MicroImage Video Systems PXD510E User manual

Page 12
WARRANTY
MicroImage Video Systems warrants that each PXD510ET1 is free from
defects due to faulty materials or im ro er workmanshi for a eriod of
one (1) year. MicroImage Video Systems further warrants that any art
which roves defective in materials or workmanshi within one (1) year,
will be re laced or re aired at no cost to the user. Labor to re lace
defective arts will be done without charge, rovided the equi ment is
returned to MicroImage Video Systems re aid, insured and ro erly
ackaged. Prior return authorization must be obtained from MicroImage
Video Systems.
NOTE
This warranty covers the MicroImage PXD510ET1 only.
CONDITIONS
This warranty is void if the warranted art has been altered or subjected
to abuse or misuse. Defective arts must be returned to MicroImage
Video Systems.
SOLE WARRANTY
This Warranty is in lieu of all other warranties ex ressed or im lied
including, without limitation, any im lied warranty or any im lied
warranty of fitness for a articular ur ose. MicroImage Video Systems
shall have the final right to determination as to the existence and cause of
any defect and its a ro riate adjustment in accordance with the terms of
this warranty. In no event shall MicroImage Video Systems be liable for
any consequential or collateral damages.
RETURNS
All returns MUST have an RMA number. Please call, fax or email
for an RMA form. The RMA form will have the ro er shi ing
address for returns.
Phone [phone]
Fax [phone]
Email techsu [e-mail]
PIX/2 DSP
Operation Manual
Model PXD510E
Advanced DSP Video
Fade Controller
MicroImage Video S stems
division of World Video Sales Co., Inc
PO Box 331
Boyertown, PA 19512
Phone [phone]
Fax [phone]
[e-mail]
www.mivs.com

Page 2
CONTENTS
DESCRIPTION...........................................................................................3
UNPACKING..............................................................................................3
INITIAL SETUP..........................................................................................4
SIGNAL STANDARD SELECTION.............................................................4
INPUT SIGNAL SELECTION......................................................................5
CAMERA CENTER SPLIT MODE ..............................................................5
CONNECTIONS.........................................................................................6
Power.....................................................................................................6
Inputs.....................................................................................................6
Outputs..................................................................................................6
OPERATION..............................................................................................6
Power.....................................................................................................6
Cam A....................................................................................................6
Cam B....................................................................................................7
H Split....................................................................................................7
V Split ....................................................................................................7
Fade ......................................................................................................7
Difference...............................................................................................7
Freeze....................................................................................................7
Exchange...............................................................................................8
Mix.........................................................................................................8
SEPERTAOR.............................................................................................8
Width......................................................................................................8
Color......................................................................................................8
Save ......................................................................................................9
COLOR BARS............................................................................................9
IN CASE OF DIFFICULTY..........................................................................9
SPECIFICATIONS....................................................................................10
WARRANTY.............................................................................................12
RETURNS................................................................................................12
Rev 0 08-10-2007, Reviewed 07-07-2015
Page 11
Power Module
Ty e Switching ower su ly, UL, CUL/CSA, CE, TUV a roved
Out ut 12 VDC, 1000-2000mA, Regulated (no minimum load)
Voltage In 100 - 240 VAC, 47 - 63 Hz
In ut Cable Standard IEC-320 3 wire in ut connector, standard 6ft. Power
cord for USA use included.
Out ut Cable 6ft. 2 wire, 2.1mm female coaxial barrel connector
Consum tion 0.4A max
Size Contact MicroImage Video Systems for current data
Weight Contact MicroImage Video Systems for current data
The PXD510 series is manufactured in the USA by MicroImage Video Systems.

