Microchip Technology Microsemi HDMI TX IP User manual

UG0862
User Guide
HDMI TX

50200862. 1.0 6/19
Microsemi Headquarters
One Enterprise, Aliso Viejo,
CA 92656 USA
Within the USA: [phone]
Outside the USA: [phone]
Sales: [phone]
Fax: [phone]
Email: [email protected]
www.microsemi.com
©2019 Microsemi, a wholly owned
subsidiary of Microchip Technology Inc. All
rights reserved. Microsemi and the
Microsemi logo are registered trademarks of
Microsemi Corporation. All other trademarks
and service marks are the property of their
respective owners.
Microsemi makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of
its products and services for any particular purpose, nor does Microsemi assume any liability whatsoever arising out of the
application or use of any product or circuit. The products sold hereunder and any other products sold by Microsemi have
been subject to limited testing and should not be used in conjunction with mission-critical equipment or applications. Any
performance specifications are believed to be reliable but are not verified, and Buyer must conduct and complete all
performance and other testing of the products, alone and together with, or installed in, any end-products. Buyer shall not
rely on any data and performance specifications or parameters provided by Microsemi. It is the Buyer’s responsibility to
independently determine suitability of any products and to test and verify the same. The information provided by Microsemi
hereunder is provided “as is, where is” and with all faults, and the entire risk associated with such information is entirely
with the Buyer. Microsemi does not grant, explicitly or implicitly, to any party any patent rights, licenses, or any other IP
rights, whether with regard to such information itself or anything described by such information. Information provided in this
document is proprietary to Microsemi, and Microsemi reserves the right to make any changes to the information in this
document or to any products and services at any time without notice.
About Microsemi
Microsemi, a wholly owned subsidiary of Microchip Technology Inc. (Nasdaq: MCHP), offers a comprehensive portfolio of
semiconductor and system solutions for aerospace & defense, communications, data center and industrial markets.
Products include high-performance and radiation-hardened analog mixed-signal integrated circuits, FPGAs, SoCs and
ASICs; power management products; timing and synchronization devices and precise time solutions, setting the world's
standard for time; voice processing devices; RF solutions; discrete components; enterprise storage and communication
solutions, security technologies and scalable anti-tamper products; Ethernet solutions; Power-over-Ethernet ICs and
midspans; as well as custom design capabilities and services. Learn more at www.microsemi.com.

Microsemi Proprietary and Confidential UG0862 User Guide Revision 1.0 i
Contents
1 Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Revision 1.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3 Hardware Implementation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4 Inputs and Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4.1 Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4.2 Configuration Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4.3 Testbench Simulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4.4 Timing Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.5 Resource Utilization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Microsemi Proprietary and Confidential UG0862 User Guide Revision 1.0 ii
Figures
Figure 1 HDMI TX IP Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Figure 2 Creating SmartDesign Testbench . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Figure 3 Naming SmartDesign Testbench . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Figure 4 HDMI TX in Libero SoC Catalog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Figure 5 Parameter Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Figure 6 Promote to Top Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Figure 7 Generate Component . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Figure 8 Simulating Testbench . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Figure 9 ModelSim Tool with HDMI TX Testbench File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Figure 10 HDMI TX IP Timing Diagram of Video Data for 1 Pixel Per Clock . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Figure 11 HDMI TX IP Timing Diagram of Control Data for 1 Pixel Per Clock . . . . . . . . . . . . . . . . . . . . . . . . . 8

Microsemi Proprietary and Confidential UG0862 User Guide Revision 1.0 iii
Tables
Table 1 Inputs and Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Table 2 Configuration Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Table 3 Testbench Configuration Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Table 4 Resource Utilization for 1 Pixel Per Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Table 5 Resource Utilization for 4 Pixels Per Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Revision History
Microsemi Proprietary and Confidential UG0862 User Guide Revision 1.0 1
1 Revision History
The revision history describes the changes that were implemented in the document. The changes are
listed by revision, starting with the most current publication.
1.1 Revision 1.0
This is the first publication of this document.

