MHM iQ-Oval CDS User manual

Operating instructions iQ-Oval CDS V1-4.docx page 1 of 66
OPERATING INSTRUCTIONS
(Translation of the original instructions)
©2022 Machines Highest Mechatronic GmbH, Erl, Austria

Operating instructions iQ-Oval CDS V1-4.docx page 2 of 66
Preface
Dear Customer,
congratulations and thank you for choosing the MHM iQ-Oval CDS Screen Printing
Machine. This machine is designed to provide the highest standards of performance
and reliability during its guaranteed long operating life. Highly innovative and precise
MHM technology provides a combination of the finest built quality along with optimal
safety. We trust that these Operating Instructions will assist you in becoming familiar
with the safe and efficient operation of the machine.
Important Note:
Due to our policy of continuous improvement, we reserve the right to change
specifications without prior notice. Therefore, certain individual fittings and
components may differ slightly from the model detailed in this document. For any
further questions regarding your iQ-Oval CDS, please contact the MHM service team.
Wishing you every success with your future production.
Machines Highest Mechatronic GmbH
Important Advice Regarding These Operating Instructions
These Operating Instructions form an integral part of the iQ-Oval CDS and must be
made available to all authorized personnel at all times. No particular sections or pages
must be removed from these Operating Instructions, and any missing sections or pages
should be replaced immediately, in particular with regard to section “1. Safety
Instructions”.
These Operating Instructions are subject to international copyright and may not be
reproduced and/or revised without our prior written approval.
©2020 Machines Highest Mechatronic GmbH, Erl, Austria. (All rights reserved).
Published by: Machines Highest Mechatronic GmbH
Muehlgraben 43a
A-6343 Erl / AUSTRIA
Contact details: Homepage: www.mhmscreenprinting.com
E-mail: [email protected]
Erl, February 2022

Operating instructions iQ-Oval CDS V1-4.docx page 3 of 66
Content:
Preface .................................................................................................................................... 2
Important Advice Regarding These Operating Instructions .............................................. 2
1. Safety Instructions.......................................................................................................... 6
1.1. Description of Key Words and Symbols in the Operating Instructions .............. 6
1.2. General Information ................................................................................................ 7
1.3. Qualification of Operating and Service Staff ......................................................... 7
1.4. Required qualification for operations .................................................................... 8
1.5. Safety Instructions for the Operating Staff............................................................ 9
1.6. Personal Protective Equipment .............................................................................. 9
1.7. Additional Risks ...................................................................................................... 10
1.8. Safety Signs on the Machine ................................................................................. 11
1.9. Other Valid Rules and Regulations: ...................................................................... 11
2. Intended usage of the machine .................................................................................. 11
3. Data................................................................................................................................ 11
3.1. Serial Number and Year of Manufacture............................................................. 12
3.2. Dimensions ............................................................................................................. 12
3.3. Specifications.......................................................................................................... 13
4. Transportation and packaging.................................................................................... 14
4.1. General Notes with Regard to Transportation and Danger Warnings ............. 14
4.2. Packaging ................................................................................................................ 14
4.3. Unloading of the crates ......................................................................................... 14
4.4. Packaging material................................................................................................. 15
5. Assembly ....................................................................................................................... 15
5.1. General Assembly Instructions ............................................................................. 15
5.2. Positioning of the iQ-Oval CDS ............................................................................. 15
5.3. Ambient Conditions ............................................................................................... 16
5.4. External supply/Connection ports........................................................................ 16
5.4.1. Electrical Connections..................................................................................... 17
5.4.2. Compressed Air ............................................................................................... 17
6. Commissioning the iQ-Oval CDS................................................................................. 18
7. Design and Operation.................................................................................................. 19
7.1. General Process Description................................................................................. 19
7.2. Overview Machine Parts........................................................................................ 19
7.3. Main control panel ................................................................................................. 20
7.4. Safety Devices......................................................................................................... 22
7.5. Base frame.............................................................................................................. 22
7.6. Tables ...................................................................................................................... 22
7.7. Pallets ...................................................................................................................... 23
7.8. Footswitch............................................................................................................... 23

