Microsemi 9501GO-ET
1-Port, 802.3at Outdoor PoE Midspan
User Installation Guide
Deutsch

Copyright 2017 Microsemi Page 2
PD-9501GO-ET
One Enterprise Aliso Viejo, CA 92656 USA
Notice
It is Microsemi’s policy to improve its products as new technology,
components, software, and firmware become available. Microsemi,
therefore, reserves the right to change specifications without prior
notice.
Technical Support
If you encounter problems when installing or using this product, please
consult the Microsemi website at: http://www.Microsemi.com.
USA/Canada: [phone]
[e-mail]

Copyright 2017 Microsemi Page 3
PD-9501GO_ET
One Enterprise Aliso Viejo, CA 92656 USA
English
Product Overview
Microsemi PD-9501GO-ET is a 1-Port 802.3at Gigabit PoE Outdoor
Midspan that offers a cost effective, IEEE 802.3atTM compliant
solution, guaranteeing 60 Watts of power and ensures safe and
reliable operation in outdoor environments for standard PoE data
terminal. The PD-9501GO-ET supports 10/100/1000Mbps data rates
and is powered via wide-range AC input (100-240VAC).
The PD-9501GO-ET is IP67 rated and has extended temperature
range so it can be installed in an outdoor environment. In a typical
installation the PD-9501GO-ET will provide power to outdoor
devices such as WLAN AP, WLAN Mesh, or to an IP Camera, etc.
PD-9501GO-ET EMC Compliance:
CE:
oEN55024, EN61000-4-5 Class 5 (6KV on AC Lines)
oEN55032 class B
FCC Part 15 class B
VCCI
PD-9501GO-ET Safety Compliance:
UL60950-1
UL60950-22
GS Compliance
PD-9501GO-ET Lightning Protection:
Designed to meet GR-1089-CORE lightning protection
requirements
Designed to meet ITU K.21 lightning protection- Enhanced level
Other Standards and Approvals:
IEEE 802.3at & IEEE 802.3af (PoE) standards
RoHS Compliant
WEEE Compliant
REACH Compliant

Copyright 2017 Microsemi Page 4
PD-9501GO-ET
One Enterprise Aliso Viejo, CA 92656 USA
Dust & Water protection
oIEC60529, level IP67
oNEMA 250, level 4x
Note
Do not use cross-over cable between the PoE Midspan output
port and load device.
WARNING
Take extra care when connecting the AC power inlet terminals, so
that 'N', 'L' and 'Ground' are connected to the proper polarity.
Ensure the AC power is within the allowed range.
Mounting Instructions Installation
Note: Before mounting the PoE Midspan to a fixed location:
To insure weather-proof connection in order to meet IEC60529
level IP67. PoE Midspan AC power plug needs to be connected to
a weather-proof AC power source box.
There is no “On-Off” switch; simply plug the PoE Midspan into an
AC main power source.
PoE Midspan AC power lines should be connected to the socket-
outlet that shall be installed near the equipment and be easily
accessible.

Copyright 2017 Microsemi Page 5
PD-9501GO_ET
One Enterprise Aliso Viejo, CA 92656 USA
English
Product View
Figure 1
Installing the unit
Warning
Earth ground screw must be connected to Earth ground in all
types of installations.
Step1: Connect the chassis bolt to earth ground.
CONNECT TO
EARTH GROUND
USE A TORQUE OF 10Lb-in (1.1Nm) - 15Lb-in(1.7Nm)
FOR TIGHTENING THE NUT
Figure 2

Copyright 2017 Microsemi Page 6
PD-9501GO-ET
One Enterprise Aliso Viejo, CA 92656 USA
Step 2: There are two options for the installation of PD-9501GO-ET:
A. Wall installation –PoE Midspan unit can be mounted on a
wall/bench (all kind of flat surfaces: wood, brick, concrete
etc.) using the mounting holes.
B. Pole installation - using optional mount kit (sold separately).
Step 2A: Wall installation
Fasten the PD-9501GO-ET using three screws, see figure 3 (Screw
holes are marked 1, 2, 3 & 4):
184.8
117.8
Figure 3

Copyright 2017 Microsemi Page 7
PD-9501GO_ET
One Enterprise Aliso Viejo, CA 92656 USA
English
Step 2B: Pole installation using optional mount kit (sold separately)
1.
2.
Warning: Mounting bracket must be connected to earth ground!

