AIR-COOLED SCROLL MODULAR CHILLER
TECHNICAL SERVICE MANUAL
R410A (30kW-250kW) 50Hz
Models:
MCC(D)H30A-TA3SL
MCC(D)H65A-SA3L
MCCH130A-SA3L
MCCH185A-SA3
MCCH250A-SA3T
DM13-01.01.14en
Библиотека СОК 

Air-cooled modular chiller unit
Content
1 General information ................................................................................ 3
2. Features ...................................................................................................5
3. Specification ...........................................................................................9
4 Dimension ..............................................................................................17
5 Refrigeration system drawing ..............................................................27
6. Piping diagram ...................................................................................... 30
7 Wiring diagrams.....................................................................................36
8 Electric characteristics .........................................................................50
9 Capacity tables ......................................................................................51
10 Troubleshooting ................................................................................. 61
11 Installation .......................................................................................... 77
1 Commissioning .................................................................................. 1
1 Maintenance ....................................................................................... 1
1 Control system .................................................................................. 1
Appendix .................................................................................................

Air-cooled modular chiller unit
3
1 General information
1.1Nomenclature
1.2 Product schedule
No Model Power supply Heat
exchanger type Maximum combinations Maximum capacity(kW) Wired controller
1 MCCH30A-TA3SL 380~ 415V/3ph/50Hz Double pipe 1 30 KJR-120A/MBE
2 380~415V/3ph/50Hz Double pipe 1 30 KJR-120A/MBE
3MCCH65A-SA3L 380~400V/3ph/50Hz Shell and tube 16 1040
KJR-120A/MBE
4 MCCD65A-SA3L 380~415V/3ph/50Hz Shell and tube 16 1040 KJR-120A/MBE
5 MCCH130A-SA3L 380~400V/3ph/50Hz Shell and tube 8 1040 KJR-120A/MBE
6 MCCH185A-SA3 380~400V/3ph/50Hz Shell and tube 5 1000
7 MCCH250A-SA3T 380~400V/3ph/50Hz Shell and tube 8 2000 KJR-120A/MBE
Technical features
S: Hydraulic module;
L: Low temperature cooling;
T: T3 condition (up to +52 °С).
Power supply
3: 3Ph, 380~415V, 50 Hz.
Refrigerant type
A: R410A.
The heat exchanger type
S: Shell and tube;
T: Double pipe.
Series, modication
A...Z
Rated cooling capacity
kW*1.
Function mode
H: Cooling and heating mode;
C: Cooling only.
Type and technology of compressor
D: Digital Scroll;
C: Constant speed.
System type
С: Modular chiller.
Midea
С H A A SM C S L3
130
KJR-120A/MBE
MCDH30A-TA3SL

Air-cooled modular chiller unit
4
1.3 External appearance:
MCCH30A-TA3SL
MCDH30A-TA3SL
MCCH130A-SA3L
MCCH185A-SA3
MCCH250A-SA3T
MCCH65A-SA3L
MCCD65A-SA3L

Air-cooled modular chiller unit
5
2. Features
1). Low ambient temperature cooling function (Available for MCC(D)H30A-TA3SL,
MCC(D)H65A-SA3L, MCCH130A-SA3L)
The ambient temperature is down to -10℃ in cooling mode, and heating down to -10˚C ambient by added
one board (see picture1). Wide ambient temperature range are available by adjustable address between
different conditions to meet different requirements.
Mode
Ambient temp.
Cooling
Normally（S8 address OFF）
10~46℃
※Low temp. (S8 address ON)
-10~46℃
Heating
-10~21℃
2). Wide range of outlet water temperature (For the module with KJR-120A/MBE)
Cooling: 5~17˚C (Set in factory), 0~17˚C can be available by switch the S5 on PCB, the antifreeze must be
put into pipeline.
Heating: 40~50˚C (Set in factory), 22~50˚C can be available by switch the address.
Mode
Outlet water temp.
Cooling(S5 address)
Normally(OFF)
5~17℃
Low water temp.(ON)
0~17℃
Heating(S4 address)
Normally(OFF)
40~50℃
Low water temp. (ON)
22~50℃
3).Built-in hydraulic module (Available for MCC(D)H30A-TA3SL)
The unit built-in hydraulic module to simplified installation, save space and beautification appearance,
simultaneous effectively reduce installation costs and covering area.