Operating instructions iQ-Oval CDS V1-4.docx page 4 of 66
7.9. Main Power Switch................................................................................................. 23
7.10. Type Plate ............................................................................................................ 23
7.11. Print Stations ....................................................................................................... 24
7.11.1. Overview Print Stations ............................................................................... 24
7.11.2. Squeegee Drive Motor................................................................................. 25
7.11.3. Frequency inverter....................................................................................... 25
7.11.4. Squeegee/Print Arm .................................................................................... 25
7.11.5. Screen Adjustment/Micro-Registration ..................................................... 25
7.11.6. Squeegee Stroke Length Adjustment ........................................................ 25
7.11.7. Squeegee/Print Arm Lock............................................................................ 25
7.11.8. Squeegee pressure control......................................................................... 25
7.11.9. Optional station lifting................................................................................. 26
7.11.10. Dryer connector........................................................................................ 26
7.11.11. Control Keypad ......................................................................................... 27
7.11.12. Squeegee Carriage ................................................................................... 31
7.12. Additional equipment......................................................................................... 32
7.12.1. Flash Cure Units ........................................................................................... 32
7.12.1. Flocking Devices ........................................................................................... 33
8. Danger Zones................................................................................................................ 34
9. Control of the Machine ................................................................................................ 35
9.1. Starting up and shutting down the iQ-Oval CDS................................................. 35
9.1.1. Putting the Machine into Operation.............................................................. 36
9.1.2. Switching the Machine Off after normal operation ..................................... 37
9.1.3. Stopping the Machine in the event of an Emergency.................................. 37
9.1.4. Stopping the Machine in the event of Malfunction...................................... 38
9.1.5. Long-term Shutdown ...................................................................................... 38
9.1.6. Permanent Shutdown of the Machine .......................................................... 38
9.2. Configuration of the Control................................................................................. 38
9.3. Hybrid-Control........................................................................................................ 38
9.4. Operating the machine with tablet „m-touch pro“ ............................................. 39
9.4.1. Adjust................................................................................................................ 39
9.4.2. Manually........................................................................................................... 42
9.4.3. Automatic ......................................................................................................... 44
9.4.4. BasicSetup........................................................................................................ 46
9.4.5. Help................................................................................................................... 47
9.5. Blocked operation.................................................................................................. 48
9.6. Operating the machine with the terminal ........................................................... 49
9.6.1. Adjust................................................................................................................ 51
9.6.2. Manual.............................................................................................................. 52
9.6.3. Automatic ......................................................................................................... 53
9.7. 2-Job-Mode.............................................................................................................. 54
9.7.1. Brief description .............................................................................................. 54
9.7.2. Activation.......................................................................................................... 55

Operating instructions iQ-Oval CDS V1-4.docx page 5 of 66
9.7.3. Display „main terminal“ .................................................................................. 56
9.7.4. Display „optional terminal“............................................................................. 56
9.7.5. Settings ............................................................................................................. 57
9.7.6. Starting the production................................................................................... 57
9.7.7. Inlet-, Outlet- und Sample-Mode ................................................................... 57
9.7.8. Piece counter ................................................................................................... 57
9.7.9. Display and operating with terminal ............................................................. 58
9.8. Error- and status signals........................................................................................ 59
9.8.1. Signal lights and horn ..................................................................................... 59
9.8.2. Error display keypad ....................................................................................... 59
9.8.3. Error messages tablet..................................................................................... 60
9.8.4. Error messages terminal ................................................................................ 60
9.9. Trouble shooting .................................................................................................... 60
9.9.1. Error Messages control system...................................................................... 61
9.9.2. Basic errors (without error message)............................................................ 62
10. Maintenance of the iQ-Oval CDS ................................................................................ 63
11. Terms of the Guarantee .............................................................................................. 66
12. Limitation of liability..................................................................................................... 66
13. Support, Customer Service and Hotline..................................................................... 66

