Guarantee Card WatchBP Home
Name of Purchaser / Ф.И.О. покупателя / П.I.П. покупця / Inkö-
parens namn / Ostajan nimi / Forhandlers navn / Kjøpers navn
Serial Number / Серийный номер / Серiйний номер / Serie-
nummer / Sarjanumero / Serienummer / Serienummer
Date of Purchase / Дата покупки / Дата покупки / Inköpsdatum /
Ostopäivämäärä / Købsdato / Kjøpsdato
Specialist Dealer / Специализированный дилер /
Спецiaлiзований дилер / Återförsäljare / Alan kauppias /
Specialforhandler / Spesialist forhandler

1WatchBP Home EN
Display
Read the instructions carefully before using this device.
Microlife WatchBP Home EN
1ON/OFF Button
2Display
3M-Button (Memory)
4Cuff Socket
5Mains Adapter Socket
6USB Port
7Battery Compartment
8Cuff
9Cuff Connector
AT Mode Switch
AK Systolic Value
AL Diastolic Value
AM Pulse
AN Pulse Rate
AO Battery Display
AP Stored Value
AQ Morning Data
AR Evening Data
AS Date/Time
BT Mode Indication
BK Doctor Symbol
BL Out of Measurement Time
BM Relax
BN Number of stored Data
BO Delete Memory Data

2
Dear Customer,
The Microlife WatchBP Home is designed to provide reliable and
unbiased patients’ home readings, strictly following the European
Society of Hypertension (ESH) recommendations 1, 2. The accuracy of
the monitor has been clinically validated according to the ESH
protocol 3. Self-blood pressure monitoring by patients at home has
been endorsed by hypertension societies as an important adjunct to
the conventional office blood pressure measurements.
The doctor asks patient to take home readings for seven consecutive
working days in the «DIAG.» mode. In this mode, the device allows
for only two BP measurements to be taken in the morning (6-9 am)
and another two in the evening (6-9 pm). After completing seven
days, the device displays a symbol suggesting that the patient has to
consult his/her doctor. Pressing the memory button on the device
displays the average of all measurements after discarding those of
the first day.
In the «USUAL» mode, casual blood pressure readings can be taken
at any time of the day; up to 250 measurements can be stored.
The device has computer link capacity to display, store or print
through a computer all BP data.
Please read through these instructions carefully so that you under-
stand all functions and safety information. We want you to be happy
with your Microlife product. If you have any questions, problems or
want to order spare parts, please contact Microlife-Customer
Service. Your dealer or pharmacy will be able to give you the address
of the Microlife dealer in your country. Alternatively, visit the Internet
at www.microlife.com where you will find a wealth of invaluable
information on our products.
Stay healthy – Microlife AG!
1European Society of Hypertension recommendations for conven-
tional, ambulatory and home blood pressure measurement.
O’Brien E, Asmar R, Beilin L, Imai Y, Mallion JM, Mancia G, Mengden T, Myers M, Padfield
P, Palatini P, Parati G, Pickering T, Redon J, Staessen J, Stergiou G, Verdecchia P, on behalf
of the European Society of Hypertension Working Group on Blood Pressure Monitoring
2A tool for reliable self-home blood pressure monitoring designed
according to the European Society of Hypertension recommenda-
tions: The Microlife WatchBP Home monitor.
Stergiou G, Jaenecke B, Giovas P, Chang A, Chung-Yueh Y, Tan T, Blood Pressure Monitoring
2007, 12:127–131
3Validation of the Microlife WatchBP home device for self-home
blood pressure measurement according to the International Protocol.
Stergiou G, Giovas P, Gkinos C, Patouras J, Blood Pressure Monitoring 2007, 12:185–188

