Microedge Instruments PRECISE -LOG User manual

User’s Manual
Microedge Instruments Inc.
407 –15216 North Bluff Road
White Rock, BC, Canada, V4B 0A7
Toll Free: 1.877.352.9158
www.microedgeinstruments.com
Multi-Channel Data Loggers
PRECISE-LOG
407 –15216 North Bluff Road
White Rock, BC
Canada V4B 0A7
Phone: [phone]
Toll Free: 1.877.352.9158
Fax: [phone]
Email: [e-mail]
Web: www.microedgeinstruments.com

PRECISE-LOG Data Loggers User’s Manual Page 1/57
A
Ab bo ou ut t t th hi is s M Ma an nu ua al l
This manual contains operational information for PRECISE-LOG Data Loggers. Please read this
manual before using the data loggers.
Limits of Liability and Disclaimer of Warranty:
The manual contained in this document is furnished for informational use only and is subject to
change without notice.
Microedge Instruments Inc. shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance, or use of this material.
Copyright and Trademarks
This manual contains proprietary information which is protected by copyright. All rights are
reserved. No part of this document may be photocopied, reproduced, or translated to another
language without prior written consent of Microedge Instruments Inc.
Microedge Instruments Inc., PRECISE-LOG, SiteView are the trademarks of Microedge
Instruments Inc.
All other trademarks and registered trademarks are the property of their respective owners.
Microedge Instruments Inc.
407 - 15216 North Bluff Road
White Rock, BC, Canada, V4B 0A7
Toll Free: 1.877.352.9158
Web-Site: www.microedgeinstruments.com
Email: [email protected]
Rev 1.0 March. 2016

PRECISE-LOG Data Loggers User’s Manual Page 2/57
C
Co on nd di it ti io on ns s o of f S Sa al le e a an nd d P Pr ro od du uc ct t W Wa ar rr ra an nt ty y
Microedge Instruments Inc. (MEI) and the Buyer agree to the following terms and conditions of Sale and
Purchase:
1. Limited Warranty.
MEI warrants its product(s) to be free from defects in materials and workmanship for a period of one year from the date of
registered purchase. Any unit which is found to be defective will, at the discretion of MEI, be repaired or replaced.
MEI will not be responsible for the repair or replacement of any unit damaged by user modification, negligence, abuse,
improper installation, or mishandling.
MEI reserves the right to alter any feature or specification at any time.
2. Limitation of Liability.
The product must NOT be used in applications where failure of the product could lead to physical harm or loss of human life.
Buyer is responsible to conduct their own tests to meet the safety regulation of their respective industry.
IN NO EVENT WILL MEI BE LIABLE TO ANY PARTY FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL,
CONSEQUENTIAL OR PUNITIVE DAMAGES FOR USE OF THE PRODUCT, INCLUDING, WITHOUT LIMITATION,
LOST PROFITS OR REVENUES, COSTS OF REPLACEMENT, BUSINESS INTERRUPTIONS, LOSS OF DATA OR
DAMAGES RESULTING FROM USE OF OR RELIANCE ON THE PRODUCT, EVEN IF MEI IS EXPRESSLY
ADVISED ABOUT THE POSSIBILITY OF SUCH DAMAGES.
3. Extended Warranty.
Extended 2-year warranty service is available to purchase on new products at time of order entry and up to ninety days
thereafter. The extended warranty protects you from unbudgeted service expenses and provide additional 2 years of protection
at a fraction of the price of a repair.
4. Return Policy.
Defective Product Return:
A Buyer may return a defective product to MEI for repair or replacement, at MEI option, in the event MEI determines that the
product is defective. The defective product must be returned to MEI within the warranty period. The Buyer shall be
responsible for all shipping costs. Repaired or replaced products are warranted for the balance of the original warranty period,
or at least 90 days.
Non-defective Product Return:
Products that are not defective may be returned to MEI within 30 days from the date of shipment. All non-defective product
returns are subject to a 20% restocking fee. If the product is unsatisfactory for the application for which it was purchased, MEI
shall, at its option, either refund the purchase price paid by the Buyer or replace the product with one that is satisfactory for the
application. The Buyer shall be responsible for all shipping costs and restocking fee determined by MEI.
Method of Return:
Prior to returning the product, completely fill out the RMA Application Form, send it to MEI or contact MEI directly for a
Return Material Authorization number. All products returned to MEI must be securely packaged in the original shipping
materials and reach MEI without damage and shipped in accordance with Applicable laws, rules, and regulations. The products
must contain all software and accessories that were shipped to the Buyer in connection with the product.
5. MEI reserves the right to alter any feature or specification at any time.
Notes to Buyer:
If you disagree with any of the above terms or conditions you should promptly return the unit to the
manufacturer or distributor within 30 days from date of purchase.

