Miele KM 6002 User manual

Operating and Installation Instructions
Ceramic cooktops
To avoid the risk of accidents or damage to the appliance it is impera‐
tive that you read these instructions before installing the appliance and
using it for the first time.
en-CA M.-Nr. 10 171 920
KM 6002

Contents
2
Warning and safety instructions........................................................................... 4
Caring for the environment ................................................................................. 12
Overview ............................................................................................................... 13
Cooktop ................................................................................................................. 13
Burner data ............................................................................................................ 14
Using for the first time......................................................................................... 15
Cleaning the cooktop for the first time .................................................................. 15
Turning on the cooktop for the first time................................................................ 15
How the burners work ......................................................................................... 16
Cookware.............................................................................................................. 17
Energy saving tips ............................................................................................... 18
Power setting ranges........................................................................................... 19
Operation .............................................................................................................. 20
Burner control knobs ............................................................................................. 20
Switching on .......................................................................................................... 20
Switching off .......................................................................................................... 20
Residual heat indicator .......................................................................................... 20
Switching on second heating zones ...................................................................... 21
Overheat protection............................................................................................. 22
Cleaning and care ................................................................................................ 23
Problem solving guide ........................................................................................ 25
Optional accessories ........................................................................................... 26
Safety instructions for installation ..................................................................... 27
Safety clearances................................................................................................. 28
Bottom cover panel ............................................................................................. 31
Instructions for installation ................................................................................. 32
Installation dimensions........................................................................................ 33
Installation ............................................................................................................ 34
Connecting the cooktop...................................................................................... 36

Contents
3
Electrical connection........................................................................................... 37
After-sales service, data plate, warranty........................................................... 38

Warning and safety instructions
4
This appliance conforms to current safety requirements. However,
improper use can result in personal injury and damage to proper
ty.
To prevent accidents and damage to the cooktop, please read
these instructions carefully before using the cooktop for the first
time. They contain important notes on installation, safety, use and
maintenance.
Miele cannot be held liable for damage occurring as a result of
non-compliance with these instructions.
Keep these instructions in a safe place and pass them on to any
future owners.

Warning and safety instructions
5
Intended use
ʊThis cooktop is intended for domestic use and use in other similar
environments.
ʊThis cooktop is not intended for outdoor use.
ʊThe cooktop is intended to prepare food and keep it warm in do
mestic use only. Any other use may be hazardous.
ʊPersons who are unable to safely operate the cooktop due to limi
ted physical, sensory or mental abilities or because they lack experi
ence or knowledge may only use the appliance if they are super
vised while doing so. These persons may only use the cooktop with
out supervision if they have been shown how to use it in a safe man
ner, and if they are able to recognize and understand the potential
risks of improper use.

Warning and safety instructions
6
Safety with children
ʊChildren under 8 years of age must be kept away from the cook
top unless they are constantly supervised.
ʊChildren ages 8 and up may only use the cooktop without super
vision if they have been shown how to use it in a safe manner, and if
they are able to recognize and understand the potential risks of im
proper use.
ʊChildren must not be allowed to clean the cooktop without super
vision.
ʊBe sure to supervise any children in the vicinity of the cooktop,
and do not let them play with it.
ʊThe cooktop gets hot when in use and remains hot for some time
after being switched off. Keep children away from the cooktop until
it has cooled down and is no longer a burn hazard.
ʊBurn hazard.
Keep the spaces above and behind the cooktop clear of any items
that could draw the attention of children. Otherwise, they can be
tempted into climbing onto the appliance.
ʊRisk of burning or scalding.
Turn all handles away from the front of the cooktop so that children
cannot pull pots and pans down and burn themselves.
ʊRisk of suffocation. Children may be able to wrap themselves in
packaging material or pull it over their heads with the risk of suffoca
tion. Keep children away from all packaging materials.

