Midea MGCT-F30W/PN1 User manual

R410A tropical air-cooled scroll chiller unit 60Hz MCAC-ATSM-2014-09
2
Content
1 General information.......................................................................................3
2. Features.........................................................................................................4
3. Specification .................................................................................................8
4 Dimension ....................................................................................................14
5 Refrigeration system drawing.....................................................................22
6. Piping diagram............................................................................................24
7 Wiring diagram.............................................................................................28
8 Electric characteristics................................................................................36
9 Capacity tables ............................................................................................38
10 Exploded view............................................................................................46
11 Trouble shooting........................................................................................61
12 Installation..................................................................................................76
13 Commissioning........................................................................................101
14 Maintenance.............................................................................................102
15 Control system.........................................................................................106
Appendix .....................................................................................................167

MCAC-ATSM-2014-09 R410A tropical air-cooled scroll chiller unit 60Hz
3
1 General information
1.1 Nomenclature
MG BT- F60 W / PN1
1.2 Product list
No
Model
Power supply
Heat exchanger
type
Maximum
combinations
Maximum
capacity(kW)
Wired controller
1
MGCT-F30W/PN1
380V/3Ph/60Hz
Double pipe
16
480
KJRM-120D/BMK-E
2
MGCT-D30W/PN1
380V/3Ph/60Hz
Double pipe
16
480
KJRM-120D/BMK-E
3
MGBT-F60W/PN1
380V/3Ph/60Hz
Shell and tube
16
960
KJRM-120D/BMK-E
4
MGBT-F120W/PN1
380V/3Ph/60Hz
Shell and tube
8
960
KJRM-120D/BMK-E
5
MGBT-F180W/PN1
380V/3Ph/60Hz
Shell and tube
5
900
KJRM-120D/BMK-E
Refrigerant type
N1:R410A Omit for R22
Power Supply
P: 380V, 60Hz, 3Ph
D: 220V, 60Hz, 3Ph
Outdoor Unit
Rated cooling capacity (kW)
The special function code
D: Digital scroll
F: Fixed scroll
V: Inverter system
T: T3 condition
Omit for T1 condition
The heat exchanger type
A: Plate
B: Shell and tube
C: Double pipe
Light chiller system
Midea

R410A tropical air-cooled scroll chiller unit 60Hz MCAC-ATSM-2014-09
4
1.3 External appearance
60kW
120kW
180kW
30kW

MCAC-ATSM-2014-09 R410A tropical air-cooled scroll chiller unit 60Hz
5
2. Features
1). Wide range of outlet water temperature
Cooling: 5~17˚C (7˚C is default, set in factory), 0~17˚C can be available by switch the S5 on PCB, the
antifreeze must be put into pipeline.
Heating: 40~50˚C (45˚C is default, set in factory), 22~50˚C can be available by switch the address.
Mode
Outlet water temp.
Cooling(S5
address)
Normally(OFF)
5~17℃
Low water temp.(ON)
0~17℃
Heating(S4
address)
Normally(OFF)
40~50℃
Low water temp. (ON)
22~50℃
2).Humanized remote control
S7 address on PCB should be switched to ON to realize remote
control, which including remote ON/OFF, remote heating and
cooling mode selection, remote alarm. The customer can simply
and conveniently control the chiller and acquire the running
information on real time in door.
3).Modular design, flexible combination, more convenient for design and installation.
The unit adopts modular design, which can make more units to connect together. The units can be
combined freely, meanwhile every separate module can be operated as main unit, also each module can be
a slave unit with modules combination, more convenient for design and installation.
4).The maximum combination of the system consists of 1 main unit and 15 slave units for
30kW&60kW modules, 1 main unit and 7 slave units for 120kW module, 1 main unit and 4 slave units
for 180kW module.
Easy connection between main unit and slave units.
All the units can be connected together with a wired controller in series type. Using three-core shielded
twisted wire as communication wire.
Wired controller
Three-core shielding
twisted pair Three-core shielding
twisted pair
Water outlet temp. Water outlet temp. Water outlet temp.
Total water outlet temp.
(Just for master unit) Total water outlet temp.
(Just for master unit) Total water outlet temp.
(Just for master unit)
5).Environmental care
Ecological R410A refrigerant.
60kW
60kW
960kW
Max 16 modules