3WatchBP Home EN
Table of Contents
1. Important Facts about Blood Pressure and Self-Measurement
•How do I evaluate my blood pressure?
2. Using the Instrument for the First Time
•Activate the fitted batteries
•Setting the date and time
•Select the correct cuff
3. Selecting «DIAG.» or «USUAL» Mode
•«DIAG.» Mode
•When and how to measure?
•Evaluation
•«USUAL» Mode
4. Taking a Blood Pressure Measurement using this Instrument
•«DIAG.» Mode
•«USUAL» Mode
5. Data Memory and Evaluation
•Viewing the stored values
•«DIAG.» Mode
•«USUAL» Mode
•Clear all values
6. Data Transfer to the Computer
•Installation of the software program
•How to transfer data to the computer?
7. Battery Indicator and Battery change
•Batteries almost flat
•Batteries flat – replacement
•Which batteries and which procedure?
8. Using a Mains Adapter
9. Error Messages
10. Safety, Care, Accuracy Test and Disposal
•Safety and protection
•Instrument care
•Cleaning the cuff
•Accuracy test
•Disposal
11. Guarantee
12. Technical Specifications
Guarantee Card (see Back Cover)

4
1. Important Facts about Blood Pressure and Self-
Measurement
•Blood pressure is the pressure of the blood flowing in the arteries
generated by the pumping of the heart. Two values, the systolic
(upper) value and the diastolic (lower) value, are always measured.
•The instrument also indicates the pulse rate (the number of times
the heart beats in a minute).
•Permanently high blood pressure values can damage your
health and must be treated by your doctor!
•Always discuss your values with your doctor and tell him/her if you
have noticed anything unusual or feel unsure. Never rely on
single blood pressure readings.
•There are many causes of excessively high blood pressure
values. Your doctor will explain them in more detail and offer
treatment where appropriate. Besides medication, weight loss
and exercise can also lower your blood pressure.
•Under no circumstances should you alter the dosages of
any drugs prescribed by your doctor!
•Depending on emotions, physical exertion and condition, blood
pressure is subject to wide fluctuations as the day progresses.
You should therefore take your measurements in the same
quiet conditions and when you feel relaxed!
•It is quite normal for two measurements taken in quick succession
to produce significantly different results.
•Deviations between measurements taken by your doctor or in the
pharmacy and those taken at home are quite normal, as these situ-
ations are completely different.
•Several measurements provide a much clearer picture than just
one single measurement.
•Leave a small break of at least 30 - 60 seconds between 2
measurements.
•If you are pregnant, you should monitor your blood pressure very
closely as it can change drastically during this time!
•If you suffer from an irregular heartbeat, measurements taken
with this instrument should only be evaluated after consultation
with your doctor.
•The pulse display is not suitable for checking the
frequency of heart pacemakers!

5WatchBP Home EN
How do I evaluate my blood pressure?
The higher value is the one that determines the evaluation. Example:
a readout value between 150/85 or 120/98 mmHg indicates «Grade 1
Hypertension».
2. Using the Instrument for the First Time
Activate the fitted batteries
Pull out the protective strip projecting from the battery compartment 7.
Setting the date and time
Select the correct cuff
Microlife offers 3 different cuff sizes: S, M andL. Select the cuff size to
match the circumference of your upper arm (measured by close fitting
in the centre of the upper arm). M is the correct size for most people.
Table for classifying blood pressure values in adults in accordance to
the guidelines of the European Society of Hypertension (ESH) in 2003.
Data in mmHg.
Category Systolic Diastolic
Optimal < 120 < 80
Normal 120 - 129 80 - 84
High normal 130 - 139 85 - 89
Grade 1 Hypertension (mild) 140 - 159 90 - 99
Grade 2 Hypertension (moderate) 160 - 179 100 - 109
Grade 3 Hypertension (severe) > 180 > 110
Isolated Systolic Hypertension > 140 < 90
1. After the new batteries are fitted, the year number flashes in the
display. You can set the year by pressing the M-button 3. To
confirm and then set the month, press the ON/OFF button 1.
2. You can now set the month using the M-button. Press the ON/OFF
button to confirm and then set the day.
3. Please follow the instructions above to set the day, hour and
minutes.
4. Once you have set the minutes and pressed the ON/OFF button,
the date and time are set and the time is displayed.
5. If you want to change the date and time, briefly take out one
battery and put in back, then the year number starts to flash. Now
you can enter the new values as described above.
Cuff size for circumference of upper arm
S 17 - 22 cm (6.75 - 8.75 inches)
M 22 - 32 cm (8.75 - 12.5 inches)
L 32 - 42 cm (12.5 - 16.5 inches)