PRECISE-LOG Data Loggers User’s Manual Page 3/57
TABLE OF CONTENTS
ABOUT THIS MANUAL................................................................................................................ 1
LIMITS OF LIABILITY AND DISCLAIMER OF WARRANTY: ................................................................ 1
COPYRIGHT AND TRADEMARKS ...................................................................................................... 1
1. INTRODUCTION........................................................................................................................ 6
1.1 FEATURES OF THE LOGGER........................................................................................................ 6
1.2 APPROVALS............................................................................................................................... 6
1.3 CARE OF THE LOGGER ............................................................................................................... 7
1.4 IDENTITY OF THE LOGGER ......................................................................................................... 7
1.5 BATTERY................................................................................................................................... 7
1.6 RECALIBRATION........................................................................................................................ 8
1.7 SAFETY WARNING .................................................................................................................... 8
Maximum Input Voltage Range ................................................................................................. 8
Maximum Input Current Range................................................................................................. 8
External Power Supply .............................................................................................................. 8
Grounding.................................................................................................................................. 8
2. HARDWARE & MECHANICAL DIMENSION..................................................................... 9
Logger Diagram:....................................................................................................................... 9
USB Port Pin-out (Face-In)..................................................................................................... 10
Antenna:................................................................................................................................... 10
3. CHANNELS AND SENSOR CONNECTIONS...................................................................... 12
PL-V/PL-VW (WIFI ENABLED)–VOLTAGE INPUTS ................................................................... 12
Channel and Sensor Specifications: ........................................................................................ 12
PL-C/PL-CW (WIFI ENABLED)–CURRENT INPUTS..................................................................... 13
Channel and Sensor Specifications: ........................................................................................ 13
PL-T/PL-TW (WIFI ENABLED)–THERMOCOUPLE INPUTS .......................................................... 14
Channel and Sensor Specifications: ........................................................................................ 14
Measure Temperature:............................................................................................................. 15
PL-H/PL-HW (WIFI ENABLED)–THERMISTOR /RESISTOR INPUTS............................................ 15
Channel and Sensor Specifications: ........................................................................................ 16
Measure Resistance:................................................................................................................ 16
Measure Temperature:............................................................................................................. 16
4 BASIC FUNCTIONS.................................................................................................................. 19
BUILT-IN EQUATIONS ................................................................................................................... 19
MEASURING &LOGGING .............................................................................................................. 20
Start Time: ............................................................................................................................... 20
End Time:................................................................................................................................. 20
Sampling Interval: ................................................................................................................... 20
Logging Mode:......................................................................................................................... 20
DOWNLOADING DATA .................................................................................................................. 20

PRECISE-LOG Data Loggers User’s Manual Page 4/57
FIELD ACTIVATION ....................................................................................................................... 20
RESET DEVICE .............................................................................................................................. 22
STATUS LED................................................................................................................................. 22
5. SOFTWARE............................................................................................................................... 23
SYSTEM REQUIREMENTS............................................................................................................... 23
COMMUNICATIONS INTERFACES ................................................................................................... 23
INSTALL SITEVIEW AND USB DRIVER.......................................................................................... 24
CONNECT DATA LOGGER.............................................................................................................. 29
ACTIVATE SITEVIEW .................................................................................................................... 32
MAIN WINDOW FRAME................................................................................................................. 34
Communication Panel.............................................................................................................. 34
Menu Bar ................................................................................................................................. 34
Tool Bar................................................................................................................................... 34
Main Working Panel................................................................................................................ 35
Information Log Panel............................................................................................................. 35
VIEW LOGGER STATUS ................................................................................................................. 35
General .................................................................................................................................... 36
Alarm........................................................................................................................................ 36
CONFIGURE LOGGER..................................................................................................................... 38
Description: ............................................................................................................................. 39
Sampling Interval: ................................................................................................................... 39
On-Board LED......................................................................................................................... 40
When Memory Full .................................................................................................................. 40
Time to Start & Time to End.................................................................................................... 40
Total Time Span....................................................................................................................... 40
Enabled.................................................................................................................................... 40
Channel Range......................................................................................................................... 41
Description............................................................................................................................... 41
Equation................................................................................................................................... 41
Cali. Low & Cali. High............................................................................................................ 41
DOWNLOAD LOGGER .................................................................................................................... 43
Filename & Browse ................................................................................................................. 45
Start Time & End Time ............................................................................................................ 45
REAL-TIME DISPLAY .................................................................................................................... 46
List View Visible ...................................................................................................................... 48
Chart View Visible................................................................................................................... 48
Vertical View............................................................................................................................ 48
Horizontal View....................................................................................................................... 48
Time Span................................................................................................................................. 48
Dataset..................................................................................................................................... 49
Settings..................................................................................................................................... 49
CALIBRATE A CHANNEL................................................................................................................ 50
Understand Cali. Low & Cali. High........................................................................................ 50
Decide On-Line or Off-Line Calibration................................................................................. 51
COMMUNICATE WITH PRECISE-LOG WIRELESSLY .................................................................... 54