Operating instructions iQ-Oval CDS V1-4.docx page 6 of 66
1. Safety Instructions
This section describes the safety instructions for the correct and safe operation of the
iQ-Oval CDS. In addition, this section also contains references to the European rules
and regulations concerning the guarantee of industrial safety along with safety at the
workplace. These rules and regulations provide the basis for these operating
instructions.
These Operating Instructions include:
1. General safety instructions.
2. Special safety instructions, if they are relevant to a specific section, at the
beginning of that respective section.
3. Special safety instructions, if they are important for detailed sequences of
operation before the description of that respective sequence of operation.
4. Indications to read such instructions included in the respective section.
1.1. Description of Key Words and Symbols in the Operating Instructions
In these operating instructions classified key words and symbols are used to identify
dangers and items that require special attention. Particular attention is to be paid to
the sections marked in this manner, because they contribute to personal safety as well
as the prevention of damage to the machine.
Symbol
Key word
Meaning
DANGER
This symbol indicates possible risk for life.
CAUTION
This symbol indicates danger of damage to
property and/or environment.
NOTE
This symbol indicates useful additional
information and operating suggestions.

Operating instructions iQ-Oval CDS V1-4.docx page 7 of 66
1.2. General Information
The iQ-Oval CDS is built in accordance to all appropriate safety regulations. Owing to its
complex design, the iQ-Oval CDS must only be operated and maintained by suitably
skilled staff.
Installation, operation or maintenance of the iQ-Oval CDS by persons who have not
been suitably trained, introduced or acquainted with the system and informed
regarding the possible dangers may result in:
1. Failure of essential functions of the iQ-Oval CDS.
2. Danger to persons through electrical or mechanical actions.
3. Material damage to the iQ-Oval CDS.
1.3. Qualification of Operating and Service Staff
‘Qualified personnel’ refers to people who are able to carry out the required procedures
and be able to recognize as well as prevent potential risks, as a result of their training
and experience. Such personnel should have a good knowledge of any relevant
standards, regulations, rules of accident prevention and internal conditions etc.
Every person instructed to perform any operation on the iQ-Oval CDS must:
1. Be physically and mentally capable of coping with the respective tasks.
2. Be suitably instructed in operating the iQ-Oval CDS.
3. Be familiar with the Operating Instructions, in particular the general safety
instructions in the individual sections and have read and understood them.
4. Be aware of any additional general safety regulations of any local
authorities/associations.
5. Be aware of the principles of industrial hygiene and be able to demonstrate
them.
6. Be aware of the contents of suppliers’ safety instructions, should they affect
his/her area of responsibility.
7. Be aware of any relevant safety devices at the workplace and be able to use them.
8. Be informed regarding the prevention of environmental damage in respect of
his/her area of responsibility.
9. Be informed regarding the prevention of material damage in respect of his/her
area of responsibility.
If casual workers are employed for assistance work they must be particularly informed
regarding existing and potential dangers and instructed accordingly.

Operating instructions iQ-Oval CDS V1-4.docx page 8 of 66
1.4. Required qualification for operations
Skill
Assistant
Operating
personnel
Maintenance
personnel
Service
personnel
Colour refill (only at standstill)
x
x
x
x
Unloading substrates
x
x
x
x
Cleaning of the machine (only at
standstill)
x
x
x
x
Setting screens
x**
x
x
x
Equip flood and print squeegees
x**
x
x
x
Equip the screens
x**
x
x
x
Adjust squeegees
x**
x
x
x
Clean of the screens in clean mode
x**
x
x
x
Equip machine with dryer or
changing the position
x**
x
x
x
Applying substrates
x
x
x
Enable and disable printing heads
x
x
x
Enable and disable of dryer
x
x
x
Start of all printing processes and
adjustment work
x
x
x
Activities at the maintenance unit
x
x
x
Lubricate of the machine
x
x
x
Shutting down the machine
x
x
x
Long-term shutdown
x
x
Permanent shutdown of the machine
x
x
Maintenance and repairs at the
pneumatically system
x*
x
Maintenance and repairs at the
electrical system
x*
x
Maintenance and repairs at the
mechanical system
x*
x
Maintenance and repairs at
additional units
x*
x
Maintenance and repairs at the
electronically system
x
Maintenance and repairs at the
safety system
x
* only with the required qualification
** only together with the operating
personnel