6
3. Selecting «DIAG.» or «USUAL» Mode
Using the mode switch AT on the side of the device select between
«DIAG.» (Diagnostic) or «USUAL» (Usual) mode.
«DIAG.» Mode
The «DIAG.» mode should be selected, so that the blood pressure
measured by the patient at home is exactly recorded in accordance to
the guidelines of the European Society of Hypertension (ESH).
When and how to measure?
)Use only Microlife cuffs!
X
Contact Microlife Service, if the enclosed cuff 8does not fit.
X
Connect the cuff to the instrument by inserting the cuff connector
9into the cuff socket 4as far as it will go.
•The patient should carry out readings on 7 consecutive working
days (or normal week days), taking one measurement cycle in the
morning and one cycle in the evening. No readings should be
taken on «non-working» days (or particularly relaxing days) in
this mode!
•If possible, the measurements should be taken in the morning
between 06:00 - 09:00 and in the evening between 18:00 - 21:00.
Measure in the morning after getting up when you feel relaxed
and evening at least 15 minutes after your meal. If you are on
medication to lower your blood pressure it is important that you
take the measurements before taking your medication.
•Press the ON/OFF button 1to start the measurement cycle. Every
measurement cycle comprises 2 consecutive automatic measure-
ments. First, you will notice that the measurement mode selected
flashes on the screen. This is followed by a 60 second relaxation
period before the first measurement is taken. Then there is
another 60 second relaxation period before the second measure-
ment starts. Finally, the result of the second measurement is
displayed on the screen and both values automatically stored.
)In the «DIAG.» mode, the device accepts measurements
between 06:00 - 12:00 for morning measurements and
between 18:00 - 24:00 for evening measurements. Outside
these times, measurements cannot be taken and the appro-
priate symbol BL is displayed. This symbol also appears, if
measurements have already been recorded for this morning or
evening session, as no further measurement is necessary at
this time.

7WatchBP Home EN
Evaluation
After measurements have been carried out on 7 working days, you
should bring the monitor to the doctor for evaluation of your home
blood pressure values. The doctor will then read the values directly
from the monitor, as described in this manual.
«USUAL» Mode
In this mode, the device functions like a normal blood pressure
monitor – single measurements are automatically stored and can be
evaluated by a doctor.
4. Taking a Blood Pressure Measurement using this
Instrument
«DIAG.» Mode
Move the slide switch AT to «DIAG.» position (indicated by blue dot).
)The device automatically recognises, when measurements
have been carried out on 7 days. The doctor symbol BK will
flash on the screen, if an attempt is made to carry out more
measurements.
)Select the «USUAL» mode to take and store measurements at
any times (outside the time range of the «DIAG.» mode, for
any additional measurement or after completion of the diag-
nosis phase).
Checklist for taking a reliable measurement
1. Avoid activity, eating or smoking immediately before the
measurement.
2. Sit down for at least 5 minutes before the measurement - and
relax.
3. Always measure on the same arm – the arm that gives higher
readings.
4. Remove close-fitting garments from the upper arm.
5. Always ensure the cuff is positioned correctly.
•Fit the cuff closely, but not too tight.
•Make sure that the cuff is 3 cm (1 inch) above your elbow
with the tube on the inside of your arm.
•Support your arm so it is relaxed.
•Ensure that the cuff is at the same height as your heart.
6. Press the ON/OFF button 1to start the measurement.
7. The «DIAG.» symbol flashes to confirm the correct mode selec-
tion. Then a 60 second count down starts to make sure that you
are relaxed before the measurement. the last 5 seconds are
indicated by beep sounds.

