Midea AM823A2AM User manual

SAVE THESE INSTRUCTIONS CAREFULLY
Read these instructions carefully before using your
microwave oven, and keep it carefully.
If you follow the instructions, your oven will provide you with
many years of good service.
INSTRUCTION MANUAL
Microwave Oven
Guangdong Midea Kitchen Appliances Manufacturing Co., Ltd.
No.6, Yong An Road, Beijiao, Shunde, 528311 Foshan,
Guangdong, People's Republic of China
www.midea.com
MODEL:AM823A2AM

(a) Do not attempt to operate this oven with the door
open since this can result in harmful exposure to
microwave energy. It is important not to break or tamper
with the safety interlocks.
(b) Do not place any object between the oven front face
and the door or allow soil or cleaner residue to accumulate
on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the
oven must not be operated until it has been repaired by
a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of
cleanliness, its surface could be degraded and affect the
lifespan of the apparatus and lead to a dangerous situation.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
Specifications
Model:
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
240V~50Hz230V~50Hz
1270W
800W
2
AM823A2AM-P00F AM823A2AM-P00E

To reduce the risk of fire, electric shock, injury to
persons or exposure to excessive microwave oven
energy when using your appliance, follow basic
precautions, including the following:
IMPORTANT SAFETY INSTRUCTIONS
WARNING
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.( For appliance with
type Y attachment)
AVOIDPOSSIBLE EXPOSURETO EXCESSIVE
MICROWAVE ENERGY".
4. If the supply cord is damaged, it must be replaced by
before replacing the lamp to avoid the possibility of
electric shock.
5. WARNING: Ensure that the appliance is switched off
1. Read and follow the specific:"PRECAUTIONS TO
3. Keep the appliance and its cord out of reach of children
less than 8 years.
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children unless they are older than 8
2. This appliance can be used by children aged from 8
and supervised. Children less than 8 years of age shall be
kept away unless continuously supervised.
3

.ovens
and keep the door closed in order to stifle any flames.
delayed eruptive boiling, therefore care must be taken
when handling the container.
shall be stirred or shaken and the temperature checked
before consumption, in order to avoid burns.
12.The contents of feeding bottles and baby food jars
13. Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
deposits removed.
14. The oven should be cleaned regularly and any food
11. Microwave heating of beverages can result in
keep an eye on the oven due tothe possibility of ignition.
in sealed containers since they are liable to explode.
could lead to deterioration of the surface that could
15. Failure to maintain the oven in a clean condition
7. WARNING: Liquids and other foodsmust not be heated
10. If smoke is emitted, switch off or unplug the appliance
competent person to carry out any service or repair
operation that involves the removal of a cover which
gives protection against exposure to microwave energy.
6. WARNING: It is hazardous for anyone other than a
adversely affect the life of the appliance and possibly
result in a hazardous situation.
8. When heating food in plastic or paper containers,
9. Only use utensils that are suitable for use in microwave
4

-by clients in hotels, motels and other residential type
environments;
-farm houses;
-bed and breakfast type environments.
beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
21.The microwave oven is intended for heating food and
and similar applications such as:
-staff kitchen areas in shops, offices and other working
environments;
decorative door open. (for ovens with a decorative door.)
18.The microwave oven shall not be placed in a cabinet
unless it has been tested in a cabinet.
this oven.(for ovens provided with a facility to use a
17.Only use the temperature probe recommended for
temperature-sensing probe.)
allowed during microwave cooking.
cleaner.
19.The microwave oven must be operated with the
22. Metallic containers for food and beverages are not
23. The appliance shall not be cleaned with a steam
16. The appliance must not be installed behind a
applicable for appliances with decorative door.)
decorative door in order to avoid overheating. (This is not
24.The appliance is intended to be used freestanding.
20.This appliance is intended to be used in household
a wall.
25.The rear surface of appliances shall be placed against
5

READ CAREFULLY AND KEEPFORFUTURE
REFERENCE
be taken to avoid touching heating elements inside the
oven.
30. During use the appliance becomes hot. Care should
26. Steam cleaner is not to be used.
27. Surface ofa storage drawer can gethot.
use. Young children should be kept away.
become hot during use. Care should be taken to avoid
touching heating elements. Children less than 8 years
of age shall be kept away unless continuously supervised.
29. WARNING: The appliance and its accessible parts
adult supervision due to the temperatures generated.
combination mode, children should only use the oven under
32. WARNING: When the appliance is operated in the
to clean the oven door glass since they can scratch
which may result in shattering of the glass.
scrapers
the surface,
28. Do not use harsh abrasive cleaners or sharp metal
31. WARNING: Accessible parts may become hot during
6
33. Appliances are not intended to be operated by means of an
external timer or separate remote-control system.

