Middle Atlantic Products MPR-SEQ Series User manual

I-00539 Rev D
MPR-SEQ SERIES
Six Channel Sequencing Controller
Instruction Sheet
THANK YOU
Thank you for purchasing the MPR-SEQ Series Six (6) Channel Sequencing Controller. Please
read these instructions thoroughly before installing this product.
PRODUCT FEATURES
- Provides economical six (6) step sequencing using contact closure.
- Controls up to 30 modules, evenly distributed over five modules per channel.
- Sequencing can be initiated locally and remotely via contact closure.
(MPR-SEQ-1CA SHOWN)
Conforms to UL Stds
60950-1& 60065 & 1419
Certified to CSA Stds
C22.2 No. 60950-1& 60065

Page 2
1 2
5
6
4
3
7
FEATURES
WARNING !
During the installation and maintenance, the AC power must be disconnected
at the source of supply.
This installation should be made by a qualified service person and should
conform to all local codes.
(MPR-SEQA shown)
(REAR)
(FRONT)
LOCAL CONTROL BUTTONS
These two momentary push buttons (SYSTEM UP and DOWN) provide local control
of sequencer and are positioned for easy system testing. Pressing these buttons are
functionally equivalent to a closure on the remote control terminal block.
3
WARNING !
WARNING !
1
2
REMOTE CONTROL TERMINAL BLOCK
This three position terminal block is for the connection of customer provided remote
control wiring and switching devices. The three terminals are designated UP, COMMON
and DOWN. A momentary switch closure between UP and COMMON will initiate system
sequence UP. Output control relays, the contacts of which are connected to 6 output
terminal blocks 1 through 6 will CLOSE in numerical order. A Momentary Contact
Switch closure between DOWN and COMMON will initiate system sequence DOWN, turning
outputs off (contacts OPEN), in reverse order (6 through 1).
CHANNEL STATUS LEDs
These six yellow LEDs are adjacent to each channel terminal block and indicate the
status of the output relay contacts. An illuminated LED indicates that the output
contact is closed.
To be used indoors in dry location only.
Conforms to UL Stds
60950-1& 60065 & 1419
Certified to CSA Stds
C22.2 No. 60950-1& 60065

MASTER POWER SWITCH
This switch turns the sequencer on and off. While in the ON position the MPR-SEQ will
accept and process control signals. In the OFF position, control signals will not be
processed and all output contacts will remain OPEN. Turning this switch OFF with
control channels activated will turn all output channels off simultaneously.
LED POWER INDICATOR
This green LED will be illuminated whenever the master power switch is on and AC power
is applied to the controller.
Page 3
4
POWER CONNECTORS
Two parallel 30 Amp genderless power connectors are provided, and accept standard MPR
J-Series jumpers and T-Series tails. These connectors are for 120V AC (main) power.
NOTE: The MPR-SEQ-1CA receives power via power cord.
NOTE: MPR-SEQ-1CA has a integrated bonding stud.
FUNCTIONS
INTERVAL TIME
Control channel #1 will come ON immediately upon system activation. Subsequent
channels will be activated with a 2 second interval between each sequence step
(1 through 6). Total elapsed time for activation of all channels is 10 seconds. The
two second interval timing also applies to the sequence DOWN operation
(6 through 1). Interval time is not adjustable.
POWER FAILURE RESTART
The MPR-SEQA/MPR-SEQ-1CA will remember the status of the control channels after
a power failure.
Upon the reapplication of AC power, the following scenarios will apply:
A) If all channels are ON prior to power failure, the MPR-SEQA/MPR-SEQ-1CA
will sequence UP from the beginning (channels 1 through 6).
B) If the MPR-SEQA/MPR-SEQ-1CA was sequencing UP/DOWN or was OFF
during a power failure, the control channels will remain off.
OUTPUT CONTROL TERMINAL BLOCKS
Six, two pole terminal blocks are included (one for each control channel) and provide
dry contact output. These terminal blocks are for the connection of the MPR-SEQ to
(corresponding) RLM modules. The RLM modules will turn ON and OFF sequentially
as instructed by the MPR-SEQ.
5
6
7

Page 4
WARRANTY
Middle Atlantic Products, Inc. (the "Company") warrants the MPR Series Six Channel Sequencing Controller to be free from defects in
material or workmanship under normal use and conditions for a period of (3) three years from date of shipment by the company.
The Company's entire liability to the purchaser, and the purchaser's (or any other party's) sole and exclusive remedy, under this warranty
shall be limited, at the Company's option, to either (a) return of and refund of the price paid for, or (b) repair or replacement at the
Company's factory of the products purchased, or any part or parts thereof, which the Company has determined to be defective after
inspection thereof at the Company's factory.
This warranty does not cover damage due to acts of God, accident, misuse, abuse or negligence by parties other than the Company, or
any modification or alteration of the products. In addition, this warranty does not cover damage due to improper handling, assembly,
installation or maintenance.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL THE COMPANY BE LIABLE FOR ANY SPECIAL, INCIDENTAL,
INDIRECT, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION OR ANY OTHER PECUNIARY LOSS) ARISING OUT OF THE USE OF THE PRODUCTS PURCHASED, EVEN IF THE
COMPANY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE COMPANY'S LIABILITY TO THE PURCHASER
(OR ANY OTHER PARTY) HEREUNDER, IF ANY, SHALL IN NO EVENT EXCEED THE PURCHASE PRICE OF THE PRODUCTS PAID TO THE COMPANY.
Corporate Headquarters
Corporate Voice 973-839-1011 - Fax [phone] / International Voice [phone] - Fax [phone]
middleatlantic.com - [email protected]
Middle Atlantic Canada
Voice 613-836-2501 - Fax [phone] / middleatlantic.ca - [email protected]
Factory Distribution
USA: NJ - CA - IL Canada: ON - BC
2) The mounting hole pattern on the mounting bracket allows the module to mount any EIA compliant
rackrail.
It is recommended that a 10 - 100 Ω resistor be installed in series with the dry contact.
Select an appropriate power rating for the load current.
EXAMPLE:
100mA Load - 10 Ω Resistor
Power = 10 Ω • (100mA²) = 100mW (R • I²)
Use a resistor with a power rating AT LEAST twice the anticipated power. In this example a 10 Ω, ¼W
resistor is sufficient and commonly available.
USING THE MPR-SEQ TO CONTROL DEVICES WHEN A HIGH INITIAL LOAD IS PRESENT,
OR AN INDUCTIVE LOAD (SUCH AS A RELAY COIL)
INSTALLATION
MPR-SEQA
1) Refer to instruction sheet # I-00544, provided with the MPR raceway.
MPR-SEQ-1CA
1) Modules can be mounted to rackrail brackets or any flat surface using appropriate customer supplied
hardware.
MPR-SEQ
CONTROLLED
DEVICE
10 - 100 Ω