Warning and safety instructions
7
Technical safety
ʊInstallation, maintenance and repair work should only be per
formed by a Miele authorized service technician. Installation, mainte
nance and repair work by unqualified persons can cause considera
ble danger to users.
ʊA damaged cooktop can be dangerous. Always check for visible
signs of damage. Never use a damaged appliance.
ʊReliable and safe operation of the cooktop can only be guaran
teed if it is connected to the public power supply.
ʊThe electrical safety of this cooktop can only be guaranteed when
it is properly grounded. Compliance with this essential safety re
quirement is absolutely necessary. If in any doubt, please have the
building's electrical system checked by a qualified electrician.
ʊTo avoid damaging the cooktop, make sure that the connection
data (voltage and frequency) on the data plate correspond to the
building's power supply before connecting the appliance.
When in doubt, consult a qualified electrician.
ʊThe cooktop may only be combined with the ovens specified by
Miele. The manufacturer cannot guarantee trouble-free operation if
the cooktop is used in combination with any other appliances. Doing
so will void the warranty.
ʊFor safety reasons, the cooktop may only be used when it has
been fully installed.
ʊThis cooktop must not be used in non-stationary locations (e.g.
on a ship).
ʊAny contact with live connections or tampering with the electrical
or mechanical components of the cooktop will endanger your safety
and may lead to cooktop malfunctions.
Do not open the casing of the cooktop under any circumstances.

Warning and safety instructions
8
ʊAny repairs not performed by a Miele authorized service techni
cian will void the warranty.
ʊMiele can only guarantee the safety of the appliance if genuine
Miele spare parts are used. Defective components must only be re
placed by genuine Miele spare parts.
ʊThe appliance is not intended for use with an external timer switch
or a remote control system.
ʊThe cooktop must be connected to the oven by a qualified electri
cian (see "Electrical connection").
ʊDuring installation, maintenance, and repair work, the cooktop
must be completely disconnected from the household electricity
supply. It is only completely isolated from the electricity supply
when:
– The main circuit breaker has been tripped, or
– The plug fuses have been fully unscrewed (where applicable).
ʊRisk of electric shock.
If the ceramic surface of the cooktop is defective or chipped,
cracked or broken in any way, immediately turn the cooktop off and
do not continue to use it. Disconnect the cooktop from the power
supply and contact Miele.
ʊIf the cooktop is installed behind a cabinet door, do not close the
door while the cooktop is in operation. Heat and moisture can build
up behind the closed door and cause damage to the cooktop, cab
inetry and flooring. Do not close the door until the cooktop has com
pletely cooled down.

Warning and safety instructions
9
Proper use
ʊThe cooktop gets hot when in use and remains hot for a while af
ter being turned off. A burn hazard is present until the residual heat
indicators go out.
ʊWhen in use, the cooktop emits a significant amount of heat,
which could cause objects in the vicinity to catch fire.
Never use the cooktop to heat the room.
ʊOil and fat can catch fire if overheated. Never leave the cooktop
unattended when cooking with oil and fat. If the oil or fat catches
fire, do not attempt to put the flames out with water.
Turn off the cooktop and smother the flames using a lid or a suitable
fire blanket.
ʊThe flames could set the grease filters of a ventilation hood on
fire. Do not flambé under a hood.
ʊSpray canisters, aerosols and other flammable substances can ig
nite when heated. Therefore, do not store such items or substances
in a drawer under the cooktop. Any cutlery inserts must be heat-re
sistant.
ʊNever heat empty cookware.
ʊDo not heat or can food in closed containers, such as tins or
sealed jars, on the cooktop, as pressure will build up in the container
and cause it to explode.
ʊIf the cooktop is covered, there is a risk that the material of the
cover will ignite, explode or melt if the range is still hot or if it is
turned on inadvertently. Never cover the appliance with a cover,
cloth or protective foil.
ʊIf the cooktop is on or accidentally turned on, or if it is still hot,
metal objects on the cooktop can heat up. Other items may melt or
catch fire. Damp lids can become attached to the cooktop by suc
tion. Do not store items on the cooktop. Always turn the burners off
after use.

