Metabo HPT C3607DWA Troubleshooting guide

Model
Modèle
Modelo
C 3607DWA
Cordless Rear Handle Circular Saw
Scie circulaire sans fil à poignée arrière
Sierra Circular Inalámbrica con Mango Posterior
SAFETY INSTRUCTIONS AND INSTRUCTION MANUAL
WARNING
IMPROPER OR UNSAFE use of this power tool can result in death or serious bodily injury!
This manual contains important information about product safety. Please read and
understand this manual BEFORE operating the power tool. Please keep this manual
available for other users and owners before they use the power tool. This manual should be
stored in safe place.
INSTRUCTIONS DE SECURITE ET MODE D’EMPLOI
AVERTISSEMENT
Une utilisation INCORRECTE OU DANGEREUSE de cet outil motorisé peut entraîner la
mort ou de sérieuses blessures corporelles!
Ce mode d’emploi contient d’importantes informations à propos de la sécurité de ce produit.
Prière de lire et de comprendre ce mode d’emploi AVANT d’utiliser l’outil motorisé. Garder ce
mode d’emploi à la disponibilité des autres utilisateurs et propriétaires avant qu’ils utilisent
l’outil motorisé. Ce mode d’emploi doit être conservé dans un endroit sûr.
INSTRUCCIONES DE SEGURIDAD Y MANUAL DE INSTRUCCIONES
ADVERTENCIA
¡La utilización INAPROPIADA O PELIGROSA de esta herramienta eléctrica puede resultar
en lesiones de gravedad o la muerte!
Este manual contiene información importante sobre la seguridad del producto. Lea y
comprenda este manual ANTES de utilizar la herramienta eléctrica. Guarde este manual
para que puedan leerlo otras personas antes de utilizar la herramienta eléctrica. Este
manual debe ser guardado en un lugar seguro.
Designed for operating in USA & Canada only.
When this product is used in areas other than the USA & Canada,
we cannot guarantee the product quality and performance.
00BookC3607DWANA.indb100BookC3607DWANA.indb1 2021/06/1016:51:392021/06/1016:51:39

IMPORTANT SAFETY INFORMATION
Read and understand all of the safety precautions, warnings and operating instructions in the Instruction Manual before
operating or maintaining this power tool.
Most accidents that result from power tool operation and maintenance are caused by the failure to observe basic safety
rules or precautions. An accident can often be avoided by recognizing a potentially hazardous situation before it occurs,
and by observing appropriate safety procedures.
Basic safety precautions are outlined in the “SAFETY” section of this Instruction Manual and in the sections which
contain the operation and maintenance instructions.
Hazards that must be avoided to prevent bodily injury or machine damage are identified by WARNINGS on the power
tool and in this Instruction Manual.
NEVER use this power tool in a manner that has not been specifically recommended by metabo HPT.
MEANINGS OF SIGNAL WORDS
WARNING indicates a potentially hazardous situations which, if ignored, could result in death or serious injury.
CAUTION indicates a potentially hazardous situations which, if not avoided, may result in minor or moderate injury, or
may cause machine damage.
NOTE emphasizes essential information.
SAFETY
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
Read all safety warnings, instructions, illustrations and specifications provided with this power tool.
Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and matching outlets will reduce
risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will increase the risk
of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool.
Keep cord away from heat, oil, sharp edges or
moving parts.
Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the
risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
2
English
00BookC3607DWANA.indb200BookC3607DWANA.indb2 2021/06/1016:51:402021/06/1016:51:40

3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication.
A moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection.
Protective equipment such as a dust mask, non-
skid safety shoes, hard hat or hearing protection
used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool.
Carrying power tools with your finger on the switch
or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on.
A wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times.
This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts.
Loose clothes, jewellery or long hair can be caught
in moving parts.
g) If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used.
Use of dust collection can reduce dust-related
hazards.
h) Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles.
A careless action can cause severe injury within a
fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application.
The correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off.
Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any
adjustments, changing accessories, or
storing power tools.
Such preventive safety measures reduce the risk
of starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool.
Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation.
If damaged, have the power tool repaired
before use.
Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier
to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed.
Use of the power tool for operations different
from those intended could result in a hazardous
situation.
h) Keep handles and grasping surfaces dry,
clean and free from oil and grease.
Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in
unexpected situations.
5) Battery tool use and care
a) Recharge only with the charger specified by
the manufacturer.
A charger that is suitable for one type of battery
pack may create a risk of fire when used with
another battery pack.
b) Use power tools only with specifically
designated battery packs.
Use of any other battery packs may create a risk of
injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
3
English
00BookC3607DWANA.indb300BookC3607DWANA.indb3 2021/06/1016:51:402021/06/1016:51:40

