Micro control systems MCS-EXV-Driver-115 Quick start guide

-115/230
CHECKING VALVE TYPE - SEE BACK

Valve Code # of Steps EXV TYPE
A1 750 Alco EX4-EX5-EX6
A2 1660 Alco EX7
A3 2600 Alco EX8
CL 500 CAREL E2V, E3V, E4V, E5V, E6V, E7V
D1 2625 Danfoss ETS-12/25/50
D2 3530 Danfoss ETS-100
D3 3810 Danfoss ETS-250/400
S1 1596 Sporlan SEI 0.5 to 11
S2 1596 Sporlan SER 1.5-20 (AA,A,B,C,D,E)
S3 3193 Sporlan SEI 30; SDR –3, SDR-3x
S4 2500 Sporlan SER-AA-A, B.C,D
Sporlan SERI-F,G,J,K,L, CDS -2, -4, -7
S5 6388 Sporlan SEI-50, SEH (I)-100, -175, -400; CDS –9, -16, -17; SDR –4
T1 1596 Sporlan SEI 0.5 to 11- two valves wired to one MCS-EXV-DRIVER
T2 1596 Sporlan SER 1.5-20 (AA,A,B,C,D,E)- two valves wired to one
MCS-EXV-DRIVER
T3 3193 Sporlan SEI 30; SDR –3, SDR-3x- two valves wired to one
MCS-EXV-DRIVER
T4 2500 Sporlan SER-AA-A, B.C,D
Sporlan SERI-F,G,J,K,L
CDS -2, -4, -7 - two valves wired to one MCS-EXV-DRIVER
T5 6388 Sporan SEI-50, SEH (I)-100, -175, -400;
CDS -9, -16, -17,; SDR -4 - two valves wired to one MCS-EXV-DRIVER
HOW TO CHECK VALVE TYPE
When in Auto mode press three keys, UP , DOWN and AUTO/MANUAL simultaneously, this will display the valve type.
SEE CHART BELOW FOR VALVE TYPE
- Valve Type = Sporlan S5
S5
EXAMPLE
Valve Code # of Steps EXV TYPE
A1 750 Alco EX4-EX5-EX6
A2 1660 Alco EX7
A3 2600 Alco EX8
CL 500 CAREL E2V, E3V, E4V, E5V, E6V, E7V
D1 2625 Danfoss ETS-12/25/50
D2 3530 Danfoss ETS-100
D3 3810 Danfoss ETS-250/400
S1 1596 Sporlan SEI 0.5 to 11
S2 1596 Sporlan SER 1.5-20 (AA,A,B,C,D,E)
S3 3193 Sporlan SEI 30; SDR –3, SDR-3x
S4 2500 Sporlan SER-AA-A, B.C,D
Sporlan SERI-F,G,J,K,L, CDS -2, -4, -7
S5 6388 Sporlan SEI-50, SEH (I)-100, -175, -400; CDS –9, -16, -17; SDR –4
T1 1596 Sporlan SEI 0.5 to 11- two valves wired to one MCS-EXV-DRIVER
T2 1596 Sporlan SER 1.5-20 (AA,A,B,C,D,E)- two valves wired to one
MCS-EXV-DRIVER
T3 3193 Sporlan SEI 30; SDR –3, SDR-3x- two valves wired to one
MCS-EXV-DRIVER
T4 2500 Sporlan SER-AA-A, B.C,D
Sporlan SERI-F,G,J,K,L
CDS -2, -4, -7 - two valves wired to one MCS-EXV-DRIVER
T5 6388 Sporan SEI-50, SEH (I)-100, -175, -400;
CDS -9, -16, -17,; SDR -4 - two valves wired to one MCS-EXV-DRIVER
HOW TO CHECK VALVE TYPE
When in Auto mode press three keys, UP , DOWN and AUTO/MANUAL simultaneously, this will display the valve type.
SEE CHART BELOW FOR VALVE TYPE
- Valve Type = Sporlan S5
S5
EXAMPLE