Air-cooled modular chiller unit 50Hz MCAC-ATSM-2012-10
6
4).Humanized remote control (For the module with KJR-120A/MBE)
S7 address on PCB should be switched to ON to realize remote
control, which including remote ON/OFF, remote heating and
cooling mode selection, remote alarm. The customer can simply
and conveniently control the chiller and acquire the running
information on real time in door.
5)Digital scroll technique，new type modular air-cooled chiller
system.
Capacity output is controlled depending on controlling compressor to on/off in traditional modular air-cooled
chiller system control. The precision of the control mode is not very good, and the compressor is frequently
on and off, which is very bad for the compressor‟s life.
Digital scroll modular air-cooled chiller system breaks traditional design, which is inconceivably designed
with digital scroll compressor and constant scroll compressor parallel connection. The system can achieve
linear capacity output within 0.5%-100%, the scope is widest in industry. When the system operates at the
part-load, the system can accurately adjust cooling and heating capacity output basing on actual
requirement of the indoor room.
6).Modular design, flexible combination, more convenient for design and installation.
The unit adopt modular design, which can makes more unit connect together. The unit can be combined
max. 16 separate module(30, 65kW module) or 8 module (250kW module).Cooling(heating)
capacity can be increased step by step by 5kW per each time within 30kW-2000kW,meanwhile every
separate module can be operated as main unit, also each module can be a slave unit with modules
combination, more convenient for design and installation.
7).The maximum combination of the system consists of 1 main unit and 15 slave units for
65kW module, 1 main unit and 7 slave units for 130kW module, 1 main unit and 4
slave units
for 185kW module，1 main unit and 7 slave units for 250kW module.
Easy connection between main unit and slave units.
All the units can be connected together with a wired controller in series type. Using three-core shielded
twisted wire as communication wire.
Max 8 modules
2000kW
250kW
250kW
1.2
60
120
180
240
0
25
50
75
100
Capacity output
(%)
Capacity output of digital modular air-cooled chiller system

Air-cooled modular chiller unit
7
Wired controller
Three-core shielding
twisted pair
Three-core shielding
twisted pair
Water outlet temp. Water outlet temp. Water outlet temp.
Total water outlet temp.
(Just for master unit)
Total water outlet temp.
(Just for master unit)
Total water outlet temp.
(Just for master unit)
8).Environmental care
Ecological R410A refrigerant.
 Chlorine-free and environmental friendly refrigerant, zero ozone depletion potential.
 High density refrigerant, therefore, less refrigerant required.
 Leak-tight refrigerant circuit, Brazed refrigerant connections for increased leak-tightness.
9) Economical operation
New design adopts electronic expansion valve precise refrigerant control in wider range. Electronic
expansion valve allows operation at lower condensing pressure, adjustment can be made fast linear
response, making the system more stable output, the indoor temperature more uniform, and enhance
human comfortable.
10).Compact structure
Air cooled modular chiller structure are compact, light weight. The system adopts double pipe, shell and tube
heat exchanger, not only greatly enhanced the transfer performance, but also reduce the unit weight, the
lightest single module only has 380kg.
11).Backup function
When unit is failed.
 If master unit fails, all the units will stop.
 If one slave unit fails, this unit will stop but the others will keep running.
 When the master unit fails, any of the slave one can be set as the master unit by manual setting.
When unit is under protection
 If master unit‟s protection occurs, this unit will stop but the others will keep running.
 If slave unit‟s protection occurs, this unit will stop but the others will keep running.
 ( Except PE, P9 protection happen)
PE： Low temperature protection of evaporator.
P9： Outlet and inlet water temperature difference protection.
Master Slave
Master Slave