8
«USUAL» Mode
Move the slide switch AT to «USUAL» position (indicated by green dot).
Follow the same instructions as given for «DIAG.» mode.
5. Data Memory and Evaluation
Data measured in the «DIAG.» or «USUAL» mode is stored sepa-
rately from each other.
Viewing the stored values
With the monitor switched off, move the switch AT to the mode with
the data you want to view, then press the M-button 3.
8. The cuff will now pump up automatically. Relax, do not move
and do not tense your arm muscles until the measurement is
completed. Breathe normally and do not talk.
9. When the correct pressure is reached, the pumping stops and
the pressure falls gradually. If the required pressure was not
reached, the instrument will automatically pump some more air
to the cuff.
10. During the measurement, the heart symbol AN flashes in the
display and a beep sounds every time a heartbeat is detected.
11. After the first measurement is completed, the 60 second count
down starts again to relax between the measurements. Then
the second measurement starts automatically. If an error
occurs, the measurement is automatically repeated.
12. The result, comprising the systolic AK and the diastolic AL
blood pressure and the pulse AM is displayed and longer beep
is heard. Note also the explanations on further displays in this
booklet.
13. At the end of a measurement, this instrument automatically
stores each result, including date and time.
14. When the measurement has finished, remove the cuff.
15. Switch off the instrument. (The monitor does switch off auto-
matically after approx. 1 min.).
)You can stop the measurement at any time by pressing the
ON/OFF button (e.g. if you feel uneasy or an unpleasant pres-
sure sensation).
)In this mode, the device functions like a normal blood pressure
monitor – single measurements are automatically stored and
can be evaluated by a doctor.

9WatchBP Home EN
«DIAG.» Mode
«USUAL» Mode
Clear all values
The data of the two memories «DIAG.» and «USUAL» can be deleted
separately.
•When the M-button 3is pressed, it briefly displays how many
measurements are stored in the «DIAG.» mode, e.g. N=20 BN.
−One measurement cycle always stores 2 readings.
−N=20 indicates 10 measurement cycles in the memory (without
the first day measurements).
−In accordance with the ESH recommendations, the first day
measurements are not included, since this is the familiarisation
phase.
•Subsequently the average of all values «A» is displayed.
−This average is the average home blood pressure calcu-
lated exactly to the ESH guidelines.
•The average is not displayed «- -», if the number of measurements
BN is less than 12 (meaning that at least 6 measurement cycles
must be taken).
•Pressing the M-button again displays the average of all morning
values and press it again to show the average of all evening
values.
•All individual readings will be displayed by repeatedly pressing
the M-button.
−The symbols AQ or AR show, if it is a morning or evening
value.
)Select the «USUAL» mode to take and store measurements at
any times (outside the time range of the «DIAG.» mode, for
any additional measurement or after completion of the diag-
nosis phase).
)Further measurements in the «DIAG.» mode are only possible,
after the values have been evaluated by a doctor and the
memory deleted.
•When the M-button 3is pressed, it briefly displays how many
measurements are stored in the «USUAL» mode, e.g. N=63 BN.
•Subsequently the average of all values «A» is displayed.
•All individual readings will be displayed by repeatedly pressing
the M-button.
Pay attention that the maximum memory capacity of 250 is not
exceeded. When the memory is full, the old values are
automatically overwritten with new ones. Values should
be evaluated by a doctor before the memory capacity is
reached – otherwise data will be lost.