d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water.
If liquid contacts eyes, additionally seek
medical help.
Liquid ejected from the battery may cause irritation
or burns.
e) Do not use a battery pack or tool that is
damaged or modified.
Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion
or risk of injury.
f) Do not expose a battery pack or tool to fire or
excessive temperature.
Exposure to fire or temperature above 265 °F may
cause explosion.
g) Follow all charging instructions and do
not charge the battery pack or tool outside
the temperature range specified in the
instructions.
Charging improperly or at temperatures outside
the specified range may damage the battery and
increase the risk of fire.
6) Service
a)Have your power tool serviced by a
qualified repair person using only identical
replacement parts.
This will ensure that the safety of the power tool is
maintained.
b) Never service damaged battery packs.
Service of battery packs should only be performed
by the manufacturer or authorized service
providers.
– WARNING –
To reduce the risk of injury, user must read
instruction manual.
CORDLESS REAR HANDLE CIRCULAR
SAW SAFETY WARNINGS
Cutting procedures
a) DANGER: Keep hands away from cutting area
and the blade. Keep your second hand on sub
handle.
If both hands are holding the saw, they cannot be cut
by the blade.
b) Do not reach underneath the workpiece.
The guard cannot protect you from the blade below
the workpiece.
c) Adjust the cutting depth to the thickness of the
workpiece.
Less than a full tooth of the blade teeth should be
visible below the workpiece.
d) Never hold the workpiece in your hands or across
your leg while cutting. Secure the workpiece to a
stable platform.
It is important to support the work properly to minimise
body exposure, blade binding, or loss of control.
e) Hold the power tool by insulated gripping
surfaces, when performing an operation where
the cutting tool may contact hidden wiring.
Contact with a “live” wire will also make exposed
metal parts of the power tool “live” and could give the
operator an electric shock.
f) When ripping, always use a rip fence or straight
edge guide.
This improves the accuracy of cut and reduces the
chance of blade binding.
g) Always use blades with correct size and shape
(diamond versus round) of arbour holes.
Blades that do not match the mounting hardware of
the saw will run off-centre, causing loss of control.
h) Never use damaged or incorrect blade washers
or bolt.
The blade washers and bolt were specially designed
for your saw, for optimum performance and safety of
operation.
Kickback causes and related warnings
– kickback is a sudden reaction to a pinched, jammed
or misaligned saw blade, causing an uncontrolled saw
to lift up and out of the workpiece toward the operator;
– when the blade is pinched or jammed tightly by the
kerf closing down, the blade stalls and the motor
reaction drives the unit rapidly back toward the
operator;
– if the blade becomes twisted or misaligned in the cut,
the teeth at the back edge of the blade can dig into the
top surface of the wood causing the blade to climb out
of the kerf and jump back toward the operator.
Kickback is the result of saw misuse and/or incorrect
operating procedures or conditions and can be avoided by
taking proper precautions as given below.
a) Maintain a firm grip with both hands on the saw
and position your arms to resist kickback forces.
Position your body to either side of the blade,
but not in line with the blade.
Kickback could cause the saw to jump backwards,
but kickback forces can be controlled by the operator,
if proper precautions are taken.
b) When blade is binding, or when interrupting a
cut for any reason, release the trigger and hold
the saw motionless in the material until the blade
comes to a complete stop.
Never attempt to remove the saw from the work
or pull the saw backward while the blade is in
motion or kickback may occur.
Investigate and take corrective actions to eliminate
the cause of blade binding.
4
English
00BookC3607DWANA.indb400BookC3607DWANA.indb4 2021/06/1016:51:402021/06/1016:51:40

Others
1. ALWAYS wear proper apparel. Do not wear loose
clothing, gloves, neckties, rings, bracelets or other
jewelry which may get caught in moving parts to
lead personal injury. Wear protective hair covering to
contain long hair.
2. ALWAYS wear eye protection. Any power tool can
throw foreign objects into eyes and could cause
permanent eye damage. ALWAYS wear Safety
Goggles (not glasses) that comply with ANSI Safety
standard Z87.1. Everyday eyeglasses have only
impact–resistant lenses. They ARE NOT safety
glasses.
3. Wear suitable personal protective equipment when
necessary, this could include:
● hearing protection to reduce the risk of induced
hearing loss;
● eye protection;
● respiratory protection which are approved by
NIOSH/OSHA to reduce the risk of inhalation of
harmful dust;
● gloves for handling saw blades (saw blades shall
be carried in a holder wherever practicable) and
rough material.
4. Keep alert. Never operate the saw when you feel tired
or when you are under the the influence of any drugs,
alcohol or medication that could affect your ability to
use the tool properly.
5. Keep the working environment well ventilated. Some
dust created by power sanding, sawing, grinding,
drilling and other construction activities contains
chemicals to cause cancer, birth defects or other
reproductive harm. Therefore, work in a well ventilated
area, and work with approved safety equipment, such
as those dust masks that are specially designed to
filter out microscopic particles.
6. Avoid prolonged contact with dust from power
sanding, sawing, grinding, drilling, and other
construction activities. Wear protective clothing and
wash exposed areas with soap and water. Allowing
dust to get into your mouth, eyes, or lay on the skin
may promote absorption of harmful chemicals.
7. To prevent from fire or toxic reactio, never use
gasoline, naphtha acetone, lacquer thinner or similar
highly volatile solvents to clean the saw.
SPECIFIC SAFETY RULES
1. Adjustments. Before cutting be sure depth and
bevel adjustments are tight.
2. Avoid cutting nails. Inspect for and remove all
nails from work piece before cutting.
3. When operating the saw, keep the cord away
from the cutting area and position it so that it
will not be caught on the workpiece during the
cutting operation.
c) When restarting a saw in the workpiece, centre
the saw blade in the kerf so that saw teeth are not
engaged into the material.
If a saw blade binds, it may walk up or kickback from
the workpiece as the saw is restarted.
d) Support large panels to minimise the risk of
blade pinching and kickback.
Large panels tend to sag under their own weight.
Supports must be placed under the panel on both
sides, near the line of cut and near the edge of the
panel.
e) Do not use dull or damaged blades.
Unsharpened or improperly set blades produce
narrow kerf causing excessive friction, blade binding
and kickback.
f) Blade depth and bevel adjusting locking levers
must be tight and secure before making the cut.
If blade adjustment shifts while cutting, it may cause
binding and kickback.
g) Use extra caution when sawing into existing
walls or other blind areas.
The protruding blade may cut objects that can cause
kickback.
Lower guard function
a) Check the lower guard for proper closing before
each use. Do not operate the saw if the lower
guard does not move freely and close instantly.
Never clamp or tie the lower guard into the open
position.
If the saw is accidentally dropped, the lower guard
may be bent.
Raise the lower guard with the retracting handle and
make sure it moves freely and does not touch the
blade or any other part, in all angles and depths of cut.
b) Check the operation of the lower guard spring.
If the guard and the spring are not operating
properly, they must be serviced before use.
Lower guard may operate sluggishly due to damaged
parts, gummy deposits, or a build-up of debris.
c) The lower guard may be retracted manually
only for special cuts such as “plunge cuts” and
“compound cuts”.
Raise the lower guard by the retracting handle
and as soon as the blade enters the material, the
lower guard must be released.
For all other sawing, the lower guard should operate
automatically.
d) Always observe that the lower guard is covering
the blade before placing the saw down on bench
or floor.
An unprotected, coasting blade will cause the saw to
walk backwards, cutting whatever is in its path.
Be aware of the time it takes for the blade to stop after
switch is released.
5
English
00BookC3607DWANA.indb500BookC3607DWANA.indb5 2021/06/1016:51:402021/06/1016:51:40

