Midea MDG09EH80 User manual

Read all instructions and explanations for
the installation before use. Follow the
instructions carefully. Keep the operation
instructions handy for later use. If the
appliance is sold or passed on, ensure
that the new owner always receives this operation instructions.
delete installation before use. Follow the
instructions carefully. Keep the operation
instructions handy for later use. If the
product is sold or passed on then ensure
that the new owner always receives this
manual.
EN
TUMBLE DRYER
Dryer
MODEL:
MDG09EH80

CONTENTS
SAFETY INSTRUCTIONS
Safety Instructions ..................................................
INSTALLATION
Product Description ................................................
Installation ...........................................................
OPERATION
Quick Start .............................................................
Before each Drying ..................................................
Control Panel .........................................................
Option....................................................................
Drying Programmes Table ........................................
MAINTENANCE
Cleaning and Care .................................................
Trouble Shooting ....................................................
Technical Specifications .........................................
Product Fiches.........................................................
2
9
9
12
13
15
16
19
21
24
26
27
1

SAFETY INSTRUCTIONS
Safety Instructions
2
Warning!
！
To prevent any damages to your and others' life or
property, you have to follow the safety notes.
This heat pump dryer is intended for drying typical
amounts of household laundry, which have been washed
with water. It has been designed solely for private use
and is not suitable for commercial or shared use (i.e. by
several families in an apartment building).
• Use this appliance only as described in this user manual.
• This appliance is for indoor use only.
• Any other use is deemed improper and may result in
damage to property or even personal injury.
• The manufacturer accepts no liability for damage caused
by improper use.
•
Safety Instructions
•
only be connected to a plug with a protective conductor
that has been installed properly. When connecting the
appliance to the mains, make sure that the mains voltage
is correct. You can find more information about this on
the rating plate.
The appliance corresponds to protection class I and may
Intended use
CAUTION: RISK OF FIRE !

SAFETY INSTRUCTIONS
3
• The electrical safety of this tumble dryer can only be
guaranteed when correctly earthed. It is essential that
this standard safety requirement is met. If in any doubt,
please have the household wiring system tested by a
qualified electrician. The manufacturer cannot be held
liable for the consequences of an inadequate earthing
system (e.g. electric shock).
Warning!
！
Electric shock hazard
•
connection parameter on the rating plate (fuse rating,
voltage and frequency) match the mains electricity supply.
If in any doubt, consult a qualified electrician.
• The electrical safety of this tumble dryer can only be
guaranteed when correctly earthed. It is essential that
this standard safety requirement is met. If in any doubt,
please have the household wiring system tested by a
qualified electrician. The manufacturer cannot be held
liable for the consequences of an inadequate earthing
system (e.g. electric shock).
• Do not pull the power cord forcefully. Please grasp the
mains plug instead
• Do not plug/draw the mains plug with wet hands.
• Do not bend, clamp or damage the power cord and the
power plug.
• If the power cable is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Before connecting the tumble dryer, ensure that the

SAFETY INSTRUCTIONS
4
•
external switching device, such as a timer, or connected
to a circuit that is regularly switched on and off by a utility.
• Do not connect the appliance to the mains electricity
supply by an extension lead, multi-socket adapter or similar.
• The accessibility of the plug must always be ensured, in
order to disconnect the tumble dryer from the mains.
• If the appliance appear high temperature abnormally,
please draw the mail plug immediately.
Warning: The appliance must not be supplied through an
Injury danger
•
a sliding door or a door with a hinge on the opposite side
to that of the tumble dryer, in such a way that a full
opening of the tumble dryer door is restricted.
• Do not disassemble or install the dryer without any
instruction or supervision.
• Do not stack this dryer on washing machine without
stacking kits. (If you want to stack this dryer on a washing
machine, please purchase the independent parts.
Installation shall be done by the manufacturer, its service
agent or similarly qualified persons to avoid any hazards.)
• Do not lean on the opened door of the dryer.
• Condensed water is not drinking water. It can cause
health problems in both people and animals if consumed.
The appliance must not be installed behind a lockable door,
Damage danger
•
See the related chapter in the user manual.
Do not put more load than rated in this user manual.

SAFETY INSTRUCTIONS
5
CAUTION: RISK OF FIRE !
Explosion & Fire danger
•
substances such as kerosene or alcohol. Otherwise, there
may be explosion.
• The appliance contains an environmentally friendly but
flammable R290 refrigerant. Keep away from open flame
and other sources of ignition.
• The tumble dryer is not to be used if industrial chemicals
have been used for cleaning.
• Do not dry unwashed items in the tumble dryer.
• Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent
before being dried in the tumble dryer.
Please do not dry the clothes with any flammable
• Do not operate the dryer without the door filter.
• Do not dry the clothes before being spun.
• Do not expose the dryer directly under the sun.
• Do not install the dryer in humid and drenching environment.
• While cleaning and maintenance, please do remember to
pull out the power plug and do not directly spray the dryer
with water.
• The appliance should not be overturned during normal use
or maintenance.

SAFETY INSTRUCTIONS
6
• Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows fitted with foam rubber pads should not be dried in
the tumble dryer.
• Fabric softeners, or similar products, should be used as
specified by the fabric softener instructions.
• Oil-affected items can ignite spontaneously, especially
when exposed to heat sources such as in a tumble dryer.
The items become warm, causing an oxidation reaction in
the oil. Oxidation creates heat. If the heat cannot escape,
the items can become hot enough to catch fire. Piling,
stacking or storing oil-affected items can prevent heat
from escaping and so create a fire hazard.
• Remove all objects from pockets such as lighters and
matches.
• If it is unavoidable that fabrics that contain vegetable or
cooking oil or have been contaminated by hair care
products be placed in a tumble dryer they should first be
washed in hot water with extra detergent. This will reduce,
but not eliminate, the hazard.
• WARNING: Never stop a tumble dryer before the end of the
drying cycle unless all items are quickly removed and
spread out so that the heat is dissipated.
• Openings must not be obstructed.
• The lint trap has to be cleaned frequently.
• Lint must not to be allowed to accumulate around the
tumble dryer.

Safety with children
SAFETY INSTRUCTIONS
7
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be done by
children without supervision.
• Children should be supervised to ensure that they do not
play with the appliance.
• Children of less than 3 years should be kept away unless
continuously supervised.
• Always close the door after use. In this way you will avoid
the danger of:
1. Children climbing onto or into the dryer or hiding things
in it.
2. Pets or other small animals climbing into it.

SAFETY INSTRUCTIONS
8
Model Rated capacity
MDG09EH80 8.0kg
The packaging is designed to protect the appliance from
damage during transportation. The packaging materials
are environmentally friendly and should be recycled.
Recycling the packaging can reduce the use of raw
materials in the manufacturing process and the amount
of waste in landfill sites.
•
Disposal of packaging material
Correct Disposal of this product:
This marking indicates that this product should not
be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment
or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable
reuse of material resources. To return your used
device, please use the return and collection systems
or contact the retailer where the product was
purchased. They can take this product for
environmental safe recycling.

INSTALLATION
9
Product Description
Installation
Pull up the upper drain hose Connect the external
drain hose to the water
pump
Put the external drain hose into the floor drain
(be careful not to bend the external drain hose)
Accessories
The following parts are optional for specific models.
If your dryer has following parts, please wear gloves to them
as per the instruction below .
install
Power cord
Door filter
Water container
Door
Control panel
Air inlet
Maintenance cover
Drum
Top board
Note: The actual model you purchased might differ. Please see the product you purchased in kind prevail.
Connector