Introduction
Microsemi Proprietary and Confidential UG0862 User Guide Revision 1.0 2
2 Introduction
Microsemi’s High-Definition Multimedia Interface (HDMI) transmitter IP supports transmitting video data
described in the HDMI standard specification.
HDMI TX IP features are:
• Supports HDMI 2.0 and HDMI 1.4
• Supports 1, 2, and 4 pixels per clock input
• Supports 8-bits color depth
• Supports up to 4K resolutions of 4096x2160 at 60 Hz
• Supports Encoding Scheme - TMDS
HDMI is a high-speed, serial, digital signaling system that is designed to transmit large amounts of digital
data over a long cable length. To achieve these goals, HDMI utilizes Transition Minimized Differential
Signaling (TMDS), which is optimized for robust digital data transmission.
A TMDS link consists of a single clock channel and three data channels. The video pixel clock is
transmitted on the TMDS clock channel, which helps to keep the signals in synchronization. Video data is
carried as 24-bit pixels on the three TMDS data channels, where each data channel is designated for
red, green, and blue color component.
TMDS encoder allows transmitting serial data at a high speed, while minimizing potential for EMI
(Electro-Magnetic Interference) over copper cables by minimizing the number of transitions (reducing
interference between channels), achieves DC balance, on the wires, by keeping the number of ones and
zeros, on the line nearly equal.
HDMI TX IP is designed to be used along with PolarFire device transceivers. The IP is compatible with
HDMI 1.4 and HDMI 2.0 and supports up to 60 frames per second with a maximum bandwidth of
18 Gbps. The IP uses TMDS encoder that converts the 8 bits per channel into the 10-bit DC-balanced,
transition minimized sequence, which is then transmitted serially at a rate of 10 bits per pixel per channel
on the video data period. During the video blanking period, control tokens are transmitted that are
generated based on hsync and vsync signals.
The control tokens can have one of the four predefined values:
10'b1101010100, 10'b0010101011, 10'b0101010100, and 10'b1010101011. Control data characters are
designed to have a large number (7) of transitions to help the receiver synchronize its clock with the
transmitter clock.
The HDMI TX IP can process the data at 1, 2, or 4 pixels per clock. When the IP operates in 2 or 4 pixels
per clock, it also produces the output in the form of two or four encoded pixels per clock.

Hardware Implementation
Microsemi Proprietary and Confidential UG0862 User Guide Revision 1.0 3
3 Hardware Implementation
The following figure illustrates the HDMI TX IP in 1 pixel mode for PolarFire devices:
Figure 1 • HDMI TX IP Block Diagram
In the TMDS encoder, the first stage is an XOR/XNOR operation, which minimizes the number of
transitions, and the second stage is an INV/NONINV, which minimizes the disparity (DC balance). The
extra two bits are added at this stage of operation. Control data (hsync and vsync) is encoded to 10 bits
in 4 possible combinations to help the receiver synchronize its clock with the transmitter clock. A
Transceiver should be used along with the HDMI TX IP to serialize the 10 bits (1 pixel mode) or 40 bits (4
pixels mode).
SYS_CLK_I
RESET_N_I
DATA_VALID_I
H_SYNC_I
V_SYNC_I
DATA_R_I[7:0]
DATA_G_I[7:0]
DATA _B_I[7:0]
10'h1F
TMDS_R_O[9:0]
TMDS_G_O[9:0]
TMD S_ B_O[ 9:0]
TX_PLL
DISPLAY_CLK
LANE_ TX_CLK_R
LANE _C LK_TX D[ P,N]
LANE_R_TXD[P,N]
LANE_G_TXD[P,N]
LANE_B_TXD[P,N]
LANE _CLK_ TX_ DATA[9:0 ]
LANE_R_TX_DATA[9:0]
LANE _G_ TX_ DATA[9:0 ]
LANE_B_TX_DATA[9:0]
HDMITX
XCVR
LANE _CLK_CD R_REF_ CLK_F AB
LANE_R_CDR_REF_CLK_FAB
LANE_G_CDR_REF_CLK_FAB
LANE_B_CDR_REF_CLK_FAB