To Reduce the Risk of Injury to Persons
Grounding Installation
DANGER
Electric Shock Hazard
Touching some of the
internal components can
cause serious personal
injury or death. Do not
disassemble this
appliance.
WARNING
ElectricShock Hazard
Improper
use of the grounding
can
result in electric shock.
Do not plug into an outlet
until appliance is properly
installed and grounded.
This appliance must be
grounded. In the event of
an electrical short circuit,
grounding reduces the
risk of electric shock by
providing an escape wire
for the electric current.
This appliance is equipped
with a cord having a
grounding wire with
a grounding plug. The
plug must be plugged into
an outlet that is properly
installed and grounded.
Consult a qualified
electrician or serviceman
if the grounding instructions
are not completely
understood or if doubt exists
as to whether the appliance
is properly grounded.
If it is necessary to use an
extension cord, use only
a 3-wire
1. A short power-supply cord
is provided to reduce the risks
resulting from becoming
entangled in or tripping over a
longer cord.
2. If a longcord set or extension
cord is used:
1)The marked electrical rating
of the cord set or extensioncord
should be at least as great as
the electrical rating of the
appliance.
2)The extensioncord must be
a grounding-type 3-wire cord.
3)The longcord should be
arranged so that it will not drape
over the counter top or tabletop
where it can be pulled on
by children or tripped over
unintentionally.
extension cord.
7

CLEANING
Be sure to unplug the appliance from the power supply.
1. Clean the cavity of the oven after using with a slightly damp
cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be
cleaned carefully with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the oven door glass since they can scratch the surface,
which may result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the
food cooked can touch: Place half a lemon in a bowl, add 300ml
(1/2 pint) water and heat on 100% microwave power for 10
minutes. Wipe the oven clean using a soft, dry cloth.
UTENSILS
CAUTION
Personal Injury Hazard
It is hazardous for
anyone other than a
competent person to
carry out any service
or repair operation that
involves the removal of
a cover which gives
protection against
exposure to microwave
energy.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is
warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave oven."
There may be certain non-metallic utensils that are not
safe to use for microwaving. If in doubt, you can test the
utensil in question following the procedure below.
8

Materials you can use in microwave oven
Utensils Remarks
Follow manufacturer’s instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
ThermometersMicrowave-safe only (meat and candy thermometers).
Wax paperUse as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
9

10
A) Control panel
A
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
B
C
D
E
F
B) Turntable ring assembly
C) Glass tray
D) Observation window
E) Door assembly
F) Safety interlock system
Turntable Installation
Hub (underside)
Glass tray
Turntable ring assembly
Turntable shaft

Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Countertop Installation
Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
Installation
1.Select a level surface that
provide enough open space
for the intake and/or outlet
vents.
(1) The minimum installation
height is 85cm.
(2) The rear surface of
appliance shall be placed
against a wall.
Leave a minimum clearance
of 30cm above the oven, a
minimum clearance of 20cm
is required between the oven
and any adjacent walls.
(3) Do not remove the legs
from the bottom of the oven.
(4) Blocking the intake and/
or outlet openings can
damage the oven.
(5) Place the oven as far
away from radios and TV
as possible. Operation of
microwave oven may
cause interference to your
radio or TV reception.
2. Plug your oven into a
standard household outlet.
Be sure the voltage and
the frequency is the same
as the voltage and the
frequency on the rating
label.
WARNING: Do not install
oven over a range cooktop
or other heat-producing
appliance. If installed near
or over a heat source, the
oven could be damaged
and the warranty would be
void.
20cm
30cm
20cm
min85cm
0cm
The accessible
surface may be
hot during operation.
11

This microwave oven uses modern electronic control to adjust cooking parameters
to meet your needs better for cooking.
OPERATION INSTRUCTION
.
", the minute figures will flash.
1) "
.
1.Clock Setting
" to finish clock setting.
When the microwave oven is electrified, the screen will display " ", buzzer will ring once.
e input time should be within 0--23. Th
e input time should be withinTh 0--59.
Note: 1)
2) After step 5, if you do not press "
"within 1 minute,
the oven back to the previous status automatically.
The clock will not work if it is not set when powered.
will go
In waiting state, press "
2. Kitchen Timer
" to confirm setting.
set the kitchen timer. (The maximum cooking time is 95 minutes .)
1) "
In waiting state, press " " once ,the screen displays ".
will flash.
" " to adjust the minute figures
12
" once ,the screen displays
2) Turn " " to adjust the hour figures
3) Press "
4) Turn
5) Press "
2) Turn ""to
3) Press "
Kitchen Timer
Clock
Clock
Clock
Clock
Start/+30Sec./Confirm
"
0:00
0:00 hour figure
and the
Notes: 1)Any other programs cannot be set during the kitchen timer.
2)Opening or close the oven door cannot interrupt the kitchen timer.

