31” DELUXE PUSH PAVEMENT/LEAF/LAWNSWEEPER
MODEL B-319NT
No Tools Required Owner’s Manual and Parts List
SAVE THIS MANUAL
You will need this manual for the safety instructions, assembly instructions and parts list. Put it in a
safe, dry place for future reference.

©2017 Mid West Products, Inc. -2- Form No. M1-1639
1. Lay all parts on a flat surface, and follow these few
simple instructions.
2. Set chassis (36) on its wheels and swing support stand
(31) to rear until ends of stand are against stops in
chassis end plates. It is not necessary to loosen nuts
(12). See figure 3.
3. Remove wing nuts (6) and hook bolts (14) from the
steering handle (30). Slip reduced ends with holes of
side handle tubes (33) into ends of steering handle tube
(30). Line up hole in each end and reinsert hook bolts
(14) through tubes. Secure with wing nuts (6). See
figures (1 and 2) for correct position of all parts. NOTE:
Make certain hook bolt points to rear of sweeper.
4. Now, remove wing nuts (6) from the bottom ends of the
side handle tubes (33). Slip bottom ends of side handle
tubes (33) inside chassis (36) See Figure 8. Make
certain the thumb screws (28) go through the hole in
the formed pocket. Reattach the wing nuts (6) onto the
thumb screws (28) now protruding through the outside
of the chassis (36).
5. Hang hamper (35) inside handle assembly with rear
hamper rod (32) in hooks (14). Place front hamper rod
(32) in slots “Y” of chassis end plates. See figure 2 and
4.
Fasten hangers (5) on side handles. Tilt hanger in—slide
and twist out over tube. See figure 6.
All “right” and “left” directions should be considered
as from your position behind the lawnsweeper
CHASSIS (36)
(The correct positioning of the handle tubes as you are
looking into the brush assembly of the chassis)
FIG 8
Left Side Handle Right Side Handle
Tube Tube

©2017 Mid West Products, Inc. -3- Form No. M1-1639
Your Lawn Sweeper box contains the following items: 1- Chassis, 1- Steering Handle Assembly, 2-
Side Handle Assemblies (R.H & L.H.), 1- Manual, & 1- Hamper Assembly.
Key
Part No.
Description
Qty
Key
Part No.
Description
Qty
1
L-127
5/16-18 X 1-1/2 Hex Hd. Cp. Sc.
2
21
L-5496
Wheel Stud Axle
2
2
L-262
5/8 Type "E" Retaining Ring
2
22
L-6103
Bumper Tube
1
3
L-279
5/16-18 X 1/2 Hex Hd. Sc.
6
23
L-6151
Spring Adjustment
1
6
X-1152
1/4-20 Wing Nut
4
24
L-6157
Pinion Gear
2
7
L-5485
3/8-24 Pilot Nut
2
25
L-6190B
Caster Wheel
2
8
L-5486M
3/8-24 Lock Nut (Spec.)
2
26
1-3344
Brush Strip
6
9
X-1041
1/2 Push On
2
27
1-1080
Flange Bearing
2
11
X-1043
Brush Holder Spring
18
28
X-1182
1/4-20 X 1-1/4 Bolt
2
12
X-1107
5/16-18 Center Lock Nut
8
29
1-1287
Rubber Cap
4
13
X-1348
5/16" Push On Cap
2
30
1-1355
Steering Handle
1
14
X-1360
Hook Bolt
2
31
1-1337
Carriage Tube
1
15
L-5464
10" Plastic Wheel
2
32
1-1389
Hamper Rod
2
16
1-1418E
10” Ribbed Tire
2
33
1-2274
Side Handle Tube R.H.
1
18
L-5472
Wheel Bushing
4
NI
1-2275
Side Handle Tube L.H.
1
19
1-2399
Wheel Shield
2
34
1A-1311
Caster Bracket Assembly
2
20
L-5480
Pinion Pawl
6
35
1A-2010
Hamper Assembly
1
36
1A-2278
Shield Assembly
1
NI = Not Illustrated
PARTS DIAGRAM & LIST

©2017 Mid West Products, Inc. -4- Form No. M1-1639
1. BRUSH HEIGHT ADJUSTMENT. You can sweep both
lawn and paved areas by a simple adjustment of the
brush. To raise brush to sweep your lawn, merely
squeeze brush control and push down on front of
bumper tube. At the same time, with the other hand,
pull up on right corner of chassis. To lower brush, just
reverse above instructions. See Figure 5. Whenever
sweeper seems to push hard, merely raise brush one
notch higher. For best operation on lawns the brush
should merely flick the top of grass blades.
2. DUMPING SWEEPER. Release hamper hanger from
side hamper tubes. Then, lift front hamper rod up and
to rear of sweeper. Now, remove rear hamper rod from
hooks (14) and lift hamper from sweeper. If dumping
location is far from sweeping area, it may be desirable
to pile several hamper loads of debris on a tarpaulin for
faster removal to dumping location.
3. STORAGE. Just fold stand forward under chassis.
Hamper will fold itself when sweeper is hung on wall or
set in corner against wall for compact winter storage.
4. NO LUBRICATION REQUIRED. Brush axle bearings
are lubricated and sealed during factory assembly. No
other lubrication is necessary. DO NOT OIL OR
GREASE GEARS IN WHEELS. If oil or grease is
applied to these parts the brush will not rotate. Then it
is necessary to re-move wheel and wipe all parts clean.
5. When servicing or replacing the pinion or pawl pins
please refer to the PINION & PAWL INSTALLATION
figure. Right (R) and Left (L) notations on the pinion
gears are from your position behind the lawnsweeper.
6. Your lawnsweeper is precision manufactured by
experienced craftsmen, using the very finest in tools
and materials. Although it is ruggedly constructed, do
not subject it to misuse. CAUTION: DO NOT PUSH
SWEEPER TOO CLOSE TO FIRE –the brushes will
burn. BE SURE TO WIPE OFF YOUR
LAWNSWEEPER AFTER EACH USE. Store in a dry
place out of direct sunlight. Don’t permit the sweeper
to stand in the hot sun unless it is in actual use.
You will find many work-saving uses for your lawnsweeper.
Use it in the early spring to give your lawn a good healthful
scrubbing. Use it throughout the spring and summer both
before and after mowing. Sweeping before mowing stands
up the grass for a clean, even mowing –and protects your
mower from sticks, stones, or nuts which might damage the
blades of your mower. After mowing, your lawnsweeper will
whisk away unsightly grass clippings –leaving your lawn
velvety smooth.
OPERATION
GUARANTEE
The merchandise you have purchased from us has been carefully engineered and manufactured under
Mid West Products rigid quality standards and should give you satisfactory, dependable operation.
However, like all mechanical merchandise, it may occasionally require adjustment or maintenance.
Should you need technical assistance, please contact MID WEST PRODUCTS.