R410A tropical air-cooled scroll chiller unit 60Hz MCAC-ATSM-2014-09
6
Chlorine-free and environmental friendly refrigerant, zero ozone depletion potential.
High-density refrigerant, therefore, less refrigerant required.
Leak-tight refrigerant circuit, Brazed refrigerant connections for increased leak-tightness.
6) Economical operation
New design adopts electronic expansion valve precise refrigerant control in wider range. Electronic
expansion valve allows operation at lower condensing pressure, adjustment can be made fast linear
response, making the system more stable output, the indoor temperature more uniform, and enhance
human comfortable.
7).Back up function
When unit is failure
If master unit fails, all the units will stop.
If one slave unit fails, this unit will stop but the others will
keep running.
When the master unit fails, any of the slave one can be set
as the master unit by manual setting.
When unit is under protection
If master unit’s protection occurs, this unit will stop but the
others will keep running.
If slave unit’s protection occurs, this unit will stop but the
others will keep running.
( Except PE, P9 protection happen)
8).Strong micro-computer intelligent control and monitor function.
Optimizing the design of system and using varieties of protection devices, to make the system more safe
and reliable.
9). Superior reliability
System will be more reliable with new type efficient heat exchanger. The 30kW module adopts double pipe
heat exchanger, the 60&120&180kW module adopt shell and tube heat exchanger for evaporator.
Shell and tube heat exchanger
Master Slave
Master Slave

MCAC-ATSM-2014-09 R410A tropical air-cooled scroll chiller unit 60Hz
7
10). Applicable temperature range
Mode
Ambient temperature range
Water outlet temperature range
Cooling
10˚C ~52˚C
0~17˚C(The antifreeze must be added.)
Heating
-10˚C ~24˚C
22˚C ~50˚C
Chilled outlet water temperature can be adjusted by wired controller according to customer’s demand.
-15˚C
Ambient temperature range
-10˚C
-5˚C
0˚C
5˚C
10˚C
15˚C
20˚C
25˚C
30˚C
35˚C
40˚C
45˚C
50˚C
Cooling range
10˚C
52˚C
Heating range
-10˚C
24˚C
Water outlet temperature range
5˚C
17˚C
50˚C
5˚C
17˚C
Heating range
Cooling range
40˚C
22˚C
0˚C
40˚C
50˚C
Cooling range
0˚C
17˚C
Heating range
22˚C
50˚C

R410A tropical air-cooled scroll chiller unit 60Hz MCAC-ATSM-2014-09
8
3. Specification
Model
MGCT-F30W/PN1
MGCT-D30W/PN1
Cooling Capacity (*1)
kW
30
30
Btu/h
102,300
102,300
Cooling Capacity (*2)
kW
25.8
25.8
Btu/h
88,030
88,030
Heating Capacity
kW
32
32
Power input
Cooling (*1)
kW
10.0
10.0
Cooling rated current (*1)
A
16.3
16.3
Cooling (*2)
kW
12
12
Cooling rated current (*2)
A
19.56
19.56
Heating
kW
9.8
9.8
Heating rated current
A
16.0
16.0
Power supply
V/Ph/Hz
380/3/60
380/3/60
Power supply
Manual switch
A
50
50
Fuse
A
36
36
Max. Input consumption
kW
14.8
13.8
Max. Current
A
25.3
24.2
Compressor
Type
Scroll (fixed speed)
Scroll (Digital +fixed speed)
Brand
Copeland
Copeland
Model
ZP57K3E-TF7-522
ZPD51K5E-TF7-532/
ZP57K3E-TF7-522
Quantity
Pieces
2
1+1
Capacity
Btu/h
58000
50400/58000
Input
kW
5.48
4.71/5.48
Rate load current(RLA)
A
10.1
9.6/10.1
Locked rotor Amp(LRA)
A
94
65.6/94
Refrigerant oil
ml
1685
1242/1685
Refrigerant
Type
R410A
R410A
Refrigerant control
EXV
EXV
Weight
lb
6.834×2
6.834×2
Condenser (Air side)
Air side heat-exchanger type
Fin-coil
Fin-coil
Quantity of fan motor
Pieces
1
1
Air flow volume
×103m3/h
12
12
Fan motor model
YDK550-8B
YDK550-8B
Fan motor rated current
A
4
4
Fan motor input
kW
0.85
0.85
Evaporator (Water
side)
Water side heat-exchanger type
Double pipe
Double pipe
Water resistance loss
kPa
60
60
Water inlet/outlet pipeline
inside normal diameter
inch
1-1/2”
1-1/2”
Water flow volume
m3/h
5.2
5.2
Max. Pressure
MPa
1
1
Water pipe connection type
Flexible joint
Flexible joint
Dimension
Net(W×H×D)
inch
59.61×73.43×33.11
59.61×73.43×33.11
Packing size(W×H×D)
inch
62.6×81.3×39.17
62.6×81.3×39.17