Operate with proper hand support, proper workpiece
support, and supply cord routing away from the work
area.
WARNING
It is important to support the work piece properly
and to hold the saw firmly to prevent loss of
control which could cause personal injury. Fig. 1
illustrates typical hand support of the saw.
A TYPICAL ILLUSTRATION OF PROPER
HAND SUPPORT WORKPIECE SUPPORT.
Fig. 1
4. Place the wider portion of the base on that part of
the work piece which is solidly supported, not on
the section that will fall offwhen the cut is made.
As examples, Fig. 2 illustrates the RIGHT way to cut
offthe end of board, and Fig. 3 the WRONG way. If the
work piece is short or small, clamp it down.
DON’T TRY TO HOLD SHORT PLACES BY HAND!
Fig. 2
Fig. 3
5. Never attempt to saw with the circular saw held
upside down in a vise.
This is extremely dangerous and can lead to serious
accidents. (Fig. 4)
Fig. 4
6. Before setting the tool down after completing a
cut, be sure that the lower (telescoping) guard
has closed and the blade has come to a complete
stop.
7. Never touch moving parts.
Never place your hands, fingers or other body parts
near the tool’s moving parts.
8. Never operate without all guards in place.
Never operate this tool without all guards or safety
features in place and in proper working order. If
maintenance or servicing requires the removal of a
guard or safety feature, be sure to replace the guard
or safety feature before resuming operation of the
tool.
9. Use right tool.
Don’t force small tool or attachment to do the job of a
heavy-duty tool.
Don’t use tool for purpose not intended —for
example— don’t use circular saw for cutting tree
limbs or logs.
10. Never use a power tool for applications other
than those specified.
Never use a power tool for applications other than
those specified in the Instruction Manual.
11. Handle tool correctly.
Operate the tool according to the instructions provided
herein. Do not drop or throw the tool. Never allow the
tool to be operated by children, individuals unfamiliar
with its operation or unauthorized personnel.
12. Definitions for symbols.
V .................volts
—.................direct current
no................no load speed
---/min..........revolutions or reciprocation per minute
Hz ................hertz
A..................amperes
13. Do not run the saw while carrying it at your side.
14. Keep all screws, bolts and covers tightly in place.
Keep all screws, bolts, and plates tightly mounted.
Check their condition periodically.
6
English
00BookC3607DWANA.indb600BookC3607DWANA.indb6 2021/06/1016:51:402021/06/1016:51:40

15. Do not use power tools if the plastic housing or
handle is cracked.
Cracks in the tool’s housing or handle can lead to
electric shock. Such tools should not be used until
repaired.
16. Blades and accessories must be securely
mounted to the tool.
Prevent potential injuries to yourself or others. Blades,
cutting implements and accessories which have been
mounted to the tool should be secure and tight.
17. Never use a tool which is defective or operating
abnormally.
If the tool appears to be operating unusually, making
strange noises, or otherwise appears defective, stop
using it immediately and arrange for repairs by a
metabo HPT authorized service center.
18. Carefully handle power tools.
Should a power tool be dropped or struck against
hard materials inadvertently, it may be deformed,
cracked, or damaged.
19. Do not wipe plastic parts with solvent.
Solvents such as gasoline, thinner benzine, carbon
tetrachloride, and alcohol may damage and crack
plastic parts. Do not wipe them with such solvents.
Wipe plastic parts with a soft cloth lightly dampened
with soapy water and dried thoroughly.
20. Never wear gloves made of material liable to roll
up such as cotton, wool, cloth or string, etc.
21. Keep motor air vent clean.
The tool’s motor air vent must be kept clean so that
air can freely flow at all times. Check for dust build-up
frequently.
22. NEVER leave tool running unattended. Turn
power off.
Don’t leave tool until it comes to a complete stop.
23. NEVER touch the blade with bare hands after
operation.
24. Because the cordless circular saw operates by
battery power, be aware of the fact that it can begin to
operate at any time.
25. When working at elevated locations, clear the area of
other people and aware of conditions below you.
26. Do not give a strong shock to the switch panel or
break it. It may lead to a trouble.
27. Do not use the product if the tool or the battery
terminals (battery mount) are deformed.
Installing the battery could cause a short circuit that
could result in smoke emission or ignition.
28. Keep the tool’s terminals (battery mount) free of swarf
and dust.
○ Prior to use, make sure that swarf and dust have not
collected in the area of the terminals.
○ During use, try to avoid swarf or dust on the tool from
falling on the battery.
○ When suspending operation or after use, do not leave
the tool in an area where it may be exposed to falling
swarf or dust.
Doing so could cause a short circuit that could result
in smoke emission or ignition.
IMPORTANT SAFETY INSTRUCTIONS
FOR CHARGER OR ADAPTER
The term “charger or adapter” in the safety instructions
refers to your battery charger or AC/DC adapter.
WARNING
Death or serious bodily injury could result from
improper or unsafe use of charger or adapter.
To avoid these risks, follow these basic safety
instructions:
READ ALL INSTRUCTIONS
1. This manual contains important safety and operating
instructions for battery charger Model UC18YSL3 or
AC/DC adapter Model ET36A.
2. Before using charger or adapter, read all instructions
and cautionary markings on (1) charger or adapter, (2)
battery, and (3) product using battery.
3. When charging the battery with a battery charger,
reduce the risk of injury by charging metabo HPT
rechargeable battery multi volt type series and BSL18
series. Other type of batteries may burst causing
personal injury and damage.
4. Do not expose charger or adapter to rain or snow.
5. Use of an attachment not recommended or sold by
the charger or adapter manufacturer may result in a
risk of fire, electric shock, or injury to persons.
6. To reduce risk of damage to electric plug and cord,
pull by plug when disconnecting charger or adapter.
7. Make sure cord is located so that it will not be stepped
on, tripped over, or otherwise subjected to damage or
stress.
8. An extension cord should not be used unless
absolutely necessary. Use of improper extension
cord could result in a risk of fire and electric shock.
If extension cord must be used make sure:
a. That blades of extension cord are the same
number, size, and shape as those of plug on
charger or adapter:
b. That extension cord is properly wired and in good
electrical condition; and
c. That wire size is large enough for AC ampere
rating of charger or adapter as specified in
Table 1.
7
English
00BookC3607DWANA.indb700BookC3607DWANA.indb7 2021/06/1016:51:412021/06/1016:51:41