Air-cooled modular chiller unit 50Hz MCAC-ATSM-2012-10
8
12).Strong micro-computer intelligent control and monitor function
Optimizing the design of system and using varieties of protection devices, to make the system more safe
and reliable.
13). Superior reliability
System will be more reliable with new type efficient heat exchanger.
Evaporator 30kW module adopts double pipe heat exchanger ，evaporator of
65kW ,130kW, 185kW and 250kW modules adopt shell and tube heat exchanger.
Double pipe heat exchanger Shell and tube heat exchanger
14). Applicable temperature range
Mode
Ambient temperature
range
Water outlet temperature range
Application module
Cooling
10˚C ~46˚C
0~17˚C(The antifreeze must be added)
The module with KJR-120A/MBE
-10˚C ~46˚C
5˚C ~17˚C
Available for MCC(D)H30A-TA3SL,
MCC(D)H65A-SA3L , MCCH130A-SA3L
Heating
-10˚C ~21˚C
22˚C ~50˚C
The module with KJR-120A/MBE
Chilled outlet water temperature can be adjusted by wired controller according to customer‟s demand.
-15 ˚C
Ambient temp. range
-10 ˚C
-5 ˚C
0 ˚C
5 ˚C
10 ˚C
15 ˚C
20 ˚C
25 ˚C
30˚C
35 ˚C
40 ˚C
45 ˚C
Cooling range
10 ˚C
46 ˚C
Heating range
-10 ˚C
21 ˚C
Water outlet temp. range
5 ˚C
17 ˚C
50 ˚C
5 ˚C
17 ˚C
Heating range
Cooling range
45 ˚C
22 ˚C
0 ˚C
45 ˚C
50 ˚C
Cooling range
0 ˚C
17 ˚C
Heating range
22 ˚C
50 ˚C
Cooling range
-10 ˚C
46 ˚C
50 ˚C

Air-cooled modular chiller unit
9
Model
MCCH30A-TA3SL MCDH30A-TA3SL
Cooling Capacity
kW
30
30
Btu/h
102,300
102,300
Heating Capacity
kW
32
32
Power supply
V/Ph/Hz
380-415/3/50
Power supply
Manual switch
A
50
Fuse
A
36
Compressor
Type
Fixed speed
Digital Scroll + Fixed speed
Quantity
Pieces
1+1
1+1
Model
ZP67KCE-TFD-522
ZPD67KCE-TFD-532/
ZP67KCE-TFD-522
Brand
Copeland
Capacity
W
16200×2
Input
W
5200×2
Rate current(RLA)
A
9.1×2
Locked rotor Amp(LRA)
A
74×2
Power input
Cooling
kW
10
10
Cooling rated current
A
16.3
16.3
Heating
kW
9.8
9.8
Heating rated current
A
16
16
Max. Input consumption
kW
13.4
Max. Current
A
22.5
Refrigerant
Type
R410A
Weight
kg
3.5×2
Refrigerant control
EXV
Condenser
(Air side)
Air side heat-exchanger type
Fin-coil
Quantity of fan motor
Pieces
1
Air flow
×103m3/h
12
Fan motor input
kW
0.55
Evaporator
(Water side)
Water side heat-exchanger type
Double-pipe
Water resistance loss
kPa
/
Water inlet/outlet pipeline inside
normal diameter
mm
DN40
inch
1-1/2”
Water flow
m3/h
5.2
5.2
Max. Pressure
MPa
1
Water pipe connection type
Flexible joint
Dimension
Net(W×H×D)
mm
1514×1865×841
inch
59.6×73.4×33.1
Packing(W×H×D)
mm
1590×2065×995
inch
62.6×81.3×39.2
Weight
Net weight
kg
430
Operation weight
kg
450
Connection wire
Power wire
mm2×No.
10×4+6×1
Signal wire
mm2×No.
0.75×3-core with shielding
Control type
Wired controller
3. Specification

Air-cooled modular chiller unit
10
Note:
Please refer to the water flow volume in the above table strictly to design and install.
All the above data is measured base on the following working condition:
1. Cooling mode: water side fouling factor: 0.086m2·℃ /kW, chilled water inlet/outlet: 12℃ / 7℃, and outdoor ambient temp. of
35℃ DB.
2. Heating mode: water side fouling factor: 0.086m2·℃/kW, warm water inlet/outlet: 40℃ / 45℃, and outdoor ambient temp.
7℃ DB/6℃ WB.
Safety protection device
1) Protection for over-high discharge pressure.
2) Protection for over-low suction pressure.
3) Power supply phase sequence protection.
4) Anti-freezing protection in cooling mode.
5) Anti-freezing protection in Winter.
6) Protection for compressor over current.
7) Protection for compressor overload.
8) Outlet and inlet water temperature difference
protection.
9) Compressor discharge temperature protection.
10) Water flow cut-off protection.
11) Sensor malfunction protection.
12) Low ambient temperature drive-up protection
13) Low temperature protection of shell and tube heat
exchanger.
Noise level(semi-anechoic )
dB(A)
67
Operation water temp
℃
Cooling：0～17(Less than 5℃ must add antifreeze)
Heating：22～50
Ambient temp
℃
Cooling：-10～46
Heating：-10～21