Warning and safety instructions
10
ʊYou can burn yourself on a hot cooktop. When cooking on the
cooktop, protect your hands by using heat-resistant pot holders or
oven mitts. Only use dry pot holders and oven mitts. Wet or damp
textiles conduct heat more effectively and produce steam, which
poses a burn hazard.
ʊWhen using an electrical appliance, e.g. a hand mixer, near the
cooktop, make sure that the power cable does not come into con
tact with the hot cooktop. The cable's insulation could become
damaged.
ʊGrains of salt, sugar and sand (e.g. from cleaning vegetables) can
cause scratches if they get onto pan bottoms. Make sure that the
ceramic surface and pan bottom are clean before placing any pans
on the cooktop.
ʊEven light objects (such as a salt shaker) can cause damage to
the ceramic cooktop in certain circumstances. Do not drop anything
on the ceramic surface.
ʊHot objects on the residual heat indicators can cause damage to
the electronics underneath. Do not place hot pans in these areas.
ʊDo not allow solid or liquid sugar, or pieces of plastic or aluminum
foil, to get on the cooktop when it is hot, as they can damage the
ceramic surface when it cools down. If this should occur, turn off the
appliance immediately and scrape off all the sugar, plastic or alumi
num residues while still hot using a scraper blade. Wear oven mitts
when doing so. Allow the burners to cool down and clean them with
a suitable ceramic cleaning agent.
ʊPans that boil dry can damage the ceramic surface. Never leave
the cooktop unattended during use.
ʊPots and pans with rough bottoms can scratch the ceramic sur
face. Only use pots and pans that are smooth on the bottom.
ʊLift pans into position on the cooktop. Sliding them into place can
cause scuff marks and scratches.

Warning and safety instructions
11
ʊCookware made of plastic or aluminum foil will melt high tempera
tures. Do not use any plastic or aluminum foil cookware.
ʊThe cooktop trim or edge (in the case of bevelled cooktops) can
become hot due to the following factors: operating time, high output
settings, large cookware, and number of burners in use.
ʊCookware that is made of aluminum or has an aluminum bottom
can leave behind shiny metallic spots. These spots can be removed
with ceramic and stainless steel cleaner (see "Cleaning and care").
ʊIf spills or splatters are allowed to remain on the cooktop for any
length of time, they can bake onto the cooktop, and it may not be
possible to remove them. Remove spills and splatters immediately.
Also make sure that the bottom of any cookware is clean, dry, and
free of grease before placing it on the cooktop.
Cleaning and care
ʊDo not use a steam cleaner to clean the cooktop.
The steam could reach electrical components and cause a short cir
cuit.

Caring for the environment
12
Disposal of the packaging ma‐
terial
The cardboard box and packaging ma
terials protect the appliance during
shipping. They have been designed to
be biodegradable and recyclable.
Recycling the packaging reduces the
use of raw materials in the manufactur
ing process and also reduces the
amount of waste in landfill sites. You
can return the packaging to your Miele
dealer.
Disposing of your old appli‐
ance
Old electrical and electronic equipment
often still contain valuable materials.
However, they may also include harmful
substances that were essential for
proper functioning and safe use. Im
properly disposing of these items in
your household waste can be harmful
to your health and the environment.
Therefore, please do not dispose of
your old appliance in your regular
household waste.
Instead, use your local community
waste collection and recycling centre
for electric and electronic appliances.
Contact your dealer for more informa
tion.
Ensure that your old appliance does not
pose a danger to children while being
stored for disposal.

Overview
13
Cooktop
&Variable burner
'Standard burner
(Standard burner
)Standard burner
*Display with residual heat indicators

Overview
14
Burner data
Burner ERating in watts
in cm in inch 208/240 V
Ʊ12.0 / 21.0 4³/ " / 8¹/" 750 / 2200
Ư14.5 5¹¹/ 1200
ư18.0 7¹/" 1800
Ʋ14.5 5¹¹/ 1200
Total: 6400

Using for the first time
15
ĺPlease affix the extra appliance data
plate supplied with this documenta
tion in the space provided in the "Af
ter-sales service, data plate, warran
ty" section of this manual.
ĺRemove any protective foil and stick
ers from the cooktop.
Cleaning the cooktop for the
first time
ĺBefore using it for the first time, wipe
down the cooktop with a damp cloth
and then wipe it dry.
Turning on the cooktop for the
first time
The cooktop's metal components are
protected by a conditioning agent.
Smells and vapor may occur when the
appliance is used for the first time.
The smell and any vapors that may oc
cur do not indicate a faulty connection
or defective appliance and are not
harmful to your health.

