METREL RS232 User manual

METREL test and measurement accessories:
RS232 to USB adapter for
external USB keyboard
A 1578
Instruction manual
Version 1.1.1, Code no. 20 752 823

A_1578_RS232_to_USB_adapter_for_external_USB_keyboard_ANG_Ver_1.1.1_20752823.docx
Distributor:
Manufacturer:
METREL d.d.
Ljubljanska cesta 77
1354 Horjul
Slovenia
web site: http://www.metrel.si
e-mail: [email protected]
Mark on your equipment certifies that this equipment meets the requirements of the
all applicable EU (European Union) regulations
© 2018 METREL
No part of this publication may be reproduced or utilized in any form or by any means
without permission in writing from METREL.

A 1578 RS232 to USB adapter for external USB keyboard Instruction manual
3
Table of contents
1Preface.........................................................................................................................4
2Safety and operational considerations.....................................................................4
2.1 Warnings and notes...............................................................................................4
2.2 Standards applied..................................................................................................4
3External keyboard application description ..............................................................5
3.1 A 1578 set .............................................................................................................6
4External keyboard operation .....................................................................................7
4.1 Setup.....................................................................................................................7
4.2 Operational note....................................................................................................7
5Maintenance................................................................................................................8
5.1 Cleaning ................................................................................................................8
5.2 Service ..................................................................................................................8
6Technical specifications ............................................................................................8
6.1 General data..........................................................................................................8

A 1578 RS232 to USB adapter for external USB keyboard Instruction manual
4
1 Preface
METREL instruments are able to communicate with USB or wireless external keyboard,
that offers to operate with the instruments without touching them.
The following instruments have ability to operate with the external keyboard:
- MI 3325,
- MI 3360.
- MI 3394
Metrel and/or theirs distributors have the latest information of applicable test equipment.
2 Safety and operational considerations
2.1 Warnings and notes
Consider warnings and notes of master Metrel instrument and USB keyboard.
2.2 Standards applied
Note:
- External keyboard manufacturer or theirs representative shall provide information
related to applied standards.

A 1578 RS232 to USB adapter for external USB keyboard Instruction manual
5
3 External keyboard application description
Figure 3.1: Components for wired USB keyboard application
Figure 3.2: Components for wireless keyboard application

A 1578 RS232 to USB adapter for external USB keyboard Instruction manual
6
Legend:
1
Keyboard
2
Keyboard receiver
3
A 1578 RS232 to USB adapter for external USB keyboard
4
USB wired keyboard connector
Notes:
- Keyboard receiver (2) is part of wireless keyboard set.
- For USB wired keyboard, just A 1578 adapter (3) is required.
3.1 A 1578 set
A 1578 RS232 to USB adapter for external USB keyboard
A 1578 Instruction manual
Note:
- Keyboard is not included in the set.

A 1578 RS232 to USB adapter for external USB keyboard Instruction manual
7
4 External keyboard operation
4.1 Setup
1. Read and apply instructions of USB connected / wireless keyboard. (Insert batteries
if required).
2. Connect keyboard receiver (2), or USB wired keyboard (4) into USB connector of
the A 1578 adapter (3).
3. Connect RS232 connector of the A 1578 adapter (3) into instruments RS232
connector dedicated for communication with external reading devices (see
instruments instruction manual for details).
4. Turn power on of the instrument.
5. Select General settings / Settings menu and set Ext. Keyboard to ON.
Figure 4.1: External keyboard enabled
6. The external keyboard is ready for operation.
4.2 Operational note
- Test instrument shall have inserted Micro SD card. The instrument will in this case
keep enabled external keyboard status. Without SD card the steps of 4.1 Setup
shall be applied.

A 1578 RS232 to USB adapter for external USB keyboard Instruction manual
8
5 Maintenance
There are no replaceable parts in A 1578.
5.1 Cleaning
No special maintenance is required for the housing. To clean the surface of A 1578 use a
soft cloth slightly moistened with soapy water or alcohol. Then leave the A 1578 to dry
totally before use.
Warnings:
Do not use liquids based on petrol or hydrocarbons!
Do not spill cleaning liquid over the adapter!
5.2 Service
For repairs under warranty, or at any other time, please contact your distributor.
6 Technical specifications
6.1 General data
Supported USB keyboards ............... wired, 2.4 GHz wireless
Converts key strokes to .................... ASCII
Power supply.................................... 5 V
Output ............................................ 3.3 V (250 mA)
Dimensions (w h l) ...................... 3.4 cm 1.8 cm 14.0 cm
Weight ............................................ 40 g
Operation conditions
Working temperature range.............. 0C 40 C
Maximum relative humidity ............... 85 %RH (0C 40 C), non-condensing
Storage conditions
Temperature range........................... -10C +60 C
Maximum relative humidity ............... 90 %RH (-10C +40 C)
80 %RH (40C 60 C)
