AIR COOLER
OWNER’S MANUAL
10L AIR COOLER
MODEL:AC120-16AR
READ AND SAVE THESE INSTRUCTIONS
Attention: Pictures in the IM are for reference only.
GD Midea Environment Appliances MFG.Co.,Ltd.
No.28, Dong Fu Road, Hesui East Industrial Area, Dong Feng Town,
Zhongshan, Guangdong 528425 P.R.China

1. Non-specialized personnel or unauthorized repair personnel shall
not to repair or modify the machine.
2. It is forbidden to operate with wet hands to avoid electric shock.
3. Any power cord, which suffers from aging and knotting and whose
plug is damaged, should be stopped its use immediately, and must
be repaired by a professional manufacturer or equally qualified
personnel.
4. No cleaning, maintenance or movement of the unit is allowed if it
does not switch off.
5. If the unit is not in use for a long time, unplug the power cord.
6. To prevent accidental injury or damage to the unit, please do not
insert any foreign matter into the air inlet and outlet, because the
unit incorporates a high-speed wind rotor,
7. It is prohibited to use this unit in environments with flammable and
explosive gases and direct sunlight for a long period shall be
avoided.
8. Do not place this unit in an inclined or other uneven place to
prevent the unit from falling and causing damage to the unit or
internal parts.
9. This machine is suitable for indoor use instead of outdoor use.
10. This machine has a safety switch. If the honeycomb filter support
has not been installed well, the unit will not work as usual; when
the machine is working, do not remove the honeycomb filter frame.
11. At any time the water level in the tank shall not exceed "MAX"
(maximum) scale, and during humidification, the total water level in
the tank shall be controlled, and shall not be below "MIN"
(minimum) scale.
12. After the water tank is filled with water, do not tilt or collide with the
unit when placing or moving it. To move the unit body, please drive
it slowly from the side to prevent water overflow.
13. In using the unit, prohibit overturning to avoid any accident. If the
unit topples over accidentally, and it contains water, unplug the
power cord immediately and take it to repair store.
14. Do not place items on the unit, and covering the outlet is strictly
prohibited.
1
SAFETY INSTRUCTION

15. When wash the unit appearance, apply a damp cloth (or add a
little cleaning agent) to wipe, and never use corrosive cleaning
agent or solvent for cleaning. Never rinse the unit with water.
16. Do not have the air inlet and outlet of the unit close to walls,
curtains and other objects, or they may block the airflow and affect
air supply.
17. When the unit is running, do not knock at or shock the unit body
forcibly or it may lead to automatic shutdown, in which case simply
restart the unit.
18. In summer, the water in the tank may easily deteriorate and
generate odor, please pay attention to regular change of water; if
the indoor temperature is below zero in winter humidification, it is
best to use warm water for humidification.
19. Do not place the unit directly below the power outlet.
20. Do not use the unit around the tub, sprinkler or swimming pool.
21. Product repair must be carried out in a designated agency.
22. If the supply cord is damaged, it must be replaced by manufacturer
or its service agent or a similarly qualified person in order to avoid a
hazard.
23. Indoor use only.
24. To protect against the risk of electrical shock, do not immerse the
unit, cord or plug in water or other liquid.
25. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Young children should be
supervised to ensure that they do not play with the appliance.
26. When the appliance is not in use and before cleaning, unplug the
appliance from the outlet.
27. Keep electrical appliances out of reach from Children or infirm
persons. Do not let them use the appliances without supervision.
28. Unplug the appliance during filling and cleaning.
29. Prior to cleaning or other maintenance, the appliance must be
disconnected from the supply mains.
30. Use a soft cloth moisten with mild soap, and then use a dry cloth
to wipe it again.
2

Foot-wheel
Foot-Wheel Installation
Gently pull out the honeycomb
filter from the stand to remove it.
Removing the honeycomb filter
31.
Correct Disposal of this product
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm
to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
3
INSTALLATION INSTRUCTIONS
Name of components
Ice box
Honeycomb Filter
Water Tank
Water Tank Plug
Circlip
Considerate Hint:
1. Insert an ice box into the water tank before installing
the honeycomb filter.
2. When humidifying, water level in the Water Tank must
remain under MAX indication; replenish water if level
gets lower than MIN indication.
3. When filling the water tank, make sure that the stopper
and spring are properly positioned.
Honeycomb
Filter Frame
Honeycomb Filter

Battery Installation
Locking latch
Pull Notch
4
INSTRUCTIONS FOR USE
Instructions for key of remote controller
Considerate Hint:
1. Install the battery with positive side facing up.
2. Effective Range of Remote Control: within 5m
distance and 30-degree deflection in front of
Product.

5
Instructions for operation of body
EVA.
COOLER
PRO.
TIMER STYLE SPEED OSC. ON/OFF
TROUBLESHOOTING
In case the product cannot be operated normally after installation, checks
shall be made for items described bellow:
1. Power cable unplugged or faulty contact.
2. Honeycomb filter assembly not properly installed.
3. Power Switch on the back of product or in the display panel not switched
on.
If product remains dysfunctional after checking, a local dealer shall be
sought for assistance.
Press a key on the unit to activate a corresponding function.
For instance:
● Press [SPEED] Key to adjust 3 speeds of air flow.
● Press [STYLE] Key to switch between Natural and Sleep Functions.
● Press [PRO./TIMER] Key：When the fan is on, press the“PRO./TIMER”
key to time the fan to shut down after 1-7 hours. In stand-by mode, you
can pre-set the fan to start in 1-7 hours.
● When [EVA./COOLER] Key is pressed, the indicator lights up constantly
if the operation is normal; when the indicator flashes, it denotes a water
shortage, please add water immediately.
Please note:Push Buttons on the unit may differ based on the actual product model.

MAINTENANCE
Never clean the product with
any abrasive tool or solvent.
Clean with detergent and wipe
dry with cloth immediately.
Never dismantle the product
or attempt to make any
modification. Regular check
and cleaning of the product is
recommended for prolonging
its lifespan.
Make sure power supply is
disconnected before cleaning
the product.
Never wash the unit in water.
For cleaning, remove
components (water tank,
honeycomb filter, etc.) and
clean them with water and soft
brush. Allow them to air-dry
before re-assembling.
