Microlife WatchBP Home User manual

EN 1
Accurate home and
nocturnal blood pressure
measurements
with the WatchBP home N.
Instruction Manual

Microlife WatchBP Home N is the device designed to measure nocturnal blood pressure during sleep
time. It strictly follows European Society of Hypertension (ESH)1, 2 and American Heart Association (AHA)3
recommendations for home blood pressure measurement. Using the WatchBP Home N device helps you
collect accurate home and nocturnal blood pressure measurements. This gives a good insight into your
daily blood pressure pattern and therefore provides valuable information for your doctor. The WatchBP
Home N device has been clinically validated according to the ESH protocol 4.
1 O’Brien E, Asmar R, Beilin L, Imai Y, et al. European Society of Hypertension recommendations for conventional, ambulatory and home blood pressure
measurement. European Society of Hypertension Working Group on Blood Pressure Monitoring. J Hypertens 2003;21:821-848.
2 Stergiou GS, et al. A tool for reliable self-home blood pressure monitoring designed according to the European Society of Hypertension
recommendations: The Microlife WatchBP Home monitor. Blood press Monit. 2007;12:127-131.
3 Pickering TG, Hall JE, Appel LJ, et al. Recommendations for Blood Pressure Measurement in Humans and Experimental Animals:
Part 1: Blood Pressure Measurement in Humans: A Statement for Professionals From the Subcommittee of Professional and Public Education of the
American Heart Association Council on High Blood Pressure Research. Hypertension 2005;45;142-161.
4 Stergiou GS, Giovas PP, Gkinos CP, Patouras JD. Validation of the Microlife WatchBP Home device for self home blood pressure measurement according
to The International Protocol. Blood Press Monit. 2007;12(3):185-188.

EN
Before using WatchBP Home N for the rst time
Product description .....................................................3–4
Activating the device ...................................................... 5
Selecting the correct cuff ................................................ 6
Taking measurements using WatchBP Home N
«USUAL» Mode ............................................................... 8
«DIAG.» Mode ............................................................8–10
«NOCTURNAL» Mode .................................................... 11
Storing measurement values and medication intake
Measurement values stored automatically ................. 12
Recording medication intake ................................. 13–14
Eight steps for taking accurate blood pressure
Blood pressure measurement procedures ..............15-18
Special function
Atrial Fibrillation Detection .......................................19-20
Viewing, deleting, and transferring measurement
values
Viewing measurement values ............................... 21–22
Deleting measurement values ............................... 23–24
Transferring measurement values.......................... 25–26
Appendix
Batteries and power adaptor ................................. 27–28
Safety, care, accuracy test and disposal ................. 29–30
Error messages ....................................................... 31–32
Important facts ....................................................... 33–34
Technical specications ................................................ 31
Table of Contents

3
SYS
mmHg
mmHg
DIA
PUL
/min
USUAL
DIAG.
NOCTURNAL
M Button (Memory)
N
O
C
TU
R
N
A
L
D
IAG
.
U
SU
A
L
Display
ON/OFF Button
Cuff Socket
Power Socket
Serial Port Battery Compartment
Mode Switch
Medication Button

4EN
Mode Indicators
Doctor Symbol
Atrial Fibrillation Detection
Outside Measurement time
Relax
Battery Display
Delete Memory Data
Morning Data
Evening Data
Date/Time
Systolic Value
Diastolic Value
Pulse Indicator
Pulse Rate
Number of Stored Data
USUAL
DIAG.
NOCTURNAL

5
2)Set the month – Press the M button to select the
month. Press the ON/OFF button to conrm.
Before using WatchBP Home N for the rst time
Activating the Device
Pull out the protective strip from the battery
compartment to activate the device.
Press M button to select.
Press ON/OFF button to conrm.
3)Set the day – Press the M button to select the day.
Press the ON/OFF button to conrm.
SYS
mmHg
mmHg
DIA
PUL
/min
USUAL
DIAG.
NOCTURNAL
1)Set the year – Upon removing the protective strip or
installing new batteries, the year number ashes in
the display. Use the M button to select the year. Press
the ON/OFF button to conrm the selection.

