MPLAB®ICD 3

In-Circuit Debugger

User’s Guide

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

Information contained in this publication regarding device

applications and the like is provided only for your convenience

and may be superseded by updates. It is your responsibility to

ensure that your application meets with your specifications.

MICROCHIP MAKES NO REPRESENTATIONS OR

WARRANTIES OF ANY KIND WHETHER EXPRESS OR

IMPLIED, WRITTEN OR ORAL, STATUTORY OR

OTHERWISE, RELATED TO THE INFORMATION,

INCLUDING BUT NOT LIMITED TO ITS CONDITION,

QUALITY, PERFORMANCE, MERCHANTABILITY OR

FITNESS FOR PURPOSE. Microchip disclaims all liability

arising from this information and its use. Use of Microchip

devices in life support and/or safety applications is entirely at

the buyer’s risk, and the buyer agrees to defend, indemnify and

hold harmless Microchip from any and all damages, claims,

suits, or expenses resulting from such use. No licenses are

conveyed, implicitly or otherwise, under any Microchip

intellectual property rights.

Trademarks

The Microchip name and logo, the Microchip logo, Accuron,

dsPIC, KEELOQ, KEELOQ logo, MPLAB, PIC, PICmicro,

PICSTART, rfPIC, SmartShunt and UNI/O are registered

trademarks of Microchip Technology Incorporated in the

U.S.A. and other countries.

FilterLab, Linear Active Thermistor, MXDEV, MXLAB,

SEEVAL, SmartSensor and The Embedded Control Solutions

Company are registered trademarks of Microchip Technology

Incorporated in the U.S.A.

Analog-for-the-Digital Age, Application Maestro, CodeGuard,

dsPICDEM, dsPICDEM.net, dsPICworks, dsSPEAK, ECAN,

ECONOMONITOR, FanSense, In-Circuit Serial

Programming, ICSP, ICEPIC, Mindi, MiWi, MPASM, MPLAB

Certified logo, MPLIB, MPLINK, mTouch, PICkit, PICDEM,

PICDEM.net, PICtail, PIC32 logo, PowerCal, PowerInfo,

PowerMate, PowerTool, REAL ICE, rfLAB, Select Mode, Total

Endurance, WiperLock and ZENA are trademarks of

Microchip Technology Incorporated in the U.S.A. and other

countries.

SQTP is a service mark of Microchip Technology Incorporated

in the U.S.A.

All other trademarks mentioned herein are property of their

respective companies.

Printed on recycled paper.

Note the following details of the code protection feature on Microchip devices:

• Microchip products meet the specification contained in their particular Microchip Data Sheet.

• Microchip believes that its family of products is one of the most secure families of its kind on the market today, when used in the

intended manner and under normal conditions.

• There are dishonest and possibly illegal methods used to breach the code protection feature. All of these methods, to our

knowledge, require using the Microchip products in a manner outside the operating specifications contained in Microchip’s Data

Sheets. Most likely, the person doing so is engaged in theft of intellectual property.

• Microchip is willing to work with the customer who is concerned about the integrity of their code.

• Neither Microchip nor any other semiconductor manufacturer can guarantee the security of their code. Code protection does not

mean that we are guaranteeing the product as “unbreakable.”

Code protection is constantly evolving. We at Microchip are committed to continuously improving the code protection features of our

products. Attempts to break Microchip’s code protection feature may be a violation of the Digital Millennium Copyright Act. If such acts

allow unauthorized access to your software or other copyrighted work, you may have a right to sue for relief under that Act.

Microchip received ISO/TS-16949:2002 certification for its worldwide

headquarters, design and wafer fabrication facilities in Chandler and

Tempe, Arizona; Gresham, Oregon and design centers in California

and India. The Company’s quality system processes and procedures

are for its PIC®MCUs and dsPIC®DSCs, KEELOQ®code hopping

devices, Serial EEPROMs, microperipherals, nonvolatile memory and

analog products. In addition, Microchip’s quality system for the design

and manufacture of development systems is ISO 9001:2000 certified.