Operating instructions iQ-Oval CDS V1-4.docx page 9 of 66
1.5. Safety Instructions for the Operating Staff
All cabinets and covers on the iQ-Oval CDS must always be kept
closed. Open cabinets and covers are extremely dangerous as live
electrical components are accessible.
Mechanical or electrical failures must only be repaired by an MHM
authorized/approved technician.
On every occasion, the operator should check the correct
functioning of the safety devices (Emergency STOP, Safety Bars,
Safety Cables), before commencing use of the iQ-Oval CDS.
No modifications to any part of the machine or its assembly system
that may adversely affect safety must be carried out without the
prior approval of MHM.
Program modifications in the control program and changes of
settings which may affect the iQ-Oval CDS’s operation should only
be carried out by an MHM authorized/approved technician.
All working spaces, passageways, escape and emergency routes and
exits must be kept clear.
No tools or other objects must be kept or left in the area of the
machine.
Any modifications or changes to the iQ-Oval CDS’s settings should
only be carried out by an MHM authorized/approved technician.
Always wear protective gloves and safety goggles during cleaning
work, in particular when using solvents!
Any remains of potentially harmful substances should be disposed
of according to the legal requirements of the country or state in
which the iQ-Oval CDS is operated.
All accessories for service and maintenance work (e.g. cleaning
agents) must be collected in suitable containers and disposed of
according to any relevant regulations.
1.6. Personal Protective Equipment
Personal protective equipment must be used at work. This equipment comprises
close-fitting working clothes with tight sleeves and high tearing resistance without any
protruding parts. These features prevent operators from getting caught by moving
machine parts.

Operating instructions iQ-Oval CDS V1-4.docx page 10 of 66
1.7. Additional Risks
Even though the iQ-Oval CDS has been designed and built according to the most
stringent safety criteria, as with all machinery we have to anticipate certain additional
risks, which are detailed below:
Danger
Description
Behavior/Action
Electrical threats:
Indirect contact (in case of
defect)
Danger of life-threatening
electrical shock by indirect
contact with defective
parts carrying voltage (in
particular in case of
defective insulation).
Switch off the machine
with the main power
switch and EMERGENCY
STOP facilities. Isolate the
mains supply.
Mechanical threats:
Crushing
Crushing of parts of the
body -in particular arms
and hands.
Be aware of moving parts
whilst operating the
machine. Wear protective
clothing at all times.
Mechanical threats:
Getting caught or trapped
Danger through moving
parts (linear or rotary
drive systems).
Danger in reaching into,
under or over the
machine. Only reach into
the machine from the
indicated points. Wear
suitably fitting clothing,
particularly in the area of
the arms.
Mechanical threats:
Slipping, stumbling and
falling
Danger of falling (e.g.
obstacles on the floor).
The floor area around the
machine must be kept
free from any obstacles.
Danger through contact
with or inhaling of
substances
Danger through contact
with or inhaling
substances or materials
with harmful or toxic
effects.
Observe the safety
instructions for handling
such substances.

Operating instructions iQ-Oval CDS V1-4.docx page 11 of 66
1.8. Safety Signs on the Machine
The following safety signs are attached to the corresponding points of the machine:
Danger
Description
Location
Warning against squashing of
parts of the body, in particular
arms or hands.
At squeegee carriages.
Warning of dangerous voltage.
At current-carrying parts of the
machine with 230/400VAC.
The adhesive labels must be replaced if illegible (due to dirt or damage).
1.9. Other Valid Rules and Regulations:
The customer must comply with all regulations applicable in the country where the
machine is located.
2. Intended usage of the machine
The machine is intended for the printing of substrates (usually textiles such as T-
shirts, but also paper or similar materials) by means of screen printing. The substrates
are conveyed by tables with single drive units. With the use of optional accessories,
the substrate can also be dried or treated with other finishing techniques (e.g.
flocking).
3. Data
This section details the iQ-Oval CDS technical specifications.
NB: As our policy is one of continuous improvement, we reserve the
right to change specifications without prior notice.
Any other use of the machine than described above may result in
danger to persons or material damage and is therefore forbidden.

