METVISA BIMG LQL.2 Series User manual
1
2
TABLE OF CONTENTS
1.
Safety Information................................................................................................. 3
1.1
General warnings ............................................................................................................... 3
2.
Technical Characteristics .................................................................................... 4
2.1
Main Components .............................................................................................................. 4
2.2
Technical Data ................................................................................................................... 5
3.
Installation............................................................................................................. 5
3.1
Device Layout ................................................................................................................... 5
4.
Use of the Device .................................................................................................. 6
4.1
Utility .................................................................................................................................. 6
4.2
Commands ......................................................................................................................... 7
4.3
Operating Procedures ....................................................................................................... 7
5.
Cleaning and Maintenance ......................................................................................... 9
........................................................................................................... 9
5.1
Cleaning Procedures and Products Used .......................................................................... 9
........................................................................................ 9
5.2
Maintenance and Procedures in Case of Malfunctions .................................................... 10
................................................... 10
6.
Annexes .............................................................................................................. 12
Electrical Schematic - Voltage 110 V ............................................................................... 12
Electrical Schematic - Voltage 220 V ............................................................................... 13
Exploded Design............................................................................................................... 14
List of Replacement Parts................................................................................................. 15
ATTENTION!
The characteristics, pictures and figures presented in this manual should be considered for
information. BIMG BRASIL reserves the right to make such modifications as may be deemed
necessary without prior notice.
3
1. Safety Information
1.1 General Warnings
• Cautions/precautions must be observed when installing, using, maintaining and discontinuing use of
this device;
• Before carrying out any operation (assembly, utilization (use), maintenance and reuse after
prolonged use of the equipment), read the manual carefully;
• The equipment must be used by trained personnel familiar with the use and safety standards
described in this manual;
This device is not intended for use by persons (including children) with reduced physical, sensory or
mental capacities, or people with lack of experience and knowledge, unless they have received
instructions regarding the use of the device or are under the supervision of a person responsible for
their safety;
• It is recommended that children be supervised to ensure that they are not playing with the
equipment;
• In case of change of the personnel that will work with the equipment, the new operator must be
educated about the standards and the operation of the same one;
• The operator must use the Adequate PPE's (equipment for individual safety). As for example: use
touches the hair avoiding that they lock in the moving parts of the machine;
• The operator must always be aware of situations that can cause a risk of accidents and avoid them.
For example: avoid working with loose uniform sleeves, where they can lock in moving parts, causing
accidents;
• After being held to read and answered all the questions, this manual must be stored carefully in
place of easy access, known by all the people who will operate the equipment and made available for
the people who carry out maintenance, to any queries. Whenever any questions arise, be sure to
check the manual. Do not operate the equipment in any way with doubts;
• In the installation, it is essential to make this manual available to the professionals who will do the
same;
• Never place hands, fingers or objects inside the cup while the device is on, as this could cause an
accident;
• Never turn on the device with the cup uncovered, and also don't remove the cup while the device in
operation;
• Do not leave the device turned on without supervision and operating for more than 3 uninterrupted
minutes;
• This appliance is intended for home use and similar applications such as: shop kitchens, offices and
other similar workplaces; farm houses; by customers in hotels, motels and other similar places;
dormitory environments and small meals.
ATTENTION!
Do not perform repairs on your own. Refer servicing to qualified service personnel. Use only
original parts in your device.
4
2. Technical Features
2.1 Main Components
For the equipment described in this manual, safety in use, cleaning, maintenance and
maximum hygiene are guaranteed by the design and special project for all parts, as well as by using
stainless steel and other materials suitable for contact with food.
The device was built with the following features:
• Cover made of non - toxic plastic (polyethylene - PE). Material resistant to citric acid (found in lemon
and orange juice), is easy to maintain, hygienic and resistant to corrosion;
• Cup manufactured in stainless steel 304, which resists the attack of several corrosive agents, such
as the majority of the organic acids, organic substances in general, alkalis, oxy-salts, etc..
Note: stainless steel 304 is attacked by sulfuric acid, and also cannot withstand hydrochloric
acid, diluted sulfuric acid, chlorides and halides in general.
• Cabinet made of 430 stainless steel, which has higher corrosion resistance than other steels. It's a
material resistant to the attack of several corrosive agents;
• The blades are made of 304 hardened stainless steel, which increases wear resistance. Very
resistant to aggressive agents such as fruit and vegetable juices, some mild acids and alkalies, water
vapor free of contaminants, etc.
• Plastic base and cup holder are produced in non-toxic ABS plastic, high strength and hygiene.
See the following for the main components of the device:
Note: For the exploded
drawing with spare parts list,
see the annexes.
