Meteor Whiz 2.0 User manual

METEOR LIGHTING P: 213.255.2060 F: 213.596.3704 www.meteor-lighting.com
*METEOR LIGHTING reserves the right to make changes to this product at any time without prior notice and such modification shall be effective immediately.
Page 1
Installation Instructions
ADVANCED HIGH CEILING
IMPORTANT SAFETY INFORMATION.
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
!
IMPORTANT SAFETY INFORMATION. READ AND FOLLOW ALL SAFETY INSTRUCTIONS. Before wiring to power supply
and during servicing or relamping, turn off power at fuse or circuit breaker. All servicing or relamping must be performed
by qualified service personnel. Product must be grounded to avoid potential electric shock or other potential hazard.
Product must be at locations and at heights and in a manner consistent with its intended use, and in compliance with
Electrical Code and local codes.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Whiz 2.0 - OCC sensor with Stem
Front
(Power Box)
Right
(Power Box) Whiz 2.0 Stem (2ft / 4ft)
Accessory
Pack
2.36"
6.61"
9.74"
14.29"
Push the Enlighted RJ45 connector and DC cables through the
stem.
Screw stem in place.
Step 2Step 1
Top
(Power Box)
Ø16.24"
4.44"
Ø1.1"
Ø0.47"
Ø0.19"
Ø0.47"
Ø0.47"
12.9"
2.36"
0.67"
1.69"

METEOR LIGHTING P: 213.255.2060 F: 213.596.3704 www.meteor-lighting.com
*METEOR LIGHTING reserves the right to make changes to this product at any time without prior notice and such modification shall be effective immediately.
Page 2
Installation Instructions
ADVANCED HIGH CEILING
Whiz 2.0 - OCC sensor with Stem
Slot through the RJ45 connector and DC cables through a Hex
screw and tighten the Hex screw on the stem grooves.
Step 3 Step 4
Step 6
Fasten the top bracket on the desired location on the ceiling.
Step 5
Align both lower and upper brackets and fasten in place. Unscrew the DC junction box and loosen the cable clamp. Insert the
DC wire through the cable clamp and connect them to the wires in the
junction box. After connection, ensure firmness by tightening cable
clamp. Connect the RJ45 connector to the port on the power box.
Refer to the wiring diagram for a detailed explanation.
1
2

Page 3
METEOR LIGHTING P: 213.255.2060 F: 213.596.3704 www.meteor-lighting.com
*METEOR LIGHTING reserves the right to make changes to this product at any time without prior notice and such modification shall be effective immediately.
Installation Instructions
ADVANCED HIGH CEILING
Whiz 2.0 - OCC sensor with Stem
Slip the power box hook with fastener over the lock-in grooves
allocated and fasten screws on either side to keep the power box in
place.
Step 7 Step 8
Hook the safety cable.
Connect AC Cable to Junction Box.
Step 9

Page 4
METEOR LIGHTING P: 213.255.2060 F: 213.596.3704 www.meteor-lighting.com
*METEOR LIGHTING reserves the right to make changes to this product at any time without prior notice and such modification shall be effective immediately.
Installation Instructions
ADVANCED HIGH CEILING
Wiring Diagram
NOD with OCC sensor | Standard 0-10V (WS2.0-120 / WS2.0-170 / WS2.0-240)
Black(Line)
Green(Ground)
White(Neutral)
Green(Ground)Green(Ground)
White(+)
White(+)Red(+)
Black(-)
Black(-)
Black(-)
LED
Fixture
Power Box
(Junction Box)
Whiz 2.0 - OCC sensor with Stem