10
6. Data Transfer to the Computer
This device can be connected to a computer to transfer stored values.
Installation of the software program
How to transfer data to the computer?
Before deleting values, you should show them to your
doctor. Only delete the memories, when you are sure that you
no longer need the values.
)If you want to give the device to another patient, ensure that
both memories have been deleted.
)Individual values cannot be deleted.
1. With the monitor switched off, move the switch AT to the mode
with the data you want to delete.
2. Press the M-button 3and hold it until the delete symbol BO
flashes.
3. Release M-button 3and press it once more while the delete
symbol BO flashes.
4. To delete the other memory, repeat the procedure 1-3.
Note minimum system requirements stated on the CD.
Only connect the computer and the device, when you are
prompted to.
1. Put the CD in the CD-ROM drive of your computer. Alternatively
click on «SETUP.EXE» in the CD’s directory.
2. An installation window appears on the computer monitor – simply
follow the instructions.
3. When installation is finished, restart the computer before you
work with the program.
1. Start the software program and connect the device to the
computer using the cable supplied.
2. A successful connection is displayed by «Connected» on the
screen.
3. Enter the name, identity number and date of birth of the patient.
X
To transfer the «DIAG.» mode values click «Download».
X
All values with a «;» designation are used to calculate averages.
If necessary you can remove the checkmark and the corresponding
value will not be used to calculate the average.
X
To store values, click «Save». The data is stored in a data table.
−The file name is formed automatically from the patient’s iden-
tity number and the suffix «Dmode.xls» for stored values from
the «DIAG.» mode.
−To view the data later, click «Patient Files».

11WatchBP Home EN
7. Battery Indicator and Battery change
Batteries almost flat
When the batteries are approximately ¾ used the battery symbol AO
will flash as soon as the instrument is switched on (partly filled
battery displayed). Although the instrument will continue to measure
reliably, you should obtain replacement batteries.
Batteries flat – replacement
When the batteries are flat, the battery symbol AO will flash as soon
as the instrument is switched on (flat battery displayed). You cannot
take any further measurements and must replace the batteries.
Which batteries and which procedure?
8. Using a Mains Adapter
You can operate this instrument using the Microlife mains adapter
(DC 6V, 600mA).
X
To store values from the «USUAL» mode, click «Download
Usual Mode Data».
−The file name is formed automatically from the patient’s iden-
tity number and the suffix «Umode.xls» for stored values from
the «USUAL» mode.
−To view the data later, click «Patient Files».
X
To print the data sheet, click «Print».
X
To delete the memories of the device, click «Clear Memory».
X
To close the program, click «Exit».
Ensure that the patient’s data is stored before using «Clear
Memory» or «Exit».
)If you want to give the device to another patient, ensure that
both memories have been deleted.
1. Open the battery compartment 7at the back of the instrument.
2. Replace the batteries – ensure correct polarity as shown by the
symbols in the compartment.
)Please use 4 new, long-life 1.5V, size AA batteries.
)Do not use batteries beyond their date of expiry.
)Remove batteries, if the instrument is not going to be used for
a prolonged period.
)Use only the Microlife mains adapter available as an original
accessory appropriate for your supply voltage, e.g. the
«Microlife 230V adapter».
)Ensure that neither mains adapter nor cable are not damaged.

12
When the mains adapter is connected, no battery current is consumed.
9. Error Messages
If an error occurs during the measurement, the measurement is inter-
rupted and an error message, e.g. «ERR 3», is displayed.
* Please consult your doctor, if this or any other problem occurs
repeatedly.
1. Plug the adapter cable into the mains adapter socket 5in the
blood pressure monitor.
2. Plug the adapter plug into the wall socket.
Error Description Potential cause and remedy
«ERR 1» Signal too
weak The pulse signals on the cuff are too weak. Re-position the cuff and repeat the
measurement.*
«ERR 2» Error signal During the measurement, error signals were
detected by the cuff, caused for instance by
movement or muscle tension. Repeat the
measurement, keeping your arm still.
«ERR 3» No pressure
in the cuff An adequate pressure cannot be generated in the cuff. A leak may have occurred. Check
that cuff and pump ball are correctly
connected and that the cuff is not fitted too
loosely. Replace the batteries if necessary.
Repeat the measurement.
«ERR 5» Abnormal
result Themeasuringsignalsareinaccurateand no result can therefore be displayed. Read
through the checklist for performing reliable
measurements and then repeat the
measurement.*
«HI» Pulse or cuff
pressure too
high
The pressure in the cuff is too high (over 300
mmHg) OR the pulse is too high (over 200
beats per minute). Relax for 5 minutes and
repeat the measurement.*
«LO» Pulse too low The pulse is too low (less than 40 beats per
minute). Repeat the measurement.*
)If you think the results are unusual, please read through the
information in «Section 1.» carefully.
Error Description Potential cause and remedy