Table 1
RECOMMENDED MINIMUM AWG SIZE FOR
EXTENSION CORDS FOR CHARGER OR ADAPTER
AC Input Rating Amperes* AWG Size of Cord
Equal to or
greater than but less than
Length of Cord, Feet (Meter)
25 (7.5) 50 (15) 100 (30) 150 (45)
0 2 18 18 18 16
2 3 18 18 16 14
3 4 18 18 16 14
* If the input rating of a charger or adapter is given in
watts rather than in amperes, the corresponding
ampere rating is to be determined by dividing the
wattage rating by the voltage rating–for example:
1,250 watts = 10 amperes
125 volts
9. Do not operate charger or adapter with damaged cord
or plug-replace them immediately.
10. Do not operate charger or adapter if it has received a
sharp blow, been dropped, or otherwise damaged in
any way; take it to a qualified serviceman.
11. Do not disassemble charger or adapter; take it to
a qualified serviceman when service or repair is
required. Incorrect reassembly may result in a risk of
electric shock or fire.
12. To reduce risk of electric shock, unplug charger
or adapter from receptacle before attempting any
maintenance or cleaning. Removing the battery will
not reduce this risk.
13. This AC/DC adapter is for use only with specific tools,
including C3607DWA. The adapter might be suitable
for use with other metabo HPT battery operated tools.
It is necessary to confirm suitability by referencing the
instruction manual of the specific tool or by consulting
our web site https://www.metabo-hpt.com/. Failure
to confirm suitability before using the adapter with
specific tools could result in fire hazard.
IMPORTANT SAFETY INSTRUCTIONS
FOR USE OF THE BATTERY AND
CHARGER OR ADAPTER
You must charge the battery before you can use the power
tool. Before using the model UC18YSL3 battery charger,
be sure to read all instructions and cautionary statements
on it, the battery and in this manual.
CAUTION
USE ONLY metabo HPT BATTERY MODELS OF
THE MULTI VOLT SERIES. OTHER MODELS OF
BATTERIES MAY BURST AND CAUSE INJURY!
Follow these instructions to avoid the risk of injury:
WARNING
Improper use of the battery or battery charger
can lead to serious injury. To avoid these injuries:
1. NEVER disassemble the battery or AC/DC adapter.
2. NEVER incinerate the battery or AC/DC adapter, even
if it is damaged or is completely worn out. The battery
can explode in a fire.
3. NEVER short-circuit the battery or AC/DC adapter.
4. NEVER insert any objects into the charger or
adapter’s air vents. Electric shock or damage to the
charger or adapter may result.
5. NEVER use outdoors. Keep the battery or AC/DC
adapter away from direct sunlight and use only where
there is low humidity and good ventilation.
6. NEVER charge when the temperature is below 32°F
(0°C) or above 104°F (40°C). (UC18YSL3)
NEVER use when the temperature is below 14°F
(-10°C) or above 104°F (40°C). (ET36A)
7. NEVER connect two charger or adapter together.
8. NEVER insert foreign objects into the hole for the
battery or the charger or adapter.
9. NEVER use a booster transformer.
10. NEVER use DC power.
11. NEVER store the battery or charger or adapter in
places where the temperature may reach or exceed
104°F (40°C) such as inside metal box or car.
12. NEVER expose the battery or charger or adapter to
rain or wet conditions.
13. ALWAYS operate charger or adapter on standard
household electrical power (120 volts). Using the
charger or adapter on any other voltage may overheat
and damage the charger.
14. ALWAYS wait at least 15 minutes between charges to
avoid overheating the charger. (UC18YSL3)
15. ALWAYS disconnect the power cord from its
receptacle when the charger or adapter is not in use.
8
English
00BookC3607DWANA.indb800BookC3607DWANA.indb8 2021/06/1016:51:412021/06/1016:51:41

[The information below applies only to ET36A]
16. Do not use the product if the tool or the AC/DC adapter
terminals (AC/DC adapter mount) are deformed.
Installing the AC/DC adapter could cause a short
circuit that could result in smoke emission or ignition.
17. Keep the tool’s terminals (AC/DC adapter mount) free
of swarf and dust.
○ Prior to use, make sure that swarf and dust have not
collected in the area of the terminals.
○ During use, try to avoid swarf or dust on the tool from
falling on the AC/DC adapter.
○ When suspending operation or after use, do not leave
the tool in an area where it may be exposed to falling
swarf or dust.
Doing so could cause a short circuit that could result
in smoke emission or ignition.
18. The product is intended for Use in Pollution Degree
2 or PD2 environments. Operate only in areas of
non-conductive pollution. A temporary conductivity
caused by condensation is normally expected.
19. This is a precision machine so do not drop or expose
to impact.
20. Do not use this product near a pacemaker or other
similar implanted device, which may be affected by a
magnetic field produced by this product.
21. The adapter, power supply box and the inside of the
DC cord generates a boosted high voltage of 380 V so
please be careful of the following.
○ Do not disassemble the product.
○ Do not drop or expose to impact.
In the event the product is damaged from strong
impact, do not use the product.
○ Do not use the product in areas exposed to rain,
snow, iron powder or wet condition.
○ Do not touch the product with wet hands.
○ Do not spill or pour liquid onto the product.
○ Do not pull the cord with excessive force.
○ Use the product in a well-ordered work environment.
CAUTION
1. When the mesh of the vent is plugged by objects such
as wood shavings, try to keep the objects out when
you clear the mesh.
(If not properly maintained, the temperature protective
feature could shut the product off)
2. When the temperature protective feature frequently
cuts the power off, do not overload the machine with
continued work, but let the machine rest for a little
before continuing operation.
3. The machine does get hot. However, this does not
indicate an abnormality.
Keep the electricity running and operate the internal
fan to cool the machine before carrying it elsewhere.
When carrying the product, make sure to use the cord
armor. The case may be hot so please be careful.
4. During use, do not pull the cord to move the Box.
Doing so may result in damage.
5. Do not use more that a single cord reel of 30 meters.
Doing so may result in damage.
6. During use, if the machine stops running after the
Box’s LED lamp blinks, confirm the power supply
environment.
7. Do not drag the cord when using or carrying the
machine.
Doing so may tear the cord insulation or break the
cord which could result in electric shock.
8. Do not stretch the cord out any more than required.
When using tools such as gardening clippers or
circular saws, always make sure of the power cord’s
position to avoid cutting the cord during operation.
9. To use the AC/DC adapter after it shuts down due to
high temperature, disconnect the box’s power plug,
wait for the LED lamp to go out and then reconnect
the box’s power plug.
If the machine cuts offeven after sufficiently cooling it
offwith the built-in fan, discontinue use as there may
be a problem with the machine.
10. Do not use this product near a radio. Doing so could
cause noise from the radio, making it difficult to listen
to a broadcast.
11. This is a power source for multi volt products. Do not
use with 18 V products or chargers. Doing so could
result in damage.
12. Overload behavior may differ when compared with
BSL36B18 battery use.
With the battery where the LED should blink on the
main unit, the LED on the AC/DC adapter may blink
instead.
PRECAUTIONS FOR AC/DC ADAPTER
The adapter equips with the protection function to stop the
output. In the cases of 1 to 2 described below, when using
this product, even if you are pulling the switch, the motor
may stop. This is not the trouble but the result of protection
function.
1. If the tool is overloaded, output may stop. In this case,
release the switch of tool and eliminate causes of
overloading.
2. If the adapter is overheated under overload work,
output may stop. In situations like this, discontinue
use of the adapter and detach it from the tool. Allow
the adapter to cool in a location such as a shaded
area with good air circulation.
9
English
00BookC3607DWANA.indb900BookC3607DWANA.indb9 2021/06/1016:51:412021/06/1016:51:41