MCAC-ATSM-2014-09 R410A tropical air-cooled scroll chiller unit 60Hz
9
Weight
Net weight
lb
837.8
837.8
Gross weight
lb
881.8
881.8
Connection wiring
Power wire
mm2×No.
10×4+6 ×1
10×4+6 ×1
Signal wire
mm2×No.
0.75×3-core with shielding
Control type
Wired controller
Safety protection device
1) Protection for over-high discharge pressure
2) Protection for over-low suction pressure
3) Power supply phase sequence protection
4) Anti-freezing protection in cooling mode
5) Anti-freezing protection in winter
6) Protection for compressor over current
7) Protection for compressor overload
8) Outlet and inlet water temperature difference protection
9) Compressor discharge temperature protection
10) Water flow cut-off protection
11) Sensor malfunction protection
12) Low-temperature protection of shell and tube heat
exchanger.
Noise level
dB(A)
67
Operation water temperature
℃
Cooling：0～17(Less than 5℃must add antifreeze.)
Heating：22～50
Ambient temperature
℃
Cooling：10～52 Heating：-10～21
Note:
Please refer to the water flow volume in the above table strictly to design and install.
Specifications are based on the following conditions:
Cooling : (*1)chilled water inlet/outlet: 12℃/ 7℃, and outdoor ambient temp. of 35°C DB.
(*2) chilled water inlet/outlet: 12℃/ 7℃, and outdoor ambient temp. of 46°C DB.
Heating : warm water inlet/outlet: 40℃/ 45℃, and outdoor ambient temp. 7°C DB/6°C WB.
Water side fouling factor: 0.086m2·℃/kW.
1m away in open field (sound pressure).

R410A tropical air-cooled scroll chiller unit 60Hz MCAC-ATSM-2014-09
10
Model
MGBT-F60W/PN1
MGBT-F120W/PN1
Cooling Capacity (*1)
kW
60
120
Btu/h
204,700
409,400
Cooling Capacity (*2)
kW
51.6
103.2
Btu/h
176,100
352,100
Heating Capacity
kW
65
130
Power input
Cooling (*1)
kW
19.7
39.4
Cooling rated current (*1)
A
63
126
Cooling (*2)
kW
23.64
47.28
Cooling rated current (*2)
A
75.6
151.2
Heating
kW
19.9
39.8
Heating rated current
A
65.5
130
Power supply
V/Ph/Hz
380/3/60
380/3/60
Power supply
Manual switch
A
125
200
Fuse
A
100
150
Max. Input consumption
kW
26.9
51.44
Max. Current
A
48.7
95
Compressor
Type
Scroll (fixed speed)
Scroll (fixed speed)
Brand
Danfoss
Danfoss
Model
SH105A9ALC
SH105A9ALC
Quantity
Pieces
2
4
Capacity
Btu/h
97060
97060
Input
kW
9.9
9.9
Rate load current(RLA)
A
21.4
21.4
Locked rotor Amp(LRA)
A
124
124
Refrigerant oil
ml
3300
3300
Refrigerant
Type
R410A
R410A
Refrigerant control
EXV+ capillary
EXV+ capillary
Weight
lb
14.33×2
14.33×4
Condenser (Air
side)
Air side heat-exchanger type
Fin-coil
Fin-coil
Quantity of fan motor
Pieces
2
4
Air flow volume
×103m3/h
24
48
Fan motor model
YS650-8C
YS650-8C
Fan motor rated current
A
2.1×2
2.1×4
Fan motor input
kW
1.03×2
1.03×4
Evaporator (Water
side)
Water side heat-exchanger type
Shell and tube
Shell and tube
Water resistance loss
kPa
15
25
Water inlet/outlet pipeline
inside normal diameter
inch
4”
2-1/2”
Water flow volume
m3/h
10.3
20.6
Max. Pressure
MPa
1
1
Water pipe connection type
Flexible joint
Flexible joint
Dimension
Net(W×H×D)
inch
78.74×74.02×35.43
78.74×82.28×66.34
Packing size(W×H×D)
inch
82.28×82.48×38.78
81.89×88.19×69.09
Weight
Net weight
lb
1,300.727
2,601.455
Gross weight
lb
1,388.889
2,711.64
Connection wiring
Power wire
mm2×No
16×4+10 ×1
35×3+16 ×2