EN
6
4)Set the time – Press the M Button to select the time.
Press the ON/OFF button to conrm. When the date
and time are set, the current time is displayed.
5)If you want to change the date and time, take out one
battery from the battery compartment briey and
press ON/OFF button to turn off the device; then put it
back. The year number will ash. Complete the process
as described above.
M (Medium size)
22 - 32 cm (8.7 - 12.6 inches)
M is the correct size for most people.
L (Large size)
32 - 42 cm (12.6 - 16.5 inches)
Selecting the correct cuff
The WatchBP Home N device is available with different
cuff sizes. If the cuff provided with the device is not the
correct size, please consult your doctor.
* please use only Microlife cuffs!

7
Prior to each measurement, use the Mode Switch
on the right side of the device to select the proper
measurement mode. There are three modes to be
selected:
«USUAL» (Usual) mode,
for a regular single measurement.
«DIAG.» (Diagnostic),
for diagnosis or follow-up.
«NOCTURNAL» (Nocturnal) mode
for measurements of blood pressure during sleep.
N
O
C
TU
R
N
A
L
D
IAG.
U
SU
A
L
Taking measurements using WatchBP Home N
NOCTURNAL DIAG. USUAL
NOCTURNAL DIAG. USUAL NOCTURNAL DIAG. USUAL

EN
8
«USUAL» Mode
The «USUAL» mode should be selected when the
measurement of blood pressure is recommended by
guidelines. In «USUAL» mode, single measurements can
be taken at any time, and the measurement values are
automatically stored for later evaluation by your doctor.
Anytime
NOCTURNAL DIAG. USUALNOCTURNAL DIAG. USUAL
NOCTURNAL DIAG. USUAL
«DIAG.» Mode
The «DIAG.» mode should be selected as requested.
The blood pressure can only be measured in
accordance to the measurement schedule as
prescribed by the European Society of Hypertension
(ESH).
NOCTURNAL DIAG. USUAL
NOCTURNAL DIAG. USUAL NOCTURNAL DIAG. USUAL

9
No measurements on non-work days
In «DIAG.» mode, blood pressure measurements are
taken on 7 consecutive working days (or normal
week days). Do not take measuremetns on
«non-working» days (or particularly relaxing days)
in this mode!
Two sets of measurements per day
ESH guidelines recommend one double measurement
to be taken in the morning between 06:00 - 09:00 and
one in the evening between 18:00 - 21:00. Always take
the measurements before taking your medication,
unless otherwise directed by your doctor.
Jan
JAN
30 7working
days
X1
X1
06:00 - 09:00
18:00 - 21:00
X1
X1
04:00 - 12:00
18:00 - 24:00
ESH Guidelines Extended Time
Taking measurements using WatchBP Home N (cont.)

EN
10
Evaluation
After measurements have been carried out for a total
of 7 working days, take the device to your doctor for
evaluation of your home blood pressure.
Extended measurement period
WatchBP Home N has an extended measurement period
and allows morning measurements between 04:00 -
12:00 and evening measurements between 18:00 - 24:00.
If it is not in the
measuring time
period, the symbol
will be displayed and
the measurements
can not be taken.
When measurements
have been carried out
for the full 7 days, the
doctor symbol will
ash on the screen.
USUAL
DIAG.
NOCTURNAL
USUAL
DIAG.
NOCTURNAL

11
«NOCTURNAL» Mode
The «NOCTURNAL» mode enables you to measure and
record blood pressures during sleep time. It can be
selected when requested by your doctor.
NOCTURNAL DIAG. USUAL
NOCTURNAL DIAG. USUAL
NOCTURNAL DIAG. USUAL
Three measurements during sleep time
Select «NOCTURNAL» mode while you are going to
sleep. Press the start button for 3 seconds, the device
will take one measurement automatically to activate the
nocturnal procedure. It will take the rst measurement
two hours later; the second measurement one hour after
the rst measurement; and the third measurement one
hour after the second measurement.
1 hour 1 hour
12 3
0
2 hours
Press for
3 seconds
Taking measurements using WatchBP Home N (cont.)
*The average blood pressure value of the 1st, 2nd and 3rd
measurement will be calculated by the device.