PRECISE-LOG Data Loggers User’s Manual Page 5/57
6. SPECIFICATIONS.................................................................................................................... 56
COMMON SPECIFICATIONS............................................................................................................ 56
LOGGING CAPACITY ..................................................................................................................... 57

PRECISE-LOG Data Loggers User’s Manual Page 6/57
1
1. . I In nt tr ro od du uc ct ti io on n
1.1 Features of the logger
Congratulations on purchasing the PRECISE-LOG series data loggers! These portable battery
powered data loggers allow recording information and saving measurements to a 8MB flash
memory for later retrieval.
The internal lithium battery provides up to 10 years of instantaneous logging operation when
sampling at interval of one minute in stand-alone mode.
PRECISE-LOG data logger can be manipulated by SiteView Windows software for data
downloading, logging management, and property configuration. It has USB interface for local
communications and a WIFI module for remote access (PL-[x]W Series).
PRECISE-LOG data logger features a wide sampling interval range from one second to 12
hours.
The 16-bit analog-to-digital converter makes the measurements more precise and accurate.
Rugged, splash resistant aluminum enclosure makes it excellent in the harshest industrial
environment.
WIFI enabled version allows remote data monitoring and downloading.
1.2 Approvals
All PRECISE-LOG Series data loggers are in conformity with the EN standard(s) listed below:
EN 61000-6-1:[2007]
EN61000-4-2:2009
EN61000-4-3:2006/A2:2010
EN61000-4-4:2012
EN61000-4-5:2006
EN61000-4-6:2014
EN61000-4-11:2004
EN 61000-6-3:[2007]
EN Standards for WIFI module:

PRECISE-LOG Data Loggers User’s Manual Page 7/57
EN62311:2008
EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
ETSI EN300 328 V1.8.1 (2012-06)
ETSI EN 301 489-1 V1.9.2 (2011-09)
ETSI EN 301 489-17 V2.2.1 (2012-09)
For WIFI enabled models:
Contains FCC ID:2ACZO-WIFI1232T
All PRECISE-LOG Series data loggers comply with Part15 of the FCC Rules. Operation is
subject to the following two conditions:
1. These devices may not cause harmful interference, and
2. These devices must accept any interference received, including interference that may cause
undesired operation.
1.3 Care of the logger
PRECISE-LOG data loggers are designed to work in humid atmospheres of up to 95% RH non-
condensing. They should be protected against immersion. The environment temperature should
be within –40 to +70°C (-40 to + 158°F).
1.4 Identity of the logger
Each logger has its own unique serial number, which can be found on the back of the enclosure.
The serial number is used to identify the logger and enable us to keep a record of its history like
calibrations and warranty. Please reference it in any correspondence with MEI.
1.5 Battery
The battery lasts in excess of 10 years when sampling at 1-minute intervals in stand-alone
mode. When the battery is nearing the end of its service life, the on-board status LED will glow
in amber each time the logger is sampling the data. The battery indicator on the status window
in SiteView software will also display warning of low battery level. The battery operates
approximately one or two weeks from the time the logger first indicates a low battery, but we
recommend that the battery be changed as soon as the warning is displayed. The battery is
factory replaceable only.

