Midian Electronics VTE-1 User manual

1
VTE-1
Voting Tone Encoder
Manual Revision: 2011-08-26
Covers Loader Firmware Revisions:
1.70 & Higher
Covers Application Firmware Revisions:
1.40 & Higher
Covers PCB Revisions:
F

2
TABLE OF CONTENTS
Specifications 3
General Information 4
Hardware Installation 5
Hardware Alignment 6
Jumper Settings 7
Controls & Indicators 8
Operation 8
Theory of Operation 9
Technical Notes 10
Contact Information 10

3
SPECIFICATIONS
Voltage/Current:
Operating Voltage: 13-18 VDC
Operating Current (standby): 125 mA
LED Current: 4 mA
Fuse Protection Auto Resettable with surge suppression: 300 mA
RX Input from Radio:
Frequency Range: 300-3000 Hz
Notch Filter Depth: 45 db relative to 1 KHz
Dynamic Range 30 dB
COR Input Logic Low
Dedicated Phone Line:
Output Level -20 to +10 dB pot adjustable
Output Impedance 600 Ohm
Fuse Protection Auto Resettable with surge suppression: 300 mA
Mechanical:
Dimensions: 1.45" H x 6” W x 7.6" L
Operating Temp: 0° to +50° C
Default Pilot Tone Frequencies:
1950 Hz (default)
2175 Hz
2700 Hz
1600 Hz
No Tone (for auxiliary receivers)

4
GENERAL INFORMATION
Midian Electronics’ VTE-1, voting tone encoder (also known as a pilot tone generator or status tone generator)
with a 600-ohm line driver, pairs with a radio receiver to create an analog satellite voting receiver or auxiliary
receiver. Satellite voting receivers are spread out over a geographic area to provide greater radio coverage and
are connected via a dedicated line, telemetry link or microwave to a voting comparator. The voting comparator
looks at the signal to noise ratio from multiple voting receivers and passes the best quality signal to the
dispatcher/repeater.
The VTE-1 looks at the COR coming from the receiver. When COR is inactive the VTE-1 generates a voting tone
to the voting comparator. This tone is selectable as 1950 Hz, 2175 Hz, 1600 Hz or 2700 Hz. Custom tones can
also be ordered from Midian. When the receiver’s COR is active the tone is no longer generated and the audio
from the radio is sent to the voting comparator.
Midian’s VTE-1 is compatible with the following types of voting systems:
Motorola Spectra-TAC
JPS Communications (Raytheon) SNV-12
GE Mastr II
RF Technologies Eclipse
Other systems using 1950 Hz, 2175 Hz, 1600 Hz or 2700 Hz as the voting tone.

5
HARDWARE INSTALLATION
Be certain to follow standard anti-static procedures when handling any of Midian’s products.
Getting Started:
The VTE-1 has a number of adjustment potentiometers and configuration jumpers. These have been adjusted
and configured at the factory for a typical installation. However, audio levels should be verified and adjusted (if
necessary) at the time of installation. Also, the configuration jumpers should be inspected prior to installation to
verify that they are in the right configuration. Jumper descriptions appear in the jumper settings section with a
quick reference table.
Line Interface
The line interface connector CON7 is a 10-pin RJ-45 style connector on the left side of the back panel.
2-Wire Operation: For a 2-wire installation, simply connect pins 5 and 6 (red and green) to the dedicated line. A
standard 4 conductor phone cable will function properly in connector CON7. See table 3.1.
Table 3.1
Pin Color 2-Wire
CON7-4 Black Not Used
CON7-5 Red Line 1
CON7-6 Green Line 1
CON7-7 Yellow Not Used
Radio Interface:
CON6 is located in the middle of the back panel and is used to connect the VTE-1 to the satellite or auxiliary
receiver. The following are the connection points:
CON6:
CON6-2 (Orange): COR: Connect this lead to the busy detect of the radio. This input is used to control whether
audio should be passed down the line to the voting comparator or generate the pilot tone.
CON6-6 (Red): Battery (13-18 VDC): Connect this lead to 13-18 VDC from the base station/repeater.
CON6-7 (Black): Ground: Connect this lead to the base station’s or repeater’s ground.
CON6-8 (White): RX Input: Connect to the receive audio in the satellite or auxiliary receiver after the sub-audible
hi-pass filter and at some point that gives flat audio to the VTE-1. Speaker audio is fine if it is single ended, but
make certain the volume control cannot be turned down accidentally.
Diagram 3.1
1