5
2.2 Technical Data
Model
Nominal Measures
Length.xHt.xWidth
(mm)
Net
weight
(kg)
Voltage
(V)
Power
Nominal
(W)
Capacity
(L)
LQL2110M604
200x585x200
7.7
110
560
2
LQL2220M501
200x585x200
7.7
220
450
2
LQL2220M502
200x585x200
7.7
220
450
2
LQL2220M504
200x585x200
7.7
220
450
2
LQL2220M604
200x585x200
7.7
220
450
2
LQL4L110M604
200x705x200
7.9
110
560
3.5
LQL4L220M501
200x705x200
7.9
220
450
3.5
LQL4L220M502
200x705x200
7.9
220
450
3.5
LQL4L220M504
200x705x200
7.9
220
450
3.5
LQL4L220M604
200x705x200
7.9
220
450
3.5
Noise level (device with load): 65 dB.
ATTENTION!
Features like: model, serial number and voltage of the equipment are provided on the label
(figure below). Before installation, check that the power supply voltage of the appliance
corresponds to that of the mains.
3. Installation
3.1 Equipment Layout
The connection to the mains and the arrangement for operation must be carried out by a
qualified professional. Check that the voltage of the eqiuipment matches the mains voltage.
It is essential to make this manual available to the professionals who carry out the
installation.
6
To ensure correct operation and safety, the machine must be positioned in an airy
environment and on a sufficiently wide, level, dry and stable support surface, away from heat sources
and water taps, and at a medium height of 80 cm. Install your appliance by leaving a distance of at
least 20 cm around it so that it has sufficient space for inspection, maintenance, cleaning and use.
ATTENTION!
The installation and location of the appliance must be in accordance with the regulations on the
prevention of risks and safety at work (regulatory standard in force in your country).
The manufacturer shall not be liable for any direct or indirect damages caused by non-
compliance with these standards and other instructions presented in this manual.
4. Use of the Device
4.1 Utility
This device is intended exclusively for grinding light food products with liquid addition and
dissolution of frozen fruit pulps and shall be exclusively for domestic use and not intended for any
other purpose.
7
4.2 Commands
The appliance consists of the on-off button on the front of the cabinet.
See descriptive of the following command:
• On/Off Button - used to turn the device on and off. In position "1" turns on, in position "0" turns off.
4.3 Operating Procedures
Before operating your device, make sure that the items that come into contact with the food
(cup, lid and overcap) are perfectly clean. Perform cleaning with the appliance disconnected from the
electrical network. Follow the cleaning instructions in item 5 of this manual.
Make sure that the cup is firmly inserted in the coupling and cup holder. Also check that the
supply voltage of the device (110 V ou 220 V) complies with that of the power grid.
After verifying these items, follow the device operating processes below:
ATTENTION!
To avoid damaging the device, never turn it on with the glass empty. Before connecting it,
insert liquid in the minimum amount at twice the height of the blade.
• Connect the power cord to the power grid;
8
• Add the liquid according to your recipe, but always comply with the "MAX" level indicated on the cup.
In possession of the pre-cut pieces of food (approximately 2 cm), place them in the cup;
• Before plugging in your device, always lock the cover with the overcap on the cup;
• To start processing, press the on/off button in the "1" (on) position;
• To add ingredients during processing, remove the overcap by turning it counterclockwise and pulling
it up vertically. Use the opening in the cover without needing to remove it;
• Leave the device running for a maximum of 3 minutes;
• After the process is completed, turn the device off by pressing the on/ off button in the "0" position
(off) and remove the device from the socket.
IMPORTANT
When processing a liquid that is hot, remove the overcap to allow steam to escape. For your
safety, the temperature of the processed products must not exceed 40° C.
If food sticks to the wall of the cup, turn off the appliance and unplug the device from the
socket. Use a spatula to remove food from the wall of the cup.
ATTENTION!
Never turn on the device with the cup uncovered, and also don't remove the cup while the
device is in operation.
To add ingredients or for viewing the food being processed, remove only the overcap.
9
ATTENTION!
This appliance is intended for household use and should not be used for any other purpose.
Do not leave the appliance running for more than 3 uninterrupted minutes. If processing has
not finished after that time, let it stand for 10 minutes before putting it back into operation.
To avoid damaging the device, never turn it on with the glass empty.
Do not use this appliance to process pastes with thick textures similar to mayonnaise and
açaí pastes. Ice crushing is also not recommended. For grinding of solid foods add liquid,
otherwise overheating may occur, damaging the cup sealing system, wear and/or breaking
of the blades and other components of the device.
If you notice that the device cannot process the food or that it stops processing, decrease
the amount or size of the food in the pre-cut before inserting it into the cup.
Failure to comply with these guidelines will be considered an unsafe act and abusive use of
the device.
In the case of any irregularities contact your nearest authorized service center.
5. Cleaning and Maintenance
5.1 Cleaning Procedures and Products Used
Your equipment is built with first-line materials, so use it correctly and you will get great
satisfaction. Keep your equipment always clean and well taken care of, as this will make it have a
much longer shelf life.
A daily cleaning of the machine must be carried out for good operation and durability.
ATTENTION!
Before performing maintenance or cleaning, make sure that the on/off switch is in the "0"
(off) position and the plug is disconnected from the power grid.
ATTENTION!
Do not use a water jet to clean the appliance.
IMPORTANT
This equipment is not intended to be fully immersed in water for cleaning.
Follow the instructions below to find out which parts can be immersed and the special care
to be taken with the other parts.