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

MPLAB®ICD 3 IN-CIRCUIT

DEBUGGER USER’S GUIDE

Table of Contents

Preface ...........................................................................................................................1

Part 1 –Getting Started

Chapter 1. Overview

1.1 Introduction ..................................................................................................... 9

1.2 MPLAB ICD 3 In-Circuit Debugger Defined ................................................... 9

1.3 How the MPLAB ICD 3 In-Circuit Debugger Helps You ............................... 10

1.4 MPLAB ICD 3 In-Circuit Debugger Kit Components ....................................10

1.5 Device and Feature Support ........................................................................11

Chapter 2. Theory of Operation

2.1 Introduction ...................................................................................................13

2.2 MPLAB ICD 3 In-Circuit Debugger vs. MPLAB ICE 2000/4000

In-Circuit Emulators ................................................................................ 13

2.3 MPLAB ICD 3 In-Circuit Debugger vs. MPLAB ICD 2 Debugger .................13

2.4 Debugger To Target Communication ...........................................................14

2.5 Communication Connections .......................................................................15

2.6 Debugging with the Debugger ......................................................................17

2.7 Requirements For Debugging ...................................................................... 18

2.8 Programming with the Debugger ..................................................................20

2.9 Resources Used by the Debugger ...............................................................20

Chapter 3. Installation

3.1 Introduction ...................................................................................................21

3.2 Installing the Software .................................................................................. 21

3.3 Installing the USB Device Drivers ................................................................ 21

3.4 Connecting the Target .................................................................................. 22

3.5 Setting Up the Target Board ......................................................................... 22

3.6 Setting Up MPLAB IDE ................................................................................ 23

Chapter 4. General Setup

4.1 Introduction ...................................................................................................25

4.2 Starting the MPLAB IDE Software ................................................................ 25

4.3 Creating a Project ......................................................................................... 26

4.4 Viewing the Project ....................................................................................... 26

4.5 Building the Project ......................................................................................26

4.6 Setting Configuration Bits ............................................................................. 27

4.7 Setting the Debugger as the Debugger or Programmer ...............................27

4.8 Debugger/Programmer Limitations ..............................................................27

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

MPLAB®ICD 3 In-Circuit Debugger User’s Guide

Chapter 5. Tutorial

5.1 Introduction ................................................................................................... 29

5.2 Setting Up the Environment and Selecting the Device ................................. 30

5.3 Creating the Application Code ...................................................................... 30

5.4 Running the Project Wizard .......................................................................... 33

5.5 Viewing the Project ....................................................................................... 35

5.6 Viewing Debug Options ................................................................................ 36

5.7 Creating a Hex File ....................................................................................... 37

5.8 Setting Up the Demo Board ......................................................................... 39

5.9 Loading Program Code For Debugging .......................................................39

5.10 Running Debug Code ................................................................................. 40

5.11 Debugging Code Using Breakpoints .......................................................... 40

5.12 Programming the Application ..................................................................... 45

Part 2 –Troubleshooting

Chapter 6. Frequently Asked Questions (FAQs)

6.1 Introduction ................................................................................................... 49

6.2 How Does It Work ........................................................................................ 49

6.3 What’s Wrong ............................................................................................... 50

Chapter 7. Error Messages

7.1 Introduction ................................................................................................... 53

7.2 Specific Error Messages .............................................................................. 53

7.3 General Corrective Actions .......................................................................... 57

Part 3 –Reference

Chapter 8. Basic Debug Functions

8.1 Introduction ................................................................................................... 63

8.2 Breakpoints .................................................................................................. 63

8.3 Stopwatch ..................................................................................................... 63

Chapter 9. Debugger Function Summary

9.1 Introduction ................................................................................................... 65

9.2 Debugging Functions ................................................................................... 65

9.3 Debugging Dialogs/Windows ....................................................................... 68

9.4 Programming Functions ............................................................................... 73

9.5 Settings Dialog ............................................................................................. 74

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

Table of Contents

Chapter 10. Hardware Specification

10.1 Introduction ................................................................................................. 79

10.2 Highlights ....................................................................................................79

10.3 Declaration of Conformity ........................................................................... 79

10.4 USB Port/Power ......................................................................................... 80

10.5 MPLAB ICD 3 Debugger ............................................................................80

10.6 Standard Communication Hardware ..........................................................81

10.7 ICD 3 Test Interface Board ......................................................................... 82

10.8 Target Board Considerations ..................................................................... 83

Glossary .......................................................................................................................85

Index .............................................................................................................................99

Worldwide Sales and Service ..................................................................................102

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

MPLAB®ICD 3 In-Circuit Debugger User’s Guide

NOTES:

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

MPLAB®ICD 3 IN-CIRCUIT

DEBUGGER USER’S GUIDE

Preface

INTRODUCTION

This chapter contains general information that will be useful to know before using the

MPLAB ICD 3 in-circuit debugger. Items discussed in this chapter include:

• Document Layout

• Conventions Used in this Guide

• Warranty Registration

• Recommended Reading

• The Microchip Web Site

• Development Systems Customer Change Notification Service

• Customer Support

• Revision History

DOCUMENT LAYOUT

This document describes how to use the MPLAB ICD 3 in-circuit debugger as a

development tool to emulate and debug firmware on a target board, as well as how to

program devices. The document is organized as follows:

Part 1 – Getting Started

•Chapter 1. Overview – What the MPLAB ICD 3 in-circuit debugger is, and how it

can help you develop your application.