Press the " key to start cooking.
Microwave
"
3.
"to confirm the power.
Level
Power
1) " " will flash on the screen .P100
High M.High Med M.Low Low
P100 P80 P50 P30 P10
Press " " once,
" repeatedly or turn " " to select microwave power
from P100 to P10.
Cooking
adjust the cooking time. ( The range of the time is 0:05~95:00 ）
NOTE: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
Microwave Power Chart
13
Microwave
Microwave
2) Press "
3) Press the "
4) Turn " " to
5)
Start/+30Sec./Confirm
Start/+30Sec./Confirm
" key to start defrosting.
The weight should be 100g-2000g.
1)
2) Turn " " to select the weight of food.
3) Press "
" key to start defrosting.
) Press "
2) Turn " " to adjust cooking time.
3
In waiting state, press " " , the screen displays "dEF1".
1) In waiting state, press " " , the screen displays "dEF2".
Weight Defrost
Start/+30Sec./Confirm
Start/+30Sec./Confirm
4. Defrost by W.T.
5. Defrost by Time
Time Defrost

Two stages can be maximumly set. If one stages is defrosting, it should be put in the first
stage automatically. The buzzer will ring once after each stage and the next stage will begin.
Note: Auto menu cannot be set as one of the multi stage.
Example: if you want to defrost the food for 5 minutes, then to cook with 80%
microwave power for 7 minutes. The steps are as following:
1) Press "
2) Turn " " to adjust the defrost time of 5 minutes;
" to confirm;
" to start cooking.
" " will flash on the screen;P100Press " " once,3)
14
Microwave
"once, the screen will display "dEF2";
Start/+30Sec./Confirm
Start/+30Sec./Confirm
1) In standby state, press " " to start cooking with 100%
each added press will increase 30 seconds cooking time up
power for
to 95
"
30 seconds, minutes .
" key to cook with 100% microwave power.
2) In standby state, turn " " left to choose cooking time directly then
Lock-out Function for Children
Start/+30Sec./Confirm
Start/+30Sec./Confirm
8.
4) Turn " " to choose 80% microwave power till "P80" display;
5) Press "
6) Turn " " to adjust the cooking time of 7 minutes;
7) Press "
3 seconds. After 3 seconds, the oven will turn
press
6. Multi-Stage Cooking
7. Quick Microwave cooking
Time Defrost
You can use this function to prevent children from accidentally turning the oven on.
To activate the lock:
In waiting state, press and hold “Stop/Clear” for three seconds. A long beep sounds
and the locked icon will display.
To deactivate the lock:
In locked state, press and hold “Stop/Clear” for three seconds. A long beep sounds.

15
10. Specification
(1) Once the cooking time has finished, the buzzer will sound five times.
(2) The buzzer will sound once when you start turning the knob.
(3) If the oven door is opened during cooking, you need to press “Start/+30Sec./Confirm”
to continue cooking.
(4) When you have set the cooking program, please press “Start/+30Sec./Confirm” within 1 minute.
Otherwise, the setting will be canceled.
(5) When you open the oven door, the lamp will light up all the time.
(6)The buzzer will sound once when you press valid keys, the invalid keys are noiseless.
1) In states of microwave cooking, press " "
2) In cooking state, press " to inquire the time and the time will flash 3 seconds."
Clock
Microwave
displayed forthe current power will be
3 seconds. After 3 seconds, the oven will turn back to the former state;
for
9.Inquiring Fuction

" to confirm the menu you need.
" to start cooking.
1) In waiting state, turn " "right to choosethe menu,
2) Press "
3) Turn " " to choose the weight of menu.
4) Press "
Start/+30Sec./Confirm
Start/+30Sec./Confirm
1 . Auto menu
Display
Pizza
Fish
Pasta
Meat
Potato
100g(with water 800g)
200g
400g
250g
350g
450g
250g
350g
450g
50g(with cold water 450g)
200
400
Vegetable
Beverage
200g
00g
300g
4
200g
400g
600g
200
400
600
85g
100g
1cup(about 120ml)
cups( about 0ml)
2cups(about 240ml)
3 36
250
350
450
200
300
400
100
250
350
450
1
2
3
85
100
50g
cold
and "A1" to "A8" will display.
A1
A2
A3
A4
A5
A6
A7
A8
50
50
0
Weight
Popc rn o

PN:P0000002993531
According to Waste of Electrical and Electronic Equipment
(WEEE) directive, WEEE should be separately collected and
treated. If at any time in future you need to dispose of this
product please do NOT dispose of this product with household
waste. Please send this product to WEEE collecting points
where available.
Microwave oven interfering
TV reception
Radio and TV reception may be interfered when
microwave oven operating. It is similar to the
interference of small electrical appliances, like
mixer, vacuum cleaner, and electric fan.
It is normal.
Dim oven light
Oven cannot
be started.
(1) Power cord is not
plugged in tightly.
Unplug. Then plug again after
10 seconds.
Replace fuse or reset circuit
breaker (repaired by
professional personnel of our
company)
Test outlet with other electrical
appliances.
Close door well.
(3) Trouble with outlet.
(4) Door is not closed
well.
(2) Fuse blowing or
circuit breaker
works.
Oven does not heat.
In low power microwave cooking, oven light may
become dim. It is normal.
In cooking, steam may come out of food. Most will
get out from vents. But some may accumulate on
cool place like oven door. It is normal.
Steam accumulating on
door, hot air out of vents
Oven started accidentally
with no food in.
It is forbidden to run the unit without any food inside.
It is very dangerous.
Normal
Trouble Possible Cause Remedy
Trouble shooting