Page 10
SPECIFICATIONS
In ut levels
Com osite/B&W 1V com osite 75 Ω
S-Video Y (Luminance) 1V 75 Ω,
C (Chroma) 286mV Burst 75 Ω
Out ut levels
Com osite Video 1V into 75 Ω
S-Video (Y, C) 1V Y, 286mV C (burst) into 75 Ω
Connectors
Com osite BNC female
S-Video 4 in mini-DIN female
Power 2.1mm female coaxial ower jack
RS232 Remote 3.5mm female mini hone jack
RS232 Interface 9600 baud, 8 data bits, no arity, 1 sto bit.
S lit Range
Horizontal 0 to 53.3uS from start of active video, 256 ste s
greater than 98% of screen width ty ical
Vertical NTSC/RS-170 - 0 to 485 lines, fully variable 100% screen height
ty ical;
PAL/CCIR - 0 to 586 lines, fully variable in, 100% screen height
ty ical
Fade Range A:B ratio: 100%/0% to 0%/100%, 256 ste s
Difference Range A:B ratio: 100%/-0% to 0%/-100%, 256 ste s
Memory 10 megabits/channel (full frame X1 each in ut)
Timebase Correction Digital memory, frame aligned
Decoding 9 bit multi-standard digital decoding
Processing 8 bit, 4:2:2, ITU-R601 and ITU-R656 standards
Encoding Digital Modulation
Oversam ling 2x (27MHz) out ut over-sam ling
Out ut DACs 10 bit Digital to Analog converters
In ut Filters Analog anti-aliasing filters
Out ut Filters Digital lus 4
th
order analog anti-aliasing filters
Horizontal Freq.
RS-170/NTSC 15.734KHz ty ical
CCIR/PAL 15.625KHz ty ical
Vertical Frequency
RS-170/NTSC 59.94Hz ty ical
CCIR/PAL 50Hz ty ical
Bandwidth 6 Mhz ty ical
Crosstalk Greater than 48dB
Gain Match A to B Ty ically within 2%
Tem erature
O erating 0E - 40E C (32E - 104E F)
Storage -40E - 60E C (-40E - 140E F)
Humidity
O erating 10% - 90% (non-condensing)
Storage 5% - 95% (non-condensing)
Power
Voltage +10 to +20VDC (+12VDC ty ical), neg ground
Consum tion 150mA ty ical (1.8W)
Protection Automatic electronic fuse, internal, self resetting
Size 7.25" W x 5.50" D x 1.60" H (193 x 140 x 40 mm)
Weight 18.5 oz. (525g)
Page 3
DESCRIPTION
The MicroImage PIX/2 DSP family of controllers is designed to
combine the images from two video cameras into one image. The
images can be s lit on the screen showing a ortion of each
image, or the two images may be mixed or faded together as an
overlay.
The images can be s lit in either the horizontal or vertical
direction. The A camera is normally dis layed on the left or to
and the B camera on the right or bottom. These ositions may be
interchanged at the touch of a button. The s lit osition can
ty ically be adjusted over 100% of the screen area with the front
anel rotary control.
The Fade and Difference modes allow the two images to be added
together or subtracted. The mix can be adjusted over the entire
range from a full camera A image to a full camera B image.
The PIX/2 DSP family consists of several roducts to work with a
variety of cameras or other video sources, either Black & White or
Color. Each unit rovides the ro er signals and connectors to
work correctly with the intended video standard(s).
Board Level and OEM PIX/2 DSP roducts are also available.
Please contact your dealer or MicroImage Video Systems for
additional information.
UNPACKING
The PIX/2 DSP ackage includes the following items:
PXD510E PIX/2 DSP control unit
+12 VDC Regulated Universal Power Module
This o eration manual
Please ins ect all items carefully and re ort damaged or missing
items to your dealer or MicroImage Video Systems immediately.

Page 4
INITIAL SETUP
Before the unit can be used, it must be set u for the ro er video
standard and in ut signal selections. These two functions (and the
center s lit mode enable) are set with four DIP switches located
on the rear of the unit. Each switch is numbered and OFF is in the
UP osition while ON is in the DOWN osition. The following
sections describe how to set these switches ro erly.
SIGNAL STANDARD SELECTION
The PIX/2 DSP roducts MUST be set to the ro er video standard
to work correctly. The choices are NTSC (RS170/60Hz) or PAL
(CCIR/50Hz). NTSC is the common video standard for North
America while PAL is common in Euro e and other arts of the
world. The factory default setting is NTSC (DIP switch number 1
off).
To set the unit for PAL o eration, lace the DIP switch in the
LOWER (ON) osition. The RAISED (OFF) osition is for NTSC
standard.
The unit must be set to the same standard as the video sources
(cameras, VCRs, etc) and the monitor.
Page 9
Save After setting the desired se arator width and color,
ressing the FADE button will save the changes and
return the unit to normal o eration. The selected width
and color choices will affect both the vertical and the
horizontal s lit modes. The unit will remember these
settings if ower is removed.
COLOR BARS
The PIX2 DSP can roduce color bars for use as a test signal. To
activate the internal color bar generator, the unit should first be
switched off. De ress and continue to hold in the FREEZE switch
while turning the unit on again. The 3 LEDs just to the left of the
MIX control should blink when the unit is roducing color bars.
You may then release the FREEZE switch. To deactivate the color
bars, either ress the EXCHANGE switch or turn the unit off. The
unit will return to normal o eration when it is turned on again.
Color bars may also be enabled with the o tional RS-232 remote
control.
IN CASE OF DIFFICULTY
If you are ex eriencing roblems with any MicroImage roduct,
you can contact MicroImage Su ort using the following methods:
Phone [phone]
Fax [phone]
Email techsu [e-mail]
Web www.mivs.com