Air-cooled modular chiller unit
11
Model
MCCH65A-SA3L MCDH65A-SA3L
Cooling Capacity
kW
65
65
Heating Capacity
kW
69
69
Power input
Cooling
kW
20.4
20.4
Cooling rated current
A
36.5
36.5
Heating
kW
21.5
21.5
Heating rated current
A
37.2
37.2
Power supply
V/Ph/Hz
380-400/3/50
380-415/3/50
Power supply
Manual switch
A
150
150
Fuse
A
100
100
Max. Input consumption
kW
27.9
27.1
Max. Current
A
50
51.7
Compressor
Type
Scroll (fixed speed)
Scroll (fixed speed + digital
scroll)
Brand
Danfoss
Copeland
Model
SH140A4ALC
ZP144KCE-TFD-522 /
ZPD72KCE-TFD-433 /
ZP67KCE-TFD-420
Quantity
Pieces
2
3
Capacity
W
34700×2
36
17
16.3
Input
W
10860×2
10.8
5.75
5.2
Rate current(RLA)
A
21.4×2
18.7
9.8
9.1
Locked rotor Amp(LRA)
A
147×2
144
82.4
74
Refrigerant
Type
R410A
R410A
Refrigerant control
EXV+ capillary
EXV+ capillary
Weight
kg
7.0×2
7.0×2
Condenser (Air
side)
Air side heat-exchanger type
Fin-coil
Fin-coil
Quantity of fan motor
Pieces
2
2
Air flow
×103m3/h
24
24
Fan motor input
kW
0.865×2
0.865×2
Evaporator (Water
side)
Water side heat-exchanger type
Shell and tube
Shell and tube
Water resistance loss
kPa
15
15
Water inlet/outlet pipeline
inside normal diameter
mm
DN100
DN100
Water flow
m3/h
11.2
11.2
Max. Pressure
MPa
1
1
Water pipe connection type
Flexible joint
Flexible joint
Dimension
Net(W×H×D)
mm
2000×1880×900
2000×1880×900
Packing size(W×H×D)
mm
2106×2090×998
2106×2090×998
Weight
Net weight
kg
580
610
Operation weight
kg
650
680
Connection
Power current
mm2
25×4+16×1
25×4+16×1
Signal wiring
mm2
0.75×3-core with shielding
0.75×3-core with shielding
Control type
Wired controller
Wired controller

Air-cooled modular chiller unit
12
Safety protection device
1) Protection for over-high discharge pressure.
2) Protection for over-low suction pressure.
3) Power supply phase sequence protection.
4) Anti-freezing protection in cooling mode.
5) Anti-freezing protection in Winter.
6) Protection for compressor over current.
7) Protection for compressor overload.
8) Outlet and inlet water temperature difference protection.
9) Compressor discharge temperature protection.
10) Water flow cut-off protection.
11) Sensor malfunction protection.
12) Low ambient temperature drive-up protection
13) Low-temperature protection of shell and tube heat
exchanger.
Noise level
dB(A)
67
Operation water temp
℃
Cooling：0～17（Less than 5℃ must add antifreeze）
Heating：22～50
Ambient temp
℃
Cooling：-10～46 Heating：-10～21
Note:
Please refer to the water flow volume in the above table strictly to design and install.
All the above data is measured base on the following working condition:
1. Cooling mode: water side fouling factor: 0.086m2·℃ /kW, chilled water inlet/outlet: 12℃ / 7℃, and outdoor ambient temp. of
35℃ DB.
2. Heating mode: water side fouling factor: 0.086m2·℃/kW, warm water inlet/outlet: 40℃ / 45℃, and outdoor ambient temp.
7℃ DB/6℃ WB.