CAUTION ON LITHIUM-ION BATTERY
To extend the lifetime, the lithium-ion battery equips with
the protection function to stop the output.
In the cases of 1 to 3 described below, when using this
product, even if you are pulling the switch, the motor may
stop. This is not the trouble but the result of protection
function.
1. When the battery power remaining runs out, the motor
stops.
In such case, charge it up immediately.
2. If the tool is overloaded, the motor may stop. In this
case, release the switch of tool and eliminate causes
of overloading. After that, you can use it again.
3. If the battery is overheated under overload work, the
battery power may stop.
In this case, stop using the battery and let the battery
cool. After that, you can use it again.
Furthermore, please heed the following warning and
caution.
WARNING
In order to prevent any battery leakage, heat generation,
smoke emission, explosion and ignition beforehand,
please be sure to heed the following precautions.
1. Make sure that swarf and dust do not collect on the
battery.
○ During work make sure that swarf and dust do not fall
on the battery.
○ Make sure that any swarf and dust falling on the power
tool during work do not collect on the battery.
○ Do not store an unused battery in a location exposed
to swarf and dust.
○ Before storing a battery, remove any swarf and dust
that may adhere to it and do not store it together with
metal parts (screws, nails, etc.).
2. Do not pierce battery with a sharp object such as a
nail, strike with a hammer, step on, throw or subject
the battery to severe physical shock.
3. Do not use an apparently damaged or deformed
battery.
4. Do not use the battery in reverse polarity.
5. Do not connect directly to an electrical outlets or car
cigarette lighter sockets.
6. Do not use the battery for a purpose other than those
specified.
7. If the battery charging fails to complete even when a
specified recharging time has elapsed, immediately
stop further recharging.
8. Do not put or subject the battery to high temperatures
or high pressure such as into a microwave oven,
dryer, or high pressure container.
9. Keep away from fire immediately when leakage or foul
odor are detected.
10. Do not use in a location where strong static electricity
generates.
11. If there is battery leakage, foul odor, heat generated,
discolored or deformed, or in any way appears
abnormal during use, recharging or storage,
immediately remove it from the equipment or battery
charger, and stop use.
12. Do not immerse the battery or allow any fluids to flow
inside. Conductive liquid ingress, such as water, can
cause damage resulting in fire or explosion. Store your
battery in a cool, dry place, away from combustible
and flammable items. Corrosive gas atmospheres
must be avoided.
CAUTION
1. If liquid leaking from the battery gets into your eyes,
do not rub your eyes and wash them well with fresh
clean water such as tap water and contact a doctor
immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well with
clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using
the battery for the first time, do not use and return it to
your supplier or vendor.
WARNING
If an electrically conductive foreign object enters the
terminals of the lithium ion battery, a short-circuit may
occur resulting in the risk of fire. Please observe the
following matters when storing the battery.
○ Do not place electrically conductive cuttings,
nails, steel wire, copper wire or other wire in the
storage case.
○ Either install the battery in the power tool or store
by securely pressing into the battery cover until
the ventilation holes are concealed to prevent
short-circuits (See Fig. 7).
10
English
00BookC3607DWANA.indb1000BookC3607DWANA.indb10 2021/06/1016:51:412021/06/1016:51:41

REGARDING LITHIUM-ION BATTERY
TRANSPORTATION
When transporting a lithium-ion battery, please observe
the following precautions.
WARNING
Notify the transporting company that a package
contains a lithium-ion battery, inform the company
of its power output and follow the instructions of the
transportation company when arranging transport.
● Lithium-ion batteries that exceed a power output
of 100 Wh are considered to be in the freight
classification of Dangerous Goods and will
require special application procedures.
● For transportation abroad, you must comply with
international law and the rules and regulations of
the destination country.
● If the BSL36B18 is installed in the power tool,
the power output will exceed 100 Wh and the unit
will be classified as Dangerous Goods for freight
classification.
Wh
Power Output
2 to 3 digit number
Fig. 5
USB DEVICE CONNECTION
PRECAUTIONS
When an unexpected problem occurs, the data in a USB
device connected to this product may be corrupted or lost.
Always make sure to back up any data contained in the
USB device prior to use with this product.
Please be aware that our company accepts absolutely no
responsibility for any data stored in a USB device that is
corrupted or lost, nor for any damage that may occur to a
connected device.
SAVE THESE INSTRUCTIONS
AND
MAKE THEM AVAILABLE TO OTHER USERS
AND
OWNERS OF THIS TOOL!
11
English
00BookC3607DWANA.indb1100BookC3607DWANA.indb11 2021/06/1016:51:412021/06/1016:51:41

