MicroImage Video Systems ENC400B User manual

Page 4
WARRANTY
MicroImage Video Systems warrants that each ENC400B is free from
defects due to faulty materials or improper workmanship for a period of
one 1) year. MicroImage Video Systems further warrants that any part
which proves defective in materials or workmanship within one 1) year,
will be replaced or repaired at no cost to the user. Labor to replace
defective parts will be done without charge, provided the equipment is
returned to MicroImage Video Systems prepaid, insured and properly
packaged. Prior return authorization must be obtained from MicroImage
Video Systems.
NOTE
This warranty covers the MicroImage ENC400B only.
CONDITIONS
This warranty is void if the warranted part has been altered or subjected
to abuse or misuse. Defective parts must be returned to MicroImage
Video Systems.
SOLE WARRANTY
This Warranty is in lieu of all other warranties expressed or implied
including, without limitation, any implied warranty or any implied
warranty of fitness for a particular purpose. MicroImage Video Systems
shall have the final right to determination as to the existence and cause of
any defect and its appropriate adjustment in accordance with the terms of
this warranty. In no event shall MicroImage Video Systems be liable for
any consequential or collateral damages.
RETURNS
All returns MUST have an RMA number. Please call, fax or email for an
RMA form. The RMA form will have the proper shipping address for
returns.
Phone [phone]
Fax [phone]
Email [e-mail]
Video Encoder
Operation Manual
RGB to NTSC and S-Video Encoder
Model ENC400B
MicroImage Video Sys ems
division of World Video Sales Co., Inc
PO Box 331
Boyertown, PA 19512
Phone [phone]
Fax [phone]
[e-mail]
www.mivs.com

Page 2
CONTENTS
SPECIFICATIONS............................................................................2
UNPACKING ....................................................................................3
CONNECTIONS...............................................................................3
Power ...........................................................................................3
Video Connections........................................................................3
IN CASE OF DIFFICULTY................................................................3
WARRANTY.....................................................................................4
RETURNS........................................................................................4
Rev 2 02-16-2001, Reviewed 07-06-2015
SPECIFICATIONS
Input level (RGB) 1.0 Vpp Composite, 75 Ωterminated
(S) 5.0 Vpp max 75 Ωterminated
Output level (Y & Video) 1 Vpp typical into 75 ohm
(C) 0.28 Vpp burst typical into 75 ohm
Connectors (R, G, B, S, Video) BNC female
(S-Video) 4 pin mini DIN F
Resolution Greater than 400 lines
Modulation R-Y, B-Y Axes
Genlock Combination Analog & Digital Synthesis
Sync Internal (sync on green) or External (default)
Video System NTSC, RS170
H & V Frequency 15.734 Khz (H), 59.95 Hz (V)
Chroma Frequency 3.579545 Mhz
Temperature Operating: 0E-40EC (32E-104EF)
Storage: -40E-60EC (-40E-140EF)
Humidity Operating 10% -90%, Storage 5% -95% (non-condensing)
Power 11-20 VDC (+12 VDC typical)
120V power adapter included
Size 5.6" (w) x 4.1" (D) x 1.6" (H)
142 mm (w) x 104 mm (D) x 40 mm (H)
Weight 12 oz. (340 g)
Manufactured in USA by MicroImage Video Systems
Page 3
UNPACKING
The ENC400B package includes the following items:
ENC400B Video Encoder
12V wall plug transformer -
DPD120050 or optional universal power
supply DTS120150
This operation manual
Please inspect all items carefully and report damaged or missing
items to your dealer or MicroImage Video Systems.
CONNECTIONS
Power
The ENC400B uses a 12 VDC wall plug transformer which is included
with the unit. Connect to a source of 120VAC, 60Hz. The ENC400B
has a soft touch power switch and will remember the switch setting
when power is removed.
Video Connec ions
Connect the video source i.e. camera) to the RGBS IN connectors on
the ENC400B unit. Connect the OUTPUT signals Video or S-Video)
from the ENC400B unit to the video displays as required.
The ENC400B is set from the factory to work with external sync. An
internal jumper can be changed to select internal sync on green).
The RGB signal source mus meet NTSC RS-170 A) specifications H
& V frequency) for this product to work properly.
IN CASE OF DIFFICULTY
If you are experiencing problems with any MicroImage product, you
can contact MicroImage Support using the following methods:
Phone [phone]
Fax [phone]
Email [e-mail]
Web www.mivs.com