Air-cooled modular chiller unit 50Hz
13
Model
MCCH130A-SA3L
Cooling Capacity
kW
130
Btu/h
443,560
Heating Capacity
kW
138
Power supply
V/Ph/Hz
380-400/3/50
Power
supply
Manual switch
A
250
Fuse
A
200
Compressor
Type
Fixed speed Scroll
Quantity
Pieces
4
Model
SH140A4ALC
Brand
Danfoss
Capacity
kW
34.7×4
Input
kW
10860×4
Rate current(RLA)
A
21.4×4
Locked rotor Amp(LRA)
A
147×4
Power input
Cooling
kW
40.8
Cooling rated current
A
73
Heating
kW
43.0
Heating rated current
A
74.4
Max. Input consumption
kW
55.5
Max. Current
A
93.8
Refrigerant
Type
R410a
Weight
kg
7×4
Refrigerant control
EXV+ capillary
Condenser
(Air side)
Air side heat-exchanger type
Fin-coil
Quantity of fan motor
Pieces
4
Air flow
×103m3/h
48
Fan motor input
kW
0.88×4
Evaporator
(Water side)
Water side heat-exchanger type
Shell and tube
Water resistance loss
kPa
25
Water inlet/outlet
pipeline inside normal
diameter
mm
DN65
inch
2-1/2”
Water flow
m3/h
22.4
Max. Pressure
MPa
1
Water pipe connection type
Flexible joint
Dimension
Net(W×H×D)
mm
2000×2080×1685
inch
78.7×82.3×66.3
Packing(W×H×D)
mm
2090×2240×1755
inch
82.3×88.2×69

Air-cooled modular chiller unit
14
Weight Net weight kg 1150
Operation weight kg 1270
Power wire mm2×No. 35×3+16×2
Signal wire mm2×No.
Control type
Safety protection device
Noise level(semi-anechoic) dB(A) 74
Operation water temp
Cooling：0〜17
（Less than 5°C
must add
antifreeze）
Heating：22〜50
Ambient temp Cooling：-10〜46
Heating：-10〜21
Wired controller
0.75x3-core
°C
°C
1) Protection for
over-high discharge
pressure.
2) Protection for over-low
suction pressure.
3) Power supply phase
sequence protection.
4) Anti-freezing
protection in cooling
mode.
5) Anti-freezing
protection in Winter.
6) Protection for
compressor over current.
7) Protection for
compressor overload.
8) Outlet and inlet water
temperature dierence
protection.
9) Compressor discharge
temperature protection.
10) Water ow cut-o
protection.
11) Sensor malfunction
protection.
12) Low ambient
temperature drive-up
protection
13) Low-temperature
protection of shell and
tube heat exchanger.
Note:
Please refer to the water ow volume in the above table strictly to design and install.
All the above data is measured base on the following working condition:
1. Cooling mode: water side fouling factor: 0.086m2·°C/kW, chilled water inlet/outlet: 12°C / 7°C, and outdoor ambient temp. of
35°C DB.
2. Heating mode: water side fouling factor: 0.086m2·°C/kW, warm water inlet/outlet: 40°C / 45°C, and outdoor ambient temp.
7°C DB/6°C WB.