FUNCTIONAL DESCRIPTION
NOTE
The information contained in this Instruction Manual is designed to assist you in the safe operation and maintenance
of the power tool.
NEVER operate, or attempt any maintenance on the tool unless you have first read and understood all safety
instructions contained in this manual.
Some illustrations in this Instruction Manual may show details or attachments that differ from those on your own
power tool.
NAME OF PARTS
1. Cordless Rear Handle Circular Saw (C3607DWA)
Inclined gauge
Lock lever
Battery Incline lever
Nameplate
Handle
Hook
Motor
Saw blade
Washer (B)
Base
Saw cover
90° & 45°
guide notches
Trigger switch
Lock-offbutton
Cutting depth lever
Lower guard lever
Guide (Rip fence)
(sold separately)
Hexagonal flange bolt
Sub handle
Lower guard
Fig. 6
12
English
00BookC3607DWANA.indb1200BookC3607DWANA.indb12 2021/06/1016:51:412021/06/1016:51:41

2. Battery 3. Battery Charger
Ventilation holes
Latch
Terminals
Battery cover
Battery
<BSL36B18> <UC18YSL3>
Nameplate
Cord
Guide rail
Charge indicator lamp
Ventilation holes
Body
Fig. 7 Fig. 8
4. AC/DC Adapter
(optional accessories...sold separately)
Plug
Latch
Ventilation holes
Terminals
AC cord
DC cord
Box
Cord armor
Cord armor
Cord armor
Adapter
Error lamp
Error lamp
Power lamp
<ET36A>
Fig. 9
SPECIFICATIONS
1. Cordless Rear Handle Circular Saw
Model C3607DWA
Voltage 36 V
Motor DC brushless motor
No-load speed 5,100 /min
Blade Size 7-1/4" (185 mm) D × 5/8" (15.9 mm) H
Max. Cutting Depth 2-7/16" (62 mm)
Max. Blade Angle Adjustable 0°–53°
Power supply Type* Li-ion battery Model BSL36B18 /
AC/DC adapter Model ET36A (sold separately)
Voltage 36 V
Weight 10.4 lbs. (4.7 kg) (BSL36B18 attached)
* Existing batteries (BSL3660/3626/3620, BSL18xx and BSL14xx series, etc.) cannot be used with this tool.
If using the AC/DC adapter, please read and understand its manual before operating the power tool.
13
English
00BookC3607DWANA.indb1300BookC3607DWANA.indb13 2021/06/1016:51:412021/06/1016:51:41

2. Battery Charger
Model UC18YSL3
Input power source Single phase: AC 120 V 60 Hz
Charging time
(At a temperature of 68°F (20°C)) BSL36B18 : Approx. 52 min
Charging voltage DC 14.4–18 V
Charging current DC 8.0 A
Weight 1.3 lbs. (0.6 kg)
NOTE: The charging time may vary according to temperature and power source voltage.
3. AC/DC Adapter
Model ET36A
Input power source Single phase: AC 120 V 60 Hz
Output voltage 36 V
Operating temperature range 14°F (-10°C)–104°F (40°C)
Weight Adapter : 1.8 lbs. (0.8 kg)
Box : 2.6 lbs. (1.2 kg)
Electronic control
○ Soft-start
○ Overload protection
This protection feature cuts offthe power to the motor
in the event of overloading of motor or a conspicuous
reduction in rotational speed during operation.
When the overload protection feature has been
activated, the motor may stop.
In this case, release the tool switch and eliminate
causes of overloading.
After that you can use it again.
○ Overheat protection
This protection feature cuts offthe power to the motor
and stops the power tool in the event of overheating of
motor during operation.
When the overheat protection feature has been
activated, the motor may stop.
In this case, release the tool switch and cool it down in
a few minutes.
After that you can use it again.
14
English
00BookC3607DWANA.indb1400BookC3607DWANA.indb14 2021/06/1016:51:422021/06/1016:51:42

ASSEMBLY AND OPERATION
APPLICATIONS
○
Cutting various types of wood.
WARNING
● Use extra caution when cutting freshly cut green
lumber, hardwood, wet wood, composite wood,
pressure treated wood, wood containing knots
or having other characteristics which may put a
heavy load on the saw or blade. If this occurs, do
not force the tool. Push the tool more slowly, but
with enough force to keep working without much
decrease in speed.
● To avoid serious injury, do not cut the metal with
a metal cutting blade attached. Also, do not use
for applications other than wood cutting.
REMOVAL AND INSTALLATION METHOD
OF BATTERY
○
How to install the battery.
Align the battery with the groove in tool handle and
slip it into place.
Always insert it all the way until it locks in place with a
little click, If not, it may accidentally fall out of the tool,
causing injury to you or someone around you (Fig. 10).
○ How to remove the battery.
Withdraw battery from the tool handle while pressing
the latch (2 pcs) of the battery (Fig. 10).
Latch
Push
Battery
Pull out
Insert
Handle
Fig. 10
CHARGING METHOD
NOTE
Before plugging into the receptacle, make sure the
following points.
○ The power source voltage is stated on the
nameplate.
○ The cord is not damaged.
WARNING
Do not charge at voltage higher than indicated
on the nameplate.
If charged at voltage higher than indicated on the
nameplate, the charger will burn out.
1. Connect the charger’s power cord to a receptacle.
When the power cord is connected, the charge
indicator lamp will blink in red. (At 1-second intervals)
WARNING
Do not use the electrical cord if
damaged. Have it repaired immediately.
2. Insert the battery to the battery charger.
Firmly Insert the battery into the battery charger as
shown in Fig. 11.
Charge indicator lamp
Guide rail
Battery
Fig. 11
3. Charging
When inserting a battery in the charger, the charge
indicator lamp will blink in blue.
When the battery becomes fully recharged, the
charge indicator lamp will light up in green.(See
Table 2)
(1) Charge indicator lamp indication
The indications of the charge indicator lamp will be
as shown in Table 2, according to the condition of the
battery charger or the battery.
15
English
00BookC3607DWANA.indb1500BookC3607DWANA.indb15 2021/06/1016:51:422021/06/1016:51:42