10
To sanitize the cup, follow the instructions below:
• With the cup attached to the coupling and cup holder, add warm water (500ml less than the
maximum capacity of the cup or at least twice the height of the blade) and a little neutral detergent
inside the cup. Place the cover and turn the device on for a few seconds. When the appliance is
turned off, remove the cup from the holder and rinse in running water.
The removable parts (cover and top cover) must be washed with water and neutral soap.
Clean the corners thoroughly, eliminating food residue.
The rest of the appliance should only be cleaned with a damp cloth as many times as possible
to prevent food residues from drying out and sticking to the parts. Dry all cleaned parts with a soft, dry
cloth.
Never use abrasive products or sponges and substances containing acids or chlorine to clean
the metallic parts, as they may scratch or damage the surface of the parts causing corrosion points.
Do not spill water on the engine and electrical parts for cleaning, otherwise, turning it on may cause
electric shock or even burn the device.
ATTENTION!
Take care when cleaning the glass, as the blades are exposed and are extremely sharp.
Handle with care, otherwise it could cause accidents. The same attention is paid to any
other sharp component of the device.
IMPORTANT
The manufacturer shall not be liable for any direct or indirect damages caused by non-
compliance with these standards and instructions presented in this manual.
ATTENTION!
It is extremely important that the products used in the cleaning ensure maximum
cleanliness and are not toxic.
5.2 Maintenance and Procedures in Case of Malfunctions
The operator must be instructed to perform routine inspections, making minor adjustments,
the cleaning and to observe signs of breakdowns that could occur. Examples include: checking for
extraneous noise; loss of power of the appliance; the non-performance by the appliance of the service
to which it proposes; among others. Actions such as these are essential to ensure a longer equipment
life.
ATTENTION!
When maintenance is made (even if small adjustments), always unplug the appliance from the
mains.
11
ATTENTION!
The blades may be re-sharpened when they lose their cut. To do this, contact the nearest
technical assistance.
It is recommended to carry out preventive maintenance every 6 months, checking and
adjusting clearances, cleaning internal parts, etc.. When detecting broken or malfunctioning parts,
always replace using original parts.
By carrying out preventive maintenance, the inconvenience of keeping the device still when
needed most is eliminated, the cost of maintenance is reduced and the risk of accidents is reduced.
ATTENTION!
Preventive maintenance requires a trained professional.
Make sure the device is disconnected from the power grid.
Whenever an item related to the safety of the device is removed (e.g. when performing
maintenance), put it back in its proper place and confirm that it is performing its function
correctly.
When a breakdown or non-compliance is detected, refer your device to the nearest technical
assistance. See technical assistance on our website: www.metvisa.com.br
12
6. ANNEXES
Electrical Schematic - Voltage 110 V
NOTE: In the above Electrical Schematic, white wires are represented by pink.
13
Electrical Schematic - Voltage 220 V
NOTE: In the above Electrical Schematic, white wires are represented by pink.
14
Exploded Design
15
Replacement Parts
Item
Code
Description
Qty.
1
BAS046
Gray Square Base
01
2
GAB133
Welded case
01
3
MTE220
Electric Motor 1/3 cv 60 Hz 110 V
01
MTE221
Electric Motor 1/3 cv 60 Hz 220 V
01
MTE026
Electric Motor 1/3 cv 50 Hz 220 V
01
4
RBT002
Rivet
08
5
SUC020
Black Cup Holder
01
6
CJT689
Full Coupling
01
6.1
ADA022
Coupling
01
6.2
PRN002
Allen Screw
01
7
CJT841
2 Liter Jar with Plastic Cap
01
CJT860
3.5 Liter Jar with Plastic Cap
7.1
TAP103
Overcap of the blenders
01
7.2
TAP156
Plastic cover
01
7.3
COP117
Jar 2 Liter Dotted Stainless Steel
01
COP135
Jar 3.5 Liter Dotted Stainless Steel
7.4
CJT685
Full Bearing
01
7.4.1
POC006
Nut Hat
01
7.4.2
LMT011
Stainless Steel Blade
01
7.4.3
VRG001
V'ring
01
7.4.4
ARE012
Celeron Graphite Washer Ø 8
04
7.4.5
POE009
Bearing Nut
01
7.4.6
ARE036
Celeron Graphite Washer Ø 1/4"
01
7.4.7
CJT138
Bearing with Bushing
01
7.4.8
EIX206
Axis of the Jar
01
8
PRS008
Hexagonal Screw
03
9
ARL003
Flat washer
03
10
PEP014
Foot for Plastic Base
04
11
CBE023
Electrical Cable - Type 1
01
CBE029
Electrical Cable - Type 2
CBE001
Electrical Cable - Type 4
12
TCE021
Print cable
01
13
CHE128
On/Off Switch
01
14
CRC477
Closing Plate
01
15
TCE013
Female Terminal
02
16
TCE004
Terminal Fit
02
17
TCE033
Threaded Connector
01
18
CBE157
Electrical Seam Cable
01
This manual suits for next models
11
Table of contents
Other METVISA Blender manuals
