Thank you for your purchase of the PS Audio Juice Bar II
The Juice Bar is designed to provide unrestricted current flow to each of its outlets. It can be used
as a standalone power distribution device. It can also be used to extend the benefit of the clean,
protected power provided by other power distribution products, such as the PS Audio Duet, Quintet,
Quintessence or Power Plant.
In most commercial power strips the resistance of the current flow increases with the distance from
the power inlet. The Juice Bar uses heavy and thick solid copper bus bars for power delivery to the
outlets which gives all outlets equal power delivery.
What will it do?

4826 Sterling Drive, Boulder, CO 80301
PH: 720.406.8946 [email protected] www.psaudio.com
®Getting Started
Getting Started 1
©2008 PS Audio International Inc. All rights reserved.
Owner’s Reference Juice Bar II
Once your new Juice Bar is unpacked, you’ll need to find a convenient place to set it.
There are several ways to mount the Juice Bar: on the floor, on a shelf, or in a rack. If you mount it
on the floor, it can either lay flat on its bottom, or be placed at an angle between the floor and the
wall. Note the Juice Bar is shaped in a truncated triangle on the bottom to facilitate placing it in an
angled position.
If your equipment is located a long distance from the Juice Bar, it is preferable to use a long, heavy
gauge shielded power cable between the wall AC receptacle and the Juice Bar, rather than long
individual power cables between the equipment and the Juice Bar.
The Juice Bar can benefit from aftermarket isolation devices such as cones, spikes and Sorbothane
pads.
Once you have chosen the location for the Juice Bar you can use the supplied AC power cord to
connect it to the AC wall receptacle or you can use an aftermarket power cord and receptacle.
We strongly recommend the use of a PS Audio xStream Power™ AC cable and a PS Power Port™
AC receptacle, or Soloist AC receptacle to feed the Juice Bar electricity. While the supplied power
cable is adequate for the task, it is not going to provide the best performance. Choosing any
xStream Power cable will make a significant performance improvement over the stock power cable.
We recommend the use of a PS Soloist in-wall conditioner to feed this device.
Isolation
Power Cables
Location
Mounting
Conditioners

4826 Sterling Drive, Boulder, CO 80301
PH: 720.406.8946 [email protected] www.psaudio.com Quick Start Guide 2
®Quick Start Guide
©2008 PS Audio International Inc. All rights reserved.
Owner’s Reference Juice Bar II
We would recommend that you power the entire system down before attempting to connect
equipment to the Juice Bar.
Plug the Juice Bar into an AC receptacle with at least 15 amps of service (in the US) or 7.5 amps of
service (in 220 volt countries), preferably using a dedicated AC line. A dedicated line means there is
nothing else plugged into the wiring feeding the AC receptacle and that wiring returns directly to the
AC breaker box.
If you are using the Juice Bar as a standalone power extender, our first recommendation on where
to connect your new Juice Bar would be a PS Soloist in-wall device. The Soloist provides the first
stage of cleaning and protection in the PS Power System and is an elegant in-wall solution. Our
second choice is a PS Power Port AC receptacle. While not as good as a Soloist (the Power Port
has no cleaning or protection capabilities) it is certainly preferable to a $1.99 “contractor special”
brass contact AC receptacle found in most of our homes.
Be careful where you plug in as some outlets are “switched” outlets and may be powered on or off
with the wall switch unexpectedly.
If you are using the Juice Bar as an adjunct to a Power Plant Premier or Quintessence Power Center,
then simply choose any unused IsoZone on the rear of the Power Plant or Quintessence to connect
the Juice Bar.
Use the heaviest gauge shielded AC power cable you can to connect a Juice Bar to its AC source.
The heavier the gauge used, the less the chance for restricted dynamics in both audio and video
systems.
Once the Juice Bar has been connected to an AC source it is time to connect your equipment.
Each Juice Bar has 4 receptacles. In 120 volt units, each of the 4 receptacles has two outlets for a
total of 8 outlets.
Each outlet should be used to help isolate different genres of equipment from each other. For
instance, you can group digital equipment together on a single outlet or multiple analog sources on
yet another outlet.
It is important to use only the highest quality AC power cords that are well shielded to any
connected equipment. It is a good idea to keep in mind that all equipment generates radiated noise
when it is operating. This radiated noise is harmful to both audio and video system performance and
is typically carried down the AC power line.
Turn off
Avoid switched
outlets
Connect your
equipment
Multiple units
Remove the power
cord

4826 Sterling Drive, Boulder, CO 80301
PH: 720.406.8946 [email protected] www.psaudio.com Questions and Answers 3
®Questions And Answers
©2008 PS Audio International Inc. All rights reserved.
Owner’s Reference Juice Bar II
The Juice Bar is best left powered on at all times. The current draw is zero.
There are no internal fuses or any components on the inside of the Juice Bar.. The components
inside the Juice Bar have lethal voltages when powered. Do not attempt to get inside the unit for
any reason. Should the Juice Bar cease to function, contact your dealer or PS Audio’s service
center for help.
The AC receptacle is a critical link in the electrical chain. If you are using a standard AC wall
receptacle to power your equipment, we would recommend the use of a Power Port AC receptacle,
a hospital grade AC receptacle or at the minimum a high quality spec grade receptacle, like the one
on the Juice Bar itself. The connection between the wall AC receptacle and your equipment can be
a critical link in the success of your equipment’s performance.
Placement of the Juice Bar is not critical. Place it wherever it is convenient.
Placement with respect to other equipment can be important. In general, place the Juice Bar
between the unit you are powering and the AC source. If you are using a power conditioner,
balanced isolation transformer or Power Plant, place the Juice Bar between those devices and the
unit you will be powering.
Isolation through the use of spikes, cones or Sorbothane feet is recommended for the Juice Bar if
space and budget allows. Isolation of any piece of high-end stereo and theater equipment is always
recommended wherever practical.
Should the unit
be on all the
time?
Are there any
internal fuses?