PRECISE-LOG Data Loggers User’s Manual Page 8/57
1.6 Recalibration
Any PRECISE-LOG data logger is supplied with all channels pre-calibrated and should not
require any further recalibration for a period of 12 months.
We recommend the logger be recalibrated every year. You may recalibrate the logger longer
than a year depending on your application standard.
You may return the logger to the supplier for recalibration service or recalibrate it on your own
via SiteView software.
SiteView software provides two-point calibration for the most of the loggers.
1.7 Safety Warning
Maximum Input Voltage Range
For logger model: PL-V, PL-VW (WIFI enabled):
The logger is designed to measure single common ground DC voltages in the range up to 20
VDC. Any voltages over this range may cause permanent damage to the device.
Maximum Input Current Range
For logger model: PL-C, PL-CW (WIFI enabled):
The logger is designed to measure single common ground DC current in the range up to 50
mA. Any current over this range may cause permanent damage to the device.
External Power Supply
When using external power supply (via PC’s USB port or thirty party +5 VDC power
supply) to power the logger please make sure that the external power supply has the same
common ground with the external input process signals.
When using other third party external power supplies, please make sure the voltage of the
external power supply is +5 VDC (+/- 5% ripple).
Grounding
The common ground of the PRECISE-LOG data logger is connected directly to the ground
of the input process signals and the ground of the external power supply (if applicable).

PRECISE-LOG Data Loggers User’s Manual Page 9/57
2
2. . H Ha ar rd dw wa ar re e & & M Me ec ch ha an ni ic ca al l D Di im me en ns si io on n
Logger Diagram:
For Model PL-V, PL-VW (WIFI enabled), PL-C, PL-CW (WIFI enabled), PL-T, PL-TW
(WIFI enabled), PL-H, PL-HW (WIFI enabled)

PRECISE-LOG Data Loggers User’s Manual Page 10/57
Dimension: 88 X 64.2 X 24 MM
3.46 X 2.53 X 0.95 Inches
USB Port Pin-out (Face-In)
15 432
Pin1: External Power Supply (+5 VDC)
Pin2: Logger Communications Receiver Line (RX)
Pin3: Logger Communications Transmitter Line (TX)
Pin4: Common Ground (COM , GND)
Antenna:

PRECISE-LOG Data Loggers User’s Manual Page 11/57

PRECISE-LOG Data Loggers User’s Manual Page 12/57
3
3. . C Ch ha an nn ne el ls s a an nd d S Se en ns so or r c co on nn ne ec ct ti io on ns s
All “COM” terminals are connected together and should be connected to the common ground of
the process signals.
PL-V/PL-VW (WIFI enabled) –Voltage Inputs
A PL-V or PL-VW (WIFI enabled) logger has eight external voltage DC channels used to
measure single-ended voltage DC signals maximum of 20 volt. The following figure illustrates
the correct input connections:
Voltage External Input Connections
Note: All inputs must share the same common ground.
Channel and Sensor Specifications:
Connections:
Pluggable terminal block for eight external channels
Channels:
CH1 to CH8: Eight external Voltage DC with software
programmable input range selections for each channel:
0 to 20 V, 0 to 5 V
Resolution:
0.0018%
Accuracy:
+/- 0.05% FSR @ 25°C

PRECISE-LOG Data Loggers User’s Manual Page 13/57
Input Impedance:
> 1 Mohms
Over-voltage protection:
+/- 40 VDC
PL-C/PL-CW (WIFI enabled) –Current Inputs
A PL-C or PL-CW (WIFI enabled) logger has eight external current DC channels used to
measure single-ended current DC signals maximum of 50 mA. The following figure illustrates
the correct input connections:
Current External Input Connections
Note: All inputs must share the same common ground.
Channel and Sensor Specifications:
Connections:
Pluggable terminal block for eight external channels
Channels:
CH1 to CH8: Eight external current DC with software
programmable input range selections for each channel:
4-20 mA, 50 mA
ADC Resolution:
0.0018%
Accuracy:
+/- 0.1% FSR @ 25°C
Load Resistance:
12 Ohm
Over-current Protection
+/- 100 mA

PRECISE-LOG Data Loggers User’s Manual Page 14/57
PL-T/PL-TW (WIFI enabled) –Thermocouple Inputs
Besides the on-board thermistor channel, PL-T/PL-TW (WIFI enabled) logger has eight
external voltage DC channels used to measure thermocouple probes or small voltage signals.
The following figure illustrates the correct input connections:
Thermocouple Input Connections
Note: All inputs must share the same common ground.
Channel and Sensor Specifications:
Connections:
Plugeable terminal block for eight external channels
Channels:
CH0: on-board thermistor (-40 ~ +70°C) (-40 to + 158°F).
CH1 to CH8: Eight external Voltage DC with software
programmable input range selections for each channel:
Range1: -8 to +73 mV
Range3: -2 to +18 mV
Resolution:
0.0018%
Accuracy:
Thermistor channel: +/- 0.2°C(0°C ~ 70°C)
Voltage channels:
Range:(-8 to +73 mV:
+/- 0.1% (0.08 mV) @ 25°C + T/C Accuracy
Range -2 to +18 mV:
+/- 0.15% (0.03 mV) @ 25°C + T/C Accuracy
Over-voltage protection:
+/- 20 VDC