Copyright 2017 Microsemi Page 8
PD-9501GO-ET
One Enterprise Aliso Viejo, CA 92656 USA
Step 3A: Pole of 1” (25.4mm) < ø < 3” (76.2mm)

Copyright 2017 Microsemi Page 9
PD-9501GO_ET
One Enterprise Aliso Viejo, CA 92656 USA
English
Step 3B: Pole of- 3” (76.2mm) < ø < 8” (203.2mm)
1. Insert Screwdriver, press and rotate counter-clockwise to unlock
2. Pull cap away from unit

Copyright 2017 Microsemi Page 10
PD-9501GO-ET
One Enterprise Aliso Viejo, CA 92656 USA
N L
PE
Clamping
NUT Seal BodyClamp spring Body Female
Housing
Click
Lead Rails
Step 4: AC Cable installation instruction:
Tools: Wire stripper, Solid Wrench No.30 or Monkey Wrench wide than 3cm.
Note: Please use certified outdoor cable with thickness diameter of 6-10mm with
18AWG Max gauge and 300V insulation rating.
1. Connector Parts:
2. Insert the cable through the parts, crimp and screw the wire leads
using 0.8 N*m torque
3. Push Housing into Body according to lead rails
4. Insert Seal and Clamp spring into body, then tighten the nut using
4N•m torque
5.
Figure 4

Copyright 2017 Microsemi Page 11
PD-9501GO_ET
One Enterprise Aliso Viejo, CA 92656 USA
English
Step 5: RJ45 Ethernet Cable Assembly
Note: Please use outdoor certified cable with thickness diameter of 4-8mm
STEP-1
STEP-2
STEP-3
STEP-4
STEP-5
STEP-6
FASTEN TIGHTLY BY HAND
FASTEN TIGHTLY BY HAND
Figure 5

Copyright 2017 Microsemi Page 12
PD-9501GO-ET
One Enterprise Aliso Viejo, CA 92656 USA
Step 6: Connect “DATA IN” jack (input) to the remote Ethernet
network and “DATA PWR OUT” jack (output) to the terminal.
Step 7: Verify connection to main AC power.
Notes:
2 ports RJ45 male plug waterproof cap covers are supplied with the
PoE Midspan.
AC in plug is supplied with the PoE Midspan.
Ethernet cable and RJ45 male connectors are not supplied with the
PoE Midspan.
For non AF/AT compliant unit - use a splitter; ensure splitter is
connected close to the terminal and not on the Midspan.
This unit is designed for outdoor use.

Copyright 2017 Microsemi Page 13
PD-9501GO_ET
One Enterprise Aliso Viejo, CA 92656 USA
English
Troubleshooting
Symptom
Corrective Steps
Unit does not
power up
1. Verify a reliable power cord is used.
2. Verify voltage at the power inlet is between
100- 240VAC.
3. Remove and re-apply power to the device.
PD does not
operate
1. Verify that the unit detects a PD.
2. Verify that the PD is designed for PoE
operation.
3. Verify that a standard Category 5/5e/6 cable is in
use –Straight-wired cable, with four pairs.
4. If an external power splitter is in use,
replace it with a splitter known as good.
5. Ensure input Ethernet cable is connected
to the "DATA IN" port.
6. Verify that the PD is connected to the
"DATA & PWR OUT" port.
7. Try reconnecting the same PD, there’s
probably a faulty RJ45 connection.
8. Verify there is no short over any of the
twisted-pair cables or over the RJ45
connectors.
The end
device
operates, but
there is no
data link
9. If an external power splitter is in use,
replace it with a splitter known as good.
10. Verify that for this link, you are using
standard UTP/FTP Category 5 straight
(non-crossover) cabling, with all four pairs.
11. Verify Ethernet cable length is less than
100 meters from Ethernet source to the
remote terminal.