•Chapter 2. Theory of Operation – The theory of MPLAB ICD 3 in-circuit debug-

ger operation. Explains configuration options.

•Chapter 3. Installation – How to install the debugger software and hardware.

•Chapter 4. General Setup – How to set up MPLAB IDE to use the debugger.

•Chapter 5. Tutorial – A brief tutorial on using the debugger.

NOTICE TO CUSTOMERS

All documentation becomes dated, and this manual is no exception. Microchip tools and

documentation are constantly evolving to meet customer needs, so some actual dialogs

and/or tool descriptions may differ from those in this document. Please refer to our web site

(www.microchip.com) to obtain the latest documentation available.

Documents are identified with a “DS” number. This number is located on the bottom of each

page, in front of the page number. The numbering convention for the DS number is

“DSXXXXXA”, where “XXXXX” is the document number and “A” is the revision level of the

document.

For the most up-to-date information on development tools, see the MPLAB®IDE on-line help.

Select the Help menu, and then Topics to open a list of available on-line help files.

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

MPLAB®ICD 3 In-Circuit Debugger User’s Guide

Part 2 –Troubleshooting

•Chapter 6. Frequently Asked Questions (FAQs) – A list of frequently asked

questions, useful for troubleshooting.

•Chapter 7. Error Messages – A list of error messages and suggested

resolutions.

Part 3 –Reference

•Chapter 8. Basic Debug Functions – A description of basic debugger features

available in MPLAB IDE when the MPLAB ICD 3 in-circuit debugger is chosen as

either the debug or programming tool. This includes the debug features

breakpoints, stopwatch, triggering and real-time watches.

•Chapter 9. Debugger Function Summary – A summary of debugger functions

available in MPLAB IDE when the MPLAB ICD 3 debugger is chosen as the

debug or program tool.

•Chapter 10. Hardware Specification – The hardware and electrical

specifications of the debugger system.

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

Preface

CONVENTIONS USED IN THIS GUIDE

This manual uses the following documentation conventions:

DOCUMENTATION CONVENTIONS

Description Represents Examples

Arial font:

Italic characters Referenced books MPLAB®IDE User’s Guide

Emphasized text ...is the only compiler...

Initial caps A window the Output window

A dialog the Settings dialog

A menu selection select Enable Programmer

Quotes A field name in a window or

dialog “Save project before build”

Underlined, italic text with

right angle bracket A menu path File>Save

Bold characters A dialog button Click OK

A tab Click the Power tab

N‘Rnnnn A number in verilog format,

where N is the total number of

digits, R is the radix and n is a

digit.

4‘b0010, 2‘hF1

Text in angle brackets < > A key on the keyboard Press <Enter>, <F1>

Courier New font:

Plain Courier New Sample source code #define START

Filenames autoexec.bat

File paths c:\mcc18\h

Keywords _asm, _endasm, static

Command-line options -Opa+, -Opa-

Bit values 0, 1

Constants 0xFF, ‘A’

Italic Courier New A variable argument file.o, where file can be

any valid filename

Square brackets [ ] Optional arguments mcc18 [options] file

[options]

Curly brackets and pipe

character: { | } Choice of mutually exclusive

arguments; an OR selection errorlevel {0|1}

Ellipses... Replaces repeated text var_name [,

var_name...]

Represents code supplied by

user void main (void)

{ ...

}

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

MPLAB®ICD 3 In-Circuit Debugger User’s Guide

WARRANTY REGISTRATION

Please complete the enclosed Warranty Registration Card and mail it promptly.

Sending in the Warranty Registration Card entitles users to receive new product

updates. Interim software releases are available at the Microchip web site.

RECOMMENDED READING

This user's guide describes how to use MPLAB ICD 3 in-circuit debugger. Other useful

documents are listed below. The following Microchip documents are available and

recommended as supplemental reference resources.

