MicroConnect USB3.1CMDPW User manual

USB 3.1 Type-C to
Mini DisplayPort Adapter
User Manual

USB 3.1 Type-C to Mini DisplayPort Adapter
Contents
1.0 INTRODUCTION ............................................. 1
2.0 FEATURES..................................................... 1
3.0 SPECIFICATIONS ........................................... 1
4.0 PACKAGE CONTENTS ...................................... 2
5.0 OPERATION................................................... 2
6.0 CONNECTION DIAGRAM .................................. 2

USB 3.1 Type-C to Mini DisplayPort Adapter
1
DEAR CUSTOMER
Thank you for purchasing this product. For optimum performance and
safety, please read these instructions carefully before connecting,
operating or using this product. Please keep this manual for future
reference.
1.0 INTRODUCTION
This product is a Type-C to Mini DisplayPort Adapter. It allows to
connect Type-C source or ThunderboltTM 3 source to Mini DisplayPort
display at max 3840x2160@60Hz resolution. It supports to work on
any Type-C host that supports DP1.2 Alt mode . When working on
Thunderbolt TM 3 host, this product transmits DP signal.
2.0 FEATURES
⚫Supports Type-C input and Mini DisplayPort output
⚫Supports DisplayPort 1.2 Alt mode
⚫Supports per lane data rates of 5.4Gbps (HBR2), 2.7Gbps (HBR)
and 1.62Gbps (RBR)
⚫Supports content protection of HDCP1.4 & HDCP 2.2
⚫Supports Mini DisplayPort resolution up to 3840x2160@60Hz
⚫USB bus power (no external power supply)
3.0 SPECIFICATIONS
Inputs/Output Connector
Input
Type-C Malex1
Output
Mini DisplayPort Femalex1
Resolutions
Resolutions
Up to 3840x2160@60Hz
Warranty
Limited Warranty
1 Year
Mechanical
Size(L-W-H)
Main Unit: 60x26.98x16mm
Environmental
Operating Temperature
0 ℃to +45℃
Operating Humidity
10% to 85 % RH (no condensation)
Storage Temperature
-10℃to +70℃
Storage Humidity
5% to 90 % RH (no condensation)
Power Requirement
Power Source
USB bus power
Accessories

USB 3.1 Type-C to Mini DisplayPort Adapter
2
User Manual
English Version
Notes:
This product is not a Thunderbolt 3 to Thunderbolt 2 adapter,it can
only transfer DP signal, not Thuderbolt signal, thus output port can
only be connected to mini displayport display, not Apple Thunderbolt
display.
4.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and
make sure the following items are contained in the shipping carton:
⚫Main unit x1
⚫User Manual x1
5.0 OPERATION
①Connect USB-C port of this product to host PC
②Connect Mini DisplayPort output of this product to HDTV with one
Mini DisplayPort M/M cable
6.0 CONNECTION DIAGRAM