Operating instructions iQ-Oval CDS V1-4.docx page 12 of 66
3.1. Serial Number and Year of Manufacture
Serial number and year of manufacture are indicated on the machine’s type plate.
3.2. Dimensions

Operating instructions iQ-Oval CDS V1-4.docx page 13 of 66
3.3. Specifications
Electrical supply
3 ph ~ 210/400V AC, 50/60Hz (+/- 5%)
Connected load
per print station
400 VA
Connected load
of machine base
3.1 kVA
Air pressure (minimum)
8 bar / 116 psi (filtered, dry air supply only)
Ø Air consumption
per print station
30 l/min
Ø Air consumption
per table
5 l/min
Maximum print area
50 x 70 cm
70 x 100 cm
80 x 110 cm
19.7 x 27.6"
27.6 x 39.4"
31.5 x 43.3"
Maximum frame size
105 x 115 cm
105 x 144cm
105 x 154 cm
41.3 x 45.2"
41.3 x 56.7"
41.3 x 60.6"
Length of 10-table-
machine
670 cm / 263.8"
770 cm / 303.2"
790 cm / 311"
Additional length
per 2 tables
110 cm / 43.3"
130 cm / 51.2"
Weight of 10-table
machine */**
1625 kg
1780 kg
1800 kg
Additional weight of 2-
step-section
275 kg
310 kg
315 kg
Weight of print station
100 kg
100 kg
110 kg
Max. production capacity
900-1600 (according to model / 2 job mode)
* Overall weight can be calculated by adding the following component weights:
Weight of 10-table machine + Weight of additional 2-step-sections + Weight of
print stations.
** incl. tables and pallets but without print stations.

Operating instructions iQ-Oval CDS V1-4.docx page 14 of 66
4. Transportation and packaging
This section provides an overview of the proper transportation of the iQ-Oval CDS.
4.1. General Notes with Regard to Transportation and Danger Warnings
4.2. Packaging
The iQ-Oval CDS will be packed and delivered in several wooden crates. The crates’
exact number, weight and dimensions will vary slightly according to each model/type
of machine. Contact customer service for more information about individual orders.
4.3. Unloading of the crates
The iQ-Oval CDS is to be unloaded by the customer. A forklift truck with adequate fork
length and lifting capacity (see 4.2 Packaging) will be required.
Upon delivery of the iQ-Oval CDS the consignment must be examined
for external damage immediately. In the case of any damages, they
must be documented and reported to Machines Highest Mechatronic
GmbH within 24 hours.
Danger of falling objects!
The following instructions must be observed
1. Never stand or walk under hanging loads!
2. Transportation must be carried out by qualified staff observing all
safety instructions.
3. The iQ-Oval CDS must only be lifted at the dedicated lifting points.
4. Only the lifting/handling devices and equipment indicated in this
document must be used for the movement of the iQ-Oval CDS.
Non-compliance may lead to serious damage of the iQ-Oval CDS
and result in cancellation of the warranty.
Danger of mechanical damage!
The iQ-Oval CDS must be lifted carefully and only at the dedicated
lifting points at the middle of the base unit. Lifting the iQ-Oval CDS
at/by any other point, especially the tables, may result in serious
damage. Be sure to maintain an adequate and safe distance during
lifting.

Operating instructions iQ-Oval CDS V1-4.docx page 15 of 66
4.4. Packaging material
After unpacking the machine, the packaging material must be disposed of according
to local regulations.
5. Assembly
This section describes the external supply/connection ports of the iQ-Oval CDS and the
points to be observed during assembly.
5.1. General Assembly Instructions
The customer should have a minimum of two persons available to assist the technician
with the installation and assembly of the machine.
5.2. Positioning of the iQ-Oval CDS
The machine must be mounted on a bed with sufficient load-bearing capacity. In case
of doubt this capacity has to be examined by a structural engineer.
In order to guarantee perfect installation and smooth operation of the iQ-Oval CDS,
the machine must be installed at a sufficient distance from adjacent elements of the
building (walls, columns, etc.) and/or other machines. The distance required in each
case depends on the screen size and must be chosen so as to allow the operator to
replace the screens without any problems. The dimensions of the respective machine
are indicated in Chapter 3 Data.
The iQ-Oval CDS must only be installed / assembled by an authorized
MHM service technician or by an authorized service technician from
an official MHM dealer/agent. Any assembly/installation by any third
party not listed above will result in immediate cancellation of the
warranty.