Table 2
Indications of the charge indicator lamp
Charge
indicator
lamp
(RED /
BLUE /
GREEN /
PURPLE)
Before
charging Blinks (RED)
Lights for 0.5 seconds. Does not light
for 0.5 seconds. (offfor 0.5 seconds) Plugged into power source
While
charging
Blinks
(BLUE)
Lights for 0.5 seconds. Does not light
for 1 second. (offfor 1 second) Battery capacity at less than
50%
Blinks
(BLUE)
Lights for 1 second. Does not light for
0.5 seconds. (offfor 0.5 seconds) Battery capacity at less than
80%
Lights
(BLUE) Lights continuously Battery capacity at more than
80%
Charging
complete Lights (GREEN)
Lights continuously
(Continuous buzzer sound: about
6 seconds)
Overheat
standby Blinks (RED)
Lights for 0.3 seconds. Does not light
for 0.3 seconds. (offfor 0.3 seconds) Battery overheated. Unable
to charge. (Charging will
commence when battery cools)
Charging
impossible Flickers (PURPLE)
Lights for 0.1 seconds. Does not light
for 0.1 seconds. (offfor 0.1 seconds)
(Intermittent buzzer sound: about
2 seconds)
Malfunction in the battery or the
charger
(2) Regarding the temperature of the rechargeable
battery.
The temperatures for rechargeable batteries are
as shown in the Table 3, and batteries that have
become hot should be cooled for a while before being
recharged.
Table 3
Rechargeable
batteries Temperatures at which the battery can be recharged
BSL36B18 32°F–122°F
(0°C–50°C)
(3) Regarding recharging time (At 68°F (20°C))
Table 4 Charging time
Charger
Battery UC18YSL3
BSL36B18 Approx. 52 min
NOTE
The recharging time may vary according to the
ambient temperature.
4. Disconnect battery charger from the receptacle.
CAUTION
Do not pull the plug out of the receptacle by
pulling on the cord.
Make sure to grasp the plug when removing from
receptacle to avoid damaging cord.
5. Remove the battery from the battery charger.
Supporting the battery charger with hand, pull out the
battery from the battery charger.
NOTE
Be sure to pull out the battery from the battery charger
after use, and then keep it.
Regarding electric discharge in case of new
batteries, etc.
As the internal chemical substance of new batteries
and batteries that have not been used for an extended
period is not activated, the electric discharge might
be low when using them the first and second time.
This is a temporary phenomenon, and normal time
required for recharging will be restored by recharging
the batteries 2–3 times.
16
English
00BookC3607DWANA.indb1600BookC3607DWANA.indb16 2021/06/1016:51:422021/06/1016:51:42

How to make the batteries perform longer
(1) Recharge the batteries before they become
completely exhausted.
When you feel that the power of the tool becomes
weaker, stop using the tool and recharge its battery.
If you continue to use the tool and exhaust the electric
current, the battery may be damaged and its life will
become shorter.
(2) Avoid recharging at high temperatures.
A rechargeable battery will be hot immediately after
use. If such a battery is recharged immediately after
use, its internal chemical substance will deteriorate,
and the battery life will be shortened. Leave the
battery and recharge it after it has cooled for a while.
CAUTION
●
When the battery charger has been continuosly
used, the battery charger will be heated, thus
constituting the cause of the failures. Once the
charging has been completed, give 15 minutes
rest until the next charging.
● If the battery is charged while it is heated
because it has been left for a long time in a
location subject to direct sunlight or because the
battery has just been used, the charge indicator
lamp of the charger lights for 0.3 seconds, does
not light for 0.3 seconds (offfor 0.3 seconds). In
such a case, first let the battery cool, then start
charging.
● When the charge indicator lamp flickers (at
0.2–second intervals), check for and take out
any foreign objects in the charger’s battery
installation hole. If there are no foreign objects,
it is probable that the battery or charger is
malfunctioning. Take it to your authorized
Service Center.
HOW TO RECHARGE USB DEVICE
When an unexpected problem occurs, the data in a USB
device connected to this product may be corrupted or lost.
Always make sure to back up any data contained in the
USB device prior to use with this product.
Please be aware that our company accepts absolutely no
responsibility for any data stored in a USB device that is
corrupted or lost, nor for any damage that may occur to a
connected device.
WARNING
○ Prior to use, check the connecting USB cable for
any defect or damage.
Using a defective or damaged USB cable can
cause smoke emission or ignition.
○ When the product is not being used, cover the
USB port with the rubber cover.
Buildup of dust etc. in the USB port can cause
smoke emission or ignition.
NOTE
○ The time required for charging will be longer when
a USB device and battery are being simultaneously
charged.
○ There may be an occasional pause during USB
recharging.
○ When a USB device is not being charged, turn the
USB power switch OFF and remove the USB device
from the charger.
Failure to do so may not only reduce the battery life
of a USB device, but may also result in unexpected
accidents.
(1) Select a charging method
Depending on the charge method selected, either the
battery is inserted into the charger or the power cord
is plugged into an outlet.
○ Charging a USB device by battery (Fig. 12-a)
○ Charging a USB device from a electrical outlet
(Fig. 12-b)
○ Charging a USB device and battery from a
electrical outlet (Fig. 12-c)
abc
Fig. 12
(2) Turn the USB power switch ON (Fig. 13)
When you turn the USB power switch ON, the USB
power indicator lamp will light up.
USB power
switch
USB power
indicator
lamp
Rubber cover
USB port
USB cable
Fig. 13
17
English
00BookC3607DWANA.indb1700BookC3607DWANA.indb17 2021/06/1016:51:422021/06/1016:51:42