Please read this first! This document contains important information about operational

issues that should be considered when using the MPLAB ICD 3 with your target

design

Release Notes for MPLAB ICD 3 In-Circuit Debugger

For the latest information on using MPLAB ICD 3 in-circuit debugger, read the

“Readme for MPLAB ICD 3 Debugger.htm” file (an HTML file) in the Readmes

subdirectory of the MPLAB IDE installation directory. The release notes (Readme)

contains update information and known issues that may not be included in this user’s

guide.

Using MPLAB ICD 3 In-Circuit Debugger Poster (DS51765)

This poster shows you how to hook up the hardware and install the software for the

MPLAB ICD 3 in-circuit debugger using standard communications and a target board.

MPLAB ICD 3 In-Circuit Debugger On-line Help File

A comprehensive help file for the debugger is included with MPLAB IDE. Usage,

troubleshooting andhardwarespecifications are covered.Thismaybe moreup-to-date

than the printed documentation. Also, debugger reserved resources and limitations are

listed for various devices.

Header Board Specification (DS51292)

This booklet describes how to install and use MPLAB ICD 3 in-circuit debugger

headers. Headers are used to better debug selected devices using special -ICE device

versions without the loss of pins or resources.

Transition Socket Specification (DS51194)

Consult this document for information on transition sockets available for use with

MPLAB ICE 2000/4000 device adaptors, MPLAB ICD 2 headers and MPLAB ICD 3

in-circuit debugger headers.

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

Preface

THE MICROCHIP WEB SITE

Microchip provides online support via our web site at www.microchip.com. This web

site is used as a means to make files and information easily available to customers.

Accessible by using your favorite Internet browser, the web site contains the following

information:

•Product Support – Data sheets and errata, application notes and sample

programs, design resources, user’s guides and hardware support documents,

latest software releases and archived software

•General Technical Support – Frequently Asked Questions (FAQs), technical

support requests, online discussion groups, Microchip consultant program

member listing

•Business of Microchip – Product selector and ordering guides, latest Microchip

press releases, listing of seminars and events, listings of Microchip sales offices,

distributors and factory representatives

DEVELOPMENT SYSTEMS CUSTOMER CHANGE NOTIFICATION SERVICE

Microchip’s customer notification service helps keep customers current on Microchip

products. Subscribers will receive e-mail notification whenever there are changes,

updates, revisions or errata related to a specified product family or development tool of

interest.

To register, access the Microchip web site at www.microchip.com, click on Customer

Change Notification and follow the registration instructions.

The Development Systems product group categories are:

•Compilers – The latest information on Microchip C compilers,assemblers, linkers

and other language tools. These include all MPLAB C compilers; all MPLAB

assemblers (including MPASM™ assembler); all MPLAB linkers (including

MPLINK™ object linker); and all MPLAB librarians (including MPLIB™ object

librarian).

•Emulators – The latest information on Microchip in-circuit emulators.These

include the MPLAB REAL ICE™, MPLAB ICE 2000 and MPLAB ICE 4000

in-circuit emulators

•In-Circuit Debuggers – The latest information on the Microchip in-circuit

debuggers, the MPLAB ICD 2 in-circuit debugger and PICkit™ 2 debug express.

•MPLAB®IDE – The latest information on Microchip MPLAB IDE, the Windows®

Integrated Development Environment for development systems tools. This list is

focused on the MPLAB IDE, MPLAB IDE Project Manager, MPLAB Editor and

MPLAB SIM simulator, as well as general editing and debugging features.

•Programmers – The latest information on Microchip programmers. These include

the MPLAB PM3 and PRO MATE II device programmers and the PICSTART®

Plus and PICkit 1 and 2 development programmers.

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

MPLAB®ICD 3 In-Circuit Debugger User’s Guide

CUSTOMER SUPPORT

Users of Microchip products can receive assistance through several channels:

• Distributor or Representative

• Local Sales Office

• Field Application Engineer (FAE)

• Technical Support

Customers should contact their distributor, representative or field application engineer

(FAE) for support. Local sales offices are also available to help customers. A listing of

sales offices and locations is included in the back of this document.

Technical support is available through the web site at: http://support.microchip.com.

REVISION HISTORY

Revision A (September 2008)

This is the initial release of this document.