Operating instructions iQ-Oval CDS V1-4.docx page 16 of 66
5.3. Ambient Conditions
For the electrical equipment on the iQ-Oval CDS, ambient conditions according to
standard IEC 60204 “Electrical Equipment of Industrial Machines” should be observed.
The following points should be observed in order to achieve efficient running and an
optimum level of production with the iQ-Oval CDS:
1. The premises, where the iQ-Oval CDS is to be operated, must be kept clean, dry
and well-aired.
2. The ambient temperature must not fall below +5° C or exceed +45° C.
3. Relative air humidity must not exceed 80 %.
4. The mains supply must not exceed or fall below a tolerance of +/- 5 % of the
required voltage for the iQ-Oval CDS. If this voltage stability cannot be
guaranteed, the customer must install a constant-voltage regulator to protect the
iQ-Oval CDS against such fluctuations.
5. The compressed air must be clean, filtered and dry (class 1:4:1 according
ISO8573-1:2010).
6. Compressed air supply must be sufficient in terms of pressure, volume and
consistency.
7. Electricity supply should be sufficient with adequate fuse protection.
8. Maximum installation altitude is 2000m above sea level.
5.4. External supply/Connection ports
Connections for compressed air and mains electricity are located on the base unit of
the iQ-Oval CDS as standard. Overhead supply connections may be ordered optionally
but only at time of order, to enable supplies to enter the machine from above.
Danger of tripping over!
In case of laying supply lines on the floor, it is necessary to attach
step covers.

Operating instructions iQ-Oval CDS V1-4.docx page 17 of 66
5.4.1. Electrical Connections
The electrical connections must be designed as follows:
Description
Requirement/Value
Supply voltage
3 ph. ~ 210 / 400V AC
Supply frequency
50/60Hz ±5%
Connected load
0.4 kVA x “number of print heads”+ 3,1 kVA
5.4.2. Compressed Air
Description
Value
Air pressure
(minimum)
8 bar / 116 PSI
Air quality
filtered, dry air supply only (class 1:4:1 according ISO8573-
1:2010)
Max. air consumption
(l/min)
30 l/min x „number of print heads“+
5 l/min x „number of tables“
Risk of electric shock!
Please observe the general safety regulations for electrical
connections when connecting the mains supply to the iQ-Oval CDS.
Avoid any contact with live components.
All flash cure units must be supplied through a
separate/independent connection. Please observe the precise
technical data from the flash cure unit specification sheet.

Operating instructions iQ-Oval CDS V1-4.docx page 18 of 66
6. Commissioning the iQ-Oval CDS
After the initial start-up of the machine, commissioning is to be completed in the
presence of the authorized technician along with any persons authorized on the part
of the customer. During this initial start-up and commissioning, all tasks carried out by
the MHM service engineer or the technicians of an authorized dealer are recorded.
This installation/job sheet must be clearly signed by both parties, stating the date and
location of the iQ-Oval CDS and will be legally binding hereon after.
Initial start-up of the iQ-Oval CDS should only be carried out by an
authorised MHM service engineer or by an approved technician from
an official MHM dealer/agent.
Any defects or complaints must be brought to the attention of the
authorized technician, documented in writing and recorded
immediately on the service technician’s installation/job sheet.
Before starting the machine, mains connection and compressed-air
supply must be checked and, if necessary, established according to
the instructions.

Operating instructions iQ-Oval CDS V1-4.docx page 19 of 66
7. Design and Operation
This section describes design and operation and indicates the individual assemblies.
7.1. General Process Description
The operator applies a substrate (usually a T-shirt) to the pallets at the locating
surface. The substrate will be fixed in position by means of the spray adhesive applied
to the pallets beforehand. Subsequently, the machine moves the substrate to the first
print station, where the substrate is printed by means of screen printing or treated
with optional accessories. Subsequently, the substrate moves to the second station,
where it is treated again, before the process continues with all other stations. Finally,
the substrate arrives at the unloading point, where an operator takes it from the
machine for further processing.
7.2. Overview Machine Parts
Pallets
Print stations
Control panel
Tables
Base frame

Operating instructions iQ-Oval CDS V1-4.docx page 20 of 66
7.3. Main control panel
Control panel
Keypad
Control
ON/OFF
Reset
button
Main switch
tablet
Tablet
m-touch
pro
EMERGENCY STOP
(push button)
Skip
button
Power supply
tablet
Safety
level key