13WatchBP Home EN
10. Safety, Care, Accuracy Test and Disposal
Safety and protection
Instrument care
Clean the instrument only with a soft, dry cloth.
Cleaning the cuff
You can machine wash the cuff cover at 30°C (do not iron!).
Accuracy test
We recommend this instrument is tested for accuracy every 2 years
or after mechanical impact (e.g. being dropped). Please contact
Microlife-Service to arrange the test (see foreword).
•This instrument may be used only for the purpose described in this
booklet. The manufacturer cannot be held liable for damage
caused by incorrect application.
•This instrument comprises sensitive components and must be
treated with caution. Observe the storage and operating condi-
tions described in the «Technical Specifications» section!
•Protect it from:
−water and moisture
−extreme temperatures
−impact and dropping
−contamination and dust
−direct sunlight
−heat and cold
•The cuffs are sensitive and must be handled with care.
•Only pump up the cuff when fitted.
•Do not use the instrument close to strong electromagnetic fields
such as mobile telephones or radio installations.
•Do not use the instrument if you think it is damaged or notice
anything unusual.
•Never open the instrument.
•If the instrument is not going to be used for a prolonged period the
batteries should be removed.
•Read the further safety instructions in the individual sections of
this booklet.
Ensure that children do not use the instrument unsupervised;
some parts are small enough to be swallowed.
WARNING: Under no circumstances, however, may you wash
the inner bladder! Always remove the sensitive bladder from
the sleeve before washing and replace it carefully again after-
wards.

14
Disposal
11. Guarantee
This instrument is covered by a 5 year guarantee from the date of
purchase. The guarantee is valid only on presentation of the guar-
antee card completed by the dealer (see back) confirming date of
purchase or the till receipt.
Please contact Microlife-Service (see foreword).
12. Technical Specifications
Technical alterations reserved!
Batteries and electronic instruments must be disposed of in
accordance with the locally applicable regulations, not with
domestic waste.
•Batteries, cuff and wearing parts are not included.
•Opening or altering the instrument invalidates the guarantee.
•The guarantee does not cover damage caused by improper
handling, discharged batteries, accidents or non-compliance with
the operating instructions.
Operating temperature: 10 - 40 °C / 50 - 104 °F
Storage temperature: -20 - +50 °C / -4 - +122 °F
15 - 90 % relative maximum humidity
Weight: 580 g (including batteries)
Dimensions: 150 x 100 x 50 mm
Measuring procedure: oscillometric, corresponding to Korotkoff
method: Phase I systolic, Phase V diastolic
Measurement range: 30 - 280 mmHg – blood pressure
40 - 200 beats per minute – pulse
Cuff pressure display
range: 0 - 299 mmHg
Resolution: 1 mmHg
Static accuracy: pressure within ± 3 mmHg
Pulse accuracy: ± 5 % of the readout value
Voltage source: •4 x 1.5 V Batteries; size AA
•Mains adapter DC 6V, 600 mA
(optional)
Reference to
standards:
EU Directives 93/42/EEC
NIBP requirements: EN 1060-1 /-3 /-4,
ANSI / AAMI SP10

15WatchBP Home EN

16
Дисплей
Перед использованием прибора внимательно прочтите данное
руководство.
Microlife WatchBP Home RU
1Кнопка ВКЛ/ВЫКЛ
2Дисплей
3Кнопка M (Память)
4Гнездо для манжеты
5Гнездо для блока питания
6Порт USB
7Отсек для батарей
8Манжета
9Соединитель манжеты
AT Переключатель режима
AK Систолическое давление
AL Диастолическое давление
AM Пульс
AN Частота пульса
AO Индикатор разряда батарей
AP Сохраненное значение
AQ Утренние данные
AR Вечерние данные
AS Дата/Время
BT Индикация режима
BK Символ «врач»
BL Вне периода измерений
BM Расслабление
BN Номер сохраненных данных
BO Удалить данные впамяти