6
HARDWARE ALIGNMENT
The alignments are preset at the factory and should not need to be adjusted during installation. However, if an
adjustment is needed please follow the procedures below.
RX Input Line Level Adjustment:
1. With voice being received from the base station adjust RP3 while monitoring TP1 with an oscilloscope, so that TP1
shows around 700 mV p-p. Also verify that JP22 Pin 2 shows around 180 mV p-p.
RX Output Line Level Adjustment:
1. With voice being received from the base station adjust RP6 while monitoring the line out with a line level meter and
set for approximately -10 dB on average voice or -5 dB on peak voice.
Pilot Tone Level Adjustment:
1. Prior to performing this step, the line level adjustments above must be done. Set RP2 to the desired dB level (-20 to
+10 dB). Setting the COR Input of the VTE-1 to the inactive state (logic high) will cause the unit to generate the
Pilot Tone.
Note: If a line level meter is not available for the level adjustment use an AC voltmeter with a DB scale. A voltmeter
would not be set up for balanced 600 ohm audio, but it will provide a close measurement.

7
JUMPER SETTINGS
The following table shows the default jumper settings and their function:
Jumper
Number Default Position Description
JP21 1-2 In – 2-3 Out De-Emphasis jumper
JP36 1-2 In Termination jumper
JP40 1-2 In Termination jumper
JP41 1-2 Out 2175 Hz Pilot Tone Select
JP42 1-2 In 1950 Hz Pilot Tone Select
JP43 1-2 Out 2700 Hz Pilot Tone Select
JP44 1-2 Out 1600 Hz Pilot Tone Select
JP41-JP44 All Out No Pilot Tone

8
CONTROLS & INDICATORS
Power LED: This red LED indicates that power is applied to the unit through the rear connector.
COR/MON LED: This red LED indicates carrier is detected from the receiver.
Tone LED: This red LED indicates the Pilot Tone is being generated.
OPERATION
Voting Tone Encode: When COR is inactive from the receiver to the VTE-1, the unit will generate the selected
Pilot Tone to the voting comparator.
Receive: When COR is active from the receiver to the VTE-1, the unit will pass the voice from the receiver to the
voting comparator.

9
THEORY OF OPERATION
RX Voice Path:
RX audio from the base station goes through hipass filter C39 and RP3. RP3 also serves as the RX input level
adjustment pot. This audio is then fed into audio amplifier U8:2 which acts as low pass filter for noise above 3
KHz and if jumper JP21 is installed it can provide a 6 dB per octave de-emphasis if desired.
Audio from U8:2 is fed to C56. Voice audio is input into the audio mixer U8:4. The mixer audio is then input into
the line amplifier (U20:3) which drives T1. The line amplifier has an enable transistor that is controlled by the
microprocessor. The micro can respond to the COR carrier input and enable this amplifier. Pilot Tone is injected
into the audio path at C-59 PWM input.
Power Supply:
13-18 VDC is input on the red wire of the Radio Interface connector and then into RF inductor L7 into an auto-
resettable polyswitch. D22 is a polarity protection diode that is designed to pop the resettable fuse if power is
hooked up backwards. C31 and C34 act as RF bypass caps after the RF inductor L7. U6 acts as a 12 VDC
regulator. Its output is fed to all of the analog circuitry and U14:2 acts a pseudo-ground reference at
approximately 6 VDC. The 12 VDC on the analog page schematic is also fed over to U4 which is a 5 VDC
regulator shown on the digital page to run the microprocessor and the optional encoders/decodes and serial
chips. The relays on the digital page receive their 12 VDC from the 12 VDC regulator. They are driven by open-
collector transistors to protect the microprocessor from the 12 VDC.

10
TECHNICAL NOTES
No technical notes are available at this time.
MIDIAN CONTACT INFORMATION
Midian Electronics Inc.
2302 East 22nd Street
Tucson, Arizona 85713 USA
Orders: 1-800-MIDIANS
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
Web: www.midians.com