(3) Connect the USB cable. (Fig. 13)
Pull back the rubber cover and firmly plug in a
commercially available USB cable (appropriate to the
device being charged) into the USB port.
○ When the power cord is not plugged into an outlet and
the battery runs out of power, power output will stop
and the USB power indicator lamp will shut off.
○ When the USB power indicator lamp goes out, change
the battery or plug the power cord into an electrical
outlet.
(4) When charging is completed
○ The USB power indicator lamp will not go out when a
USB device has been completely charged.
To verify charge status, check the USB device.
○ Turn the USB power switch OFF and unplug the power
cord from the electrical outlet. (Fig. 13)
○ Remove the battery from the charger and place the
rubber cover over the USB port.
PRIOR TO OPERATION
CAUTION
To avoid serious accident, ensure the switch is in
the OFF position, and pull out the battery.
1. Check the work area environment
Check the work area to make sure that it is clear of
debris and clutter.
Clear the area of unnecessary personnel. Ensure that
lighting and ventilation is adequate.
2. Mounting the Saw Blade (Fig. 14)
WARNING
● Do not use a blade larger than 7-1/4" (185 mm)
in diameter. To avoid injury from an accidental
start, ensure the switch is in the OFF position
and make sure to pull out the battery.
● Make sure the blade is installed correctly and is
tight before operating.
● If the hexagonal flange bolt is worked using
other tools than the provided wrench, excessive
tightening and insufficient tightening may take
place, resulting in injury.
(1) Thoroughly remove any sawdust which has
accumulated on the spindle, bolt and washers.
(2) For mounting saw blade, the concave sides of both
washers (A) and (B) must be fitted to the saw blade
sides. Mount the saw blade on the spindle, and finally
affix washer (B) (See Fig. 14)
(3) To assure proper rotation direction of the saw blade,
the arrow direction on the saw blade must coincide
with the arrow direction on the blade cover.
(4) Using the fingers, tighten the hexagonal bolt retaining
the saw blade as much as possible. Then depress the
lock lever, lock the spindle, and thoroughly tighten the
bolt.
(5) Confirm that the lock lever is in the original position.
Fig. 14
Washer (A)
Washer (B)
Saw Blade
Hexagonal
Flange Bolt
CAUTION
After mounting the saw blade, reconfirm that the
lock button is firmly secured in the prescribed
position.
3. Dismounting the saw blade
WARNING
The tool becomes hot after tool operation.
To avoid burns, the blade replacement work
should be done after tool has cooled sufficiently.
CAUTION
Never touch the saw blade immediately after use.
The metal is hot and can easily burn your skin.
18
English
00BookC3607DWANA.indb1800BookC3607DWANA.indb18 2021/06/1016:51:432021/06/1016:51:43

(1) Set the cutting volume at maximum, and place the
Circular Saw as shown in Fig. 15.
Wrench
Lock lever
Loosen
Fig. 15
(2) Depress the lock lever, lock the spindle, and remove
the hexagonal flange bolt and washer (B) with the
wrench.
(3) While holding the lower guard lever to keep the lower
guard fully retracted into the saw cover, remove the
saw blade (Fig. 16).
Lower guard lever
Saw cover
Saw blade
Fig. 16
4. Check performance of lower guard
WARNING
Make absolutely sure that the lower guard is not
fixed. Also, check and see if it can move smoothly.
If the saw blade is kept exposed, injury can result.
The lower guard (refer to Fig. 17) serves to protect
your body from coming into contact with the saw
blade. Make absolutely certain that the cover
smoothly performs to cover the saw blade. If the
lower guard should not move smoothly, never use it
without repairing it.
In such a case, get in touch with the store where
you bought the circular saw or the metabo HPT
AUTHORIZED SERVICE CENTER for necessary
repair.
Lower guard
Fig. 17
5. Check for proper operation of the brake
This circular saw features an electric brake that
functions when the switch is released. Before using
the circular saw, ensure that the electric brake
functions properly. If it does not, bring the tool to a
metabo HPT AUTHORIZED SERVICE CENTER.
6. Prepare a wooden work bench (Fig. 18)
Since the saw blade will extend beyond the lower
surface of the lumber, place the lumber on a work
bench when cutting. If a square block is utilized
as a work bench, select level ground to ensure it is
properly stabilized. An unstable work bench will result
in hazardous operation.
BaseLumber
Work bench Saw blade
Fig. 18
CAUTION
To avoid possible accident, always ensure that
the portion of lumber remaining after cutting is
securely anchored or held in position.
7. Check if the cutting depth lever and incline lever are
tightened.
If the the cutting depth lever to adjust cutting depth
(Fig. 21) and the incline lever to adjust angle of
inclination (Fig. 22) are loose, injury can result. Make
sure that they are tightened securely.
19
English
00BookC3607DWANA.indb1900BookC3607DWANA.indb19 2021/06/1016:51:432021/06/1016:51:43

8. Eye protection
Always wear eye protection with side shields that meets
the requirements of ANSI Standard Z87.1. Ordinary
eyeglasses do not provide adequate protection.
WARNING
Operating the tool without wearing proper eye
protection may result in serious injury.
9. Check battery insertion
WARNING
If the battery is inserted while the power switch
is in the ON position, the power tool will start
operating immediately, inviting serious accident.
CAUTION
Until the battery locks in place with a little click,
if not, it may accidentally fall out of the tool
causing injury to you or someone around you.
10. Trial run
Afterconfirming that no one isstanding behind, the power
tool start and confirm that no operating abnormalities
exist before attempting a cutting operation.
11. Inspect the rotating stability of the saw blade.
For precise cutting, rotate the saw blade and check for
deflection to confirm that the blade is not noticeably
unstable; otherwise vibrations might occur and cause
an accident.
12. Using hook
WARNING
To reduce the risk of injury from the saw falling
on operators or bystanders, make sure the saw
is supported securely when using the hook to
hang the saw from a rafter, joist or other elevated
support.
(1) Turn the hook away from the saw body to hang the saw
from a rafter, joist or other elevated support. (Fig. 19)
Hook
Fig. 19
WARNING
To reduce the risk of injury, do not use the saw
with the hook rotated below the base.
(2) When not in use, return the hook back to the storage
position until it latches against the saw body.
13. Using sub handle
When operating the saw, use both hands to hold the
saw firmly, one hand on the sub handle and the other
hand on the handle, to increase the stability of the saw
operation to avoid the possible kickback occurred.
Sub handle Handle
Fig. 20
ADJUSTSING THE SAW PRIOR TO USE
WARNING
To avoid serious accidents, ensure the switch is
in OFF position, and pull out the battery.
1. Adjusting the cutting depth (Fig. 21)
Cutting depth lever
Link
Base
Tighten
Loosen
Fig. 21
20
English
00BookC3607DWANA.indb2000BookC3607DWANA.indb20 2021/06/1016:51:432021/06/1016:51:43