Air-cooled modular chiller unit
15
Model
MCCH185A-SA3
MCCH250A-SA3T
Cooling Capacity
kW
185
250
Btu/h
631,220
830,000
Heating Capacity
kW
200
270
Power supply
V/Ph/Hz
380-400/3/50
380-400/3/50
Power supply
Manual switch
A
400
450
Fuse
A
300
350
Compressor
Type
Scroll (fixed speed)
Scroll (fixed speed)
Quantity
Pieces
6
8
Model
SH140A4ALC
SH120A4ALC
Brand
Danfoss
Danfoss
Capacity
W
34.7×6
111231
Input
W
10860×6
10275
Rate current(RLA)
A
21.4×6
20.88
Locked rotor Amp(LRA)
A
147×6
177
Power input
Cooling
kW
63
78.3
Cooling rated current
A
110
141.9
Heating
kW
61
80
Heating rated current
A
107
146
Max. Input consumption
kW
78.3
78.3
Max. Current
A
133.4
133.4
Refrigerant
Type
R410A
R410A
Weight
Kg
7×6
15×4
Refrigerant control
EXV+ capillary
EXV+ capillary
Condenser
(Air side)
Air side heat-exchanger type
Fin-coil
Fin-coil
Quantity of fan motor
Pieces
6
8
Air flow
×103m3/h
72
96
Fan motor input
kW
0.88×6
0.7×8
Evaporator
(Water side)
Water side heat-exchanger type
Shell and tube
Shell and tube
Water resistance loss
kPa
30
40
Water inlet/outlet
pipeline inside normal
diameter
mm
DN80
DN100
inch
3”
4”
Water flow
m3/h
31.8
43
Max. Pressure
MPa
1
1
Water pipe connection type
Flexible joint
Flexible joint
Dimension
Net(W×H×D)
mm
2850×2110×2000
3800×2130×2000
inch
112.2×83.1×78.7
149.6×83.86×78.74
Packing(W×H×D)
mm
2980×2260×2135
3900×2200×2100
inch
117.3×89×84.1
153.54×86.61×82.68
Weight
Net weight
kg
1730
2450
Operation weight
kg
2000
2600
Connection wire
Power wire
mm2×No.
75×3+35×2
185×4+70×1
Signal wire
mm2×No.
0.75×3-core with shielding
0.75×3-core with shielding
Control type
Wired controller
Wired controller

Air-cooled modular chiller unit
16
Note:
Please refer to the water flow volume in the above table strictly to design and install.
All the above data is measured base on the following working condition:
1. Cooling mode: water side fouling factor: 0.086m2·℃ /kW, chilled water inlet/outlet: 12℃ / 7℃, and outdoor ambient temp. of
35℃ DB.
2. Heating mode: water side fouling factor: 0.086m2·℃/kW, warm water inlet/outlet: 40℃ / 45℃, and outdoor ambient temp.
7℃ DB/6℃ WB.
.
Safety protection device
1) Protection for over-high
discharge pressure.
2) Protection for over-low suction
pressure.
3) Power supply phase
sequence protection.
4) Anti-freezing protection in
cooling mode.
5) Anti-freezing protection in
Winter.
6) Protection for compressor
over current.
7) Protection for compressor
overload.
8) Outlet and inlet water
temperature difference
protection.
9) Compressor discharge
temperature protection.
10) Water flow cut-off protection.
11) Sensor malfunction
protection.
12)Low temperature protection
of shell and tube heat
exchanger.
1) Protection for over-high
discharge pressure.
2) Protection for over-low suction
pressure.
3) Power supply phase
sequence protection.
4) Anti-freezing protection in
cooling mode.
5) Anti-freezing protection in
Winter.
6) Protection for compressor
over current.
7) Protection for compressor
overload.
8) Outlet and inlet water
temperature difference
protection.
9) Compressor discharge
temperature protection.
10) Water flow cut-off protection.
11)Sensor malfunction
protection.
12)Low ambient temperature
drive-up protection
13)Low temperature protection
of shell and tube heat
exchanger.
Noise level(semi-anechoic)
dB(A)
70
74
Operation water temp
℃
Cooling：5～17
Heating：45～50
Cooling：0～17( Less than 5℃
must add antifreeze)
Heating：22～50
Ambient temp
℃
Cooling：10～46
Heating：-10～21
Cooling：10～52
Heating：-10～21

Air-cooled modular chiller unit
17
30kW module
1865
874
317
Front view
Left view
Top view
4 Dimension

Air-cooled modular chiller unit
18
1
1
2
4
5
6
3
NO.
NAME
1 2 3 4 5 6
Air outletAir inlet Water outlet DrainWater inlet Make-up
water inlet

Air-cooled modular chiller unit
19
65kW module
Front view
Top view
Model
Unit
A
B
C
D
E
F
G
H
I
J
K
MCC(D)H65A-SA3L
mm
2000
900
1880
350
1420
225
1500
506
530
930
450
inch
78.74
35.4
74
13.78
55.91
8.86
59.06
19.92
20.87
36.61
17.72

Air-cooled modular chiller unit
20
No.
Name
1
Top cover
2
Air outlet
3
Air inlet
4
Water outlet
5
Compressor
6
Electric control box
7
Water inlet