EN
12
In «NOCTURNAL» mode
84 measurements can be stored
* Up to 21 cycles of nocturnal measurements can be stored.
50 medication records can be stored
* When the memory is full, the device will display “Full”.
250
Measurements
In «USUAL» mode
250 measurements can be stored
* When the memory of the device is full, each new
measurement will automatically overwrite the rst
measurement.
In «DIAG>» mode
28 measurements can be stored
28
Measurements
«USUAL»mode «DIAG>» mode
84
Measurements
«NOCTURNAL»mode Medication
Measurements stored automatically

13
N
O
C
TU
R
N
A
L
D
IAG
.
U
SU
A
L
Saved
The patient can record the time of the medicine intake by
pressing the Medication Button. Press and hold
for 2 Seconds...
1)Press and hold the Medication Button for 2 seconds then
release it, the Pill icon and the record number appear.
2) The Pill icon will ash alternately with the recorded time.
3)Medication record is saved .
Delete stored medication records
Recording medication intake
*Medication intake can be recorded in any of the three modes.
N
O
C
TU
R
N
A
L
D
IAG
.
U
SU
A
L

EN
14
Press and hold
for 7 seconds...
*Pressing the M Button to delete data will erase all medication
recorded data in the selected mode.
To clear the memory of all medication records, press and
hold the Medication button for 7 seconds until the “CL”
symbol ashes. Then press M to delete the memory or ON/
OFF to cancel the deletion .
N
O
C
TU
R
N
A
L
D
IAG
.
U
SU
A
L

15
Eight steps for taking proper blood pressure
Step 1
Avoid taking measurements directly after eating,
drinking or smoking. Allow at least one hour between
these activities and measurement of your blood pressure.
Step 2
Prepare a chair and table for the measurement. The
chair should have a vertical back-rest and the table
should allow your upper arm to rest at the same height
as your heart.
1 Hour Before

EN
16
Step 3
Remove all clothing covering or constricting the arm to
be measured. Apply the cuff. Make sure the lower edge
of the cuff is exactly 2–3 cm from the inner fold of your
arm. The tube connecting the cuff to the device should
be placed on the inside of the arm. (Additional visual
instruction can be found on the cuff)
Step 4
Sit down and relax for at least ve minutes prior to the
measurement.

17
Step 5
Sit upright and lean comfortably against the chair’s
backrest. Press the start button, and the device will
start to measure. During the measurement do not
move, cross your legs, or tense your arm muscles.
Breath normally and do not talk.
Step 6
When the measurement is complete, the readings
are stored for future reference by your doctor. If an
error displays after the readings, please repeat the
measurement procedure from step 1 to 5.
SYS
mmHg
mmHg
DIA
PUL
/min
USUAL
DIAG.
NOCTURNAL
Automatically stored
Eight steps for taking proper blood pressure (cont.)

EN
18
Step 7 (in «DIAG.» mode)
In «DIAG.» mode, there is a 60 second countdown before
the measurement starts. Two measurements will be
performed subsequently. After the rst measurement
another 60 second countdown starts before the second
measurement. Be relaxed and do not move during the
countdown.
Step 8 (in «DIAG.» mode)
When seven days of measurements have been collected,
the Doctor Symbol will ash on the display. Do not forget
to take your WatchBP Home N device with you on your
next visit to the doctor. (Note: the doctor symbol is only
displayed for measurements in «DIAG.» Mode.)
1 2
60 sec.

19
Special Function
The atrial brillation indicator for early
detection
The WatchBP Home N is designed to detect atrial brillation
during blood pressure measurements in the «USUAL» Mode,
«DIAG.» Mode and «NOCTURNAL» Mode. When atrial
brillation is detected, the Ab icon is displayed. The device
can detect atrial brillation with high accuracy (sensitivity
of 95% and specicity of 86%)*. If the atrial brillation
icon is displayed after the measurement, it is recommended
to visit a doctor.
IAD
* Joseph Wiesel, Lorenzo Fitzig, Yehuda Herschman and Frank
C. Messineo. Detection of Atrial Fibrillation Using a Modied
Microlife Blood Pressure Monitor.
American Journal of Hypertension 2009; 22, 8, 848–852.
doi:10.1038/ajh.2009.98
* Atrial brillation is a major cause of stroke which can be
detected by this device. However, not all risk factors for
stroke, including atrial utter, may be detected by this
device.
* This device may not detect atrial brillation in people with
pacemakers or debrillators. People with pacemakers or
debrillators should therefore not use this device to detect
atrial brillation.