17WatchBP Home RU
Уважаемый покупатель,
Прибор Microlife WatchBP Homeразработан для получения
надежных иобъективных показаний вдомашних условиях, в
строгом соответствии срекомендациями Европейского общества
гипертонии (ESH)
1,2
.Точность прибора клинически подтверждена
всоответствии спротоколом ESH/ЕОГ
3
. Самостоятельный
мониторинг артериального давления пациентами дома
рекомендован обществами по гипертонии как важное дополнение
кобычным замерам артериального давления уврача.
Врач просит пациента выполнять измерения дома втечение
нескольких рабочих дней подряд врежиме
« DIAG. » .Вэтом режиме
прибор позволяет сделать только два замера АД утром (6-9 утра) и
еще два - вечером (6-9 вечера). По истечении семи дней прибор
отображает символ, предлагающий пациенту обратиться ксвоему
врачу. При нажатии кнопки памяти на приборе отображается
среднее значение всех измерений,кроме сделанных впервый день.
Врежиме « USUAL » замеры артериального давления можно выполнять
влюбое время дня; возможно сохранение впамяти до 250 замеров.
Прибор можно подключить ккомпьютеру для отображения,
сохранения или распечатки всех данных АД.
Пожалуйста, внимательно прочтите настоящие указания для
получения четкого представления обо всех функциях итехнике
безопасности. Нам бы хотелось, чтобы Вы были удовлетворены
качеством изделия Microlife.При возникновении вопросов,проблем
или для заказа запасных частей, пожалуйста, обращайтесь в
сервисный центр Microlife. Ваш дилер или аптека могут
предоставить Вам адрес дилера MicrolifeвВашей стране.Вкачестве
альтернативы, посетите вИнтернете страницу www.microlife.ru, где
Вы сможете найти ряд полезных сведений по нашему изделию.
Будьте здоровы –Microlife AG!
1
European Society of Hypertension recommendations for conventional,
ambulatory and home blood pressure measurement.
O’Brien E, Asmar R, Beilin L, Imai Y, Mallion JM, Mancia G, Mengden T, Myers M, Padfield
P, Palatini P, Parati G, Pickering T, Redon J, Staessen J, Stergiou G, Verdecchia P, on behalf
of the European Society of Hypertension Working Group on Blood Pressure Monitoring
2
A tool for reliable self-home blood pressure monitoring designed
according to the European Society of Hypertension recommendations:
The Microlife WatchBP Home monitor.
Stergiou G, Jaenecke B, Giovas P, Chang A, Chung-Yueh Y, Tan T, Blood Pressure Monitoring
2007, 12:127–131
3Validation of the Microlife WatchBP home device for self-home
blood pressure measurement according to the International Protocol.
Stergiou G, Giovas P, Gkinos C, Patouras J, Blood Pressure Monitoring 2007, 12:185–188

18
Оглавление
1. Важная информация об артериальном давлении и
самостоятельное измерение
•Как определить артериальное давление?
2. Использование прибора впервый раз
•Активация батарей
•Установка даты ивремени
•Подбор подходящей манжеты
3. Выбор режима «DIAG.» или «USUAL»
•Режим «DIAG.»
•Когда икак выполнять измерения?
•Оценка
•Режим «USUAL»
4. Выполнение измерений артериального давления при
помощи прибора
•Режим «DIAG.»
•Режим «USUAL»
5. Память данных иоценка
•Просмотр сохраненных величин
•Режим «DIAG.»
•Режим «USUAL»
•Удаление всех значений
6. Передача данных на компьютер
•Установка программы
•Как передавать данные вкомпьютер?
7. Индикатор разряда батарей иих замена
•Батареи почти разряжены
•Замена разряженных батарей
•Элементы питания ипроцедура замены
8. Использование блока питания
9. Сообщения об ошибках
10. Техника безопасности, уход, тестирование точности и
утилизация
•Техника безопасности изащита
•Уход за прибором
•Очистка манжеты
•Проверка точности
•Утилизация
11. Гарантия
12. Технические характеристики
Гарантийный талон