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

MPLAB®ICD 3 IN-CIRCUIT

DEBUGGER USER’S GUIDE

Part 1 – Getting Started

Chapter 1. Overview....................................................................................................... 9

Chapter 2. Theory of Operation ..................................................................................13

Chapter 3. Installation..................................................................................................21

Chapter 4. General Setup............................................................................................25

Chapter 5. Tutorial........................................................................................................29

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

MPLAB®ICD 3 In-Circuit Debugger User’s Guide

NOTES:

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

MPLAB®ICD 3 IN-CIRCUIT

DEBUGGER USER’S GUIDE

Chapter 1. Overview

1.1 INTRODUCTION

An overview of the MPLAB ICD 3 in-circuit debugger system is given.

• MPLAB ICD 3 In-Circuit Debugger Defined

• How the MPLAB ICD 3 In-Circuit Debugger Helps You

• MPLAB ICD 3 In-Circuit Debugger Kit Components

• Device and Feature Support

1.2 MPLAB ICD 3 IN-CIRCUIT DEBUGGER DEFINED

The MPLAB ICD 3 in-circuit debugger is an in-circuit debugger that is controlled by a

PC running MPLAB IDE (v8.15 or greater) software on a Windows®platform. The

MPLAB ICD 3 in-circuit debugger is an integral part of the development engineer's

toolsuite. The application usage can vary from software development to hardware

integration.

The MPLAB ICD 3 in-circuit debugger is a complex debugger system used for

hardware and software development of Microchip PIC®microcontrollers (MCUs) and

dsPIC®Digital Signal Controllers (DSCs) that are based on In-Circuit Serial

Programming™ (ICSP™) and Enhanced In-Circuit Serial Programming 2-wire serial

interfaces.

The debugger system will execute code like an actual device because it uses a device

with built-in emulation circuitry, instead of a special debugger chip, for emulation. All

available features of a given device are accessible interactively, and can be set and

modified by the MPLAB IDE interface.

The MPLAB ICD 3 debugger was developed for emulating embedded processors with

rich debug facilities which differ from conventional system processors in the following

aspects:

• Processors run at maximum speeds

• Capability to incorporate I/O port data input

In addition to debugger functions, the MPLAB ICD 3 in-circuit debugger system also

may be used as a development programmer.

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

MPLAB®ICD 3 In-Circuit Debugger User’s Guide

1.3 HOW THE MPLAB ICD 3 IN-CIRCUIT DEBUGGER HELPS YOU

The MPLAB ICD 3 in-circuit debugger system allows you to:

• Debug your application on your own hardware in real time

• Debug with hardware breakpoints

• Debug with software breakpoints

• Set breakpoints based on internal events

• Monitor internal file registers

• Emulate full speed

• Program your device

1.4 MPLAB ICD 3 IN-CIRCUIT DEBUGGER KIT COMPONENTS

The components of the MPLAB ICD 3 in-circuit debugger system kit are:

1. MPLAB ICD 3 with indicator lights

2. USB cable to provide communications between the debugger and a PC and to

provide power to the debugger

3. Cable (also MPLAB ICD 2 compatible) to connect the MPLAB ICD 3 to a header

module or target board

4. MPLAB IDE Quick Start Guide (DS51281)

5. CD-ROM with MPLAB IDE software and on-line documentation

6. ICD 3 Test Interface Board

FIGURE 1-1: BASIC DEBUGGER SYSTEM

Additional hardware that may be ordered separately:

• Transition socket

• ICD headers

• MPLAB processor extension kits

MPLAB®ICD 3

Modular Cable

to Target Board

USB Cable to PC

Indicator

Lights

or Header

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

Overview

1.5 DEVICE AND FEATURE SUPPORT

Table 1-1 and Table 1-2 show the current and future support for devices and device

features.

TABLE 1-1: 32-BIT AND 16-BIT (DATA MEMORY) DEVICES

Feature PIC32MX dsPIC33F,

PIC24F/H dsPIC30F

SMPS(1) dsPIC30F

Reset application C C C C

Run, Halt C C C C

Single Step C C C C

Animate C C C C

Full Speed Emulation C C C C

Hardware Breakpoints C C C C

Advanced Breakpoints C C C C

Software Breakpoints N C C C

Peripheral Freeze(2) C C C C

Break on data fetch or write C C C C

Break on Stack overflow C C C C

Stopwatch C C C N

Pass Counter C C C C

WDT overflow C C C N

Standard Speed Comm. C C C C

Processor Pak N F F N

Legend:

C= Current support

D= Support dependent on device

F= No support now, but planned in the future

N= Support Not Available

Note 1: Current Switch Mode Power Supply (SMPS) devices: dsPIC30F1010/2020/2023.

2: This feature operates differently depending on the selected device.

