C20-HR20W01
Induction Cooker
Thank you for purchasing this Midea induction cooker. Please thoroughly
read through this instruction manual before use and store it carefully for
future use.
The pictures are only for reference, please keep the real product as a
standard.
User s Manual
,
Model:

CONTENTS
SAFETY INSTRUCTIONS 1-6
OPERATION INSTRUCTIONS 10-11
PRODUCT INTRODUCTION 7-8
COMPATIBLE COOKWARE 12
CLEANING AND MAINTENANCE 12-13
TROUBLESHOOTING 13
WARRANTY 14
SPECIAL DECLARATION 14

ENVIRONMENTAL NOTE
12 19

1
I.SAFETY INSTRUCTIONS
For safety reasons and to avoid damage to the appliance or
injuries to people, please abide by all the safety instructions
below.
Ignoring safety warnings may result in injuries.
This appliance does not take into consideration the following
situations:
--- use by children or disabled people without supervision;
— children treating it as a toy.
Symbols: AttentionWarningMandatoryForbidden
Do not directly rinse this
induction cooker under water.
Do not spill water or soup
into the internal parts of the
induction cooker.
Never heat foods in sealed
containers, such as
compressed products, cans,
orcoffee pots, to avoid
explosion caused by heat
expansion.
To avoid affecting product
performance and to prevent
injury, do not heat empty
pots. When in use, do not
leave the appliance without
supervision for a long time.
When leaving the appliance
without supervision, make
sure there is enough water in
the pot.
To avoid accidents, do not
place the induction cooker,
when in use, on a gas
stove(the magnetic lines can
heat the metal parts of the
gas stove).

2
Safety instructions
I.SAFETY INSTRUCTIONS
Do not heat iron items on the
induction cooker heating
plate to avoid danger caused
by high temperatures.
The utensils provided for the
induction cooker can only be
used for cooking with it.
These cooking utensils
cannot be used on both
induction cooker and gas
stove.
To avoid injuries such as
scalding, do not let children
operate the appliance alone.
Unplug the power cord from
the outlet after use to avoid
fire and/or damaging the
electronic components,
caused by prolonged
electrical connection.
To avoid danger, do not
insert any foreign object,
such as iron wire, nor block
the air ventilation opening or
air entry port.
People with heart
pacemakers should consult a
doctor. Only use the
appliance after confirming
that it does not affect the
pacemaker.

3
I.SAFETY INSTRUCTIONS
>10cm >10cm
≥10.
A
To avoid damage, avoid
causing impacts on the
heating plate. WARNING:
If the surfaceis cracked,
switch off the appliance to
avoid the possibility of
electric shock.
Toavoiddanger,donotplace
paper,aluminiumfoil,clothor
otherunsuitablearticlesonto
theinductioncookerheating
plateforindirect heating.
When using the induction
cooker, place it horizontally
and allow at least 10cm of
free space between the sides
and back of the induction
cooker and the wall.Do not
use the induction cooker in
narrow spaces.To avoid
hindering release of heat,do
not cover the ventilation
opening.
When using the induction
cooker, do not put it on any
metal platform (such as
iron, stainless steel,
aluminium), or place a
non-metal pad less than
10cm thick on the heating
plate.
Please use a dedicated and
high quality power outlet,
with high power rating, equal
to or above 10A. Do not use
poor quality outlets. Do not
share the power outlet with
electrical appliances with
high power ratings, such as
air conditioners,electrical
stoves etc to avoid fires
caused by overburdening the
outlet.
If the supply cord is
damaged, it must be
replaced by the
manufacturer, its service
agentor similarly qualified
persons in order to avoid a
hazard.

4
I.SAFETY INSTRUCTIONS
Do not touch the cooker plate
with sharp tools to avoid
cracking or damaging the
plate. If cracking is found on
the cooker plate, turn off the
appliance to avoid any
electrical shock that might
occur.
When using the induction
cooker or after use, please
keep it clean. Protect the
induction cooker from bugs,
dust and humidity. Avoid
letting cockroaches etc fall
into the internal parts of
induction cooker and causing
a short circuit of the electrical
board. When not in use for a
long period, please clean it
and put it into a plastic bag to
store it.
The cooker cannot be
overloaded.
Overloading the plate may
damage the plastic cover and
cooker plate.
Do not use the induction
cooker near a gas stove,
kerosene stove, gas cooker
or in any space with an open
fire or an environment with
high temperature.
Do not use the induction
cooker by putting it onto a
carpet, tablecloth or thin
paper to avoid blocking the
air inlet opening or air outlet
opening, which results in
influencing heat emission.
Metallic objects such as
knives, forks, spoons and
lids should not be placed
on the hotplate since they
can get hot.