Page 8
Exchange Pressing this key will exchange the A and B in uts
when the unit is in s lit screen mode. This will cause
the image from camera A to a ear on the right or
bottom, rather than the to or left as normal. A
Green indicator to the right of the switch will
indicate this mode is selected.
Mix The MIX rotary control is used to adjust the osition
of the s lit or the ratio of the fade. This control has
no effect when the Cam A or Cam B switches are
ressed.
Note that the MIX control does not have any effect if the unit is
set to H split or V Split and the Centered Camera Split Mode is
enabled via DIP Switch number .
SEPERTAOR
The two images on either side of a s lit may be se arated by a
border stri e, or may be laced directly adjacent for easier
com arison. This se arator may be activated or changed from a
Setu Mode. To enter Setu Mode, the unit should first be
switched off. De ress and continue to hold in the EXCHANGE
switch while turning the unit on again. The first 5 LEDs should
blink while the unit is in this setu mode. You may then release
the EXCHANGE switch.
Width The width of the se arator may be selected by ressing
the L/R switch or the T/B switch while in setu mode, to
cycle u or down through the 3 available widths or off.
The factory default setting is with the se arator off.
Color The color of the se arator may be selected by ressing
either the CAM A or the CAM B switch while in setu
mode, to cycle u or down through the list of 8 colors.
These colors are Black, Blue, Red, Magenta, Green,
Cyan, Yellow, and Gray. The border must be enabled to
see the color.
Page 5
INPUT SIGNAL SELECTION
Setting the PIX/2 DSP to acce t the ro er in ut signal is
im ortant for ro er o eration. A set of DIP switches on the rear
anel is used to select either a com osite video signal or an S-
Video signal for each in ut.
Switch 4 should be in the RAISED osition (OFF) for either a B&W
or color com osite signal (BNC connector) on In ut A. This switch
should be set to the LOWER (ON) osition for an S-Video signal on
the In ut A mini-DIN connector.
Switch 3 should be in the RAISED osition (OFF) for either a B&W
or color com osite signal (BNC connector) on In ut B. This switch
should be set to the LOWER (ON) osition for an S-Video signal on
the In ut B mini-DIN connector.
CAMERA CENTER SPLIT MODE
When this mode is enabled via DIP Switch 2, the unit will show the
center 50% of each camera image side by side or to /bottom
when the s lit modes are enabled. This allows the same ortion of
each image to be evaluated. The normal s lit modes show a
ortion of the left/to of one image and the right/bottom of the
other image.
When in the Centered Camera S lit Modes, the MIX control does
not have any effect, the s lit osition is always set to 50% of each
camera image.
To use Center Camera S lit Mode, lace DIP Switch number 2 on
the rear anel to the LOWER (ON) osition. To return to the
standard s lit modes, lace DIP Switch number 2 in the RAISED
(OFF) osition.

Page 6
CONNECTIONS
Power
Plug the small connector on the end of the ower module cord into
the ower in ut connector on the PIX/2 DSP controller. Plug the
ower module into an a ro riate ower rece tacle.\
Inputs
Connect the video out ut from camera A to the Cam A in ut on
the PIX/2 DSP controller with either a BNC or an S-Video cable.
See >In ut Signal Selection=.
Connect the video out ut from camera B to the Cam B in ut on
the PIX/2 DSP controller with either a BNC or an S-Video cable.
Outputs
Connect a video cable from the PIX/2 DSP to the video monitor or
other dis lay or recording devices using either the com osite
video out ut BNC connector, the S-Video out ut mini-DIN
connector, or both.
OPERATION
Once connected ro erly, the PIX/2 DSP is easy to use. Following
is a descri tion of each switch and control. When first testing the
PIX/2 DSP, lace the MIX control near the center of its range.
Power Pressing the ower switch will turn the ower on or
off. The green indicator next to the ower switch will
light to indicate ower is on.
Cam A Pressing the Cam A switch will change the dis lay to
show 100% of the camera A image. A Red indicator
to the right of the switch will indicate this mode is
selected.
Page 7
Cam B Pressing the Cam B switch will change the dis lay to
show 100% of the camera B image. A Red indicator
to the right of the switch will indicate this mode is
selected.
H Split Pressing this key will cause the screen to be s lit,
adjusted by the MIX control. Camera A will normally
be dis layed on the left side and camera B on the
right side. A Green indicator to the right of the
switch will indicate this mode is selected. Note that
the MIX control does not have any effect if the
Centered Camera S lit Mode is enabled via DIP
Switch number 2.
V Split Pressing this key will cause the screen to be s lit,
adjusted by the MIX control. Camera A will normally
be dis layed on the to and camera B on the
bottom. A Green indicator to the right of the switch
will indicate this mode is selected. Note that the MIX
control does not have any effect if the Centered
Camera S lit Mode is enabled via DIP Switch
number 2.
Fade Pressing this key will cause the camera images to be
added together. The MIX control will adjust the
amount of each image to be mixed, and can fade
com letely from camera A to camera B images. A
Yellow indicator to the right of the switch will
indicate this mode is selected.
Difference Pressing this key will cause the image from camera
B to be subtracted from Camera A. The MIX control
will allow the images from A and B to be canceled,
highlighting any differences. A Red indicator to the
right of the switch will indicate this mode is
selected.
Freeze Pressing this key will freeze the image from camera
B until the button is ressed again or ower is
removed. A Blue indicator to the right of the switch
will indicate this mode is selected.