MCAC-ATSM-2014-09 R410A tropical air-cooled scroll chiller unit 60Hz
11
Signal wire
mm2×No
0.75×3-core with shielding
0.75×3-core with shielding
Control type
Wired controller
Wired controller
Safety protection device
1) Protection for over-high discharge pressure
2) Protection for over-low suction pressure
3) Power supply phase sequence protection
4) Anti-freezing protection in cooling mode
5) Anti-freezing protection in winter
6) Protection for compressor over current
7) Protection for compressor overload
8) Outlet and inlet water temperature difference protection
9) Compressor discharge temperature protection
10) Water flow cut-off protection
11) Sensor malfunction protection
12) Low-temperature protection of shell and tube heat
exchanger.
Noise level
dB(A)
67
70
Operation water temperature
℃
Cooling：0～17(Less than 5℃must add antifreeze.)
Heating：22～50
Ambient temperature
℃
Cooling：10～52 Heating：-10～21
Note:
Please refer to the water flow volume in the above table strictly to design and install.
Specifications are based on the following conditions:
Cooling : (*1)chilled water inlet/outlet: 12℃/ 7℃, and outdoor ambient temp. of 35°C DB.
(*2) chilled water inlet/outlet: 12℃/ 7℃, and outdoor ambient temp. of 46°C DB.
Heating : warm water inlet/outlet: 40℃/ 45℃, and outdoor ambient temp. 7°C DB/6°C WB.
Water side fouling factor: 0.086m2·℃/kW.
1m away in open field (sound pressure).

R410A tropical air-cooled scroll chiller unit 60Hz MCAC-ATSM-2014-09
12
Model
MGBT-F180W/PN1
Cooling Capacity (*1)
kW
180
Btu/h
614,100
Cooling Capacity (*2)
kW
154.8
Btu/h
528,200
Heating Capacity
kW
195
Power input
Cooling (*1)
kW
59.1
Cooling rated current (*1)
A
189
Cooling (*2)
kW
70.92
Cooling rated current (*2)
A
226.8
Heating
kW
59.7
Heating rated current
A
196.5
Power supply
V/Ph/Hz
380/3/60
Power supply
Manual switch
A
350
Fuse
A
300
Max. Input consumption
kW
76.5
Max. Current
A
140
Compressor
Type
Scroll (fixed speed)
Brand
Danfoss
Model
SH105A9ALC
Quantity
Pieces
6
Capacity
Btu/h
97060
Input
kW
9.9
Rate load current(RLA)
A
21.4
Locked rotor Amp(LRA)
A
124
Refrigerant oil
ml
3300
Refrigerant
Type
R410A
Refrigerant control
EXV+ capillary
Weight
lb
14.33×6
Condenser (Air side)
Air side heat-exchanger type
Fin-coil
Quantity of fan motor
Pieces
6
Air flow volume
×103m3/h
72
Fan motor model
YS650-8C
Fan motor rated current
A
2.1×6
Fan motor input
kW
1.03×6
Evaporator
(Water side)
Water side heat-exchanger type
Shell and tube
Water resistance loss
kPa
30
Water inlet/outlet pipeline
inside normal diameter
inch
3”
Water flow volume
m3/h
31
Max. Pressure
MPa
1
Water pipe connection type
Flexible joint
Dimension
Net(W×H×D)
inch
112.21×83.07×78.74
Packing size(W×H×D)
inch
117.32×88.98×84.06
Weight
Net weight
lb
3,813.93
Gross weight
lb
3,924.16
Connection wiring
Power wire
mm2×No.
70×3+35 ×2