Inputs and Outputs
Microsemi Proprietary and Confidential UG0862 User Guide Revision 1.0 4
4 Inputs and Outputs
4.1 Ports
The following table describes the input and output ports of HDMI TX IP.
4.2 Configuration Parameters
The following table describes the configuration parameters in the HDMI TX IP.
4.3 Testbench Simulation
Testbench is provided to check the functionality of HDMI TX core. The following table describes the
parameters, that are configured according to application.
The following steps describe how to simulate the core using the testbench:
1. In the Design Flow window, expand Create Design.
2. Right-click Create SmartDesign testbench and click Run. See the following figure:
Table 1 • Inputs and Outputs
Signal Name Direction Width Description
SYS_CLK_I Input 1 bit System clock, usually the same clock as the display
controller
RESET_N_I Input 1 bit Asynchronous active low reset signal.
DATA_VALID_I Input 1 bit Data valid input
• 1 for video data
• 0 for control data
H_SYNC_I Input 1 bit Horizontal sync pulse
V_SYNC_I Input 1 bit Vertical sync pulse
DATA_R_I Input [g_PIXELS_PER_CLK * 8 - 1: 0] Input “R” data
DATA_G_I Input [g_PIXELS_PER_CLK * 8 - 1: 0] Input “G” data
DATA_B_I Input [g_PIXELS_PER_CLK * 8 - 1: 0] Input “B” data
TMDS_R_O Output [g_PIXELS_PER_CLK * 10 - 1: 0] Encoded “R” data
TMDS_G_O Output [g_PIXELS_PER_CLK * 10 - 1: 0] Encoded “G” data
TMDS_B_O Output [g_PIXELS_PER_CLK * 10 - 1: 0] Encoded “B” data
Table 2 • Configuration Parameters
Parameter Name Description
g_PIXELS_PER_CLK Number of pixels per clock input
if g_PIXELS_PER_CLK = 1, input data width = 8, output data width = 10
if g_PIXELS_PER_CLK = 2, input data width = 16, output data width = 20
if g_PIXELS_PER_CLK = 4, input data width = 32, output data width = 40
Table 3 • Testbench Configuration Parameter
Name Description
g_PIXELS_PER_CLK Number of pixels per clock input

Inputs and Outputs
Microsemi Proprietary and Confidential UG0862 User Guide Revision 1.0 5
Figure 2 • Creating SmartDesign Testbench
3. Enter a name for the SmartDesign testbench, and click OK.
Figure 3 • Naming SmartDesign Testbench
SmartDesign testbench is created, and a canvas appears to the right of the Design Flow pane.
4. In the Libero SoC Catalog (View > Windows > Catalog), expand Solutions-Video, and drag the
HDMI TX IP core onto the SmartDesign testbench canvas.
Figure 4 • HDMI TX in Libero SoC Catalog
5. Select required g_PIXELS_PER_CLK value in the configurator window as shown below.

Inputs and Outputs
Microsemi Proprietary and Confidential UG0862 User Guide Revision 1.0 6
Figure 5 • Parameter Configuration
6. Select all the ports. Right-click, and select Promote to Top Level, as shown in the following figure.
Figure 6 • Promote to Top Level
7. Click Generate Component from the SmartDesign toolbar, as shown in the following figure.
Figure 7 • Generate Component
8. On the Stimulus Hierarchy tab, right-click HDMI_TX_TB testbench file, and click Open
Interactively from Simulate Pre-Synth Design.

Inputs and Outputs
Microsemi Proprietary and Confidential UG0862 User Guide Revision 1.0 7
Figure 8 • Simulating Testbench
The ModelSim tool appears with the test bench file loaded on to it as shown in the following figure.
Figure 9 • ModelSim Tool with HDMI TX Testbench File
If the simulation is interrupted because of the runtime limit in the DO file, use the run -all command to
complete the simulation.

Inputs and Outputs
Microsemi Proprietary and Confidential UG0862 User Guide Revision 1.0 8
4.4 Timing Diagrams
The following timing diagram for HDMI TX IP shows video data and control data periods for 1 pixel per
clock.
Figure 10 • HDMI TX IP Timing Diagram of Video Data for 1 Pixel Per Clock
The following diagram shows the 4 combinations of control data.
Figure 11 • HDMI TX IP Timing Diagram of Control Data for 1 Pixel Per Clock
4.5 Resource Utilization
HDMI TX IP is implemented in PolarFire FPGA (MPF300T - 1FCG1152I Package). The following table
describes the resources utilized by the FPGA, when pixels per clock = 1.
The following table describes the resources utilized by the FPGA, when pixels per clock = 4.
Table 4 • Resource Utilization for 1 Pixel Per Clock
Resource Usage
DFFs 42
4LUTs 250
Table 5 • Resource Utilization for 4 Pixels Per Clock
Resource Usage
DFFs 168
4LUTs 1100