5
I.SAFETY INSTRUCTIONS
Danger of
scalding
Danger of
scalding
Mandatory
Mandatory
Warning
Always clean the induction
cooker to prevent mess from
getting into the fan, which
could influence the normal
operation of the appliance.
When operating the appliance
or after moving the pot, the
cooking area will remain hot
for a period of time. Do not
touch it, be careful of scalding
caused by the high
temperature.
This appliance is intended to
be used in household and
similar applications such as:-
staff kitchen areas in
shops,offices and other
working environments; -farm
houses;-by clients in hotels,
motels and other residential
type environments ; -bed and
breakfast type
environments.Indoor use
only.
We suggest that you should
periodically check that there
are no object (glass, paper,
etc) that could obstruct the
inlet under your induction
cooker.
Never have the induction
cooker to work without food
inside, otherwise its
operational performance may
be affected and danger may
happen.
Warning
Children should be
supervised to ensure that
they do not play with the
appliance.
Mandatory
This appliance can be used
by children aged from 8
years and above and
persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved. Children shall not
play with the appliance.
Cleaning and user
maintenance shall not be
made by children without
supervision.

6
I.SAFETY INSTRUCTIONS
Warning
The instructions shall state
that appliances are not
intended to be operated by
means of an external timer or
separate remote-control
system.
Warning
Mandatory
Keep electrical appliance
out of reach from children
or inform person. Do not
let them use the
appliances without
supervision.
This appliance is not intended for use by persons (including
children) with reduced physical,sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their
safety.

Symbol Value Unit
Model С20-HR20W01
Type of hob Freestanding
Number of cooking zones and/or
areas 1
Heating technology (induction
cooking zones and cooking areas,
radiant cooking zones, solid plates)
Induction
cooking zone
For circular cooking zones or area:
diameter of useful surface area
per electric heated cooking zone,
rounded to the nearest 5 mm
Ø 19.0 cm
Energy consumption per cooking
zone or area calculated per kg
EC electric
cooking 199.5 Wh/kg
Energy consumption for the hob
calculated per kg
EC electric
hob 199.5 Wh/kg
It is recommended to select power setting level 2 to achieve maximum energy
efficiency. The energy consumption of a domestic electric hob (EC electric hob)
is measured in Wh per kg of water heated in a normalised measurement (Wh/kg)
considering all cookware pieces under standardised test conditions and rounded
to the first decimal place. Standard EN 60350-2:2013 was used as reference for
II.PRODUCT INTRODUCTION
Model
C20-HR20W01
Applied
voltage/frequency
Rated
power
Dimension
(mm)
Weight
(kg)
220-240V~ 50/60Hz 2000W
Performance Parameters
The induction cooker is able to meet various kinds of cooking
demands by electromagnetic heating,high thermal efficiency, is
safe and reliable, easy to clean.
341x295x75 2.8
Product fiche
the measurement and calculation.
7

8
II.PRODUCT INTRODUCTION
Product Sketch Map
Control Panel
2. Power regulating controls
4. Lock control
3. Function select control
Ceramic plate
Air vent
Power cord
Air entry
Cooking zone
Control panel
Control knob
3
21
4
5
1. ON/STANDBY control
5. Timer control

9
Put the pot on the ceramic plate
Plug in
Before using New Induction cooker
Using the Touch Controls
II.PRODUCT INTRODUCTION
III. OPERATION INSTRUCTIONS
Read this guide, taking special note of the “Safety
Warnings” section.
Remove any protective film that may still be on your
ceramic plate.
The controls respond to touch, so you don't need to apply
any pressure.
Use the ball of your finger, not its tip.
You will hear a beep each time a touch is registered.
Make sure the controls are always clean, dry, and that
there is no object (e.g. a utensil or a cloth) covering them.
Even a thin film of water may make the controls difficult to
operate.
Make sure the air vents are not blocked and keep utensils
away from the immediate surrounds of the ceramic plate.
Make sure the cookware which has food or liquid is
placed in the center of ceramic plate.
After the power supply is connected, the buzzer sounds.
The display shows “L”, indicating that the induction
cooker is in standby mode.

10
III. OPERATION INSTRUCTIONS
Function
Turn on
After pressing the “ON/STANDBY” button, the induction
cooker is ready for heating. Press the function button to
start heating.
After pressing the “ON/STANDBY” button, if no function
button is pressed for 10 seconds, the induction cooker will
switch off automatically.
Under the working mode, if there is no proper pot on the
ceramic plate, the induction cooker will not heat up and the
alarm will sound to indicate that a pot is required. One
minute later, it will switch off automatically.
Function cooking mode instructions
Note: Power in each cooking mode is restricted complying with the
coking requirement and you can use manual mode if higher wattage is
required.
After switching on the induction cooker, press the
corresponding function button to enter the desired
cooking mode.
You can adjust the power level by pressing “knob” button.
Heating mode
Press the “Function ” button, choose “heating”mode, the
buzzer sounds, the “heating” indicator lamp lights up,
the induction cooker entering the heating state.
Temperature mode
Press the “Function” button, choose “Temperature”mode,
the buzzer sounds, the “Temperature” indicator lamp
lights up, the induction cooker entering the Temperature
state.