Copyright 2017 Microsemi Page 14
PD-9501GO-ET
One Enterprise Aliso Viejo, CA 92656 USA
Safety Information
Installation and removal of the PoE Midspan must be carried out by
qualified personnel only.
The PoE Midspan "DATA IN" and "DATA PWR OUT" ports are
shielded RJ45 data sockets. They cannot be used as Plain Old
Telephone Service (POTS) sockets. Only RJ45 data connectors
can be connected to these sockets.
Read the installation instructions before connecting the PoE
Midspan to its power source.
Follow basic electricity safety measures whenever connecting the
PoE Midspan to its power source.
A voltage mismatch can cause equipment damage and may pose a
fire hazard. If the voltage indicated on the label is different from the
power outlet voltage, do not connect the PoE Midspan to this power
outlet!
All wiring and connections shall be in accordance with NFPA 70
(NEC)
This product is not intended to become a permanent part of the
building structure.
Power supply cord must not be attached to the building surface or
run through walls, ceilings, floors and similar openings in the
building structure.
Measures must be taken to prevent physical damage to the power
supply cord, including proper routing.


Copyright 2017 Microsemi Page 15
PD-9501GO_ET
One Enterprise Aliso Viejo, CA 92656 USA
English
Recycling and Disposal
Disposal instructions for old products. The WEEE (Waste
Electrical and Electronic Equipment) national environmental
initiatives have been put in place to ensure that products are
recycled using best available treatment, recovery and recycling
techniques to ensure human health and high environmental
protection. Your product is designed and manufactured with high
quality materials and components, which can be recycled and
reused. Do not dispose of your old product in your general
Household waste bin. Inform yourself about the local separate
collection system for electrical and electronic products marked by
this symbol:
Use one of the following disposal options :
Dispose of the complete product (including its cables, plugs and
accessories) in the designated WEEE collection facilities.
If you purchase a replacement product, hand your complete old
product back to the retailer. He should accept it as required by
the national WEEE legislation.

Copyright 2017 Microsemi Page 16
PD-9501GO-ET
One Enterprise Aliso Viejo, CA 92656 USA
Specifications
Environmental Specifications
Mode
Temperature
Humidity
Operating
-40°C to 65°C @ 60W
(-40°F to 149°F)
10 to 95%
(no condensation
allowed)
Storage
-40 to 85°C
(-40°F to 185°F)
10 to 95%
(no condensation
allowed)
Electrical Specifications
Input Voltage
100-240VAC (50-60Hz)
Input Current (100-240VAC)
1.4A Ampere (max)
Available Output Power (max.)
60 Watts
Nominal Output Voltage
54VDC
Interface
Input (Data In):
Ethernet 10/100/1000Base-T
RJ45 female socket
Output (DATA PWR OUT):
Ethernet 10/100/1000Base-T,
plus 54VDC
RJ45 female socket, with DC
voltage on wire pairs: (-)1-2,
7-8 & (+)3-6, 4-5
AC Power IN
3 Pins AC power in –Line,
Neutral and Earth Ground

Copyright 2017 Microsemi Page 17
PD-9501GO_ET
One Enterprise Aliso Viejo, CA 92656 USA
English
The information contained in the document is PROPRIETARY AND
CONFIDENTIAL information of Microsemi and cannot be copied, published,
uploaded, posted, transmitted, distributed or disclosed or used without the
express duly signed written consent of Microsemi. If the recipient of this document
has entered into a disclosure agreement with Microsemi, then the terms of such
Agreement will also apply. This document and the information contained herein
may not be modified, by any person other than authorized personnel of
Microsemi. No license under any patent, copyright, trade secret or other
intellectual property right is granted to or conferred upon you by disclosure or
delivery of the information, either expressly, by implication, inducement, estoppels
or otherwise. Any license under such intellectual property rights must be
approved by Microsemi in writing signed by an officer of Microsemi.
Microsemi reserves the right to change the configuration, functionality and
performance of its products at any time without any notice. This product has been
subject to limited testing and should not be used in conjunction with life-support or
other mission-critical equipment or applications. Microsemi assumes no liability
whatsoever, and Microsemi disclaims any express or implied warranty, relating to
sale and/or use of Microsemi products including liability or warranties relating to
fitness for a particular purpose, merchantability, or infringement of any patent,
copyright or other intellectual property right. The product is subject to other terms
and conditions which can be located on the web at
http://www.microsemi.com/legal/tnc.asp
 Microsemi Corp. 2017
Microsemi name & logo; Microsemi name & logo are registered
trademarks of Microsemi corp.
802.3at is a trademark of IEEE
Ordering information:
Part Number: PD-9501GO-ET/AC
Description: Single-port, Outdoor 60W PoE Midspan, IEEE802.3at
Compliant, Extended temp range , worldwide use
Document P/N 06-6674-160 REV. A01
