently depending on ambient temperature and
battery characteristics, read it as a reference.
NOTE
○ Do not give a strong shock to the switch panel or
break it. It may lead to a trouble.
○ To save the battery power consumption, the
remaining battery indicator lamp lights while pressing
the remaining battery indicator switch.
3. Working performance per single charge (Reference
data)
○ Cutting capability differs according to the condition
of lumber, type of saw blade, ambient temperature,
battery characteristics, etc.
15
English
000BookC18DSLmetabo.indb15000BookC18DSLmetabo.indb15 2018/10/299:18:592018/10/299:18:59

Wing-bolt
Guide
Fig. 12 Not inclined
Inclined
gauge
Wing-bolt Cutting line
(at 45 degrees)
Fig. 13
NOTE
When using the saw at the inclination of 45 degrees,
use both the marks of on the bevel plate and [45] on
the inclined gauge of the base (Fig. 14).
What’s more, if it is absolutely essential to use the
saw at a precise angle, make adjustment using a
protractor, etc.
Bevel plate
Inclined
gauge
Wing-bolt
1 5
0
3 0
4 5
Fig. 14
(3) Ensure that the switch is turned to the ON position
before the saw blade comes in contact with the
lumber. The switch is turned ON when the trigger
is squeezed; and OFF when the trigger is released.
Moving the saw straight at a constant speed will
produce optimum cutting.
CAUTION
●
Before starting to saw, ensure that the saw blade
has reached full speed revolution.
● Should the saw blade be stopped or made an
abnormal noise during operation, turn offthe
switch immediately.
● When finished with a job, pull out the battery
from the main body.
● Twisting and forcibly pressing the saw during
cutting can result in unreasonable pressure on
the motor, so try to go straight quietly.
● In the situation where the circular saw is
continuously operated while replacing the
battery with stocked spare batteries one after
another, the motor tends to overheat. Therefore,
whenever the housing becomes hot, give the saw
a break for a while.
● Avoid cutting operation in a state where the base
bottom is afloat from the material being cut.
Otherwise, the motor can get locked.
MOUNTING AND DISMOUNTING THE SAW
BLADE
CAUTION
To avoid serious accident, ensure the switch is in
the OFF position, and pull out the battery.
1. Dismounting the saw blade
(1) Set the cutting volume at maximum, and place the
Circular Saw as shown in Fig. 15.
Box wrench
Lock lever
Tighten
Loosen
Fig. 15
(2) Depress the lock lever, lock the spindle, and remove
the left-hand bolt and washer (B2) with the box
wrench.
16
English
000BookC18DSLmetabo.indb16000BookC18DSLmetabo.indb16 2018/10/299:18:592018/10/299:18:59

(3) While holding the lower guard lever to keep the lower
guard fully retracted into the saw cover, remove the
saw blade (Fig. 16).
Lower guard lever
Saw cover
Saw blade
Fig. 16
2. Mounting the Saw Blade (Fig. 17)
WARNING
If the left-hand bolt is worked using other
tools than the provided box wrench, excessive
tightening and insufficient tightening may take
place, resulting in injury.
○ Take procedures here that are contrary to the
detaching procedures.
Left-hand bolt Ring
Washer (A1)
Spindle
Washer (B2)
Concave
Saw blade
Fig. 17
NOTE
● Thoroughly remove any sawdust which has
accumulated on the spindle, bolt and washers.
● To assure proper rotation direction of the saw blade,
the arrow direction on the saw blade must coincide
with the arrow direction on the saw cover.
● Using the fingers, tighten the left-hand bolt retaining
the saw blade as much as possible. Then depress the
lock lever, lock the spindle, and thoroughly tighten the
left-hand bolt.
CAUTION
After mounting the saw blade, reconfirm that
the lock lever is firmly secured in the prescribed
position.
REPLACING LIGHT BULB
WARNING
● Make absolutely sure that the battery is removed
from the main body before replacing the light
bulb.
● Immediately after the light is turned OFF, the
bulb retains high temperature. Make sure to cool
down the light bulb thoroughly before replacing
it so as to prevent burns.
CAUTION
When replacing the light bulb, check the shape
of base as well as the rating (12 V, 5 W), and then
carry out perfect mounting. Otherwise, the light
bulb can come offand/or cause overheat.
1. Detaching light bulb
(1) Remove the convex part of the light cover from the
concave part of the housing, and then pull out the
light cover in the arrow-marked direction as shown in
Fig. 18.
Housing
Light cover
Convex
Concave
Fig. 18 <Side View>
17
English
000BookC18DSLmetabo.indb17000BookC18DSLmetabo.indb17 2018/10/299:18:592018/10/299:18:59

(2) Push the back of the socket, and remove the socket
and the light bulb together from the housing (Fig. 19).
Housing
Back of the socket
Fig. 19
(3) Remove the light bulb from the socket (Fig. 20).
Housing
Light bulb
Socket
Fig. 20 <Top View>
2. Attaching light bulb
Take procedures here that are contrary to the
detaching procedures.
NOTE
● When attaching the light bulb to the socket, insert the
light bulb until it lightly bumps against the socket.
● When attaching the socket to the housing, align the
socket with the hole of housing while watching the
back of the socket shown in Fig. 20, and insert the
socket until it lightly bumps against the housing.
18
English
000BookC18DSLmetabo.indb18000BookC18DSLmetabo.indb18 2018/10/299:18:592018/10/299:18:59