MCAC-ATSM-2014-09 R410A tropical air-cooled scroll chiller unit 60Hz
13
Signal wire
mm2×No.
0.75×3-core with shielding
Control type
Wired controller
Safety protection device
12) Protection for over-high discharge pressure
13) Protection for over-low suction pressure
14) Power supply phase sequence protection
15) Anti-freezing protection in cooling mode
16) Anti-freezing protection in winter
17) Protection for compressor over current
18) Protection for compressor overload
19) Outlet and inlet water temperature difference
protection
20) Compressor discharge temperature protection
21) Water flow cut-off protection
22) Sensor malfunction protection
12) Low-temperature protection of shell and tube
heat exchanger.
Noise level
dB(A)
74
Operation water temperature
℃
Cooling：0～17(Less than 5℃must add
antifreeze.)
Heating：22～50
Ambient temperature
℃
Cooling：10～52 Heating：-10～24
Note:
Please refer to the water flow volume in the above table strictly to design and install.
Specifications are based on the following conditions:
Cooling : (*1)chilled water inlet/outlet: 12℃/ 7℃, and outdoor ambient temp. of 35°C DB.
(*2) chilled water inlet/outlet: 12℃/ 7℃, and outdoor ambient temp. of 46°C DB.
Heating : warm water inlet/outlet: 40℃/ 45℃, and outdoor ambient temp. 7°C DB/6°C WB.
Water side fouling factor: 0.086m2·℃/kW.

R410A tropical air-cooled scroll chiller unit 60Hz MCAC-ATSM-2014-09
14
4 Dimension
30kW module
Model
Unit
A
B
C
D
E
F
MGCT-F30W/PN1
MGCT-D30W/PN1
mm
1514
841
1865
115
315
172
inch
59.6
33.11
73.43
4.53
12.4
6.77

MCAC-ATSM-2014-09 R410A tropical air-cooled scroll chiller unit 60Hz
15
No.
Name
1
Top cover
2
Air outlet
3
Air inlet
4
Water outlet
5
Water inlet
6
Electric control box

R410A tropical air-cooled scroll chiller unit 60Hz MCAC-ATSM-2014-09
16
60kW module
Front view
Top view
Model
Unit
A
B
C
D
E
F
G
H
I
J
K
MGBT-F60W/PN1
mm
2000
900
1880
350
1420
225
1500
506
530
930
450
inch
78.74
35.4
74
13.78
55.91
8.86
59.06
19.92
20.87
36.61
17.72

MCAC-ATSM-2014-09 R410A tropical air-cooled scroll chiller unit 60Hz
17
No.
Name
1
Top cover
2
Air outlet
3
Air inlet
4
Water outlet
5
Compressor
6
Electric control box
7
Water inlet

R410A tropical air-cooled scroll chiller unit 60Hz MCAC-ATSM-2014-09
18
120kW module
Front view Side view
Top view Anchor hole
Model
Unit
A
B
C
D
E
F
G
H
MGBT-F120W/PN1
mm
2000
1685
2080
355
1420
506
1550
1586
inch
78.74
66.34
81.89
13.98
55.91
19.92
61.02
62.44

MCAC-ATSM-2014-09 R410A tropical air-cooled scroll chiller unit 60Hz
19
No.
Name
1
Top cover
2
Condenser
3
Compressor
4
Evaporator
5
Electric control box air inlet
6
Water outlet
7
Water inlet
8
Compressor

R410A tropical air-cooled scroll chiller unit 60Hz MCAC-ATSM-2014-09
20
180kW module
Model
unit
A
B
C
D
E
F
G
H
MGBT-F180W/PN1
mm
2850
2000
2110
3470
2156
506
1888
2388
inch
112.2
78.74
83.07
136.61
84.88
19.92
74.33
94.02

MCAC-ATSM-2014-09 R410A tropical air-cooled scroll chiller unit 60Hz
21
No.
Name
1
Top cover
2
Compressor
3
Evaporator
4
Water outlet
5
Electric control box
6
Water inlet
7
Condenser