11
III. OPERATION INSTRUCTIONS
Timer
Press the“Timer”button to enter the timer mode. When
the timer indicator lights up and the numbers blink on the
display, press the “knob” button to adjust the time duration.
When the adjustment is finished, the number on the
display will be shown after blinking for several seconds.
The induction cooker starts counting down.
When the counting down is over, the induction cooker
automatically stops heating and switches off.
The induction cooker will shut down when the default
timer is reached unless the user sets the timer himself.
How To Lock
Press the “Lock” button to start lock function. The “Lock” indicator
lights up. Now only the “ON/STANDBY” button can be used to
switch off the appliance, all the other operations are forbidden.
Press the “Lock” button for several seconds to quit the lock
function.The “lock” indicator turns off.
Switch Off
When the operating time is over, the induction cooker
switches off automatically.
Press the “ ” button to turn off the appliance .
ON/STANDBY

12
IV. COMPATIBLE COOKWARE
Iron oil frying
pan
Stainless steel por Iron pan Iron kettle
Enamel stainless
steel kettle
Enamel cooking
utensil
Iron plate
Requirement for por materials:containingmagneticinducting
materials.
Shape requirement: plat bottom, with the diameter more than
15 cm and less than 20 cm.
After the first use, some white spots would appear at the bottom
of the pot. This is normal.
Please pour some vinegar into the pot, heat it at about 60-80℃
then wipe the spots away with brush.
Incompatible pots material: glass, ceramic, aluminium,copper
and other non magnetic material.
If the pot removed, the induction cooker will stop heating
immediately. After the buzzer sounds for 10 seconds, it
will go into standby mode automatically.
V. CLEANING AND MAINTENANCE
Before cleaning, please switch off the appliance first and then
disconnect the power plug from the power outlet.
Wait till the cooker plate of the induction cooker is not hot and
start cleaning.
After using the induction cooker for a long time, the opening of
air inlet/air outlet will pile up with dust or other
dirt, please wipe it with a soft dry cloth. Dust in the air inlet and
outlet can be cleaned by using a soft brush or a mini vacuum
cleaner.
Note: Please do not rinse it with water.

13
V. CLEANING AND MAINTENANCE
For oil spots on the cooker plate, wipe the cooker plate by using a
soft moist cloth with a little tooth paste or mild
detergent. And then use a soft moist cloth to wipe it until no stain
remains.
When not using it for a long time, please disconnect the power plug
from the power outlet and protect the induction cooker from any
dust or bugs.
VI. TROUBLESHOOTING
Abnormalities Key checking points and trouble shooting
After plugging in the power cord and
pressing the “ON/STANDBY” key, the
indicator and display do not light up.
The “ON/STANDBY” indicator lights
up and the display works normally,
but heating does not start.
Heating suddenly stops during the
process.
Is the power plug properly connected?
Is the switch, power outlet, fuse or power cord
damaged?
Is the pot material proper?
Is the appliance in a “Preset” working status?
For other causes, please take the appliance to a
repairing and maintenance site to be fixed.
Is the temperature of the oil too high when frying
dishes?
Is the temperature of the surroundings very high?
Is the air inlet or air outlet of the induction cooker
blocked?
Is the default heating time of the induction cooker
over?
The self-safety protection of the induction cooker
starts, wait for several minutes and connect power
to use it.
Code of failure
E3 E6
Wait a moment and press the “ON/STANDBY” button
when the temperature of the hotplate becomes normal,
the induction hotplate will operate as usual.
E7 E8 Turn off the hotplate, when the voltage becomes
normal, and then turn on the hotplate, it will operate as
usual.
E1 E2 E4 E5
Eb Please contact the special maintenance department.
Emergency
During using, if there are some abnormal cases, please unplug
immediately and disconnect power.
For any failure of the product, please contact the special
maintenance department or the customer service center.

14
VII.WARRANTY
warranty
If problems occur with the product, please contact our specific repair
and maintenance site or service center.
One year warranty for the induction cooker.
The starting warranty date refers to the invoice opening date of the product.
Any problem caused by the following items is not included in the warranty:
1. Damage caused by incorrect use, storing or maintenance by the customer.
2. Disassembling or repairing the appliance by a repair agent that is not
appointed by our company, resulting in damage to the appliance.
3. The model number on the invoice is different from the one of the product to
be repaired, or the model number on the invoice is modified.
4. No valid invoice.
5. Damage due to force majeure.
6. Putting the induction cooker to commercial use.
7. We are not responsible for accidents arising due to the use of our
accessories not designed for utlilisation with this product.
8. Using the product in a non-household environment is not covered by the
warranty scope.
9. Man-made issue or problems caused by incorrect use are not covered by
the warranty scope.
For those products beyond the warranty, the customer service center of
the company will still serve you warmly.
If there is technical amendment for the product, it will be edited into the
updated version of the instruction manual. Please be aware that we will not
inform customers of this separately. If the appearance or color of the product
is modified, please refer to the real appliance as a standard..
Guangdong Midea Consumer Electric Manufacturing Co.,Ltd
Address: NO.19 San Le Road, Beijiao, Shunde, Foshan, Guangdong, China
Web: www.midea.com.cn
VIII.SPECIAL DECLARATION