MAINTENANCE AND INSPECTION
CAUTION
Pull out battery before doing any inspection or
maintenance.
1. Inspecting the saw blade
Since use of a dull saw blade will degrade efficiency
and cause possible motor malfunction, sharpen or
replace the saw blade as soon as abrasion is noted.
CAUTION
If a dull saw blade is used, reactive force is
increased during cutting operation. Avoid the
use of the dull saw blade without repair.
2. Check the mounting screws
Loose mounting screws are dangerous. Regularly
inspect them and make sure they are tight.
CAUTION
Using this power tool with loosen, screws is
extremely dangerous.
3. Performance checkup and maintenance of lower
guard
Keep the lower guard in good shape for smooth
performance at all times. Be sure to make prompt
repair in case of any malfunction.
4. Adjusting the base and saw blade to maintain
perpendicularity
The angle between the base and the saw blade
has been adjusted to 90°, however should this
perpendicularity be lost for some reason, adjust in the
following manner.
(1) Turn the base face up (Fig. 21) and loosen the wing-
bolt.
Square
Slotted
set screw
Wing-bolt
Fig. 21
(2) Apply a square to the base and the saw blade and,
turning the slotted set screw with a slotted-head
screwdriver, shift the position of the base to produce
the desired right angle.
5. Check for dust
Dust may be removed with a clean rag or a cloth
dampened with soapy water.
Do not use bleach, chlorine, gasoline or thinner, for
they may damage the plastics.
6. Disposal of the exhausted battery
WARNING
Do not dispose of the exhausted battery. The
battery must explode if it is incinerated. The
product that you have purchased contains a
rechargeable battery. The battery is recyclable.
At the end of it’s useful life, under various state
and local laws, it may be illegal to dispose of this
battery into the municipal waste stream. Check
with your local solid waste officials for details
in your area for recycling options or proper
disposal.
7. Storage
Storing in a place below 104°F (40°C) and out of the
reach of children.
NOTE
Storing lithium-ion batteries
Make sure the lithium-ion batteries have been fully
charged before storing them.
Prolonged storage (3 months or more) of batteries with
a low charge may result in performance deterioration,
significantly reducing battery usage time or rendering
the batteries incapable of holding a charge.
However, significantly reduced battery usage time
may be recovered by repeatedly charging and using
the batteries two to five times.
If the battery usage time is extremely short despite
repeated charging and use, consider the batteries
dead and purchase new batteries.
8. Service and repairs
All quality power tools will eventually require servicing
or replacement of parts because of wear from normal
use. To assure that only genuine replacement
parts must be used, all service and repairs must be
performed by a metabo HPT AUTHORIZED SERVICE
CENTER, ONLY.
CAUTION
In the operation and maintenance of power tools,
the safety regulations and standards prescribed
in each country must be observed.
19
English
000BookC18DSLmetabo.indb19000BookC18DSLmetabo.indb19 2018/10/299:18:592018/10/299:18:59

Important notice on the batteries for the metabo HPT
cordless power tools
Please always use one of our designated genuine
batteries. We cannot guarantee the safety and
performance of our cordless power tool when used
with batteries other than these designated by us, or
when the battery is disassembled and modified (such
as disassembly and replacement of cells or other
internal parts).
ACCESSORIES
WARNING
ALWAYS use Only authorized metabo HPT replacement parts and accessories. Never use replacement
parts or accessories which are not intended for use with this tool. Contact metabo HPT if you are not sure
whether it is safe to use a particular replacement part or accessory with your tool.
The use of any other attachment or accessory can be dangerous and could cause injury or mechanical
damage.
NOTE
Accessories are subject to change without any obligation on the part of the metabo HPT.
STANDARD ACCESSORIES
C18DSL
(1LSCK)
1 Saw Blade (mounted on tool) ............................................................1
External Diam. Hole Diam. Code No.
6-1/2" (165 mm) 5/8" (15.9 mm) 324293
2 Box Wrench (Code No.940543) ........................................................1
3 Guide (Code No.302756) ..................................................................1
4 Battery (BSL1830) .............................................................................1
5 Battery Charger (UC18YRSL or UC18YFSL) .....................................1
6 Plastic Case (Code No. 330274) ........................................................ 1
C18DSL
(NN)
123
1
Saw Blade (mounted on tool) ............................................................1
External Diam. Hole Diam. Code No.
6-1/2" (165 mm) 5/8" (15.9 mm) 324293
2 Box Wrench (Code No.940543) ........................................................1
3 Guide (Code No.302756) ..................................................................1
45
123
6
5
20
English
000BookC18DSLmetabo.indb20000BookC18DSLmetabo.indb20 2018/10/299:18:592018/10/299:18:59