How the burners work
16
Standard burners have one heating
band, and variable burners and casser
ole areas have two heating bands. De
pending on the model, the heating
bands may be separated by a ring.
Each burner features overheat protec
tion (internal temperature limiter), which
prevents the ceramic surface from over
heating (see "Overheat protection").
When a power level is set, heating is
activated and the heating band is visi
ble through the ceramic surface. The
heat output of the burners depends on
the power level set and is controlled
electronically. This causes the "cycling"
of a burner: the heating is turned on
and off.
Standard burner
&Overheat protection
'Heating band
Variable burner
&Technical requirement, not a defect
'Overheat protection
(Outer heating band
)Insulating ring
*Inner heating band

Cookware
17
The most suitable cookware is metal
pots and pans with thick bottoms that,
when cold, bulge slightly inward. On
warming, the bottom expands and rests
flat on the burner; this conducts the
heat optimally.
Cold Hot
Glass, ceramic or stoneware is less
suitable. These materials do not con
duct the heat well.
Cookware made of plastic or aluminum
is not suitable. These melt at high tem
peratures.
Cookware that is made of aluminum or
has an aluminum bottom can leave be
hind shiny metallic spots. These spots
can be removed with ceramic and
stainless steel cleaner (see "Cleaning
and care").
Pots and pans with rough bottoms can
scratch the ceramic surface. Only use
pots and pans that are smooth on the
bottom.
Lift pans into position on the cooktop.
Sliding them into place can cause scuff
marks and scratches.
The maximum diameter indicated by
manufacturers will often refer to the di
ameter of the top rim of the pot or pan.
The diameter of the base (generally
smaller) is more important.

Energy saving tips
18
– Make sure that the bottoms of pots
or pans either match the size of the
burner or are somewhat larger. This
ensures that heat from the burner is
not wasted.
– Whenever possible, keep pots and
pans covered while cooking. Doing
so will prevent unnecessary heat
loss.
– For small quantities, select a small
pan. A small pan on a small burner
uses less energy than a large, only
partially filled pan on a large burner.
– Cook with as little water as possible.
– Once food has come to the boil or
the pan is hot for frying, reduce the
heat to a lower power setting.
– When cooking for a longer amount of
time, turn the burner off at least 5 to
10 minutes before the end of the
cooking time. This makes use of the
residual heat.
– Use a pressure cooker to reduce the
cooking time.

Power setting ranges
19
Setting range
Melting butter, chocolate, etc.
Dissolving gelatin
Preparing yoghurt
1-2
Thickening sauces containing only egg yolk and butter
Warming small quantities of liquid
Keeping food warm that sticks easily
Cooking rice
1-3
Warming liquid and semi-solid foods
Thickening sauces, e.g. Hollandaise
Making porridge
Preparing omelettes, lightly fried eggs
Steaming fruit
3–5
Thawing frozen foods
Steaming vegetables, fish
Cooking pasta, pulses
Cooking grains
4–6
Boiling and continuing to cook large quantities of food 7
Gently frying fish, cutlets, sausages, fried eggs, etc. (without
overheating the fat)
8–9
Frying pancakes, etc. 9–11
Boiling large quantities of water
Bringing food to a boil
11–12
These settings, which are based on approx. 4 normal-sized servings, should only be taken
as a guide. With deep pans, larger quantities or when cooking without a lid, a higher setting
is required. For smaller quantities, select a lower setting.

Operation
20
ɘFire hazard.
Do not leave the appliance unatten
ded while cooking.
Burner control knobs
The oven is equipped with different
control knobs:
– Knobs with a stop. These must not
be turned past the stop to 0.
– Knobs without a stop. These can be
turned a full 360°.
Switching on
ĺTurn burner knobs with a stop clock
wise to the desired power setting.
ĺTurn burner knobs without a stop
clockwise or counter-clockwise to
the desired power setting.
Switching off
ĺTurn the burner knobs with a stop
counter-clockwise to 0.
ĺTurn the burner knobs without a
stop clockwise or counter-clockwise
to 0.
Residual heat indicator
When a specified temperature is
reached after a burner, for example the
left front, has been turned on, the corre
sponding residual heat indicator lights
up:
When the burner cools down to a
specified temperature after being
switched off, the residual heat indicator
goes out.
If extremely hot cookware remains
on the burner for a longer amount of
time after the burner is switched off,
the burner may still be hot, even
though the residual heat indicator is
no longer on.
ɘBurn hazard. Do not touch the
burners while the residual heat indi
cators are on.
Hot objects on the residual heat indi
cators can damage the electronics
underneath.
NEVER place hot pots or pans in this
area.