PRECISE-LOG Data Loggers User’s Manual Page 15/57
Measure Temperature:
Based on the thermocouple type you want to use and the desired temperature range you want
to measure you can select one of four channel’s available ranges and the correct factory
thermocouple equation:
For detailed temperature range and voltage –temperature look-up table of a specific
thermocouple type please refer to NIST’s website at:
http://srdata.nist.gov/its90/download/download.html
PL-H/PL-HW (WIFI enabled) –Thermistor / Resistor Inputs
PL-H/PL-HW (WIFI enabled) logger has eight external channels used to measure the external
thermistors or resistors. The following figure illustrates the correct input connections:
Thermistor External Input Connections

PRECISE-LOG Data Loggers User’s Manual Page 16/57
Note: All inputs must share the same common ground.
Channel and Sensor Specifications:
Connections:
Plugeable terminal block for eight external channels
Channels:
CH1 to CH8: Eight external thermistor
Resolution:
0.0018%
Accuracy:
Thermistor channel: +/- 0.2°C(0°C ~ 70°C)
External channels:
+/- 0.2% FSR @ 25°C
Measure Resistance:
SiteView provides factory resistance equation for measuring the resistor’s value. In
Configuration dialog:
Choose Resistance equation:
Measure Temperature:
The simple way to measure temperature is by using built-in “Temperature” equation. You
select “Temperature” in “Equation” column:
Then you need to change temperature coefficient values by clicking “Change Coefficients”
button in “Action” column:

PRECISE-LOG Data Loggers User’s Manual Page 17/57
In the pop-up dialog enter new temperature coefficient values and click “OK” button.

PRECISE-LOG Data Loggers User’s Manual Page 18/57
You can also use a custom equation to do the same job or even more complicated
calculation. An example of external thermistor equation is included in SiteView package.
When you create your own equation you can refer to this equation and replace those
temperature coefficients with the ones obtained from the thermistor manufacturer. The
contents of the sample equation looks like this:
Once you have created your equation (for example YSI2252(YSI thermistor 44004)), you can
apply it to the channel:

PRECISE-LOG Data Loggers User’s Manual Page 19/57
4
4 B Ba as si ic c F Fu un nc ct ti io on ns s
Built-In Equations
Equation and Channel Type are two essential parameters to make sure the physical
measurement can be converted correctly.
An equation is a software functionality identified by its name of up to 16 characters. A built-in
equation is an equation provided by SiteView software to convert a measurement for a specific
channel type.
A channel must have an equation assigned to it in order to make the measurement conversion.
“Digit” built-in equation can be assigned to any channel type. If you assign “Digit” equation to
a channel the physical measurement will be the original digital value measured by ADC
(Analog-to-digital converter) hardware.
The following table lists all available built-in equations for all channel types:
Channel Type
Equation Name
Equation Description
Internal-Thermistor
Temperature
Temperature
External-Thermistor
Temperature
Temperature
0-5 VDC
VoltageDC
Voltage DC
0-20 VDC
VoltageDC
Voltage DC
4-20 mA DC
CurrentDC
Current DC
0-50 mA DC
CurrentDC
Current DC
Thermocouple
Range:
-8 to +73 mV
ThermocoupleE
ThermocoupleJ
ThermocoupleK
ThermocoupleN
ThermocoupleT
VoltageDC
Thermocouple E
Thermocouple J
Thermocouple K
Thermocouple N
Thermocouple T
Voltage DC
Thermocouple
Range:
-2 to +18 mV
ThermocoupleB
ThermocoupleE
ThermocoupleJ
ThermocoupleK
ThermocoupleN
ThermocoupleR
ThermocoupleS
ThermocoupleT
VoltageDC
Thermocouple B
Thermocouple E
Thermocouple J
Thermocouple K
Thermocouple N
Thermocouple R
Thermocouple S
Thermocouple T
Voltage DC
X
InternalBattery
Measure the internal battery
voltage level
X
ExternalPower
Measure the external power
supply