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

MPLAB®ICD 3 In-Circuit Debugger User’s Guide

TABLE 1-2: 8-BIT (DATA MEMORY) DEVICES

Feature PIC18FXXJ PIC18F,

PIC18F Enh,

PIC18FXXK PIC12F, PIC16F

Reset application C C C

Run, Halt C C C

Single Step C C C

Animate C C C

Full Speed Emulation C C C

Hardware Breakpoints C C C

Advanced Breakpoints C C N

Software Breakpoints C C N

Peripheral Freeze(1) C C C

Break on data fetch or write C C N

Break on Stack overflow C C N

Stopwatch C N N

Pass Counter C C N

WDT overflow C N N

Standard Speed Comm. C C C

Processor Pak F F F

Legend:

C= Current support

F= No support now, but planned in the future

N= Support Not Available

Note 1: This feature operates differently depending on the selected device.

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

MPLAB®ICD 3 IN-CIRCUIT

DEBUGGER USER’S GUIDE

Chapter 2. Theory of Operation

2.1 INTRODUCTION

A simplified description of how the MPLAB ICD 3 in-circuit debugger system works is

provided here. It is intended to provide enough information so a target board can be

designed that is compatible with the debugger for both emulation and programming

operations. The basic theory of in-circuit emulation and programming is described so

that problems, if encountered, are quickly resolved.

• MPLAB ICD 3 In-Circuit Debugger vs. MPLAB ICE 2000/4000 In-Circuit

Emulators

• MPLAB ICD 3 In-Circuit Debugger vs. MPLAB ICD 2 Debugger

• Debugger To Target Communication

• Communication Connections

• Debugging with the Debugger

• Requirements For Debugging

• Programming with the Debugger

• Resources Used by the Debugger

2.2 MPLAB ICD 3 IN-CIRCUIT DEBUGGER VS. MPLAB ICE 2000/4000

IN-CIRCUIT EMULATORS

The MPLAB ICD 3 in-circuit debugger system is a next generation In-Circuit Debugger

(ICD) system. It differs from classical in-circuit emulator systems (e.g., MPLAB ICE

2000/4000) in a single, but important way: the production device and emulation device

are the same.

This is a great benefit since differences (errata) between the production silicon and

emulation silicon are eliminated. Additionally, as devices continue to operate at faster

speeds, traditional emulator systems present bottlenecks caused by internal busses

that must be carried off-chip to external memories and cannot offer full speed

emulation.

Another significant benefit is that there is no lead time between production silicon and

emulation silicon. Further, a problem encountered on a production board can be easily

debugged without having to install transition sockets and dealing with complicated

cabling systems and setups to have access to the application.

2.3 MPLAB ICD 3 IN-CIRCUIT DEBUGGER VS. MPLAB ICD 2 DEBUGGER

The MPLAB ICD 3 in-circuit debugger system is similar in function to the MPLAB ICD

2 in-circuit debugger system, but surpasses it in speed and functionality. The MPLAB

ICD 3 also:

• Features USB high speed

• Is USB powered

• Is a hardware accelerator

• Provides a programmable voltage power supply

• Eliminates the RS-232 port

• Includes a diagnostic self-test interface board

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW

MPLAB®ICD 3 In-Circuit Debugger User’s Guide

2.4 DEBUGGER TO TARGET COMMUNICATION

The debugger system configurations are discussed in the following sections.

Standard ICSP Device Communication

The debugger system can be configured to use standard ICSP communication for both

programming and debugging functions. This 6-pin connection is the same one used by

the MPLAB ICD 2 in-circuit debugger.

The modular cable can be either (1) inserted into a matching socket at the target, where

the target device is on the target board (Figure 2-1), or (2) inserted into a standard

adapter/header board combo (available as a Processor Pak), which in then plugged

into the target board (Figure 2-2).

For more on standard communication, see Chapter 10. “Hardware Specification”.

FIGURE 2-1: STANDARD DEBUGGER SYSTEM – DEVICE WITH

ON-BOARD ICE CIRCUITRY

CAUTION

Do not connect the hardware before installing the software and USB drivers. Also, do

not change hardware connections when the pod or target is powered.

Note: Older header boards used a 6-pin (RJ-11) connector instead of an 8-pin

connector, so these headers may be connected directly to the debugger.

MPLAB®ICD 3

Target Board

Target Device

or PIM

Power

WWW.100Y.COM.TW WWW.100Y.COM.TW WWW.100Y.COM.TW
